Team Group 4:

Published December 13, 2023

EEP Project

Eep proj

BeginnerProtip45

Things used in this project

Hardware components

M5Stack FIRE V2.7

M5Stack RGB Unit with NeoPixel RGB LED (SK6812)

M5Stack I2C Hub 1 to 6 Expansion TCA9548A Module

M5stack ENV III

SERVO

M5Stack PIR Sensor Human Body Infrared PIR Motion Sensor (AS312)

Software apps and online services

UiFLOW

Hand tools and fabrication machines

penknife

Box, General Purpose

Tape, Clear

Story

Hotels have large number of occupancy daily which also means that electricity is being used constantly.
Amenities such as air con, lighting usually take up most of it.
This project aims to decrease and save as much electricity as possible while allowing customers to enjoy their stay.

Objective

Tackle common areas where lighting are used more often in hotel rooms, implementing sustainable practices to reduce electricity wastage
Making sure customers comfort are not affected
Educate guest on energy-efficient practices

Research :

Electricity used by hotel rooms typically account for 10-30% of overall expenses
Disposable toothbrushes sustainability practice
How can sensor-based energy management system can help save electricity

Code

from m5stack import *
from m5ui import *
from uiflow import *
import time
import unit

setScreenColor(0x000000)
pahub_1 = unit.get(unit.PAHUB, unit.PORTA)
env3_3 = unit.get(unit.ENV3, unit.PAHUB0)
env3_5 = unit.get(unit.ENV3, unit.PAHUB2)
rgb_3 = unit.get(unit.RGB, unit.PORTB)


view = None
pointer = None
lightbar = None
rainrandom = None
i = None



MainLabel1 = M5Title(title="Mainlabel", x=10, fgcolor=0x0d0505, bgcolor=0xbc80f2)
Menu1op1 = M5TextBox(20, 35, "Light", lcd.FONT_Default, 0xFFFFFF, rotate=0)
rectangle0 = M5Rect(95, 160, 28, 2, 0xe80000, 0xff0505)
pointer1 = M5Circle(10, 41, 5, 0x56ff6a, 0x000000)
On = M5TextBox(95, 140, "On ", lcd.FONT_Ubuntu, 0xFFFFFF, rotate=0)
Dim = M5TextBox(145, 140, "Dim", lcd.FONT_Ubuntu, 0xFFFFFF, rotate=0)
Off = M5TextBox(195, 140, "Off", lcd.FONT_Ubuntu, 0xFFFFFF, rotate=0)
Outside = M5TextBox(55, 47, "Outside", lcd.FONT_DejaVu18, 0xFFFFFF, rotate=0)
Inside = M5TextBox(170, 47, "Inside", lcd.FONT_DejaVu18, 0xFFFFFF, rotate=0)
outsidetemp = M5TextBox(70, 75, "Text", lcd.FONT_Ubuntu, 0xFFFFFF, rotate=0)
insidetemp = M5TextBox(180, 75, "Text", lcd.FONT_Ubuntu, 0xFFFFFF, rotate=0)
textforlights = M5TextBox(110, 173, "Double Tap B", lcd.FONT_Ubuntu, 0xFFFFFF, rotate=0)
menu = M5TextBox(45, 107, "Press A To Go Menu", lcd.FONT_Comic, 0xFFFFFF, rotate=0)
outsidehumid = M5TextBox(70, 100, "Text", lcd.FONT_Ubuntu, 0xFFFFFF, rotate=0)
c1 = M5TextBox(113, 75, "C", lcd.FONT_DefaultSmall, 0xFFFFFF, rotate=0)
insidehumid = M5TextBox(180, 100, "Text", lcd.FONT_Ubuntu, 0xFFFFFF, rotate=0)
dot1 = M5Circle(108, 77, 2, 0xFFFFFF, 0xFFFFFF)
c = M5TextBox(224, 75, "C", lcd.FONT_DefaultSmall, 0xFFFFFF, rotate=0)
dot = M5Circle(218, 77, 2, 0xFFFFFF, 0xFFFFFF)
p = M5TextBox(107, 105, "%", lcd.FONT_Default, 0xFFFFFF, rotate=0)
firstpageA = M5TextBox(55, 220, "Text", lcd.FONT_Default, 0xFFFFFF, rotate=0)
p1 = M5TextBox(217, 100, "%", lcd.FONT_Default, 0xFFFFFF, rotate=0)
firstpageB = M5TextBox(145, 220, "Text", lcd.FONT_Default, 0xFFFFFF, rotate=0)
firstpageC = M5TextBox(235, 220, "Text", lcd.FONT_Default, 0xFFFFFF, rotate=0)
Menu1op2 = M5TextBox(20, 60, "Temperature", lcd.FONT_Default, 0xFFFFFF, rotate=0)
sun = M5Circle(30, 147, 15, 0xffb829, 0xffb809)
cloud2 = M5Circle(48, 180, 12, 0x807b7b, 0x807b7b)
cloud1 = M5Circle(62, 176, 17, 0x807b7b, 0x807b7b)
cloud4 = M5Circle(93, 180, 12, 0x807b7b, 0x807b7b)
rain = M5Rect(53, 183, 1, 1, 0x97b6f3, 0x97b6f3)
circle0 = M5Circle(79, 176, 17, 0x807b7b, 0x807b7b)
rectangle1 = M5Rect(78, 183, 1, 1, 0x97b6f3, 0x97b6f3)
rectangle2 = M5Rect(90, 192, 1, 1, 0x97b6f3, 0x97b6f3)
rectangle3 = M5Rect(65, 192, 1, 1, 0x97b6f3, 0x97b6f3)
rectangle4 = M5Rect(104, 183, 1, 1, 0x97b6f3, 0x97b6f3)
rectangle5 = M5Rect(41, 190, 1, 1, 0x97b6f3, 0x97b6f3)

