28BYJ-48 Stepper Motor Control System Based On Arduino With

#include <Stepper.h>
#include <LiquidCrystal.h>

int Iint1=0;
int Iint2=1;
int anjian1=2;
int anjian2=3;
int motorSpeed;
LiquidCrystal lcd(9,8,7,6,5,4);

const int stepsPerRevolution =200;

// 	Here set the stepper motor rotation step how much is a circle
int dim=stepsPerRevolution;

//	Set the step motor number and pin
Stepper myStepper(stepsPerRevolution, 10,11,12,13);

void setup()
{
   lcd.begin(16, 2);
   lcd.print("speed:");

   lcd.setCursor(10,0);
   lcd.print("n/min");

   lcd.setCursor(0, 1);
   lcd.print("Direction:");

   // 	Set the motor speed of 60 steps per minute
   myStepper.setSpeed(60);

   pinMode(anjian1,INPUT_PULLUP);
   pinMode(anjian2,INPUT_PULLUP);
   attachInterrupt(Iint1,counterclockwise,FALLING);
   attachInterrupt(Iint2,clockwise,FALLING);
   Serial.begin(9600);
}

void loop()
 {

   myStepper.step(dim);
   void Direction();
   //	 Read the sensor values:
   int sensorReading = analogRead(A0);
   // 	Map it to a range of 0-150:
   int motorSpeed = map(sensorReading, 0, 1023, 0, 150);
   // 	Set the motor speed:
   if (motorSpeed > 0)
    {
        myStepper.setSpeed(motorSpeed);
        lcd.setCursor(6,0);
        lcd.print(float(float(motorSpeed)/float(200)));
    }
  }

 void clockwise()
  {
     //   clockwise rotation
     dim=stepsPerRevolution;
     lcd.setCursor(10, 1);
     lcd.print(">>>>>>");
  }


  void counterclockwise()
  {
     //	anti-clockwise
     dim=-stepsPerRevolution;
     lcd.setCursor(10, 1);
     lcd.print("<<<<<<");
   }
