Things used in this project

Hardware components:
Intel.web.720.405
Intel Edison
×1
Grove 20starter 20kit 20plus 20  20intel c2 ae 20iot2 01
SeeedStudio Grove starter kit plus for Intel Edison
×1
Connector cables
×1
2471 10
Adafruit HUZZAH ESP8266 Breakout
×1
MiCS5524 Gas Sensor
×1
Software apps and online services:
Ha 2up iot
Amazon Web Services AWS IoT
React Native
Ide web
Arduino IDE
Twilio SMS
Firebase
Hand tools and fabrication machines:
09507 01
Soldering iron (generic)

Schematics

Adafruit Gas Sensor Setup
3djy7cbgnhei7o019vjk
Adafruit Gas Sensor Setup

No document.

Code

Transferring Analog output Arduino
Reading the Analog output (example uses A0 pin) to a serial port via Arduino IDE
const int analogInPin = A0; #change the pin u used
int sensorValue = 0;

void setup() {
  Serial.begin(500000);
}

void loop() {
  sensorValue = analogRead(analogInPin);
  Serial.print(sensorValue);
  Serial.print("|");
  delay(200);
}
