ChillFlix

Sure you can LOGIN and SEARCH for shows and movies on NETFLIX. How would it be to ask your assistant and get the answers .

IntermediateFull instructions provided8 hours1,713

Things used in this project

Hardware components

Echo Dot
Amazon Alexa Echo Dot
×1
Amazon Echo
Amazon Alexa Amazon Echo
×1
Amazon Tap
Amazon Alexa Amazon Tap
×1

Software apps and online services

AWS Lambda
Amazon Web Services AWS Lambda
AWS S3
Amazon Web Services AWS S3
We are using s3 only during the deployment phase to upload our zipfile created by zappa which is used by our lambda function.
AWS RDS
Amazon Web Services AWS RDS
Alexa Skills Kit
Amazon Alexa Alexa Skills Kit
TheMovieDB

Story

Read more

Schematics

High Level Infrastructure Diagram

Leveraging AWS Lambda and RDS

Interaction Model

The green boxes are for user Utterances and the Blue ones are Alexa's reply

Code

Python Class using Flask-Ask

Python
This is the python application which uses flask_ask and flask python modules to run the application.
The database that is being used in mySQL and mongodb. - Sorry about the credentials. There can be a miss use.
__author__ = 'krishnateja'

import logging
from flaskext.mysql import MySQL
from flask import Flask
from flask_ask import Ask, statement, question, session
from pymongo import MongoClient

mysql = MySQL()

app = Flask(__name__)
app.config.from_object(__name__)
app.config['MYSQL_DATABASE_USER'] = ''
app.config['MYSQL_DATABASE_PASSWORD'] = ''
app.config['MYSQL_DATABASE_DB'] = ''
app.config['MYSQL_DATABASE_HOST'] = ''
mysql.init_app(app)

ask = Ask(app, "/")

logging.getLogger("flask_ask").setLevel(logging.DEBUG)

list_of_words = ['a', 'the']
hellp_message = ''


def search_mongo(column):
    cursor_mongo = column.find({"id": int(session.attributes['moviedb'])})
    data_len = cursor_mongo.count()
    if data_len > 0:
        for document in cursor_mongo:
            return document
    else:
        return None


def search_movie(movie_name):
    print(movie_name)
    found = False
    if movie_name.split(' ', 1)[0] in list_of_words:
        movie_name = movie_name.split(' ', 1)[1]
    else:
        pass
    cursor = mysql.connect().cursor()
    query = "SELECT themoviedb,title FROM netflix_movies.movies WHERE title LIKE '%" + movie_name + "%';"
    cursor.execute(query)
    data = cursor.fetchone()
    if len(data) == 0:
        message = 'Nope, Have not found the movie' + movie_name + 'in netflix.'
    else:
        message = 'Yes, I found ' + movie_name
        session.attributes['moviedb'] = data[0]
        found = True

    return message, found


def search_show(show_name):
    found = False
    if show_name.split(' ', 1)[0] in list_of_words:
        show_name = show_name.split(' ', 1)[1]
    else:
        pass
    cursor = mysql.connect().cursor()
    query = "SELECT themoviedb, title FROM netflix_movies.shows WHERE title LIKE '%" + show_name + "%';"

    cursor.execute(query)
    data = cursor.fetchone()
    if len(data) == 0:
        message = 'Nope, Have not found the show' + show_name + 'in netflix.'
    else:
        message = 'Yes, I found ' + show_name
        found = True
        session.attributes['moviedb'] = data[0]
    return message, found


def search_show_updates():
    print('This API has to be completed.')


def search_movie_updates():
    print('This API has to be completed.')


@ask.launch
def new_search():
    welcome_msg = 'What do you want to search for in Netflix?... shows or movies?'
    return question(welcome_msg)


@ask.intent("WelcomeIntent")
def search_for(search_for):
    session.attributes['search_attr'] = str(search_for)
    message = 'Sure, I can help you with that...'
    if str(search_for) == 'show' or str(search_for) == 'movie':
        message = message + 'What is the ' + str(search_for) + ' you want to search for.'
        return question(message)
    elif str(search_for) == 'shows' or str(search_for) == 'movies':
        message = message + 'What are the ' + str(search_for) + ' you want to search for.'
        return question(message)
    else:
        message = 'Sorry. You can say something like search for shows or movies.'
        return question(message)


