/* Tested with:
- Arduino IDE version 2.3.2
- ESP32 boards package version 3.0.0
- Adafruit GFX library version 1.11.11
- Adafruit SSD1306 library version 2.5.13
- ArduinoJson library version 7.1.0
- Base64 library (default version with ESP32 boards package)
*/
#include <WiFi.h>
#include <HTTPClient.h>
#include <Base64.h>
#include "esp_camera.h"
#include <Adafruit_GFX.h>
#include <Wire.h>
#include <Adafruit_SSD1306.h>
#include <ArduinoJson.h>
// WiFi credentials
const char* ssid = "SSID";
const char* password = "PASSWORD";
// OpenAI API key
const String apiKey = "******";
#define SCREEN_WIDTH 128
#define SCREEN_HEIGHT 64
#define OLED_SCL 14
#define OLED_SDA 15
#define OLED_RESET -1
Adafruit_SSD1306 display(SCREEN_WIDTH, SCREEN_HEIGHT, &Wire, OLED_RESET);
// Pin definitions for ESP32-CAM AI-Thinker module
#define PWDN_GPIO_NUM 32
#define RESET_GPIO_NUM -1
#define XCLK_GPIO_NUM 0
#define SIOD_GPIO_NUM 26
#define SIOC_GPIO_NUM 27
#define Y9_GPIO_NUM 35
#define Y8_GPIO_NUM 34
#define Y7_GPIO_NUM 39
#define Y6_GPIO_NUM 36
#define Y5_GPIO_NUM 21
#define Y4_GPIO_NUM 19
#define Y3_GPIO_NUM 18
#define Y2_GPIO_NUM 5
#define VSYNC_GPIO_NUM 25
#define HREF_GPIO_NUM 23
#define PCLK_GPIO_NUM 22
#define BUTTON_PIN 13
#define BUZZER_PIN 2 // Buzzer connected to GPIO2
void displayCenteredText(const String& text, int textSize = 1) {
display.clearDisplay();
display.setTextSize(textSize);
display.setTextColor(SSD1306_WHITE);
int maxLineLength = 16; // Assuming 16 characters fit per line at textSize 1
String lineBuffer = "";
String wordBuffer = "";
int16_t x1, y1;
uint16_t textWidth, textHeight;
// Calculate line height
display.getTextBounds("A", 0, 0, &x1, &y1, &textWidth, &textHeight);
int lineHeight = textHeight + 2;
// Calculate the total number of lines needed
int lineCount = 0;
for (size_t i = 0; i <= text.length(); i++) {
char c = text.charAt(i);
if (c == ' ' || c == '\n' || c == '\0') {
if (lineBuffer.length() + wordBuffer.length() > maxLineLength) {
lineCount++;
lineBuffer = wordBuffer;
} else {
lineBuffer += (lineBuffer.isEmpty() ? "" : " ") + wordBuffer;
}
wordBuffer = "";
if (c == '\n') {
lineCount++;
lineBuffer = "";
}
} else {
wordBuffer += c;
}
}
if (!lineBuffer.isEmpty()) lineCount++; // Count the last line
// Calculate the vertical offset to center the block of text
int totalTextHeight = lineCount * lineHeight;
int yOffset = (SCREEN_HEIGHT - totalTextHeight) / 2;
// Render the text line by line, vertically centered
int yPos = yOffset;
lineBuffer = "";
wordBuffer = "";
for (size_t i = 0; i <= text.length(); i++) {
char c = text.charAt(i);
if (c == ' ' || c == '\n' || c == '\0') {
if (lineBuffer.length() + wordBuffer.length() > maxLineLength) {
// Render the current line
display.setCursor((SCREEN_WIDTH - lineBuffer.length() * textWidth) / 2, yPos);
display.print(lineBuffer);
yPos += lineHeight;
lineBuffer = wordBuffer;
} else {
lineBuffer += (lineBuffer.isEmpty() ? "" : " ") + wordBuffer;
}
wordBuffer = "";
if (c == '\n' || c == '\0') {
display.setCursor((SCREEN_WIDTH - lineBuffer.length() * textWidth) / 2, yPos);
display.print(lineBuffer);
yPos += lineHeight;
lineBuffer = "";
}
} else {
wordBuffer += c;
}
}
display.display();
}
