DHT22 Data to Google sheet Using ESP8266 without credential.

Here the DHT22 sensor is connected to ESP8266 NodeMCU and ESP8266 NodeMCU is connected to Internet through WiFi to send the DHT22.

IntermediateShowcase (no instructions)443
DHT22 Data to Google sheet Using ESP8266 without credential.

Things used in this project

Hardware components

Breadboard (generic)
Breadboard (generic)
×1
ESP8266 ESP-12E
Espressif ESP8266 ESP-12E
×1
DHT22 Temperature Sensor
DHT22 Temperature Sensor
×1
Jumper wires (generic)
Jumper wires (generic)
×1

Story

Read more

Schematics

Pin Diagram

Here is the circuit pin design for the device

Code

Code

C/C++
Here is the project code.
//----------------------------------------Include the NodeMCU ESP8266 Library
//----------------------------------------see here: https://www.youtube.com/watch?v=8jMr94B8iN0 to add NodeMCU ESP12E ESP8266 library and board (ESP8266 Core SDK)
#include <ESP8266WiFi.h>
#include <WiFiClientSecure.h>
#include <DNSServer.h>
#include <WiFiManager.h>
//----------------------------------------
//----------------------------------------Include the DHT Library
#include "DHT.h"
//----------------------------------------

#define DHTTYPE DHT22 //--> Defines the type of DHT sensor used (DHT11, DHT21, and DHT22), in this project the sensor used is DHT11.

const int DHTPin = D1; //--> The pin used for the DHT11 sensor is Pin D1 = GPIO5
DHT dht(DHTPin, DHTTYPE); //--> Initialize DHT sensor, DHT dht(Pin_used, Type_of_DHT_Sensor);

#define ON_Board_LED 2  //--> Defining an On Board LED, used for indicators when the process of connecting to a wifi router

//----------------------------------------SSID and Password of your WiFi router.
//const char* ssid = "SDL AP1"; //--> Your wifi name or SSID.
//const char* password = "Systechd33"; //--> Your wifi password.
//----------------------------------------

//----------------------------------------Host & httpsPort
const char* host = "script.google.com";
const int httpsPort = 443;
//----------------------------------------

WiFiClientSecure client; //--> Create a WiFiClientSecure object.

String GAS_ID = "AKfycbwriCAA9Gjh9V0sspRh8l_PPrfINCba-OwKsjBFoElH1B0ITnnGUqn9-1gTVRBLi3b-"; //--> spreadsheet script ID

//============================================================================== void setup
void setup() {
  // put your setup code here, to run once:
  Serial.begin(115200);
  delay(500);

  dht.begin();  //--> Start reading DHT11 sensors
  delay(500);

//  WiFi.begin(ssid, password); //--> Connect to your WiFi router
  Serial.println("");

  pinMode(ON_Board_LED,OUTPUT); //--> On Board LED port Direction output
  digitalWrite(ON_Board_LED, HIGH); //--> Turn off Led On Board

  //----------------------------------------Wait for connection
  Serial.print("Connecting");
  while (WiFi.status() != WL_CONNECTED) {
    Serial.print(".");
    //----------------------------------------Make the On Board Flashing LED on the process of connecting to the wifi router.
    digitalWrite(ON_Board_LED, LOW);
    delay(250);
    digitalWrite(ON_Board_LED, HIGH);
    delay(250);
    //----------------------------------------
  }
  //----------------------------------------
  digitalWrite(ON_Board_LED, HIGH); //--> Turn off the On Board LED when it is connected to the wifi router.
  //----------------------------------------If successfully connected to the wifi router, the IP Address that will be visited is displayed in the serial monitor
  Serial.println("");
  Serial.print("Successfully connected to : ");
//  Serial.println(ssid);
  Serial.print("IP address: ");
  Serial.println(WiFi.localIP());
  Serial.println();
  //----------------------------------------

  client.setInsecure();
}
//==============================================================================
//============================================================================== void loop
void loop() {
  // Reading temperature or humidity takes about 250 milliseconds!
  // Sensor readings may also be up to 2 seconds 'old' (its a very slow sensor)
  int h = dht.readHumidity();
  // Read temperature as Celsius (the default)
  float t = dht.readTemperature();

  // Check if any reads failed and exit early (to try again).
  if (isnan(h) || isnan(t)) {
    Serial.println("Failed to read from DHT sensor !");
    delay(500);
    return;
  }
  String Temp = "Temperature : " + String(t) + " C";
  String Humi = "Humidity : " + String(h) + " %";
  Serial.println(Temp);
  Serial.println(Humi);

  sendData(t, h); //--> Calls the sendData Subroutine
}
//==============================================================================
//============================================================================== void sendData
// Subroutine for sending data to Google Sheets
void sendData(float tem, int hum) {
  Serial.println("==========");
  Serial.print("connecting to ");
  Serial.println(host);

  //----------------------------------------Connect to Google host
  if (!client.connect(host, httpsPort)) {
    Serial.println("connection failed");
    return;
  }
  //----------------------------------------

  //----------------------------------------Processing data and sending data
  String string_temperature =  String(tem);
  // String string_temperature =  String(tem, DEC);
  String string_humidity =  String(hum, DEC);
  String url = "/macros/s/" + GAS_ID + "/exec?temperature=" + string_temperature + "&humidity=" + string_humidity;
  Serial.print("requesting URL: ");
  Serial.println(url);

  client.print(String("GET ") + url + " HTTP/1.1\r\n" +
         "Host: " + host + "\r\n" +
         "User-Agent: BuildFailureDetectorESP8266\r\n" +
         "Connection: close\r\n\r\n");

  Serial.println("request sent");
  //----------------------------------------

  //----------------------------------------Checking whether the data was sent successfully or not
  while (client.connected()) {
    String line = client.readStringUntil('\n');
    if (line == "\r") {
      Serial.println("headers received");
      break;
    }
  }
  String line = client.readStringUntil('\n');
  if (line.startsWith("{\"state\":\"success\"")) {
    Serial.println("esp8266/Arduino CI successfull!");
  } else {
    Serial.println("esp8266/Arduino CI has failed");
  }
  Serial.print("reply was : ");
  Serial.println(line);
  Serial.println("closing connection");
  Serial.println("==========");
  Serial.println();
  //----------------------------------------
}
//==============================================================================
