How to create AT cmd for Dev Name on DA1453x BLE devices!

char new_device_name[GAP_MAX_NAME_SIZE] __SECTION_ZERO("retention_mem_area0"); //@RETENTION MEMORY;//= "\0";
bool flag_devname  __SECTION_ZERO("retention_mem_area0"); //@RETENTION MEMORY;
bool changed_name  __SECTION_ZERO("retention_mem_area0"); //@RETENTION MEMORY;

/// at commands jumptable.
const struct at_command_characteristics_t at_commands_chars[] = {
    AT_CMD_ENTRY( AT              ,  0,  0, ""             , user_at              ),
    AT_CMD_ENTRY( ATI             ,  0,  0, "I"            , user_ati             ),
    AT_CMD_ENTRY( ATE             ,  0,  1, "E"            , user_ate             ),
    AT_CMD_ENTRY( ATZ             ,  0,  0, "Z"            , user_atz             ),
    AT_CMD_ENTRY( ATR             ,  0,  0, "R"            , user_atr             ),
    AT_CMD_ENTRY( ATF             ,  1,  1, "F"            , user_atf             ),
#ifdef USE_AT_CURSOR
    AT_CMD_ENTRY( AT_CURSOR       ,  0,  0, "CURSOR"       , user_at_cursor       ),
#endif
.....
.....
.....
#ifdef USE_AT_HRTBT
    AT_CMD_ENTRY( AT_HRTBT        ,  0,  1, "HRTBT"        , user_at_hrtbt        ),
#endif
#ifdef USE_AT_DEVNAME
		AT_CMD_ENTRY( AT_DEVNAME       ,  0,  1, "DEVNAME"         , user_at_devname         ), //custom AT command to change dev name
#endif
#ifdef USE_AT_SHOWNAME
		AT_CMD_ENTRY( AT_SHOWNAME			, 0, 		0, "SHOWNAME"				, user_at_showname			), //custom AT command to show the dev name
#endif
#ifdef USE_AT_BAUD
    AT_CMD_ENTRY( AT_BAUD         ,  0,  1, "BAUD"         , user_at_baud         ),
#endif
    AT_CMD_ENTRY( AT_INVALID      ,  0,  1, "XXX"          , user_at_invalid      )
};

#ifdef USE_AT_SHOWNAME
void user_at_showname(struct at_cmd_params_t* arg, char* reply_string)
{

					if( arg->arg_count ==0)
				{

					//Print the existing Device Name
					arch_sprintf(reply_string, "%s", device_info.dev_name.name);
					arg->success_flag = true;
				}

}
#endif

// Custom AT command to change the Device Name
#ifdef USE_AT_DEVNAME
void save_name_on_SPI(void)
{

	//Re-configure P0_0 for SPI Flash
	GPIO_ConfigurePin(SPI_DO_GPIO_PORT, SPI_DO_GPIO_PIN, OUTPUT, PID_SPI_DO, false);
  int8_t ret;
	/* Wake-up SPI Flash */
	spi_flash_release_from_power_down();
	// 32 bytes- Size of Scan Response Data and Max Device Name Length
	uint32_t pc_bytes_written= 0x20;
	/* Erase data on address 0x0BD80
		 We must always first Erase and then Write on an Address */
	ret = spi_flash_page_erase(0x0BD80);	//, SPI_FLASH_OP_BE32
#ifdef CFG_DEBUG_LOG_NAME
	if(ret == 0)	//If erase was successful
	{
		arch_printf("\n\r P25Q11U Flash sector 0x0BD80 has been erased \n\r");
	}
#endif

	/* Write data on address 0x0BD80*/
	ret = spi_flash_write_data((uint8_t *) &new_device_name, 0x0BD80, sizeof(new_device_name),  &pc_bytes_written);
#ifdef CFG_DEBUG_LOG_NAME
	arch_printf("\n\rWrite Status for 0x1FFC0: %d", ret);
	/* Print the written data if the Write Status does not return any Error */
	if(ret == 0)
	{
		arch_printf("\n\r Written Success ");
	}
#endif
	// Reduce power consumption by putting flash into sleep mode
  spi_flash_power_down();

