Smart Study Desk

Story behind the project

Nowadays, many students live in dormitories and apartments with insufficient space. In this case, a suitable study desk can bring people a more comfortable learning experience. Therefore, people pay more and more attention to functionality and practicality in the choice of study desks. So our smart study desk came into being.

Project Introduction-Functions, How to use

1. Three mode settings:

Mode 1: Turn the knob ① to the OFF position, at this time the LED light is turned off and does not emit light.

Mode 2: Find the best point by manual adjustment, when the knob ① is turned to the ON position, the LED light turns on. Directly control the light intensity through the manual adjustment knob ②.

Mode 3: Directly set the best point, and the brightness of the LED light is maintained dynamically. When the knob ① is adjusted to "smart mode", the photoreceptor will sense the light intensity of the target area and dynamically adjust the lighting effect. The final light value is regulated by the knob ②.

2. Lighting direction control:

Control the lighting direction by turning the joystick

Process and steps

1. Group brainstorming

2. Select the sensor

3. Write code and debug

4. Design 3D appearance structure renderings

5. Use a laser cutting machine to cut appearance structural parts

6. Test

7. Assembly project hardware, assembly appearance
