YOLOv8 custom classification model using Jetson Orin NX

YOLOv8 custom dataset classification model

This tutorial is part of my smart bird feeder. Here I explain how I trained the custom model for classification using Seeed Studio reComputer J4012 and YOLOv8.

Preparing the reComputer

The reComputer J4012 from Seeed Studio is a Jetson Orin NX 16GB. It's a powerfull machine, but the Tegra Linux comes with a lot of things and, boots to graphical mode.

I'm using JetPack 6.0 - So, everything here about installing packages is within this version.

Change boot mode

It's all good, but we aren't going to need graphics and, in idle mode is consuming 1.5GB of memory

So, I'm going to make it boot to CLI

sudo systemctl set-default multi-user

As of now, our reComputer will boot to CLI. Let's set it now to CLI mode

sudo systemctl isolate multi-user

We've passed from using 1.5GB of memory to 700MB. Every memory byte counts when using Machine Learning.

Change Power mode

In the file /etc/nvpmodel.conf, we have the power modes available.

< POWER_MODEL ID=0 NAME=MAXN >
< POWER_MODEL ID=1 NAME=10W >
< POWER_MODEL ID=2 NAME=15W >
< POWER_MODEL ID=3 NAME=25W >

We can then use sudo nvpmodel -m <#power model> to change the power mode. And, according to this thread post, the settings are kept even after reboots.

To see what power level are we on now,

sudo nvpmodel -q

Let's select the max power mode for the training of our model

sudo nvpmodel -m 0

After a reboot, we can confirm that we're running full power

Training the model

For the training, I'm going to use YOLOv8. Bellow are the steps needed to install it with CUDA support.

The model

Because this is a classification task, I don't need to know the position of the bird in the photo. I have procured 12 classes of birds and created a classification dataset in Roboflow.

You can use another dataset of your choice, as long as it is a Classification dataset or model

Those 12 classes of birds are the ones common to where I live and I thought that, those are the ones that have more probability to come feed on my feeder.

To use this dataset, I'm going to export it and select folder structure

Next, select Jupyter and copy the code if you're going to use a notebook, or select Terminal if you're executing the commands in the terminal.

Creating the environment

We're going to create a virtual environment, install PyTorch and install YOLOv8. Per documentation tip, it's better to install PyTorch first and then ultralytics.

Also, I'm installing jupyterlab packages to use with VSCode. The notebook is attached to this tutorial.

Let's install some dependencies first.

NOTE: Because we're going to use YOLOv8, we need to do some steps that normally we wouldn't need.

sudo apt install libopenblas-dev cuda-toolkit libcudnn8 tensorrt python3-libnvinfer nvidia-l4t-dla-compiler

Create the Python virtual environment

python -m venv birdClassificationModel

If you get an error, is because the package python3-venv is not installed. Let's install it and repeat the above command.

sudo apt install python3-venv

Activate it

source birdClassificationModel/bin/activate

You can confirm is active because the name of it is placed before your prompt.

YOLOv8

Before, and to follow on the documentation tip, let's first install PyTorch.

I'm using JetPack 6.0, that comes with NVIDIA Jetson Linux 36.3 and CUDA 12.2.

Let's upgrade PIP first

pip install -U pip

Installing Torch to be able to use it with YOLOv8, we need to follow the steps in the NVIDIA forums.

This will be done with the virtual environment active, so that it is installed in it.

Download Torch version 2.3 from NVIDIA

wget https://nvidia.box.com/shared/static/mp164asf3sceb570wvjsrezk1p4ftj8t.whl -O torch-2.3.0-cp310-cp310-linux_aarch64.whl
sudo apt-get install python3-pip libopenblas-base libopenmpi-dev libomp-dev
pip3 install 'Cython<3'
pip install numpy torch-2.3.0-cp310-cp310-linux_aarch64.whl

After this, let's compile torchvision. If we install it from the wheels, it will not have CUDA support.

The branch version is for the Torch version installed. You can see more details in the forum page.

