IoT Tic-Tac-Toe

Play tic-tac-toe using lights and two hand-crafted boards over the internet.

IntermediateWork in progress6 hours855

Things used in this project

Hardware components

Particle Photon

LED (generic)

3 Pin ON/ON SPDT Switch

Resistor 1k ohm

Resistor 2.21k ohm

Resistor 475 ohm

1/4" MDF Sheet (24" x 48")

Software apps and online services

ThingSpeak API

Particle IDE

Hand tools and fabrication machines

Soldering iron (generic)

7/32" Drill Bit

Drill

Wiring Pliers

2 Part Epoxy

Story

Background

For our MEGR 3171 IOT project, we decided to create a game with the premise of remote play. This would be impossible with just a single board. We decided to use a game familiar to everyone: Tic-Tac-Toe. Simple right? As it turned out... No.

The premise of this project would be that we would have two tic-tac-toe boards, controlled by switches, that communicated the events going on in the game with different colored LED lights. The lights would inform the user of their turn, the other player's moves, the winner, loser, and if any errors have occurred in the game. Due to the use of two boards with two Particle Photons, two people would be able to play this game in two remote locations as long as a power source and a Wi-Fi connection is present.

Creating the Board

The base for this project is the boards in which the game is played. These boards were cut from a 24" x 48" slab of 1/4" MDF wood. In each of these boards, holes were drilled out for two lights and a switch in each "section" of the tic-tac-toe board. In the top corner, four more holes were drilled in which four more lights would be inserted.

In the section of the board designated for playing the game, switches were inserted into the holes designated for the switches. These switches will be used by the player with the board to make their moves. White lights were inserted to designate the moves made by the opposing player. In the upper corner, a green, red, yellow, and blue light were inserted to designate a win, loss, error, and when the user's turn is happening, respectively. Each component is being held into the board using 2 Part Epoxy, but after a number of switch failures hot glue would probably be a better plan.

On the back of the board, jumper cables and resistors were soldered to each component to create the circuits as seen in the schematic on this page.

Creating the Circuit and Code

While the current state of this project is "in progress", the vast majority of the base algorithms and the plethora of bugs have been worked out. The Particle platform being cloud based creates a set of challenges that can be difficult to overcome with a complex code especially for beginners like us two. The code has gone through many dozen revisions to get where it is now. The boards perform all of the primary functions and utilizes some clever techniques for interfacing with the user and the cloud.

From a hardware perspective, the Photon has pretty limited I/O for a project like this. Ideally, each switch would have a single GPIO pin to activate. However, the Photon doesn't have enough pins to perform both switch recognition as well as LED output for the opponent's positions. Therefore a method was used to reduced required inputs from 9 (one per switch) to just 3 by using a variable voltage divider. From this recognition, the signal can be sent to the other board to light the correct LED. As seen in the schematic, when the player flips a switch, it moves the current in the circuit through different resistors which changes the voltage going into the photon.

Also included in the code is the blue "your turn" light turning on after a signal is sent from the other photon. This proved to be the most difficult aspect of the project. Many limitations and drawbacks of the photon were exposed while trying to make the boards reliably transfer the turns between themselves. This function now carries the position information between the Photons as well. During the two agonizing weeks of debugging lots of another integrated feature, the yellow "error" light , was seen. This LED turns on for various errors such as having switches activated during a game reset or when a solder connection breaks.

The photon can be easily programmed to recognize the different combinations for what produces a win in tic-tac-toe.

When a win is detected, the photon signals the "win" light to activate on its board, and the "lose" light to turn on on the opposing board. This also begins a reset process on both boards where the game is reset after about 20 seconds and ready to play again.

ThingSpeak - https://thingspeak.com/channels/367730

We used ThingSpeak for our cloud data logging feature. The main graph is of the TurnCount variable within the code. This proved to be a valuable debugging tool throughout the development process.

