ELEC 424/553 Final Project - Self-Driving Car (Raspberry Pi 5)
Team: Team 7
Members: Lola Cantillon, Areli Garcia, Alex Carneiro de Sousa, Santiago Brent

This script performs autonomous lane keeping, red stop-box detection,
and closed-loop speed control on an RC car using a Raspberry Pi 5,
USB webcam, and a custom optical encoder kernel driver.

Citations:
  - raja_961, "Autonomous Lane-Keeping Car Using Raspberry Pi and OpenCV."
    Instructables. https://www.instructables.com/Autonomous-Lane-Keeping-Car-Using-Raspberry-Pi-and/
  - graDudes, "Beaglebone Black (BBB) autonomous vehicle that drives between lines, stop at stop signs and stops at traffic lights."
    Hackster.io. URL: https://www.hackster.io/439751/gradudes-9d9a6e
"""

# Standard library imports for timing, file I/O, and signal handling
import time
import csv
import signal
import sys

# OpenCV for computer vision and NumPy for array math
import cv2
import numpy as np

# Hardware PWM driver for the Pi 5 - drives the steering servo and ESC.
# Install with: pip install rpi-hardware-pwm
from rpi_hardware_pwm import HardwarePWM

# ============================================================
# CONFIGURATION CONSTANTS
# ============================================================

# Camera resolution - keep low for real-time processing on the Pi 5.
FRAME_WIDTH = 320
FRAME_HEIGHT = 240

# PWM duty cycle bounds for steering. 7.5% is approximately straight,
# 6% is full left, 9% is full right (per the project guidelines).
STEERING_NEUTRAL = 7.5
STEERING_MIN = 6.0
STEERING_MAX = 9.0

# Throttle PWM bounds. Keep low for safety and to make tuning manageable.
# Note: set_throttle clamps the lower bound to THROTTLE_NEUTRAL, not below.
# That means the speed controller can only coast (toward neutral), never
# brake. Reverse would need a separate ESC arming sequence. If the car
# runs away on a downhill, the controller is saturated at neutral - lower
# THROTTLE_BASE rather than expecting active braking.
THROTTLE_NEUTRAL = 7.5
THROTTLE_BASE = 7.9       # baseline forward speed - TUNE THIS
THROTTLE_MAX = 8.2        # cap so the car never runs away

# PD controller gains for steering. Start with Kd = 0 and small Kp,
# then increase Kp until the car oscillates, then add Kd to dampen.
KP = 0.02
KD = 0.08

# Speed control gain (proportional only). Reads the encoder rate from
# the kernel driver via sysfs and adjusts throttle to hit a target.
SPEED_KP = 0.0001
TARGET_ENCODER_PERIOD_NS = 50_000_000  # ns between encoder edges - TUNE

# Stop box detection. Red is checked every N frames to preserve loop FPS.
# TODO: tune RED_PIXEL_THRESHOLD by printing the count near a stop box.
RED_CHECK_EVERY_N_FRAMES = 3
RED_PIXEL_THRESHOLD = 2000
FIRST_STOP_DURATION_S = 3.0
STOP_COOLDOWN_FRAMES = 60   # ignore red for this many frames after a stop

# Bounding the max amount of loops.
MAX_FRAMES = 3000

# Hardware PWM configuration for the Pi 5.
#   - PWM_CHIP=2 is the Pi 5's PWM controller (Pi 4 used chip 0).
#   - Channel 0 maps to GPIO 12 (or 18); channel 1 maps to GPIO 13 (or 19).
#   - 50 Hz is the standard servo / ESC frame rate.
# Requires `dtoverlay=pwm-2chan` (or equivalent) enabled in
# /boot/firmware/config.txt so both PWM channels are exposed.
PWM_CHIP = 2
STEERING_CHANNEL = 0
THROTTLE_CHANNEL = 1
PWM_FREQ_HZ = 50

# Seconds to hold neutral throttle on startup so the ESC arms cleanly.
ESC_ARM_SECONDS = 2.0

# Path to the sysfs file your encoder driver exposes. Created by the
# kernel module in encoder_driver.c (see that file).
ENCODER_SYSFS_PATH = "/sys/module/op_encoder_driver/parameters/last_interval_ns"

# CSV log path - used to generate the two plots required by the rubric.
LOG_PATH = "run_log.csv"


# ============================================================
# MOTOR CONTROL
# ============================================================

# Uses the rpi_hardware_pwm library, which drives the Pi 5's hardware
# PWM peripheral via /sys/class/pwm. Hardware PWM gives a steady signal
# (no jitter from Python's GIL) which the servo and ESC both need.