from numbers import Number
import random


# Describe this function...
def swap_page():
  global view, pointer, lightbar, rainrandom, i
  while True:
    if view == 'Menu':
      if pointer == 1 and (btnB.isPressed()):
        view = 'Light Menu'
        SetView()
      else:
        if pointer == 2 and (btnB.isPressed()):
          view = 'Temperature Menu'
          SetView()
        else:
          if pointer == 3 and (btnB.isPressed()):
            view = 'Toilet'
            SetView()
          else:
            pass
    else:
      if view == 'Light Menu':
        if lightbar == 1 and (btnB.wasDoublePress()):
          rgb_3.setBrightness(100)
          rgb_3.setColor(1, 0xffcc33)
        else:
          if lightbar == 2 and (btnB.wasDoublePress()):
            rgb_3.setBrightness(20)
            rgb_3.setColor(1, 0xffcc33)
          else:
            if lightbar == 3 and (btnB.wasDoublePress()):
              rgb_3.setColor(1, 0x000000)
            else:
              pass
      else:
        if view == 'Temperature Menu':
          pahub_1.select_only_on(0)
          pahub_1.select_only_on(2)
          insidetemp.setText(str(int((env3_3.temperature))))
          insidehumid.setText(str(int((env3_3.humidity))))
          outsidetemp.setText(str(int((env3_5.temperature))))
          outsidehumid.setText(str(int((env3_5.humidity))))
          outside()
        else:
          rgb.setColorAll(0x000000)
    wait_ms(2)

