Drift Visualizer

An IoT solution to hack drifting. Gameification built around proximity sensors. Leaderboards by location. Drift into the Future!

IntermediateWork in progress3,984

Things used in this project

Hardware components

Esquilo Air

Grove Shield with LCD RGB Display

VERRADO ELECTRIC DRIFT TRIKE

Story

Had a great time this weekend at #HardwareWeekend @kickstarter

credit yangbo du on photo storify.com/yangbodu/hardwarews

Albert Schweitzer, Javair Ratliff and Lex Dreitser took first place and drifted off with two Verrado electric drift trikes from @localmotors.
http://shop.localmotors.com/products/verrado-electric-drift-trike

Drift VisualizerAn IoT solution to hack drifting. Gameification built around proximity sensors. Leaderboards by location. Drift into the Future!

On top of that - we were able to use Esquilo @esquiloio - easily the most innovative dev board out on the market right now.
https://www.kickstarter.com/projects/esquiloio/esquilo-simple-iot-developmentThank you to the #hardware community and @hacksterio for making it happen.

https://www.hackster.io

LCD_ADDR <- (0x7c >> 1);

RGB_ADDR <- (0xc4 >> 1);
LCD_2LINE <- 0x08;

REG_RED   <- 0x04;
REG_GREEN <- 0x03;
REG_BLUE  <- 0x02;

i2c <- I2C(0);

function setReg(addr, value)
{
    i2c.address(RGB_ADDR);
    i2c.write8(addr, value);
}

function setRgb(red, green, blue)
{
    setReg(REG_RED, red);
    setReg(REG_GREEN, green);
    setReg(REG_BLUE, blue);
}

setReg(0, 0);
setReg(1, 0);
setReg(0x08, 0xAA);     // all led control by pwm

setRgb(0, 100, 200);

while(true) {
    delay(200);
    setRgb(100, 0, 0);
    local red = (rand().tofloat() / RAND_MAX) * 255.0;
    local green = (rand().tofloat() / RAND_MAX) * 255.0;
    local blue = (rand().tofloat() / RAND_MAX) * 255.0;
    setRgb(red, green, blue);
}