  // Re-enable HW reset input (must be disabled if/when further operation on
  // external flash are performed) - must set as input first!
  GPIO_ConfigurePin(SPI_DO_GPIO_PORT, SPI_DO_GPIO_PIN, INPUT_PULLDOWN, PID_GPIO, false);
	flag_devname = false;
}

void user_at_devname(struct at_cmd_params_t* arg, char* reply_string)
{
	//Restrict the AT command only via UART
	if (arg->cmd_source == CMD_SRC_LOCAL)
      {

				char zeroed[GAP_MAX_NAME_SIZE] = "0";
				//Empty the new_device_name array
				memcpy(new_device_name, &zeroed, GAP_MAX_NAME_SIZE);
				//If AT+DEVNAME
				if( arg->arg_count ==0)
				{
					//We only printed out the name, so keep flag_devname = false;
					//flag_devname = false;
					//Print the existing Device Name
					//arch_sprintf(reply_string, "%s", device_info.dev_name.name);
					arch_sprintf(reply_string, "%s", "Use the AT+SHOWNAME command \r\n");
					arg->success_flag = true;
				}
				else //else if AT+DEVNAME=
				{
					//We will change the Device Name (short and long) so change flag_devname= true
					flag_devname= true;
					changed_name = true;
					//Empty the device_info struct
					memcpy(device_info.dev_name.name, &zeroed, GAP_MAX_NAME_SIZE);
					//Save the New device name into the new_device_name variable
					memcpy(&new_device_name, &arg->cmd_buffer[arg->arg_index[0]], GAP_MAX_NAME_SIZE);
					device_info.dev_name.length = (strlen(new_device_name) <= GAP_MAX_NAME_SIZE) ?strlen(new_device_name) : GAP_MAX_NAME_SIZE;
					//Save the New device name into the device_info struct
					memcpy(device_info.dev_name.name, new_device_name, device_info.dev_name.length);
					/* Set the Device Name to the codeless_env struct  */
					 memcpy(&codeless_env.resp_data, &device_info.dev_name.name, device_info.dev_name.length);
					 codeless_env.resp_data_len = strlen(new_device_name);
					 // Instantiate the advertising update message to be sent
					struct gapm_update_advertise_data_cmd *cmd = KE_MSG_ALLOC(GAPM_UPDATE_ADVERTISE_DATA_CMD,
																																		TASK_GAPM,
																																		TASK_APP,
																																		gapm_update_advertise_data_cmd);

					cmd->operation = GAPM_UPDATE_ADVERTISE_DATA;
					//Set the Advertising Data as specifiec in user_app_init custom callback function
					#ifdef USE_AT_BINARY_MODE
					const uint8_t advertisement_data[] =
					#else
					uint8_t advertisement_data[] =
					#endif
					{ // Complete list of 128bit service UUIDs
					#ifdef USE_AT_BINARY_MODE
							17, GAP_AD_TYPE_COMPLETE_LIST_128_BIT_UUID, SPS_SERV_ADV_UUID_REV_BYTES,
					#else
							17, GAP_AD_TYPE_COMPLETE_LIST_128_BIT_UUID, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00,
							 0x00, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00,
					#endif
							 3, GAP_AD_TYPE_MORE_16_BIT_UUID, 0xF5, 0xFE, //SUOTA Service
						// Bluetooth Device Name
							 5, GAP_AD_TYPE_SHORTENED_NAME,
							 new_device_name[0],
							 new_device_name[1],
							 new_device_name[2],
							 new_device_name[3]
					};
					#ifndef USE_AT_BINARY_MODE
					for (uint8_t i = 0; i < 16; i++) {
									advertisement_data[2 + i] = codeless_const_env.adv_service_uuid[i];
					}
					#endif
					 //Save the advertisemnt_data into the codeless_env struct
					memcpy(&codeless_env.adv_data, &advertisement_data, sizeof(advertisement_data));
					 //Save the Advertisment  data length into the codeless_env struct
					codeless_env.adv_data_len = sizeof(advertisement_data);
					// Update the Advertising data
					cmd->adv_data_len = codeless_env.adv_data_len;
					memcpy(cmd->adv_data, codeless_env.adv_data, codeless_env.adv_data_len);