Gallery

An early board prototype

One day of testing and data logging

Demonstration Video

Code

IoT Tic-Tac-Toe Code

 // Define the Output Vars
    int ErrLED = D2;
    int WinLED = D6;
    int LoseLED = D1;
    int MyTurnLED = D7;
    int OpponentA1 = D3;
    int OpponentA2 = D4;
    int OpponentA3 = D5;
    int OpponentB1 = D0;
    int OpponentB2 = A3;
    int OpponentB3 = TX;
    int OpponentC1 = RX;
    int OpponentC2 = A5;
    int OpponentC3 = A4;

    // Define the Input Vars
    int PositionDetectA = A0; // Position Detection Pin for Row A
    int PositionDetectB = A1; // Position Detection Pin for Row B
    int PositionDetectC = A2; // Position Detection Pin for Row C
    int Avalue = 0;
    int Bvalue = 0;
    int Cvalue = 0;

    // Local constants
    int value1min = 2500;
    int value1max = 3000;
    int value2min = 1200;
    int value2max = 1400;
    int value3min = 1850;
    int value3max = 2400;
    int value12min = 1060;
    int value12max = 1190;
    int value23min = 945;
    int value23max = 1050;
    int value13min = 1450;
    int value13max = 1800;
    int value123min = 700;
    int value123max = 935;

    // Define the local game Vars
    int MyPositionA1; // Sets a high bit when this spot is activated by the user
    int MyPositionA2;
    int MyPositionA3;
    int MyPositionB1;
    int MyPositionB2;
    int MyPositionB3;
    int MyPositionC1;
    int MyPositionC2;
    int MyPositionC3;
    int TurnCount = 1; // Iterative counter for the number of turns. Used in error checking.
    int GameStop; // Sets a high bit when the game needs to be halted.
    int value;

    // Webhook stuff
    #define publish_delay 6000
    unsigned int lastPublish = 0;

void setup()
{
   // Set Output pins
    pinMode(ErrLED, OUTPUT);
    pinMode(WinLED, OUTPUT);
    pinMode(LoseLED, OUTPUT);
    pinMode(MyTurnLED, OUTPUT);
    pinMode(OpponentA1, OUTPUT);
    pinMode(OpponentA2, OUTPUT);
    pinMode(OpponentA3, OUTPUT);
    pinMode(OpponentB1, OUTPUT);
    pinMode(OpponentB2, OUTPUT);
    pinMode(OpponentB3, OUTPUT);
    pinMode(OpponentC1, OUTPUT);
    pinMode(OpponentC2, OUTPUT);
    pinMode(OpponentC3, OUTPUT);

   // Set Input Pins
    pinMode(PositionDetectA, INPUT);
    pinMode(PositionDetectB, INPUT);
    pinMode(PositionDetectC, INPUT);


   //Subscribe to global variables
    Particle.subscribe("nbv70rTurnChangeB", TurnChangeHandler);
    Particle.subscribe("nbv70rwinB", winHandler);
    Particle.subscribe("nbv70rResetB", resetHandler);


   // Blink 4 LEDs to check to see if we made it this far correctly
    analogWrite(ErrLED, 175);
    digitalWrite(WinLED, HIGH);
    analogWrite(LoseLED, 175);
    digitalWrite(MyTurnLED, HIGH);
    delay(3000);
    analogWrite(ErrLED, 0);
    digitalWrite(WinLED, LOW);
    analogWrite(LoseLED, 0);
    digitalWrite(MyTurnLED, LOW);
    delay(750);

    resetHandler(NULL, NULL);
}

void resetHandler (const char *event, const char *data)
{
   // Test the rows to see if everything is reset. Do nothing, but set the LED until the board is reset
   while (Avalue < value1max)
   {
       analogWrite(analogRead(A0), 175);
       delay(500);
   }
   if (analogRead(A0) > value1max)
   {
     analogWrite(ErrLED, 0);
   }

   while (analogRead(A1) < value1max)
   {
       analogWrite(ErrLED, 175);
       delay(500);
   }

   if (analogRead(A1) > value1max)
   {
      analogWrite(ErrLED, 0);
   }

   while (analogRead(A2) < value1max)
   {
       analogWrite(ErrLED, 175);
       delay(500);
   }
   if (analogRead(A2) > value1max)
   {
     analogWrite(ErrLED, 0);
   }
   delay(100);

   if (analogRead(ErrLED) < 50) // Once the board has no errors, reset the variables and the win/lose LEDs
   {
        MyPositionA1 = 0; // Set all positions to 0
        MyPositionA2 = 0;
        MyPositionA3 = 0;
        MyPositionB1 = 0;
        MyPositionB2 = 0;
        MyPositionB3 = 0;
        MyPositionC1 = 0;
        MyPositionC2 = 0;
        MyPositionC3 = 0;
   }

