Leduindo - Smart Led Bike Lightning

Get yourself noticed on the night rides using a light sensor and some shinny leds.

EasyFull instructions provided2 hours4,434
Leduindo - Smart Led Bike Lightning

Things used in this project

Hardware components

5 mm LED: Red
5 mm LED: Red
×5
Arduino Nano R3
Arduino Nano R3
×1
Resistor 10k ohm
Resistor 10k ohm
×1
Photocell
×1

Software apps and online services

Arduino IDE
Arduino IDE

Story

Read more

Schematics

Schematics - fzz file

Schematics - pic

Bike ledd

Code

DasBike - Woop woop

C/C++
Arduino ino file
int photocellPin = 0;     // the cell and 10K pulldown are connected to a0
int photocellReading;     // the analog reading from the sensor divider
int LEDbrightness;        //
int CellIntensVal;
int LEDred1 = 12;
int LEDred2 = 11;
int LEDblue1 = 10;
int LEDblue2 = 9;
int LEDgreen1 = 8;
int LEDgreen2 = 7;

void setup() {
// initialize the digital pin as an output.
Serial.begin(9600);
// Pin 12 has an LED connected on most Arduino boards:
pinMode(12, OUTPUT);
pinMode(11, OUTPUT);
pinMode(10, OUTPUT);
pinMode(9, OUTPUT);
pinMode(8, OUTPUT);
pinMode(7, OUTPUT);
}

void loop() {

photocellReading = analogRead(photocellPin);
CellIntensVal  = photocellReading;
Serial.print("Analog reading = ");
Serial.println(photocellReading);     // the raw analog reading
// LED gets brighter the darker it is at the sensor
// that means we have to -invert- the reading from 0-1023 back to 1023-0
photocellReading = 1023 - photocellReading;

//now we have to map 0-1023 to 0-255 since thats the range analogWrite uses
LEDbrightness = map(photocellReading, 0, 1023, 0, 255);

if (CellIntensVal > 760) { cmdWoopWoop();  }
if (CellIntensVal < 761 && CellIntensVal > 100 ) {  cmdOffLights();}
  else if (CellIntensVal < 101) {
    cmdDarkLights();
    }
 delay(200);
}

void cmdDarkLights() {
    digitalWrite(12, HIGH);
    digitalWrite(11, HIGH);
    digitalWrite(10, LOW);
    digitalWrite(9, LOW);
    digitalWrite(8, HIGH);
    digitalWrite(7, HIGH);
  delay(1000);
    digitalWrite(12, LOW);
    digitalWrite(11, LOW);
    digitalWrite(10, HIGH);
    digitalWrite(9, HIGH);
    digitalWrite(8, LOW);
    digitalWrite(7, LOW);
 delay(20);
    digitalWrite(12, LOW);
    digitalWrite(11, LOW);
    digitalWrite(10, LOW);
    digitalWrite(9, LOW);
    digitalWrite(8, LOW);
    digitalWrite(7, LOW);
 delay(20);
}


void cmdOffLights() {
     digitalWrite(12, LOW);
    digitalWrite(11, LOW);
    digitalWrite(10, LOW);
    digitalWrite(9, LOW);
    digitalWrite(8, LOW);
    digitalWrite(7, LOW);
}

void cmdWoopWoop() {
   digitalWrite(12, HIGH);
    digitalWrite(11, LOW);
    digitalWrite(10, LOW);
    digitalWrite(9, LOW);
    digitalWrite(8, LOW);
    digitalWrite(7, HIGH);
  delay(170); //You can make the lights change speed by changing this value.
    digitalWrite(12, LOW);
    digitalWrite(11, HIGH);
    digitalWrite(10, LOW);
    digitalWrite(9, LOW);
    digitalWrite(8, HIGH);
    digitalWrite(7, LOW);
  delay(150); //You can make the lights change speed by changing this value.
    digitalWrite(12, LOW);
    digitalWrite(11, LOW);
    digitalWrite(10, HIGH);
    digitalWrite(9, HIGH);
    digitalWrite(8, LOW);
    digitalWrite(7, LOW);
   delay(70); //You can make the lights change speed by changing this value.
    digitalWrite(12, LOW);
    digitalWrite(11, LOW);
    digitalWrite(10, LOW);
    digitalWrite(9, LOW);
    digitalWrite(8, LOW);
    digitalWrite(7, LOW);
  delay(30); //You can make the lights change speed by changing this value.
    digitalWrite(12, LOW);
    digitalWrite(11, LOW);
    digitalWrite(10, HIGH);
    digitalWrite(9, HIGH);
    digitalWrite(8, LOW);
    digitalWrite(7, LOW);
  delay(30); //You can make the lights change speed by changing this value.
    digitalWrite(12, LOW);
    digitalWrite(11, LOW);
    digitalWrite(10, LOW);
    digitalWrite(9, LOW);
    digitalWrite(8, LOW);
    digitalWrite(7, LOW);
  delay(30); //You can make the lights change speed by changing this value.
    digitalWrite(12, LOW);
    digitalWrite(11, LOW);
    digitalWrite(10, HIGH);
    digitalWrite(9, HIGH);
    digitalWrite(8, LOW);
    digitalWrite(7, LOW);
  delay(70); //You can make the lights change speed by changing this value.
    digitalWrite(12, LOW);
    digitalWrite(11, HIGH);
    digitalWrite(10, LOW);
    digitalWrite(9, LOW);
    digitalWrite(8, HIGH);
    digitalWrite(7, LOW);
  delay(70); //You can make the lights change speed by changing this value.
    digitalWrite(12, HIGH);
    digitalWrite(11, LOW);
    digitalWrite(10, LOW);
    digitalWrite(9, LOW);
    digitalWrite(8, LOW);
    digitalWrite(7, HIGH);
 delay(20);
    digitalWrite(12, LOW);
    digitalWrite(11, LOW);
    digitalWrite(10, HIGH);
    digitalWrite(9, HIGH);
    digitalWrite(8, LOW);
    digitalWrite(7, LOW);
 delay(20);
    digitalWrite(12, LOW);
    digitalWrite(11, LOW);
    digitalWrite(10, LOW);
    digitalWrite(9, LOW);
    digitalWrite(8, LOW);
    digitalWrite(7, LOW);
 delay(20);
   digitalWrite(12, LOW);
    digitalWrite(11, LOW);
    digitalWrite(10, HIGH);
    digitalWrite(9, HIGH);
    digitalWrite(8, LOW);
    digitalWrite(7, LOW);
 delay(20);
    digitalWrite(12, LOW);
    digitalWrite(11, LOW);
    digitalWrite(10, LOW);
    digitalWrite(9, LOW);
    digitalWrite(8, LOW);
    digitalWrite(7, LOW);
 delay(20);
    digitalWrite(12, LOW);
    digitalWrite(11, LOW);
    digitalWrite(10, HIGH);
    digitalWrite(9, HIGH);
    digitalWrite(8, LOW);
    digitalWrite(7, LOW);
 delay(20);
    digitalWrite(12, LOW);
    digitalWrite(11, LOW);
    digitalWrite(10, LOW);
    digitalWrite(9, LOW);
    digitalWrite(8, LOW);
    digitalWrite(7, LOW);
   delay(50);
  }