Remember, you need to have the virtual environment active so this will all be installed in it.

sudo apt-get install libjpeg-dev zlib1g-dev libpython3-dev libopenblas-dev libavcodec-dev libavformat-dev libswscale-dev
git clone --branch v0.18.0 https://github.com/pytorch/vision torchvision
cd torchvision/
export BUILD_VERSION=0.18.0
python setup.py install

After a while, it will be compiled and installed.

After installing, let's see if Cuda is available.

python -c "import torch;print (torch.cuda.is_available())"

This should return True

Install YOLOv8

pip install ultralytics

Because we've installed torch vision above, it will use that version instead of installing a new one (albeit the same version) without our CUDA support.

Let's install roboflow and jupyterlab

pip install roboflow jupyterlab

Download the dataset from roboflow

rf = Roboflow(api_key="")
project = rf.workspace("bruno-santos-omqsq").project("bird-classification-19z7c")
version = project.version(1)
dataset = version.download("folder")

After downloading the model, we now have a set of three directories (test, train, valid), each one with a certain number of images from each class. Each image from each class is in its own directory.

Training the model

Usually a dataset has the images and the labels (or annotations) with the object coordinates. Since this is a classification task, we don't need any of that. Just that the images be in each directory that's the name of the class.

Preparing the config file

We still need a config file with the classes to recognize. This file should be in the dataset directory, with.yaml extension.

vi birdClassificationModel.yaml

Place the following text inside the file

train: train/
valid: valid/
test: test/
# number of classes
nc: 12
# class names
names: ["Barn Swallow","Common Firecrest","Common Nightingale","Eurasian Chaffinch","Eurasian Crag Martin","European Goldfinch","European Greenfinch","European Serin","House Sparrow","Spanish Sparrow","Western House Martin","white Wagtail"]

For the classification, we're going to use one of pre-trained models already available from Ultralytics.

This models have been trained on ImageNet and are fine tuned for classification. We're going to use it and train it on our data.

This is what's know as transfer learning.

I'm going to use the model YOLOv8l-cls. Probably others will work fine too, but because we don't need real time, its a trade off on speed and accuracy.

Let's then train the model, using YOLOv8 CLI interface

yolo task=classify mode=train model=yolov8l-cls.pt data=Bird-Classification-1 epochs=100

Explaining:

• task=classify : We're going to classify the images
• mode=train : We're training the model
• model=yolov8l-cls.pt : We're using a classification model from YOLOv8 trained on ImageNet.
• data=Bird-Classification-1 : Our model dataset
• epochs=100 : for how long we're training the model.

Now that's it's running, here's some statistics using jtop (tegra-stats)

This will take a while, so, go have some coffee, or tea.

After a 2 hours and 9 minutes of training, the process is complete

Now, let's see how the model behaves. Let's test the model in the test images

yolo task=classify mode=predict model='./runs/classify/train6/weights/best.pt' source=Bird-Classification-1/test/**/*.jpg

This will make yolo to go into the test directories and try to predict each

The results are all correct. Let's try with two images that I've taken

yolo task=classify mode=predict model='./runs/classify/train6/weights/best.pt' source=house_sparrow.jpg

yolo task=classify mode=predict model='./runs/classify/train6/weights/best.pt' source=white_wagtail.jpg

I'm going to say that these results are great.

Exporting

We can use the model as it is for the inference, we just need to open it and use it.

For faster inference times we can export it to TensorRT, since we're on a NVIDIA Jetson Orin NX.

Is not that we need faster inference times for this project - I'm not going to use this on real time video - but it's nice we can take advantage of the platform we're on.

Unfortunately, due to the virtual environment I was unable to export it to TensorRT. For some reason, I couldn't import tensorrt in Python, but outside the virtual environment, I had no problem with tensorrt libraries.

ONNX

We can export the model to ONNX format like this

yolo export model='./runs/classify/train6/weights/best.pt' format=onnx imgsz=640

We get a best.onnx that we can use to run inference with.

To run inference using ONNX, we need to install the onnxruntime_gpu wheel.