@ask.intent("SearchIntent")
def search(search_name):
    message = 'Sorry, I think I miss heard you there. You can say things like Does netflix Have Narcos.'
    found = False

    if search_name == "" or search_name is None:
        return question(message)
    else:
        session.attributes['search_term'] = str(search_name)
        message, found = search_show(search_name)
    if found:
        session.attributes['search_attr'] = 'show'
        return question(message + '...Do you want more info about the show?')
    else:
        message, found = search_movie(search_name)
        if found:
            session.attributes['search_attr'] = 'movie'
            return question(message + '...Do you want more info about the movie?')
        else:
            return statement(message)


@ask.intent("MoreInfoIntent")
def search(more_info_search, search_name):
    search_name = search_name
    message_ending = "   Do you want to know anything else?"
    mongo_db_uri = ""
    client = MongoClient(uri)
    if search_name is not None:
        session.attributes['search_term'] = str(search_name)
        message, found = search_show(search_name)
        if found:
            session.attributes['search_attr'] = 'show'
            shows_coll = client.netflix_mongodb.netflix_shows
            search_data = search_mongo(shows_coll)
            if search_data is not None:
                if more_info_search == 'genre':
                    genres = search_data['genres']
                    message = ' It belongs to '
                    for genre in genres:
                        message += genre['name'] + "..."
                    message += message_ending
                    return question(message)
                elif more_info_search == 'overview':
                    overview = search_data['overview']
                    message = overview + message_ending
                    return question(message)
                else:
                    return statement('Sorry I could not quite understand what ' +more_info_search+' is. I can give you an overview or get you you the genre')
            else:
                return statement('Sorry I could not find any info about the show')
        else:
            message, found = search_movie(search_name)
            if found:
                session.attributes['search_attr'] = 'movie'
                return question(message + '. Do you want more info about the movie?')
            else:
                return statement(message)
    else:
        try:
            search_name = session.attributes['search_term']
        except:
            return question(
                'You can say things like what is the genre of Narcos or something like give me an overview of Shameless')
        session.attributes['search_term'] = str(search_name)
        message, found = search_show(search_name)
        if found:
            session.attributes['search_attr'] = 'show'
            shows_coll = client.netflix_mongodb.netflix_shows
            search_data = search_mongo(shows_coll)
            if search_data is not None:
                if more_info_search == 'genre':
                    genres = search_data['genres']
                    message = 'It belongs to '
                    for genre in genres:
                        message += genre['name'] + ". "
                    message += message_ending
                    return question(message)
                elif more_info_search == 'overview':
                    overview = search_data['overview']
                    message = overview + message_ending
                    return question(message)
                else:
                    return question('Sorry I could not find that info about the show but, I can give you an overview or the genre. You can say things like give me an overview or what is the genre?')
            else:
                return statement('Sorry I could not find any info about the show.')
        else:
            message, found = search_movie(search_name)
            if found:
                session.attributes['search_attr'] = 'movie'
                return question(message + ' Do you want more info about the movie?')
            else:
                return statement(message)


@ask.intent("AMAZON.HelpIntent")
def help_intent():
    message = 'You can say things like I want to search for shows... Does netflix have Narcos'
    return question(message)


@ask.intent("AMAZON.NoIntent")
def help_intent():
    message = 'Ok, Happy watching!!!'
    return statement(message)


@ask.intent("AMAZON.StopIntent")
def stop():
    message = 'Ok, Bye'
    return statement(message)


@ask.intent("AMAZON.CancelIntent")
def stop():
    message = 'Ok, Ciao'
    return statement(message)


if __name__ == '__main__':
    app.run()

IntentSchema

Textile
This is the intent schema used.
{
  "intents": [
    {
      "intent": "WelcomeIntent",
      "slots": [
        {
          "name": "search_for",
          "type": "SEARCH_FOR"
        }
      ]
    },
    {
      "intent": "SearchIntent",
      "slots": [
        {
          "name": "search_name",
          "type": "SEARCH_NAME"
        }
      ]
    },
    {
      "intent": "MoreInfoIntent",
      "slots": [
        {
          "name": "more_info_search",
          "type": "MORE_INFO"
        },
        {
          "name": "search_name",
          "type": "SEARCH_NAME"
        }
      ]
    },
    {
    	"intent": "AMAZON.HelpIntent"
    },
    {
      	"intent": "AMAZON.NoIntent"
    },
    {
      	"intent": "AMAZON.StopIntent"
    },
    {
      	"intent": "AMAZON.CancelIntent"
    }
  ]
}