    TurnCount = 1;
    // Set the A player's (my) LED HIGH because I get to start the game
    digitalWrite(MyTurnLED, HIGH);
    delay(100);
    digitalWrite(OpponentA1, LOW);
    delay(100);
    digitalWrite(OpponentA2, LOW);
    delay(100);
    digitalWrite(OpponentA3, LOW);
    delay(100);
    digitalWrite(OpponentB1, LOW);
    delay(100);
    digitalWrite(OpponentB2, LOW);
    delay(100);
    digitalWrite(OpponentB3, LOW);
    delay(100);
    digitalWrite(OpponentC1, LOW);
    delay(100);
    digitalWrite(OpponentC2, LOW);
    delay(100);
    digitalWrite(OpponentC3, LOW);
    delay(500);
    loop();
}

void loop()
{   // Didn't add code for errors if the player activates the same place as the opponent
    // Didn't add code to run a winCheck func at the end of the turn to check versus other

    if (digitalRead(MyTurnLED) == HIGH)
    {

        // Check the TurnCount vs the total number of active positions and don't continue if they aren't equal
        while (MyPositionA1 + MyPositionA2 + MyPositionA3 + MyPositionB1 + MyPositionB2 + MyPositionB3 + MyPositionC1 + MyPositionC2 + MyPositionC3 != TurnCount)
        {
            //Checking and calculating where each switch is activated in Row A
            while(analogRead(A0) < value123min);
            {
                analogWrite(ErrLED, 175);
            }

            analogWrite(ErrLED, 0);

            PositionDetectA = analogRead(A0);
            delay(1000);
            if(PositionDetectA>=value1min && PositionDetectA<=value1max && MyPositionA1 != 1)
            {
                MyPositionA1 = 1;
                delay(1100);
                Particle.publish("nbv70rTurnChangeA", "1");
            }
            if(PositionDetectA>=value2min && PositionDetectA<=value2max  && MyPositionA2 != 1)
            {
                MyPositionA2 = 1;
                delay(1100);
                Particle.publish("nbv70rTurnChangeA", "2");
            }
            if(PositionDetectA>=value3min && PositionDetectA<=value3max  && MyPositionA3 != 1)
            {
                MyPositionA3 = 1;
                delay(1100);
                Particle.publish("nbv70rTurnChangeA", "3");
            }
            if(PositionDetectA>=value12min && PositionDetectA<=value12max)
            {
                if(MyPositionA1 != 1 || MyPositionA2 != 1)
		        {
			        MyPositionA1 = 1;
                	MyPositionA2 = 1;
                	delay(1100);
                	Particle.publish("nbv70rTurnChangeA", "12");
		        }
            }
            if(PositionDetectA>=value23min && PositionDetectA<=value23max)
            {
                if(MyPositionA2 != 1 || MyPositionA3 != 1)
		        {
			        MyPositionA2 = 1;
                	MyPositionA3 = 1;
                	delay(1100);
                	Particle.publish("nbv70rTurnChangeA", "23");
		        }
            }
            if(PositionDetectA>=value13min && PositionDetectA<=value13max)
            {
                if(MyPositionA1 != 1 && MyPositionA3 != 1)
		        {
			        MyPositionA1 = 1;
                	MyPositionA3 = 1;
                	delay(1100);
                	Particle.publish("nbv70rTurnChangeA", "13");
		        }
            }
            if(PositionDetectA>=value123min && PositionDetectA<=value123max)
            {
		        if(MyPositionA1 != 1 || MyPositionA2 != 1 || MyPositionA3 != 1)
                {
			        MyPositionA1 = 1;
                	MyPositionA2 = 1;
                	MyPositionA3 = 1;
                	delay(1100);
                	Particle.publish("nbv70rTurnChangeA", "123");
                	myWin();
		        }
            }

            //Checking and calculating where each switch is activated in Row B
             while(analogRead(A1) < value123min);
            {
                delay(100);
                analogWrite(ErrLED, 175);
		        delay(100);
            }

            analogWrite(ErrLED, 0);