We need to go to the Jetson Zoo and download the pip wheel from there for our Python version (3.10) and JetPack version (6.0)

wget https://nvidia.box.com/shared/static/48dtuob7meiw6ebgfsfqakc9vse62sg4.whl -O onnxruntime_gpu-1.18.0-cp310-cp310-linux_aarch64.whl

And then install it

pip install onnxruntime_gpu-1.18.0-cp310-cp310-linux_aarch64.whl

Inference


I've used the following code to run inference with the best.pt model and see the results.

# running inference
from ultralytics import YOLO
# load the  model
bird_model = YOLO("./runs/classify/train6/weights/best.pt")
#run inference
results = bird_model("house_sparrow.jpg")[0]
# get class names
class_names = results.names
# get top class with more probability
top1 = results.probs.top1
# print the class name with the highest probability
print (f" The detected bird is: {class_names[top1]}")

That the code above does is load the model, runs inference in an image and save the results to the results variable.

Because results is ultralytics.engine.results.Results object of type list with one item, which is an instance of Results. The [0] in the results variable to hold the inference result will allow us to get to the results that we want.

results = bird_model("house_sparrow.jpg")[0]

Next, we use the results to get the class names. Not that we don't know them, but like this will allow this code to work in other models too.

class_names = results.names

One of the results is a top1 variable that holds the TOP 1 class with more probabilities. That TOP1 is given by the probs list.

top1 = results.probs.top1

Next, we print the highest probability class that should be the bird species.

print (f" The detected bird is: {class_names[top1]}")
The detected bird is: House Sparrow

Camera

Now, let's use a camera to run inference.

Jetson can use a USB camera or a RPI camera. I'm going to connect a USB camera.

The following code will check if can display a camera feed

#Lets test if we can use a USB camera
import cv2
cap = cv2.VideoCapture(0)
while True:
    ret, img = cap.read()
    cv2.imshow('Camera', img)
    if cv2.waitKey(1) & 0xFF == ord('q'):
        break
cap.release()
cv2.destroyAllWindows

This is me, on my desktop computer. Just use ssh -X username@jetson and the X11 will be forwarded to your desktop. This works because I'm using Linux too. I think that WSL could also work.

Now, let's try to run inference on a video feed, displaying the class with the higher probability

Here's the code

# again, save this code in a file a run it from the Jetson
# now, let's run inference
import cv2
from ultralytics import YOLO
import time
#define confidence level
#only equal or above this level we say it's a class of bird
confidence = 0.95
# time when processed last frame
prev_frame = 0
# time processed current frame
cur_time = 0
# load the  model
bird_model = YOLO("./runs/classify/train6/weights/best.pt")
# cv2 font
font = cv2.FONT_HERSHEY_SIMPLEX
# open camera
cap = cv2.VideoCapture(0)
while True:
    ret, img = cap.read()
    # to display fps
    cur_frame = time.time()
    fps = 1 / (cur_frame - prev_frame)
    prev_frame = cur_frame
    fps = int(fps)
    fps = str(fps)
    cv2.putText (img, fps, (550,50), font, 1, (124,10,120), 2, cv2.LINE_AA)

    # inference current frame
    results = bird_model(img, verbose=False)[0]
    # get class names
    class_names = results.names
    # get top class with more probability
    top1 = results.probs.top1
    top1conf = results.probs.top1conf.tolist()
    # we will only show the class name if the confidence is higher than defined level
    # print the class name with the highest probability
    if (top1conf >= confidence):
        bird_class = class_names[top1]
        print (f" The detected bird is: {class_names[top1]}")
        # color is in BGR
        confid = round(top1conf,2)
        img = cv2.putText(img, bird_class, (50,50), font, 0.9, (0, 0, 255), 2, cv2.LINE_AA)
        img = cv2.putText(img, "Conf: " + str(confid), (50,80), font, 0.6, (255, 0, 255), 1, cv2.LINE_AA)
        cv2.imshow('Camera', img)
    else:
        img = cv2.imshow('Camera', img)
    if cv2.waitKey(1) & 0xFF == ord('q'):
        break
cap.release()
cv2.destroyAllWindows

Here's the video showing the model working with the camera
