SMDJ64CA Overview: A Reliable 3kW Bidirectional TVS Diode

SMDJ64CA is a popular surface-mount Transient Voltage Suppressor (TVS) diode from Littelfuse's SMDJ series. It's designed to protect sensitive electronics from voltage spikes caused by lightning, inductive load switching, ESD, or other transient events.

Key Specifications (from Littelfuse official data):

• Reverse Standoff Voltage (VRWM): 64 V (Maximum continuous working voltage before it starts to conduct)
• Breakdown Voltage (VBR): Min 71.1 V – Max 78.6 V (@ 1 mA test current)
• Clamping Voltage (VC): 103 V (@ peak pulse current)
• Peak Pulse Power Dissipation: 3000 W (3 kW) for 10/1000 µs waveform
• Peak Pulse Current (IPP): 29.1 A (10/1000 µs)
• Polarity: Bidirectional (CA suffix = bidirectional protection)
• Package: DO-214AB (SMC / SMCJ package) – compact surface-mount, suitable for high-density PCBs
• Leakage Current (IR @ VR): Typical 2 µA (very low, good for low-power circuits)
• Operating Temperature: -65°C to +150°C (junction)
• Typical Failure Mode: Short circuit (safe for downstream components)

Common Applications:

• Power supply input/output lines
• Telecom, industrial control, automotive electronics
• USB ports, RS-485/RS-232 lines, Ethernet interfaces
• Any circuit where 64 V working voltage needs surge protection (positive and negative transients)

This model is bidirectional, so it's ideal for AC-coupled signals or lines where surges can appear in either polarity. Response time is extremely fast (picoseconds), clamping the voltage to a safe level before damaging ICs.

Alternatives / Equivalents:

• Bourns SMLJ64CA (very similar specs)
• Higher power versions in same family: 5.0SMDJ64CA (5 kW), 8.0SMDJ64CA (8 kW) if you need more surge handling
• Other brands often have drop-in compatible parts with matching 64 V standoff and ~103 V clamp

Datasheet is freely available on Littelfuse.com (search SMDJ series) – includes full curves for surge waveforms, derating, etc.

In PCB layout, place it close to the protected line/entry point, with short traces and good ground plane for best performance. Often paired with capacitors for filtering.
