Arduino: 自動WIFI重置器 Automatic WIFI reseter (Auto AP reseter)

因特別需求家中裝了很多無線設備，也不知道為什麼家中的中華電信數據機三不五時就會斷線，斷電再重新通電後又會恢復正常。又因為家裡不是隨時都有人可以幫忙處理，於是冒出了這個想法，要是有個設備可以自動偵測我的無線網路連線，當網路斷線時自動把AP的電源切斷，過個幾秒在通電，這樣就不用...

IntermediateFull instructions provided3 hours266
Arduino: 自動WIFI重置器 Automatic WIFI reseter (Auto AP reseter)

Things used in this project

Hardware components

Wemos D1 Mini
Espressif Wemos D1 Mini
×1
Relay (generic)
×1

Story

Read more

Code

AP Reseter

Arduino
 #include <ESP8266WiFi.h>
 #include <ESP8266Ping.h>

 const char* ssid   = "yourwifissid";
 const char* password  = "yourpassword";
 const char* remote_host = "www.google.com";

 #define MinutesToCheck   10     // set x minutes to check internet access
 #define TimesForRecheck   3      // retry x times to determine if wifi disconnected
 #define RelayPin      D4     // Relay control pin

 //-------------------------------------------------
 // Connect to WIFI
 //-------------------------------------------------
 void ConnectWifi() {
  int retry_times = 0;

  Serial.println("Connecting to WiFi");
  WiFi.disconnect();
  delay(1000);
  WiFi.begin(ssid, password);
  delay(500);

  while (WiFi.status() != WL_CONNECTED) {
   Serial.print(".");
   retry_times =retry_times + 1;
   if (retry_times >= 60) {
    WiFi.begin(ssid, password);
    retry_times = 0;
   }
   delay(500);
  }

  Serial.println();
  Serial.print("WiFi connected with ip ");
  Serial.println(WiFi.localIP());

 }

 //-------------------------------------------------
 // Ping WIFI
 //-------------------------------------------------
 boolean PingWifi() {
  Serial.print("Pinging host ");
  Serial.print(remote_host);

  if(Ping.ping(remote_host)) {
   Serial.println(" ... Success!!");
   return true;
  } else {
   Serial.println(" ... Error :(");
   return false;
  }
 }

 //-------------------------------------------------
 // Reset Relay
 //-------------------------------------------------
 void ResetRelay() {
  Serial.println("Reseting AP power");
  digitalWrite(RelayPin, HIGH);   // cut off relay
  delay(10000);           // wait for 10 seconds
  digitalWrite(RelayPin, LOW);   // restore relay
 }

 //-------------------------------------------------
 // DelayOneMinute
 //-------------------------------------------------
 void DelayOneMinute() {
  for (int i=0; i < 60; i++)
  {
   delay(1000);         // waits for a second
  }
 }

 //-------------------------------------------------
 // setup
 //-------------------------------------------------
 void setup() {
  Serial.begin(115200);
  delay(10);

  pinMode(RelayPin, OUTPUT);   // sets the digital pin as output
  digitalWrite(RelayPin, LOW);  // default LOW

  // Set ESP8266 in station mode to hide broadcasted SSID: AI-THINKER_XXXXXX
  WiFi.mode(WIFI_STA);

  Serial.println("Wait for 2 mins AP initial time");
  DelayOneMinute();        // wait for AP restart
  DelayOneMinute();        // wait for AP restart
  ConnectWifi();
  PingWifi();
 }

 //-------------------------------------------------
 // Main
 //-------------------------------------------------
 void loop() {
  for (int i=0; i < MinutesToCheck; i++) {  // waits for x minutes
   Serial.print(MinutesToCheck-i);
   Serial.println(" minutes to ping");
   DelayOneMinute();
  }

  for (int i=0; i < TimesForRecheck; i++) {
   Serial.println("Checking WIFI status...");
   if (WiFi.status() == WL_CONNECTED) {
    Serial.println("WIFI connected");
    if (PingWifi()) {
     break;
    }
   }
   if (i == TimesForRecheck-1) {   // ping failed x times, reset AP power
    ResetRelay();
    Serial.println("Wait for 2 mins AP initial time");
    DelayOneMinute();        // wait for AP restart
    DelayOneMinute();        // wait for AP restart
    ConnectWifi();
    break;
   }
   Serial.println("WIFI disconnected, wait 5 sec to retry");
   delay(5000);           // wait for re-ping again
  }
 }

Github

https://github.com/dancol90/ESP8266Ping
