YL-38 Moisture Meter (YL-69 Sensor)

Read the soil moisture level (Dry-Perfect-Wet) and display results on a corresponding LED.

BeginnerProtip19,185
YL-38 Moisture Meter (YL-69 Sensor)

Things used in this project

Hardware components

Arduino UNO
Arduino UNO
×1
5 mm LED: Red
5 mm LED: Red
×1
5 mm LED: Yellow
5 mm LED: Yellow
×1
5 mm LED: Green
5 mm LED: Green
×1
Resistor 100 ohm
Resistor 100 ohm
×3
YL-38 Controller and Sensor YL-69
×1

Software apps and online services

Arduino IDE
Arduino IDE

Hand tools and fabrication machines

Soldering iron (generic)
Soldering iron (generic)
Solder Flux, Soldering
Solder Flux, Soldering
Solder Wire, Lead Free
Solder Wire, Lead Free

Story

Read more

Schematics

Soil_Humidity_Tester

Code

Soil_Humidity_Tester.ino

Arduino
//V1.0 Soil_Humidity_Tester  Enjoy!
void setup() {
  // initialize serial communication at 9600 bits per second:

  Serial.begin(9600);
  pinMode(2, OUTPUT);
  pinMode(3, OUTPUT);
  pinMode(4, OUTPUT);

}

// the loop routine runs over and over again forever:
void loop() {
  // Set LED colour to their Digital Ouputs.  Read the input on analog pin 0:
  int yellow = 2;
  int blue = 3;
  int red = 4;
  int sensorValue = analogRead(A1);

  // Set the initial state of the LEDs to OFF
  digitalWrite(2, LOW);
  digitalWrite(3, LOW);
  digitalWrite(4, LOW);

  // Logic Loop that sets the required LED to ON
  if (sensorValue >= 1000) (digitalWrite(yellow, HIGH));
  else if ((sensorValue <= 999) && (sensorValue >=901)) (digitalWrite(blue, HIGH));
  else if (sensorValue <= 900) (digitalWrite(red, HIGH));
  else ;

  // Prints the condition of soil.  Dry, Wet or Perfect
  if (sensorValue >= 1000) (Serial.print("SOIL IS TOO DRY!!!!!    "));
  else if ((sensorValue <= 999) && (sensorValue >=901)) (Serial.print("SOIL IS PERFECT!!!!!    "));
  else if (sensorValue <= 900) (Serial.print("SOIL IS TOO WET!!!!!    "));
  else;

  // print out the value you read:
  Serial.print("Marijuana Soil Humidity is: ");
  Serial.println(sensorValue);
  delay(500);        // delay in between reads for stability



}
