Things used in this project

Hardware components:
A000053 iso both1
Arduino Micro & Genuino Micro
×1
12002 04
Breadboard (generic)
×1
11026 02
Jumper wires (generic)
×1
Mfr 25frf52 100k sml
Resistor 100k ohm
You'll need as many resistors as you want to have countries. These are for the capacitive sensors.
×8
Rotary Encoder Module
×1
Capacitor 0.1 µF
This is to debounce the rotary encoder module. You don't need it if your rotary encoder works fine.
×2
Wolrd Globe
×1
Metal Pins
You'll need as many pins as you want countries. These are for capacitive sensing, so make sure they are conductive.
×8
Software apps and online services:
Ide web
Arduino IDE

Schematics

Fritzing File
You can open it with the Fritzing software
globe-trotter_hJQwkbcnEe.fz
Breadboard view
This is a breadboard view of the hardware.
Note that the "capacitive sensing" part needs to be duplicated as many times as you have countries. Here I've only put 2, but normally in my case there should be 8.
Globe trotter bb bh4ey6niqx
Schematic view
This is a schematic view of Globe Trotter
This is a breadboard view of the hardware.
Note that the "capacitive sensing" part needs to be duplicated as many times as you have countries. Here I've only put 2, but normally in my case there should be 8.
Globe trotter schema 4jemw8zexa