            PositionDetectB = analogRead(A1);
            delay(1000);
            if(PositionDetectB>=value1min && PositionDetectB<=value1max && MyPositionB1 != 1)
            {
                MyPositionB1 = 1;
                Particle.publish("nbv70rTurnChangeA", "4");
            }
            if(PositionDetectB>=value2min && PositionDetectB<=value2max && MyPositionB2 != 1)
            {
                MyPositionB2 = 1;
                Particle.publish("nbv70rTurnChangeA", "5");
            }
            if(PositionDetectB>=value3min && PositionDetectB<=value3max && MyPositionB3 != 1)
            {
                MyPositionB3 = 1;
                Particle.publish("nbv70rTurnChangeA", "6");
            }
            if(PositionDetectB>=value12min && PositionDetectB<=value12max)
            {
		        if(MyPositionB1 != 1 || MyPositionB2 != 1)
		        {
                	MyPositionB1 = 1;
                	MyPositionB2 = 1;
                	Particle.publish("nbv70rTurnChangeA", "45");
		        }
            }
            if(PositionDetectB>=value23min && PositionDetectB<=value23max)
            {
		        if(MyPositionB2 != 1 || MyPositionB3 != 1)
		        {
                	MyPositionB2 = 1;
                	MyPositionB3 = 1;
                	Particle.publish("nbv70rTurnChangeA", "56");
		        }
            }
            if(PositionDetectB>=value13min && PositionDetectB<=value13max)
            {
		        if(MyPositionB1 != 1 || MyPositionB3 != 1)
		        {
                	MyPositionB1 = 1;
                	MyPositionB3 = 1;
                	Particle.publish("nbv70rTurnChangeA", "46");
		        }
            }
            if(PositionDetectB>=value123min && PositionDetectB<=value123max) // AutoWin
            {
		        if(MyPositionB1 != 1 || MyPositionB2 != 1 || MyPositionB3 != 1)
		        {
                	MyPositionB1 = 1;
                	MyPositionB2 = 1;
                	MyPositionB3 = 1;
                	Particle.publish("nbv70rTurnChangeA", "456");
                	myWin();
		        }
            }

            //Checking and calculating where each switch is activated in Row C
            while(analogRead(A2) < value123min);
            {
                analogWrite(ErrLED, 175);
            }

            analogWrite(ErrLED, 0);

            PositionDetectC = analogRead(A2);
            delay(1000);
            if(PositionDetectC>=value1min && PositionDetectC<=value1max && MyPositionC1 != 1)
            {
                MyPositionC1 = 1;
                Particle.publish("nbv70rTurnChangeA","7");
            }
            if(PositionDetectC>=value2min && PositionDetectC<=value2max && MyPositionC2 != 1)
            {
                MyPositionC2 = 1;
                Particle.publish("nbv70rTurnChangeA", "8");
            }
            if(PositionDetectC>=value3min && PositionDetectC<=value3max && MyPositionC3 != 1)
            {
                MyPositionC3 = 1;
                Particle.publish("nbv70rTurnChangeA", "9");
            }
            if(PositionDetectC>=value12min && PositionDetectC<=value12max)
            {
		        if(MyPositionC1 != 1 || MyPositionC2 != 1)
		        {
                	MyPositionC1 = 1;
                	MyPositionC2 = 1;
                	Particle.publish("nbv70rTurnChangeA", "78");
		        }
            }
            if(PositionDetectC>=value23min && PositionDetectC<=value23max)
            {
		        if(MyPositionC2 != 1 || MyPositionC3 != 1)
		        {
                	MyPositionC2 = 1;
                	MyPositionC3 = 1;
                	Particle.publish("nbv70rTurnChangeA", "89");
		        }
            }
            if(PositionDetectC>=value13min && PositionDetectC <=value13max)
            {
		        if(MyPositionC1 != 1 || MyPositionC3 != 1)
		        {
                	MyPositionC1 = 1;
                	MyPositionC3 = 1;
                	Particle.publish("nbv70rTurnChangeA", "79");
            	}
	        }
            if(PositionDetectC>=value123min && PositionDetectC<=value123max) // AutoWin
            {
		        if(MyPositionC1 != 1 || MyPositionC2 != 1 || MyPositionC3 != 1)
		        {
                	MyPositionC1 = 1;
                	MyPositionC2 = 1;
                	MyPositionC3 = 1;
                	Particle.publish("nbv70rTurnChangeA", "789");
                	myWin();
		        }
            }
        }