					/* Set the Device Name to Scan response data and show it */
					append_device_name(&cmd->scan_rsp_data_len,
														 codeless_env.resp_data_len,
														 &(cmd->scan_rsp_data[cmd->scan_rsp_data_len]),
														 codeless_env.resp_data);

					// Send the message
					ke_msg_send(cmd);

				//	arch_printf("Flag_devname bool : %s",flag_devname?"true":"false");


					//Print the New name
					arch_sprintf(reply_string, "%s", device_info.dev_name.name);
					arg->success_flag = true;
					//Save the New Device Name on the SPI Flash
					save_name_on_SPI();

			}
	}
}
#endif

bool flag_for_name = true;



 //Will be stored the Device Name being read from SPI Flash
char device_name_after_reset[GAP_MAX_NAME_SIZE];
 /* Read the Flag_devname from SPI Flash address 0x1FE00 */
void read_name_from_SPI(void)
{
	//Empty array
	char zeroed[GAP_MAX_NAME_SIZE] = "0";

	//Re-configure P0_0 for SPI Flash
	GPIO_ConfigurePin(SPI_DO_GPIO_PORT, SPI_DO_GPIO_PIN, OUTPUT, PID_SPI_DO, false);
	//Counter to see if we have stored another Device name in the SPI Flash
	int counter=0;
	//Variable to check if SPI Erase/Read was succesful
  int8_t ret;
	uint8_t devname_read[GAP_MAX_NAME_SIZE];
	char devname_stored[GAP_MAX_NAME_SIZE];
	//32 bytes, which is the GAP_MAX_NAME_SIZE and the MAX size of the Scan Response Data.
	uint32_t bytes_read=0x20;
	/* Wake-up SPI Flash */
	spi_flash_release_from_power_down();



	/*Read the data stored on address 0x0BD80 */
	ret = spi_flash_read_data((uint8_t *) &devname_read,0x0BD80 , sizeof(devname_read), &bytes_read);
#ifdef CFG_DEBUG_LOG_NAME
	arch_printf("\n\rRead Status for 0x0BD80: %d \n\r", ret);
#endif
	/* Print the data if the Read Status is OK
		Uncomment the arch_printf if you want to Print the Bytes we have read from SPI Flash*/
	if(ret == 0)
	{
#ifdef CFG_DEBUG_LOG_NAME
		arch_printf("Bytes read:");
#endif
		int len = sizeof(devname_read);
		//Print all the data we read from SPI Flash
		while(len != 0)
		{
#ifdef CFG_DEBUG_LOG_NAME
			arch_printf(" %d |", devname_read[sizeof(devname_read) -len]);
#endif
			//Check if all the data is empty
			if(devname_read[sizeof(devname_read) -len] == 0xFF)
			{
				counter++;
			}
			//Store the Device name into a new array
			if(devname_read[sizeof(devname_read) -len] != 0x00)
			{
				if(devname_read[sizeof(devname_read) -len] == 0xFF)
				{
					break;
				}
				device_name_after_reset[sizeof(devname_read) -len] = devname_read[sizeof(devname_read) -len];

			}

			len--;
		}
		//If address 0x0BD80 is empty, then do not change the Device Name Struct and the Scan Response Data
		if(counter==32)
		{
			flag_for_name = true;
		}
		else// if address 0xBD80 is not empty, then use the stored Device Name
		{

			flag_for_name= false;
		}
#ifdef CFG_DEBUG_LOG_NAME
		arch_printf("\n\r");
#endif
	}
	// Reduce power consumption by putting flash into sleep mode
  spi_flash_power_down();

