Sparkle Shoes

Light up shoes w/ force sensors and LEDs. There are fewer things more fun than dancing as your feet literally light up the floor. Max fun.

Work in progress1,779
Sparkle Shoes

Things used in this project

Hardware components

Adafruit Trinket
Great, tiny, arduino-ish board! However, there are even better options like: Trinket Pro - http://www.adafruit.com/product/2010, Beetle http://www.dfrobot.com/index.php?route=product/product&product_id=1075, etc.
×2
Force sensor
This works fine, but you might want to go for accelerometers instead.
×2
Power adapter
Use cheap little phone chargers as batteries with these!!!
×1
Barrel Jack Mount
make power input easy and swappable. Other options - http://www.adafruit.com/product/610, https://www.sparkfun.com/products/8734
×1

Story

Read more

Schematics

SparkleShoes.pdf

Code

Trinket-based Light Shoes

Listens for multiple "steps" on the force sensor to change animation modes. Patterns include: direct force to color, stepped colors based on force, flash light, test rainbow.
