The DRV8243 is a highly integrated brushed DC motor driver IC from Texas Instruments, designed to deliver efficient, reliable, and compact motor control for a wide range of industrial, automotive, and embedded applications. This project focuses on developing a motor driver board using the DRV8243P or DRV8243S variant, capable of driving a single brushed DC motor with a supply voltage range of 4.5V to 36V and a peak output current up to 6A.
Full project link:
https://electronicsworkshops.com/2025/02/19/motor-driver-board-using-drv8243/
PCBWAY is a highly skilled company specializing in PCB manufacturing. They offer their services at incredibly low prices, such as providing 10 PCBs for only $5. Additionally, new members receive a $5 bonus. The website allows customers to upload their Gerber Files and place orders.
PCBWAY is known for producing PCBs of exceptional quality and maintaining high standards, which is why many people trust them for their PCB and PCBA needs.
Below are some of my PCB’S manufactured by PCBWAY and I am fully satisfied by their Quality of service they provide
DRV8243The DRV8243 is a motor driver IC from Texas Instruments, designed for driving brushed DC motors and solenoids. It is part of the DRV824x family, which offers integrated features to control motors efficiently in automotive, industrial, and other embedded applications.
Key Features of DRV8243:- Motor Type: Brushed DC motors
- Voltage Range: Operates typically in the 4.5V to 36V range
- Output Current: Supports up to 6 A peak current
Control Interface:
- Can be configured for PWM (Pulse Width Modulation) control
- PH/EN or IN/IN interface options
- Control Interface:Can be configured for PWM (Pulse Width Modulation) controlPH/EN or IN/IN interface options
Protection Features:
- Over-current protection (OCP)
- Over-temperature protection (OTP)
- Under-voltage lockout (UVLO)
- Load-dump protection (automotive transients)
- Protection Features:Over-current protection (OCP)Over-temperature protection (OTP)Under-voltage lockout (UVLO)Load-dump protection (automotive transients)
- Diagnostic Feedback: Fault indication for system-level feedback
- Low Standby Current: Efficient for battery-powered systems
- Package: Typically offered in compact HTSSOP or QFN packages
- VIN: 12V to 36V input
- GND: Common ground
Capacitors:
- 100nF + 10µF (ceramic) near VIN pin
- 470µF electrolytic near input connector
- Capacitors:100nF + 10µF (ceramic) near VIN pin470µF electrolytic near input connector
📷DRV8243 Pins:
DRV8243 Pins:- IN1 / IN2 or PH / EN: Motor control (from MCU or logic pins)
- nSLEEP: Tie HIGH for operation or control via MCU
- nFAULT: Open-drain fault output (connect to MCU or LED)
- MODE: Tie LOW for IN/IN or HIGH for PH/EN
- IPROPI: Optional current sense output
- OUT1/OUT2: Connect to motor terminals
📷Schematic Diagram of DRV8243
This motor driver circuit uses the Texas Instruments DRV8243 IC to control a brushed DC motor efficiently, with integrated protection and diagnostic features. The input power (12–36V DC) is filtered and protected using a TVS diode, bulk and bypass capacitors, and a AGM40P75 N-channel MOSFET configured for reverse polarity protection. The DRV8243 receives filtered power and drives the motor via its OUT1 and OUT2 pins, while control signals (PH/EN or IN1/IN2) from a microcontroller define motor direction and speed. Pull-up resistors are used for logic pins like MODE, nSLEEP, and nFAULT, while capacitors near VIN ensure stable operation. Optional current sensing is enabled via the IPROPI pin with a resistor to ground, and nFAULT can be monitored via an MCU or LED. The result is a compact, reliable, and robust motor driver board suitable for industrial, automotive, or robotics applications
PCB FilesI have already uploaded all these required manufacturing files inPCBWAY website. You can easily go to the below link and place you order, and get your Own Home Automation PCB manufactured from one of the best pcb manufacturer PCBWAY
Order Now……
Applications:- Automotive seat and window actuators
- Power tools
- Robotics
- Factory automation
- Electric valves or pumps
This DRV8243-based motor driver board provides a compact, efficient, and protected solution for driving DC motors.
The design includes:High-current H-Bridge (5.5A peak)Adjustable current sensing (IPROPI)Robust protection (OCP, OTP, UVLO)Easy PWM control (Arduino-compatible)
Full project link:
https://electronicsworkshops.com/2025/02/19/motor-driver-board-using-drv8243/