Sample Utterances

Textile
These are the sample utterances to which the application responds to
WelcomeIntent search for {search_for}
SearchIntent does Netflix have {search_name}
SearchIntent can I find {search_name} in Netflix
MoreInfoIntent I want to know the {more_info_search}
MoreInfoIntent what is the {more_info_search}
MoreInfoIntent what is the {more_info_search} of {search_name}
MoreInfoIntent give me an {more_info_search} of {search_name}
MoreInfoIntent give me an {more_info_search}

Custom Slot for SEARCH_NAME

Textile
One of the custom slots for the application. This is just a sample fine and was created by using themoviesdb. We have the complete list for the app. I can definitely provide it to you on request.
Orange Is the New Black
Shameless
The Walking Dead
Marco Polo
Penny Dreadful
The Shannara Chronicles
Gilmore Girls
Supernatural
Breaking Bad
Pretty Little Liars
Greys Anatomy
Peaky Blinders
The Flash 2014
American Horror Story
Criminal Minds
Arrow
Sherlock
House of Cards
The Last Kingdom
Friends
Dark Matter
Bones
The One Hundred
Bloodline
The Vampire Diaries
Once Upon a Time
Sons of Anarchy
Marvels Daredevil
NCIS
Scream
Person of Interest
The Office
Dexter
How I Met Your Mother
Prison Break
Hell on Wheels
Law  Order Special Victims Unit
Narcos
Containment
Marvels Agents of SHIELD
Lost
House
Limitless
The Blacklist
Gotham
Gossip Girl
Crazy ExGirlfriend
Parks and Recreation
Zoo
New Girl
The Fosters
The XFiles
Jane the Virgin
Girl Meets World
That 70s Show
One Tree Hill
Wentworth
Better Call Saul
Archer
Pokémon
Its Always Sunny in Philadelphia
Star Trek The Next Generation
Mad Men
Spartacus
The Originals
Family Guy
Bates Motel
Blue Bloods
Hawaii Five0
How to Get Away With Murder
Midsomer Murders
Reign
Supergirl
Scandal
Glee
DCs Legends of Tomorrow
Quantico
Luther
Buffy the Vampire Slayer
Arrested Development
White Collar
iZombie
Friday Night Lights
Black Mirror
Star Trek Voyager
Freaks and Geeks
Baby Daddy
Beauty and the Beast CW
Sense8
Unbreakable Kimmy Schmidt
Aquarius
The West Wing
Scrubs
Bobs Burgers
Charmed
Grace and Frankie
The Killing
The Secret Life of the American Teenager
Skins UK
The Fall
Parenthood
The Tudors
Star Trek Deep Space Nine
Turn
Malcolm in the Middle
Californication
Firefly
American Dad
Twin Peaks
Royal Pains
The League
Hart of Dixie
90210
Young  Hungry
Weeds
BoJack Horseman
Frasier
Star Trek The Original Series
Columbo
Longmire
Last Man Standing
Liv and Maddie
Switched at Birth
Fuller House
Broadchurch
Madam Secretary
Revenge
Death in Paradise
Murder She Wrote
Thirty Rock
Happy Valley
Nurse Jackie
Salem
The Andy Griffith Show
Star Trek Enterprise
The Twilight Zone
Cheers
Agatha Christies Poirot
Hemlock Grove
Heartland
Voltron Legendary Defender

Custom Slot for SEARCH_FOR

Python
This is a custom slot file for SEARCH_FOR
shows
show
movie
movies

Custom slot for MORE_INFO

Python
This is a custom slot file for MORE_INFO
overview
genre
an overview

Credits

KRISHNA TEJA TOKALA

KRISHNA TEJA TOKALA

1 project • 2 followers
Satish Divakarla

Satish Divakarla

1 project • 0 followers

Comments