// Function to encode image to Base64
String encodeImageToBase64(const uint8_t* imageData, size_t imageSize) {
return base64::encode(imageData, imageSize);
}
void setup() {
Serial.begin(115200);
WiFi.begin(ssid, password);
pinMode(BUTTON_PIN, INPUT_PULLUP);
pinMode(BUZZER_PIN, OUTPUT); // Set Buzzer pin as output
Wire.begin(OLED_SDA, OLED_SCL);
if (!display.begin(SSD1306_SWITCHCAPVCC, 0x3C)) {
Serial.println("SSD1306 allocation failed");
for (;;)
;
}
// Display the project title on power-on
displayCenteredText("AI CAMERA MINI", 1);
delay(3000); // Hold the title screen for 3 seconds
displayCenteredText("Connecting to WiFi...");
while (WiFi.status() != WL_CONNECTED) {
delay(1000);
Serial.println("Connecting to WiFi...");
}
displayCenteredText("WiFi Connected!");
delay(2000);
camera_config_t config;
config.ledc_channel = LEDC_CHANNEL_0;
config.ledc_timer = LEDC_TIMER_0;
config.pin_d0 = Y2_GPIO_NUM;
config.pin_d1 = Y3_GPIO_NUM;
config.pin_d2 = Y4_GPIO_NUM;
config.pin_d3 = Y5_GPIO_NUM;
config.pin_d4 = Y6_GPIO_NUM;
config.pin_d5 = Y7_GPIO_NUM;
config.pin_d6 = Y8_GPIO_NUM;
config.pin_d7 = Y9_GPIO_NUM;
config.pin_xclk = XCLK_GPIO_NUM;
config.pin_pclk = PCLK_GPIO_NUM;
config.pin_vsync = VSYNC_GPIO_NUM;
config.pin_href = HREF_GPIO_NUM;
config.pin_sscb_sda = SIOD_GPIO_NUM;
config.pin_sscb_scl = SIOC_GPIO_NUM;
config.pin_pwdn = PWDN_GPIO_NUM;
config.pin_reset = RESET_GPIO_NUM;
config.xclk_freq_hz = 20000000;
config.pixel_format = PIXFORMAT_JPEG;
config.frame_size = FRAMESIZE_QVGA;
config.jpeg_quality = 10;
config.fb_count = 1;
if (esp_camera_init(&config) != ESP_OK) {
Serial.println("Camera init failed");
displayCenteredText("Camera Init Failed");
return;
}
displayCenteredText("Camera Initialized");
delay(2000);
displayCenteredText("Press button to capture");
}
void captureAndAnalyzeImage() {
Serial.println("Capturing image...");
// Capture the image frame buffer
camera_fb_t* fb = esp_camera_fb_get(); // Get the frame buffer
if (!fb) {
Serial.println("Camera capture failed");
displayCenteredText("Capture Failed");
return;
}
// After the new frame is obtained, ensure the buffer is returned (cleared)
esp_camera_fb_return(fb); // Release the frame buffer from the previous capture
// Now, capture the new image
fb = esp_camera_fb_get(); // Get the frame buffer again for the new image
if (!fb) {
Serial.println("Camera capture failed");
displayCenteredText("Capture Failed");
return;
}
Serial.println("Image captured");
String base64Image = encodeImageToBase64(fb->buf, fb->len);
beep();
// Return the frame buffer after processing the image
esp_camera_fb_return(fb); // Return the frame buffer to free memory
if (base64Image.isEmpty()) {
Serial.println("Failed to encode the image!");
displayCenteredText("Encode Failed");
return;
}
// Send the image to OpenAI for analysis
AnalyzeImage(base64Image);
}
void AnalyzeImage(const String& base64Image) {
Serial.println("Sending image for analysis...");
displayCenteredText("Processing...");
String result;
// Prepare the payload for the OpenAI API
Serial.println(url);
// Construct the payload
String payload = String("{") +
"\"model\": \"gpt-4o\", " +
"\"max_tokens\": 400, " +
"\"messages\": [{\"role\": \"user\", \"content\": " +