  // Re-enable HW reset input (must be disabled if/when further operation on
  // external flash are performed) - must set as input first!
  GPIO_ConfigurePin(SPI_DO_GPIO_PORT, SPI_DO_GPIO_PIN, INPUT_PULLDOWN, PID_GPIO, false);

}


void user_app_on_init(void)
{
    // Create a static, random, Bluetooth Device Address
#if defined(CFG_USE_GENERATED_BLUETOOTH_ADDRESS)
    user_injected_bd_address = generate_random_bd_addr();
#else
    user_injected_bd_address = get_bd_addr_from_otp_or_nvds();
#endif
    default_app_on_init();
    // Set initial Bluetooth role
#ifdef CODELESS_585
    codeless_env.bt_role = GAP_ROLE_NONE;
#endif

    // Set the application state
    codeless_env.gap_activity = IDLE;
    codeless_env.adv_intv = user_adv_conf.intv_min;
    console_env.echo = true;
    console_env.error_report_flag = true;

    #ifdef USE_AT_BINARY_MODE
    codeless_env.binary_mode=false;
    codeless_env.escape_time1=MSEC_TO_ESC_TIMER1(CODELESS_DEFAULT_ESC_TIME1); //1sec
    codeless_env.escape_time2=MSEC_TO_ESC_TIMER2(CODELESS_DEFAULT_ESC_TIME2); //1sec
    codeless_env.escape_chars[0]='+';
    codeless_env.escape_chars[1]='+';
    codeless_env.escape_chars[2]='+';
    codeless_env.escape_chars_command_input=0x2B2B2B;
    #endif

    codeless_env.is_tk_entry_pending = false;

    // Specify the advertise data

    #ifdef USE_AT_FLOWCONTROL
    codeless_env.flow_control_enabled=false;
    #endif

    #ifdef USE_AT_CONPAR
    struct connection_configuration_t *p_conf=&codeless_env.conn_conf;
    p_conf->dle_en=true;
    p_conf->dle_tx_pkt_len=CFG_MAX_TX_PACKET_LENGTH;
    p_conf->dle_rx_pkt_len=CFG_MAX_RX_PACKET_LENGTH;
    p_conf->max_mtu=user_gapm_conf.max_mtu;
    #endif

    #ifdef USE_AT_HOSTSLP
    codeless_env.hst_sleep_mode=HOSTSL_DEFAULT_SLP_MODE;
    codeless_env.hst_sleep_wakeup_byte=HOSTSL_DEFAULT_WKUP_BYTE;
    codeless_env.hst_sleep_wakeup_retry_interval=HOSTSL_DEFAULT_WKUP_INTERVAL;
    codeless_env.hst_sleep_wakeup_retry_times=HOSTSL_DEFAULT_WKUP_TRIES;
    #endif


		//Read the address 0x0BD80 on SPI Flash to see if we have stored a different Device Name
		read_name_from_SPI();
#ifdef CFG_DEBUG_LOG_NAME
		//Print True if we have not a New device Name, Print False if we had stored a new Device Name
		arch_printf("We did NOT store a new Device Name: %s",flag_for_name?"true":"false");
#endif
		if(!flag_for_name)	//if we had stored a New Device name, print it
		{
			arch_printf("\r\n %s", device_name_after_reset);
		}
		if(flag_for_name)	//Default Operation, we have not stored any alternative Device Name in the SPI Flash
		{
			#ifdef USE_AT_BINARY_MODE
			const uint8_t advertisement_data[] =
			#else
			uint8_t advertisement_data[] =
			#endif
			{ // Complete list of 128bit service UUIDs
			#ifdef USE_AT_BINARY_MODE
					17, GAP_AD_TYPE_COMPLETE_LIST_128_BIT_UUID, SPS_SERV_ADV_UUID_REV_BYTES,
			#else
					17, GAP_AD_TYPE_COMPLETE_LIST_128_BIT_UUID, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00,
					 0x00, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00,
			#endif
					 3, GAP_AD_TYPE_MORE_16_BIT_UUID, 0xF5, 0xFE, //SUOTA Service
				// Bluetooth Device Name
					 5, GAP_AD_TYPE_SHORTENED_NAME,
					 USER_DEVICE_NAME[0],
					 USER_DEVICE_NAME[1],
					 USER_DEVICE_NAME[2],
					 USER_DEVICE_NAME[3]
			};
			#ifndef USE_AT_BINARY_MODE
			for (uint8_t i = 0; i < 16; i++) {
							advertisement_data[2 + i] = codeless_const_env.adv_service_uuid[i];
			}
			#endif