# Describe this function...
def outside():
  global view, pointer, lightbar, rainrandom, i
  if view == 'Temperature Menu':
    if (env3_5.humidity) <= 50:
      sun.hide()
      rgb.setColorAll(0x3366ff)
      rain.setBgColor(0x3366ff)
      rectangle1.setBgColor(0x3366ff)
      rectangle2.setBgColor(0x3366ff)
      rectangle3.setBgColor(0x3366ff)
      rectangle4.setBgColor(0x3366ff)
      rectangle5.setBgColor(0x3366ff)
      rainrandom = random.randint(2, 30)
      rain.setSize(height=rainrandom)
      rainrandom = random.randint(2, 30)
      rectangle1.setSize(height=rainrandom)
      rainrandom = random.randint(2, 30)
      rectangle2.setSize(height=rainrandom)
      rainrandom = random.randint(2, 30)
      rectangle3.setSize(height=rainrandom)
      rainrandom = random.randint(2, 30)
      rectangle4.setSize(height=rainrandom)
      rainrandom = random.randint(2, 30)
      rectangle5.setSize(height=rainrandom)
    else:
      rgb.setColorAll(0xffff00)
      rain.hide()
      rectangle1.show()
      rectangle2.show()
      rectangle3.show()
      rectangle4.show()
      rectangle5.show()
      sun.setBgColor(0xffff00)
      cloud2.setBgColor(0xffffff)
      cloud1.setBgColor(0xffffff)
      cloud4.setBgColor(0xffffff)
      circle0.setBgColor(0xffffff)
      cloud2.setBorderColor(0xffffff)
      cloud1.setBorderColor(0xffffff)
      cloud4.setBorderColor(0xffffff)
      circle0.setBorderColor(0xffffff)
      for i in range(15, 26):
        lcd.circle(30, 147, i, color=0xffcc33)
        lcd.circle(30, 147, (i - 1), color=0x000000)
        wait(0.05)
      lcd.circle(30, 147, 25, color=0x000000)
  else:
    rgb.setColorAll(0x000000)

# Describe this function...
def SetView():
  global view, pointer, lightbar, rainrandom, i
  MainLabel1.setTitle(str(view))
  if view == 'Start':
    menu.show()
    Menu1op1.hide()
    Menu1op2.hide()
    On.hide()
    Dim.hide()
    Off.hide()
    Outside.hide()
    outsidetemp.hide()
    outsidehumid.hide()
    insidehumid.hide()
    insidetemp.hide()
    Inside.hide()
    firstpageA.show()
    firstpageB.show()
    firstpageC.show()
    textforlights.hide()
    c1.hide()
    c.hide()
    p.hide()
    p1.hide()
    sun.hide()
    cloud2.hide()
    cloud1.hide()
    cloud4.hide()
    circle0.hide()
    rain.hide()
    rectangle1.hide()
    rectangle2.hide()
    rectangle3.hide()
    rectangle4.hide()
    rectangle5.hide()
    dot1.hide()
    dot.hide()
    pointer1.hide()
    rectangle0.hide()
  else:
    if view == 'Menu':
      menu.hide()
      Menu1op1.show()
      Menu1op2.show()
      On.hide()
      Dim.hide()
      Off.hide()
      Outside.hide()
      Inside.hide()
      outsidetemp.hide()
      insidetemp.hide()
      outsidehumid.hide()
      insidehumid.hide()
      textforlights.hide()
      c1.hide()
      c.hide()
      p.hide()
      p1.hide()
      sun.hide()
      cloud2.hide()
      cloud1.hide()
      cloud4.hide()
      circle0.hide()
      rain.hide()
      rectangle1.hide()
      rectangle2.hide()
      rectangle3.hide()
      rectangle4.hide()
      rectangle5.hide()
      dot1.hide()
      dot.hide()
      rectangle0.hide()
      pointer1.show()
    else:
      if view == 'Light Menu':
        menu.hide()
        Menu1op1.hide()
        Menu1op2.hide()
        On.show()
        Dim.show()
        Off.show()
        Outside.hide()
        Inside.hide()
        outsidetemp.hide()
        insidetemp.hide()
        outsidehumid.hide()
        insidehumid.hide()
        textforlights.show()
        c1.hide()
        c.hide()
        p1.hide()
        sun.hide()
        cloud2.hide()
        cloud1.hide()
        cloud4.hide()
        circle0.hide()
        rain.hide()
        rectangle1.hide()
        rectangle2.hide()
        rectangle3.hide()
        rectangle4.hide()
        rectangle5.hide()
        dot1.hide()
        p.hide()
        dot.hide()
        pointer1.hide()
        rectangle0.show()
      else:
        if view == 'Temperature Menu':
          menu.hide()
          Menu1op1.hide()
          Menu1op2.hide()
          On.hide()
          Dim.hide()
          Off.hide()
          Outside.show()
          Inside.show()
          outsidetemp.show()
          insidetemp.show()
          outsidehumid.show()
          insidehumid.show()
          c1.show()
          sun.show()
          cloud2.show()
          cloud1.show()
          cloud1.show()
          cloud4.show()
          circle0.show()
          rain.show()
          rectangle1.show()
          rectangle2.show()
          rectangle3.show()
          rectangle4.show()
          rectangle5.show()
          dot1.show()
          c.show()
          p.show()
          p1.show()
          dot.show()
          textforlights.hide()
          pointer1.hide()
          rectangle0.hide()
        else:
          pass


