You Spin My Tea Right ‘Round

The world’s most efficient way to mix tea

AdvancedShowcase (no instructions)1,065
You Spin My Tea Right ‘Round

Things used in this project

Story

Read more

Schematics

Fritzing Diagram

Code

Code

C/C++
const int button1 = 2; //connects to constantly spinning button
const int button2 = 4; //connects to timed button

const int motorPin = 9; //connects to transistor

int switchState1 = 0; //holds value of button1
int switchState2 = 0; //holds value of button2

int potentiometerIn; //holds the input from the potentiometer

int pin1 = 5; //output to the H-Bridge for motor
int pin2 = 6; //output to the H-Bridge for motor

void setup() {
  pinMode(motorPin, OUTPUT); //motors are an output because they respond to the buttons
  pinMode(button1, INPUT); //buttons are inputs because they initiate the motor
   pinMode(button2, INPUT);
   pinMode(pin1, OUTPUT);
 pinMode(pin2, OUTPUT);
}

void loop() {
  potentiometerIn = analogRead(A0);
  int output = potentiometerIn / 4; //enables input to connect to the AnalogWrite function
  switchState1 = digitalRead(button1); //button1 is associated with switchstate1
  switchState2 = digitalRead(button2); //button2 is associated with switchstate2

//if the buttons aren’t pressed, then the motor won’t start
if (switchState1 == LOW && switchState2 == LOW) {
    digitalWrite(motorPin, LOW);
 }

//else: the motor will spin
else {
    digitalWrite(motorPin, HIGH);
}

//if button1 is pressed, then constantly spin
  if(switchState1 == HIGH) {
     analogWrite(pin1, output);
    }

  //else: don’t spin
else {
    digitalWrite(pin1, LOW); //unpressed forward button(doesn't spin)
    }

  //if button 2 is pressed, then spin for a limited amount of time
  if(switchState2 == HIGH) {
    analogWrite(pin2, output);
    }

//else: don’t spin
  else {
    digitalWrite(pin2, LOW);
    }
 delay(25); //delay at end as loop gets called continuously without any delay
}