			//Save the advertisemnt_data into the codeless_env struct
			memcpy(&codeless_env.adv_data, &advertisement_data, sizeof(advertisement_data));
			//Save the Advertisment  data length into the codeless_env struct
			codeless_env.adv_data_len = sizeof(advertisement_data);

			// Set scan response data where the full CodeLess name is shown
			codeless_env.resp_data[0] = USER_DEVICE_NAME_LEN + 1;
			codeless_env.resp_data[1] = GAP_AD_TYPE_COMPLETE_NAME;

			memcpy(&codeless_env.resp_data[2], USER_DEVICE_NAME, USER_DEVICE_NAME_LEN);
			codeless_env.resp_data_len = USER_DEVICE_NAME_LEN + 2;
	  }
		else if(!flag_for_name)	//if we have stored a different Device Name, then use this device name on the Scan Response Data
		{
						//Set the Advertising Data as specifiec in user_app_init custom callback function
					#ifdef USE_AT_BINARY_MODE
					const uint8_t advertisement_data[] =
					#else
					uint8_t advertisement_data[] =
					#endif
					{ // Complete list of 128bit service UUIDs
					#ifdef USE_AT_BINARY_MODE
							17, GAP_AD_TYPE_COMPLETE_LIST_128_BIT_UUID, SPS_SERV_ADV_UUID_REV_BYTES,
					#else
							17, GAP_AD_TYPE_COMPLETE_LIST_128_BIT_UUID, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00,
							 0x00, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00,
					#endif
							 3, GAP_AD_TYPE_MORE_16_BIT_UUID, 0xF5, 0xFE, //SUOTA Service
						// Bluetooth Device Name
							 5, GAP_AD_TYPE_SHORTENED_NAME,
							 device_name_after_reset[0],
							 device_name_after_reset[1],
							 device_name_after_reset[2],
							 device_name_after_reset[3]
					};
					#ifndef USE_AT_BINARY_MODE
					for (uint8_t i = 0; i < 16; i++) {
									advertisement_data[2 + i] = codeless_const_env.adv_service_uuid[i];
					}
					#endif
					 //Save the advertisemnt_data into the codeless_env struct
					memcpy(&codeless_env.adv_data, &advertisement_data, sizeof(advertisement_data));
					 //Save the Advertisment  data length into the codeless_env struct
					codeless_env.adv_data_len = sizeof(advertisement_data);

					//Empty array
					char zeroed[GAP_MAX_NAME_SIZE] = "0";
					//Empty the device_info struct
					memcpy(device_info.dev_name.name, &zeroed, GAP_MAX_NAME_SIZE);
					device_info.dev_name.length = strlen(device_name_after_reset);
					//Save the New device name into the device_info struct
					memcpy(device_info.dev_name.name, device_name_after_reset, device_info.dev_name.length);
					/* Set the Device Name to the codeless_env struct  */
				  memcpy(&codeless_env.resp_data, &device_info.dev_name.name, device_info.dev_name.length);
				  codeless_env.resp_data_len = strlen(device_name_after_reset);


		}

    // set codeless to connectable.
    codeless_env.is_connectable = true;
    // Initialize input command index to zero.
    console_env.input_cmd_char_index = 0;
    // Initialize parser flag
    console_env.parser_flag = CHAR_PARSER_NOT_ACTIVE;
#if defined(USE_AT_BND)
    #if (BLE_APP_SEC)
        // The bdb should be initialized once if the bonding commands are
        // included. The security should be enabled as well otherwise the
        // bond commands do not make sense.
        default_app_bdb_init();
    #else
        #warning "Bonding commands are included but security is disabled;No bonding commands will be available"
    #endif
#endif
#if defined(USE_AT_HNDL)
    // The hdb should be initialized once if the handler commands are
    // included
    app_hdb_init();
#endif

