Things used in this project

Hardware components:
Phpoc blue per 100x1000 euk22wtv9i
PHPoC Blue
×1
Relay (generic)
×1
12V LED Light
×1
SparkFun Sound Detector (SEN-12642)
×1

Schematics

Connecting to PHPoC Blue
[Sound detecting sensor] ---- [PHPoC Blue]
ENVELOPE ---- AD0
GATE ---- NSS/0
GND ---- GND
VCC ---- 3.3V

[Relay] ---- [PHPoC Blue]
IN ---- SCK/1
GND ---- GND
5V ---- PWR5
Sound detect bb jlpxasf2ao

Code

2. Clap once for On, Clap twice for OffPHP
It recognizes the number of noises within 500ms.
<?php
include_once "/lib/sd_340.php";
adc_setup(0, 0);
uio_setup(0, 0, "in");
uio_setup(0, 1, "out");
uio_out(0, 1, LOW);
st_free_setup(0);

define("FINAL_DETECTED",    0);
define("CLAP_NOT_DETECTED",   1);
define("TIMEOUT",   2);

$start_time = 0;

function indicate_clap($clap_num)
{
    if($clap_num == 2) //2 clap
        uio_out(0, 1, LOW);

    else if($clap_num == 1) //1 clap
        uio_out(0, 1, HIGH);

    usleep(100000);
}

function detect_claps($clap_num)
{
    global $start_time;

    if($clap_num == 2)  // 2 clap -> off
    {
        indicate_clap($clap_num);

        return FINAL_DETECTED;
    }

    $uio_in = uio_in(0, 0);
    $adc_in = adc_in(0, 100);

    indicate_clap($clap_num); //no clap

    if($adc_in > 600 && $uio_in == 1) //clap detect
    {
        $start_time = st_free_get_count(0);
        $current_time = st_free_get_count(0);

        while(1)
        {
            if($current_time - $start_time < 500)
            {
                $current_time = st_free_get_count(0);
                $clap_state = detect_claps($clap_num + 1);

                if($clap_state == FINAL_DETECTED)
                    return $clap_state;
            }
            else
                return TIMEOUT;
        }
    }

    return CLAP_NOT_DETECTED;
}

while(1)
{
    $clap_state = detect_claps(0);

      if($clap_state == FINAL_DETECTED)
        indicate_clap(0);

    usleep(10000);
}
?>
1. On/Off TogglePHP
<?php
include_once "/lib/sd_340.php";
adc_setup(0, 0);
uio_setup(0, 0, "in");
uio_setup(0, 1, "out");
uio_out(0, 1, LOW);
function control_led()
{
    uio_out(0, 1, TOGGLE);
    usleep(100000);
}
while(1)
{
    $uio_in = uio_in(0, 0);    //GATE
    $adc_in = adc_in(0, 100); //ENVELOPE

    if($adc_in > 600 && $uio_in == 1)
        control_led();

    usleep(10000);
}
?>
