Published September 12, 2016

UNIX Time Clock

This Clock displays "UNIX Time". Every PC, SmartPhone, Microcontroller use UNIX Time in internal. This clock display the other world's time.

IntermediateShowcase (no instructions)5 hours7,414

Things used in this project

Hardware components

SparkFun Arduino Pro Mini 328 - 5V/16MHz

SainSmart I2C RTC DS1307 AT24C32 Real Time Clock Module Board for Arduino AVR ARM PIC

Universal board

140mm x 40mm

74HC595

Shift register. This parts use to reduce use amount of arduino pin.

12V AC adapter

DC Jack

7 segment display(4 digits)

Acrylic Sheets

Cut ro 140mm x 40mm

Resistor 221 ohm

Software apps and online services

DS1307RTC

Very useful library for DS1307.

Hand tools and fabrication machines

Soldering iron (generic)

Story

Every PC, smartphone, microcontroller uses the "UNIX Time". UNIX time is also called "Epoch Time" or "POSIX Time". It is the seconds from 1 January 1970. Every computer uses UNIX Time but most of the people do not notice computers use UNIX time. I know it is not useful for humans but I think that it is funny if there is real world's UNIX time clock. So, I made it.

Credits

iizukak

2 projects • 16 followers

Maker, Software Engineer