        // Using the Turn Counter, determine if a single move has been made and switch turns
        if(MyPositionA1 + MyPositionA2 + MyPositionA3 + MyPositionB1 + MyPositionB2 + MyPositionB3 + MyPositionC1 + MyPositionC2 + MyPositionC3 == TurnCount)
        {
            //Webhook stuff
            unsigned long now = millis();
            if ((now - lastPublish) < publish_delay)
            {
                return;
            }
            value = TurnCount;
            delay(1100);
            Particle.publish("thingSpeakWrite_A0", "{ \"1\": \"" + String(value) + "\", \"k\": \"CBAPTBVL2Y4KQI3X\" }", 60, PRIVATE);
            lastPublish = now;

            digitalWrite(MyTurnLED, LOW);
            TurnCount = TurnCount + 1;
        }
    }
}

void TurnChangeHandler (const char *event, const char *data)
{
    if(strcmp(data, "1") == 0)
    {
       digitalWrite(OpponentA1, HIGH);
    }
    if(strcmp(data, "2") == 0)
    {
       digitalWrite(OpponentA2, HIGH);
    }
    if(strcmp(data, "3") == 0)
    {
       digitalWrite(OpponentA3, HIGH);
    }
    if(strcmp(data, "12") == 0)
    {
       digitalWrite(OpponentA1, HIGH);
       digitalWrite(OpponentA2, HIGH);
    }
    if(strcmp(data, "23") == 0)
    {
       digitalWrite(OpponentA2, HIGH);
       digitalWrite(OpponentA3, HIGH);
    }
    if(strcmp(data, "13") == 0)
    {
        digitalWrite(OpponentA1, HIGH);
        digitalWrite(OpponentA3, HIGH);
    }
    if(strcmp(data, "123") == 0)
    {
       digitalWrite(OpponentA1, HIGH);
       digitalWrite(OpponentA2, HIGH);
       digitalWrite(OpponentA3, HIGH);
    }

    if(strcmp(data, "4") == 0)
    {
	    digitalWrite(OpponentB1, HIGH);
	}
    if(strcmp(data, "5") == 0)
    {
       digitalWrite(OpponentB2, HIGH);
    }
    if(strcmp(data, "6") == 0)
    {
       digitalWrite(OpponentB3, HIGH);
    }
    if(strcmp(data, "45") == 0)
    {
	    digitalWrite(OpponentB1, HIGH);
	    digitalWrite(OpponentB2, HIGH);
	}
    if(strcmp(data, "56") == 0)
    {
       digitalWrite(OpponentB2, HIGH);
       digitalWrite(OpponentB3, HIGH);
    }
    if(strcmp(data, "46") == 0)
    {
        digitalWrite(OpponentB1, HIGH);
        digitalWrite(OpponentB3, HIGH);
    }
    if(strcmp(data, "456") == 0)
    {
        digitalWrite(OpponentB1, HIGH);
        digitalWrite(OpponentB2, HIGH);
	    digitalWrite(OpponentB3, HIGH);
	}

    if(strcmp(data, "7") == 0)
    {
       digitalWrite(OpponentC1, HIGH);
    }
    if(strcmp(data, "8") == 0)
    {
       digitalWrite(OpponentC2, HIGH);
    }
    if(strcmp(data, "9") == 0)
    {
       digitalWrite(OpponentC3, HIGH);
    }
    if(strcmp(data, "78") == 0)
    {
       digitalWrite(OpponentC1, HIGH);
       digitalWrite(OpponentC2, HIGH);
    }
    if(strcmp(data, "89") == 0)
    {
       digitalWrite(OpponentC2, HIGH);
       digitalWrite(OpponentC3, HIGH);
    }
    if(strcmp(data, "79") == 0)
    {
       digitalWrite(OpponentC3, HIGH);
       digitalWrite(OpponentC1, HIGH);
    }
    if(strcmp(data, "789") == 0)
    {
       digitalWrite(OpponentC1, HIGH);
       digitalWrite(OpponentC2, HIGH);
       digitalWrite(OpponentC3, HIGH);
    }

    digitalWrite(MyTurnLED, HIGH);
    delay(100);
    loop();
}

void myWin()
{	// Didn't write code to analyze and reset if errors are detected in a potential win scenario
	// This could be the winCheck function as well

