Motion Mirror

I recently built a fun and interactive web app that responds to facial movement using real-time animation. The project uses the Grove Vision AI Module V2 from Seeed Studio, which runs a pre-trained face detection model to track facial positions from a live camera feed. The face data is sent to the browser through the ESP32-S3 using the Serial Web API.

This project was created as part of MakerGram’s MakerChat0x2D – a month-long build series focused on Interactive Digital Signage.

On the frontend, I used Rive to create smooth, expressive animations that react to facial movement. Rive is a powerful tool for designing, rigging, and animating graphics—ideal for real-time, interactive UI elements.

🎥 Demo Video

🛠 Hardware

• Grove Vision AI V2
• XIAO ESP32S3
• USB-C

🧠 Making the Animation Smart

Rive supports something called a State Machine — this is like giving logic to your animation.

In my project, the animation moves based on x and y values. These values represent a person's face position. When the x/y changes, the animation moves to match.

This gave my animation a dynamic and interactive behavior — it feels alive!

📷 Getting Face Data Using Grove Vision AI Module

To detect the position of a person's face, I used a Grove Vision AI Camera v2.

Where i run a pretrained face detection model to track facial positions from a live camera feed

The camera can detect faces and give a bounding box — from that, we can get the x and y coordinates of the face.

Now I had real-time data of where the person's face was!

🔁 Sending Data with ESP32-S3

I needed to send this face position data (x and y) to my web app. So I connected the Grove camera to an ESP32-S3,The ESP32-S3 reads the x and y values from the Grove and sends them over a serial port.

🧾 Code Snippet (ESP32-S3)

#include <Seeed_Arduino_SSCMA.h>
SSCMA Infer;

void setup()
{
    Serial.begin(9600);
    Infer.begin();
}

void loop()
{
    if (!Infer.invoke())
    {
        auto boxes = Infer.boxes();
        if (boxes.size() > 0)
        {
            int x = boxes[0].x;
            int y = boxes[0].y;

            Serial.print("X: ");
            Serial.print(x);
            Serial.print(" | Y: ");
            Serial.println(y);
        }
    }

    delayMicroseconds(10);
}

This code runs on the ESP32-S3 and reads the face bounding box coordinates (x and y), then sends them over serial.

🌐 Reading Data in the Web App – Serial Web API

Now the final part: getting the data into my browser.

I used the Serial Web API, a feature in modern browsers that allows web apps to read data directly from devices connected via USB (like our ESP32-S3).

In the code:

• I opened the serial port
• Read the incoming x and y data
• Passed it into the Rive animation using its runtime API
• Now, as your face moves in front of the camera, the animation moves in real time 🎯

Huge thanks to MakerGram ❤️‍🔥
