Arduino Sound Detection Sensor Project

Sound Detecting Security System using Arduino uno and Sound Detector sensor

IntermediateProtip5,080
Arduino Sound Detection Sensor Project

Things used in this project

Hardware components

Arduino UNO
Arduino UNO
×1
SparkFun Sound Detector (with Headers)
SparkFun Sound Detector (with Headers)
×1
Solderless Breadboard Half Size
Solderless Breadboard Half Size
×1
LED (generic)
LED (generic)
×1
Buzzer
Buzzer
×1
Jumper wires (generic)
Jumper wires (generic)
×1

Hand tools and fabrication machines

Tape, Double Sided
Tape, Double Sided

Story

Read more

Schematics

diagram

Code

sound detecting security system

Arduino
int soundSensor=2;
int LED=4;
boolean LEDStatus=false;

void setup() {
 pinMode(soundSensor,INPUT);
 pinMode(LED,OUTPUT);

}

void loop() {

  int SensorData=digitalRead(soundSensor);
  if(SensorData==1){

    if(LEDStatus==false){
        LEDStatus=true;
        digitalWrite(LED,HIGH);
    }
    else{
        LEDStatus=false;
        digitalWrite(LED,LOW);
    }
  }
 }