#if defined(USE_AT_CONPAR) || defined(USE_AT_MAXMTU) || defined(USE_AT_DLEEN)
    app_cpdb_init();
    app_load_cpdb_conf_from_flash(&codeless_env.conn_conf);
#endif

#if defined (USE_AT_EVENT)
    // The events database should be initialized once if the event command
    // is included
    app_evdb_init();
#endif

}

void user_advertise(void)
{
	read_name_from_SPI();

	if(flag_for_name)// Default Operation, We have no Device Name stored in the SPI Flash (0x0BD80)
	{
				struct gapm_start_advertise_cmd* cmd;

				if (codeless_env.is_connectable)
				{
						cmd = app_easy_gap_undirected_advertise_get_active();
				}
				else
				{
						cmd = app_easy_gap_non_connectable_advertise_get_active();
				}
				// Specify the advertise data
				cmd->info.host.adv_data_len = codeless_env.adv_data_len;
				memcpy(&cmd->info.host.adv_data, &codeless_env.adv_data, codeless_env.adv_data_len);
				// Specify scan response data (if any)
				if (codeless_env.resp_data_len > 0 && codeless_env.is_connectable)
				{
						cmd->info.host.scan_rsp_data_len = codeless_env.resp_data_len;
						memcpy(&cmd->info.host.scan_rsp_data, &codeless_env.resp_data, codeless_env.resp_data_len);
				}
				else
				{
						cmd->info.host.scan_rsp_data_len = 0;
				}
				// Set advertising interval
				cmd->intv_min = codeless_env.adv_intv;
				cmd->intv_max = codeless_env.adv_intv;
				// Set the advertise mode
				if (codeless_env.is_connectable)
				{
						cmd->info.host.mode = GAP_GEN_DISCOVERABLE;
				}
				else
				{
						cmd->info.host.mode = GAP_BROADCASTER_MODE;
				}



			if (codeless_env.is_connectable)
			{
						app_easy_gap_undirected_advertise_start();
			}
			else
			{
						app_easy_gap_non_connectable_advertise_start();
			}

				// Retain the current activity state
				codeless_env.gap_activity = ADVERTISING;
		}
		else if(!flag_for_name) // If we have stored a new Device Name
		{
				struct gapm_start_advertise_cmd* cmd;

				if (codeless_env.is_connectable)
				{
						cmd = app_easy_gap_undirected_advertise_get_active();
				}
				else
				{
						cmd = app_easy_gap_non_connectable_advertise_get_active();
				}


				// Update the Advertising data
				cmd->info.host.adv_data_len = codeless_env.adv_data_len;
				memcpy(cmd->info.host.adv_data, codeless_env.adv_data, codeless_env.adv_data_len);

				/* Set the Device Name to Scan response data and show it */
				append_device_name(&cmd->info.host.scan_rsp_data_len,
													 codeless_env.resp_data_len,
													 &(cmd->info.host.scan_rsp_data[cmd->info.host.scan_rsp_data_len]),
													 codeless_env.resp_data);

				// Set advertising interval
				cmd->intv_min = codeless_env.adv_intv;
				cmd->intv_max = codeless_env.adv_intv;
				// Set the advertise mode
				if (codeless_env.is_connectable) {
						cmd->info.host.mode = GAP_GEN_DISCOVERABLE;
				} else {
						cmd->info.host.mode = GAP_BROADCASTER_MODE;
				}
				//Start Advertising
				if (codeless_env.is_connectable) {
						app_easy_gap_undirected_advertise_start();
				} else {
						app_easy_gap_non_connectable_advertise_start();
				}

				// Retain the current activity state
				codeless_env.gap_activity = ADVERTISING;
			}

}

void read_name_from_SPI(void);