"[{\"type\": \"text\", \"text\": \"Summarize the context of this image?\"}, " +
"{\"type\": \"image_url\", \"image_url\": {\"url\": \"" + url + "\", \"detail\": \"auto\"}}]}]}";
// Send request and validate response
if (sendPostRequest(payload, result)) {
Serial.print("[ChatGPT] Response: ");
Serial.println(result);
// Clear the display before showing the new response
display.clearDisplay();
display.display();
DynamicJsonDocument responseDoc(4096);
deserializeJson(responseDoc, result);
String responseContent = responseDoc["choices"][0]["message"]["content"].as<String>();
Serial.println("[ChatGPT] Parsed response: " + responseContent);
// Smooth scrolling and proper word wrapping
display.clearDisplay();
int lineHeight = 8; // Height of each line in pixels
int maxLineChars = 21; // Approx. max characters per line
int visibleLines = 7;
int scrollDelay = 2000; // Delay for scrolling in milliseconds
std::vector<String> lines; // Store formatted lines for display
// Split responseContent into words for word wrapping
String word = "";
String currentLine = "";
for (int i = 0; i < responseContent.length(); i++) {
char c = responseContent.charAt(i);
if (c == ' ' || c == '\n') {
if (currentLine.length() + word.length() <= maxLineChars) {
currentLine += (currentLine.isEmpty() ? "" : " ") + word;
} else {
lines.push_back(currentLine);
currentLine = word;
}
word = "";
} else {
word += c;
}
}
if (!currentLine.isEmpty()) lines.push_back(currentLine);
if (!word.isEmpty()) lines.push_back(word);
// Display lines with scrolling effect
for (size_t i = 0; i < lines.size(); i++) {
display.clearDisplay();
for (size_t j = 0; j < visibleLines && (i + j) < lines.size(); j++) {
display.setCursor(0, j * lineHeight);
display.print(lines[i + j]);
}
display.display();
delay(scrollDelay);
}
// Clear display after the response
display.clearDisplay();
display.display();
displayCenteredText("Press button to capture");
} else {
Serial.print("[ChatGPT] Error: ");
Serial.println(result);
display.clearDisplay();
display.setCursor(0, 0);
display.print("API Error");
display.display();
}
}
bool sendPostRequest(const String& payload, String& result) {
HTTPClient http;
http.begin("https://api.openai.com/v1/chat/completions");
http.addHeader("Content-Type", "application/json");
http.addHeader("Authorization", "Bearer " + apiKey);
http.setTimeout(20000);
Serial.print("Payload size: ");
Serial.println(payload.length());
int httpResponseCode = http.POST(payload);
if (httpResponseCode > 0) {
result = http.getString();
Serial.println("HTTP Response Code: " + String(httpResponseCode));
Serial.println("Response Body: " + result);
http.end();
return true;
} else {
result = "HTTP request failed, response code: " + String(httpResponseCode);
Serial.println("Error Code: " + String(httpResponseCode));
Serial.println("Error Message: " + http.errorToString(httpResponseCode));
http.end();
return false;
}
}
void loop() {
if (digitalRead(BUTTON_PIN) == LOW) {
Serial.println("Button pressed! Capturing image...");
displayCenteredText("Capturing...");
captureAndAnalyzeImage();
delay(1000); // Small delay to debounce button press
}
}
void beep(){
digitalWrite(2,HIGH);
delay(300);
digitalWrite(2,LOW);
}