def buttonA_wasPressed():
  global view, pointer, lightbar, rainrandom, i
  if view == 'Start':
    view = 'Menu'
    SetView()
  else:
    if view == 'Menu':
      view = 'Start'
      SetView()
    else:
      if view == 'Light Menu':
        view = 'Menu'
        SetView()
      else:
        if view == 'Temperature Menu':
          view = 'Menu'
          SetView()
        else:
          pass
  pass
btnA.wasPressed(buttonA_wasPressed)

def buttonC_wasPressed():
  global view, pointer, lightbar, rainrandom, i
  if view == 'Menu':
    if pointer < 2:
      pointer = (pointer if isinstance(pointer, Number) else 0) + 1
    else:
      pointer = 1
    pointer1.setPosition(10, (16 + 25 * pointer))
  else:
    if view == 'Light Menu':
      if lightbar < 3:
        lightbar = (lightbar if isinstance(lightbar, Number) else 0) + 1
      else:
        lightbar = 1
      rectangle0.setPosition((45 + 50 * lightbar), 160)
      SetView()
    else:
      pass
  pass
btnC.wasPressed(buttonC_wasPressed)


view = 'Start'
pointer = 1
lightbar = 1
firstpageA.setText('A')
firstpageB.setText('B')
firstpageC.setText('C')
SetView()
swap_page()

from m5stack import *
from m5ui import *
from uiflow import *
import unit

setScreenColor(0x222222)
pir_0 = unit.get(unit.PIR, unit.PORTB)
rgb_1 = unit.get(unit.RGB, unit.PORTA)






PIR = M5TextBox(103, 92, "Text", lcd.FONT_DejaVu56, 0xFFFFFF, rotate=0)


while True:
  if (btnA.isPressed()) and (pir_0.state) == 1:
    PIR.setText('On')
    rgb_1.setBrightness(100)
    rgb_1.setColor(3, 0xffff00)
  else:
    if (pir_0.state) == 0:
      PIR.setText('Off')
      rgb_1.setColor(3, 0x000000)
  wait_ms(2)

from m5stack import *
from m5ui import *
from uiflow import *
import unit

setScreenColor(0x222222)
env3_4 = unit.get(unit.ENV3, unit.PORTA)
servo_1 = unit.get(unit.SERVO, unit.PORTB)






label0 = M5TextBox(146, 112, "Text", lcd.FONT_Default, 0xFFFFFF, rotate=0)
label1 = M5TextBox(172, 112, "%", lcd.FONT_Default, 0xFFFFFF, rotate=0)


while True:
  label0.setText(str(int((env3_4.humidity))))
  label1.setText('%')
  if (env3_4.humidity) > 50:
    servo_1.write_angle(90)
  else:
    servo_1.write_angle(0)
  wait_ms(2)

Credits

MarcusPek

1 project • 0 followers

EEP Project

Things used in this project

Hardware components

Software apps and online services

Hand tools and fabrication machines

Story

Schematics

Block Diagram

Code

Main Room

toilet lights

Toilet door

Credits

MarcusPek

Comments

Embed the widget on your own site

EEP Project

EEP Project

Things used in this project

Hardware components

Software apps and online services

Hand tools and fabrication machines

Story

Schematics

Block Diagram

Code

Main Room

toilet lights

Toilet door

Credits

MarcusPek

Comments

Related channels and tags
