Published August 6, 2020

Car led indicator and horn by using boltiot Module

It is the simple project, in this the HTML code are written in bolt iot so that the indicator and horn can easily connected by button.

IntermediateFull instructions provided30 minutes240

Car led indicator and horn by using boltiot Module

Things used in this project

Hardware components

LED (generic)

Resistor 330 ohm

Buzzer

Bolt IoT Bolt WiFi Module

Jumper wires (generic)

USB-A to Micro-USB Cable

Software apps and online services

Bolt IoT Bolt Cloud

Bolt IoT Android App

Story

It is the prototype of the car which is control over the internet.

This project will be using Bolt IOT module to control the indicator and horn of a electronic car over the internet.

In this project we use the HTML code to Control the indicator and the horn

step1:-

LED Number 1

Positive Terminal - GPIO 0 Of Bolt Module Through 330 Ohm Resistor

Negative Terminal - Ground Of Bolt Module

step2:-

LED Number 2

Positive Terminal - GPIO 1 Of Bolt Module Through 330 Ohm Resistor

Negative Terminal - Ground Of Bolt Module

step3:-

Buzzer

Positive Terminal - GPIO 2 Of Bolt Module

Negative Terminal - Ground Of Bolt Module

output-

Code

control car indicator and horn

<!DOCTYPE html>
<html>
    <head>
        <title>Bolt IoT Platform</title>
        <script type="text/javascript" src="https://cloud.boltiot.com/static/js/boltCommands.js"></script>
        <script>
        setKey('{{ApiKey}}','{{Name}}');
        </script>
    </head>
    <body bgcolor="Yellow">
        <center>
        <h1> Left Indicator </h1>
        <button onclick="digitalWrite(0, 'HIGH');">ON</button>
        <button onclick="digitalWrite(0, 'LOW');">OFF</button>
        <h1> Right Indicator </h1>
        <button onclick="digitalWrite(1, 'HIGH');">ON</button>
        <button onclick="digitalWrite(1, 'LOW');">OFF</button>
        <h1> HORN </h1>
        <button onclick="digitalWrite(2, 'HIGH');">ON</button>
        <button onclick="digitalWrite(2, 'LOW');">OFF</button>
        </center>
    </body>
</html>

Credits

Deepak Batham

1 project • 0 followers