     while(digitalRead(ErrLED) == HIGH)
        {
            delay(500);
            //reset error if no problem persists
        }
     if(digitalRead(ErrLED) == LOW)
     {
        digitalWrite(WinLED, HIGH);
        delay(750);
        digitalWrite(MyTurnLED, LOW);
        delay(250);
        Particle.publish("nbv70rwinA");
        delay(9000);
        digitalWrite(WinLED, LOW);
        delay(2000);
        digitalWrite(WinLED, HIGH);
        delay(2000);
        digitalWrite(WinLED, LOW);
        delay(2000);
        digitalWrite(WinLED, HIGH);
        delay(2000);
        digitalWrite(WinLED, LOW);
        delay(2000);
        digitalWrite(WinLED, HIGH);
        delay(200);
        digitalWrite(WinLED, LOW);
        delay(200);
        digitalWrite(WinLED, HIGH);
        delay(200);
        digitalWrite(WinLED, LOW);
        delay(200);
        digitalWrite(WinLED, HIGH);
        delay(200);
        digitalWrite(WinLED, LOW);
        delay(200);
        digitalWrite(WinLED, HIGH);
        delay(200);
        digitalWrite(WinLED, LOW);
        delay(200);
        digitalWrite(WinLED, HIGH);
        delay(200);
        digitalWrite(WinLED, LOW);
        delay(200);
        digitalWrite(WinLED, HIGH);
        delay(200);
        digitalWrite(WinLED, LOW);
        delay(200);
        digitalWrite(WinLED, HIGH);
        delay(200);
        digitalWrite(WinLED, LOW);
        delay(200);
        digitalWrite(WinLED, HIGH);
        delay(200);
        digitalWrite(WinLED, LOW);
        delay(200);
        digitalWrite(WinLED, HIGH);
        delay(200);
        digitalWrite(WinLED, LOW);
        delay(200);
        digitalWrite(WinLED, HIGH);
        delay(200);
        digitalWrite(WinLED, LOW);
        delay(200);
        digitalWrite(WinLED, HIGH);
        delay(200);
        digitalWrite(WinLED, LOW);
        delay(200);
        digitalWrite(WinLED, HIGH);
        delay(200);
        digitalWrite(WinLED, LOW);

        resetHandler(NULL,NULL);
    }
}

void winHandler (const char *event, const char *data) // If the opponent wins
{
    while(digitalRead(ErrLED) == HIGH)
        {
            delay(500);
            //reset error if no problem persists
        }
     if(digitalRead(ErrLED) == LOW)
     {
        digitalWrite(LoseLED, HIGH);
        delay(500);
        digitalWrite(MyTurnLED, LOW);
        delay(9500);
        digitalWrite(LoseLED, LOW);
        delay(2000);
        digitalWrite(LoseLED, HIGH);
        delay(2000);
        digitalWrite(LoseLED, LOW);
        delay(2000);
        digitalWrite(LoseLED, HIGH);
        delay(2000);
        digitalWrite(LoseLED, LOW);
        delay(2000);
        digitalWrite(LoseLED, HIGH);
        delay(200);
        digitalWrite(LoseLED, LOW);
        delay(200);
        digitalWrite(LoseLED, HIGH);
        delay(200);
        digitalWrite(LoseLED, LOW);
        delay(200);
        digitalWrite(LoseLED, HIGH);
        delay(200);
        digitalWrite(LoseLED, LOW);
        delay(200);
        digitalWrite(LoseLED, HIGH);
        delay(200);
        digitalWrite(LoseLED, LOW);
        delay(200);
        digitalWrite(LoseLED, HIGH);
        delay(200);
        digitalWrite(LoseLED, LOW);
        delay(200);
        digitalWrite(LoseLED, HIGH);
        delay(200);
        digitalWrite(LoseLED, LOW);
        delay(200);
        digitalWrite(LoseLED, HIGH);
        delay(200);
        digitalWrite(LoseLED, LOW);
        delay(200);
        digitalWrite(LoseLED, HIGH);
        delay(200);
        digitalWrite(LoseLED, LOW);
        delay(200);
        digitalWrite(LoseLED, HIGH);
        delay(200);
        digitalWrite(LoseLED, LOW);
        delay(200);
        digitalWrite(LoseLED, HIGH);
        delay(200);
        digitalWrite(LoseLED, LOW);

        resetHandler(NULL,NULL);
     }
}

Credits

Nick Bartlett

1 project • 0 followers

Mechanical Engineering student at UNCC.

Anthony Cortina

1 project • 0 followers

IoT Tic-Tac-Toe

Things used in this project

Hardware components

Software apps and online services

Hand tools and fabrication machines

Story

Schematics

Wiring Schematic

Code

IoT Tic-Tac-Toe Code

Credits

Nick Bartlett

Anthony Cortina

Comments

Embed the widget on your own site

IoT Tic-Tac-Toe

IoT Tic-Tac-Toe

Things used in this project

Hardware components

Software apps and online services

Hand tools and fabrication machines

Story

Schematics

Wiring Schematic

Code

IoT Tic-Tac-Toe Code

Credits

Nick Bartlett

Anthony Cortina

Comments

Related channels and tags
