Rollsee

#include <Wire.h>
#include <Adafruit_Sensor.h>
#include <Adafruit_ADXL345_U.h>
#include <FastLED.h>

// ---------- LEDs ----------
#define NUM_LEDS 8
#define LED_PIN 5
CRGB leds[NUM_LEDS];

// ---------- Accelerometer ----------
Adafruit_ADXL345_Unified accel = Adafruit_ADXL345_Unified(12345);

// ---------- Ultrasonic ----------
#define TRIG_PIN 8
#define ECHO_PIN 7
long lastValidDistance = -1;

// ---------- IO ----------
#define BUZZER 9
#define BUTTON 10   // keep wiring consistent with your hardware (INPUT used)

// ---------- Modes ----------
enum Mode { ORIENTATION_MODE, DISTANCE_MODE };
Mode currentMode = ORIENTATION_MODE;

// ---------- Button / hold progress ----------
bool pressActive = false;
unsigned long buttonPressStart = 0;
int lastSecondShown = 0;
bool modeToggledThisPress = false;

// ---------- Alarm (non-blocking) ----------
bool alarmActive = false;
unsigned long alarmLastToggle = 0;
bool alarmState = false;
const unsigned long ALARM_INTERVAL = 200; // ms

// ---------- Misc timing ----------
unsigned long lastDistanceUpdate = 0;

void setup() {
  Serial.begin(9600);

  pinMode(BUZZER, OUTPUT);
  pinMode(BUTTON, INPUT);    // keep as INPUT to match your wiring (if you use pull-up change to INPUT_PULLUP and invert logic)
  pinMode(TRIG_PIN, OUTPUT);
  pinMode(ECHO_PIN, INPUT);

  FastLED.addLeds<NEOPIXEL, LED_PIN>(leds, NUM_LEDS);
  FastLED.clear();
  FastLED.show();

  if (!accel.begin()) {
    Serial.println("ADXL345 not detected");
    while (1);
  }
  accel.setRange(ADXL345_RANGE_16_G);

  Serial.println("System Ready");
}

// main loop — button handler runs first so progress always updates promptly
void loop() {
  handleButtonProgress();

  // If the button is actively being held, the progress LEDs take precedence.
  // We skip normal mode behavior while showing the progress.
  if (pressActive) return;

  if (currentMode == ORIENTATION_MODE) {
    orientationMode();
  } else {
    distanceMode();
  }
}

// ---------------- Button + progress logic ----------------
void handleButtonProgress() {
  bool pressed = digitalRead(BUTTON);

  if (pressed && !pressActive) {
    // start a new hold
    pressActive = true;
    buttonPressStart = millis();
    lastSecondShown = 0;
    modeToggledThisPress = false;
    // immediately show 0-> no leds until first second passes
    FastLED.clear();
    FastLED.show();
    return;
  }

  if (!pressed && pressActive) {
    // button released — clear progress display and reset
    pressActive = false;
    lastSecondShown = 0;
    modeToggledThisPress = false;
    FastLED.clear();
    FastLED.show();
    Serial.print("Button held for (ms): ");
    Serial.println(millis() - buttonPressStart);
    return;
  }

  if (pressed && pressActive) {
    unsigned long elapsed = (millis() - buttonPressStart) / 1000; // whole seconds
    if (elapsed > lastSecondShown && elapsed <= NUM_LEDS) {
      // show progress for each newly reached second
      lastSecondShown = elapsed;
      showProgressLeds(elapsed);
      Serial.print("Hold seconds: ");
      Serial.println(elapsed);
    }

    // If we reached 8 seconds (NUM_LEDS) toggle mode once
    if (elapsed >= NUM_LEDS && !modeToggledThisPress) {
      // give a tiny audible confirmation
      tone(BUZZER, 1200);
      delay(120);
      noTone(BUZZER);

      toggleMode();
      modeToggledThisPress = true;
    }
  }
}

void showProgressLeds(int seconds) {
  // Lights LEDs 0..seconds-1 green
  FastLED.clear();
  for (int i = 0; i < seconds && i < NUM_LEDS; i++) {
    leds[i] = CRGB::Green;
  }
  FastLED.show();
}

// ---------------- Mode switching ----------------
void toggleMode() {
  // clear outputs and switch
  noTone(BUZZER);
  FastLED.clear();
  FastLED.show();

  currentMode = (currentMode == ORIENTATION_MODE) ? DISTANCE_MODE : ORIENTATION_MODE;
  Serial.print("Switched mode to: ");
  Serial.println(currentMode == ORIENTATION_MODE ? "ORIENTATION" : "DISTANCE");
  // small debounce pause so the button release doesn't immediately retrigger things
  delay(200);
}

// ---------------- Orientation mode (non-blocking alarm) ----------------
void orientationMode() {
  sensors_event_t event;
  accel.getEvent(&event);
  float X = event.acceleration.x;
  float Y = event.acceleration.y;

  // tilt thresholds (same as your original)
  if (abs(X) > 9 || abs(Y) > 8) {
    alarmActive = true;
  } else {
    alarmActive = false;
    // ensure outputs are off when not alarming
    noTone(BUZZER);
    FastLED.clear();
    FastLED.show();
  }

  // Non-blocking blink/tone while alarmActive
  if (alarmActive) {
    unsigned long now = millis();
    if (now - alarmLastToggle >= ALARM_INTERVAL) {
      alarmLastToggle = now;
      alarmState = !alarmState;
      if (alarmState) {
        tone(BUZZER, 900);
        fill_solid(leds, NUM_LEDS, CRGB::Red);
        FastLED.show();
      } else {
        noTone(BUZZER);
        FastLED.clear();
        FastLED.show();
      }
    }
  }
}

// ---------------- Distance mode ----------------
void distanceMode() {
  // Rate-limit distance updates
  if (millis() - lastDistanceUpdate < 60) return;
  lastDistanceUpdate = millis();

  long distance = readDistanceCM();

  // Ignore invalid readings
  if (distance < 0 || distance > 80) return;

  // Hysteresis to avoid jitter
  if (lastValidDistance != -1 && abs(distance - lastValidDistance) < 2) return;
  lastValidDistance = distance;

  // ---- 1 LED per 10 cm ----
  int ledsOn = distance / 10;
  ledsOn = constrain(ledsOn, 0, NUM_LEDS);

  FastLED.clear();
  for (int i = 0; i < ledsOn; i++) {
    leds[i] = CRGB::Red;
  }
  FastLED.show();

  Serial.print("Distance: ");
  Serial.print(distance);
  Serial.print(" cm | LEDs: ");
  Serial.println(ledsOn);
}

// ---------------- Ultrasonic helper ----------------
long readDistanceCM() {
  digitalWrite(TRIG_PIN, LOW);
  delayMicroseconds(5);
  digitalWrite(TRIG_PIN, HIGH);
  delayMicroseconds(10);
  digitalWrite(TRIG_PIN, LOW);

  long duration = pulseIn(ECHO_PIN, HIGH, 30000); // 30 ms timeout
  if (duration == 0) return -1;  // NO ECHO

  return duration * 0.034 / 2;
}