class MotorController:
    """Wraps hardware PWM output for the steering servo and ESC throttle."""

    def __init__(self):
        # Bring up both PWM channels on the Pi 5's PWM controller.
        self.steering_pwm = HardwarePWM(
            pwm_channel=STEERING_CHANNEL, hz=PWM_FREQ_HZ, chip=PWM_CHIP)
        self.throttle_pwm = HardwarePWM(
            pwm_channel=THROTTLE_CHANNEL, hz=PWM_FREQ_HZ, chip=PWM_CHIP)

        # Track current duty cycle for logging and clamp checks.
        self.steering_duty = STEERING_NEUTRAL
        self.throttle_duty = THROTTLE_NEUTRAL

        # Start both channels at neutral so the car does not lurch.
        self.steering_pwm.start(STEERING_NEUTRAL)
        self.throttle_pwm.start(THROTTLE_NEUTRAL)

        # The following sequence is done for calibration purposes and
        # it tells the ESC the range of PWM signals it will receive.
        # This was adapted from the gradDudes python file with the
        # BeagleBone.
        print("let's calibrate the ESC!")

        # ESC calibration values from the assignment.
        CALIB_HIGH = 10.0  # Max throttle signal for ESC calibration
        CALIB_LOW  = 5.0   # Min throttle signal for ESC calibration

        # Sending maximum throttle signal for two seconds.
        self.throttle_pwm.change_duty_cycle(CALIB_HIGH)
        self.throttle_duty = CALIB_HIGH
        print(f"  Sending a high signal ({CALIB_HIGH}%) to the ESC for 2 seconds...")
        time.sleep(2)

        # Sending minimum throttle signal for two seconds.
        self.throttle_pwm.change_duty_cycle(CALIB_LOW)
        self.throttle_duty = CALIB_LOW
        print(f"  Sending a low signal ({CALIB_LOW}%) to the ESC for 2 seconds...")
        time.sleep(2)

        # Return to neutral, ideally this should cause two beeps to happen.
        # First one says the ESC was acknowledged, while the second one says
        # it's ready to drive.
        self.throttle_pwm.change_duty_cycle(THROTTLE_NEUTRAL)
        self.throttle_duty = THROTTLE_NEUTRAL
        print("  Setting ESC back to neutral...")

        # ESCs need to see a steady neutral pulse for a moment to arm.
        time.sleep(ESC_ARM_SECONDS)

    def set_steering(self, duty):
        # Clamp the requested duty cycle to the safe steering range.
        duty = max(STEERING_MIN, min(STEERING_MAX, duty))
        self.steering_duty = duty
        # Push the new duty cycle to the hardware PWM channel.
        self.steering_pwm.change_duty_cycle(duty)

    def set_throttle(self, duty):
        # Clamp to a safe throttle window so the car cannot run away.
        duty = max(THROTTLE_NEUTRAL, min(THROTTLE_MAX, duty))
        self.throttle_duty = duty
        # Push the new duty cycle to the hardware PWM channel.
        self.throttle_pwm.change_duty_cycle(duty)

    def neutral(self):
        # Always callable - used in the cleanup path and on Ctrl+C.
        self.set_steering(STEERING_NEUTRAL)
        self.set_throttle(THROTTLE_NEUTRAL)

    def cleanup(self):
        # Stop the motors first, then release the PWM channels so the
        # next run can grab them again without a "device busy" error.
        self.neutral()
        # Hold neutral briefly so the ESC sees the stop pulse before
        # the PWM line goes quiet.
        time.sleep(0.2)
        self.steering_pwm.stop()
        self.throttle_pwm.stop()


# ============================================================
# LANE DETECTION
# ============================================================

# This pipeline follows the raja_961 Instructable closely:
#   1. Crop to lower half of the frame (the lane is on the ground).
#   2. Convert to HSV and mask the blue lane tape.
#   3. Run Canny edge detection, then probabilistic Hough transform.
#   4. Average left and right line slopes/intercepts to estimate
#      where the lane center is at the bottom of the frame.
#   5. Compute the heading angle the car should aim for.

def detect_lane_edges(frame):
    """Return a binary edge image of just the blue lane tape."""
    # Convert to HSV - hue-based color masking is more robust than RGB.
    hsv = cv2.cvtColor(frame, cv2.COLOR_BGR2HSV)

    # TODO: confirm these HSV bounds match the blue tape in your room's
    # lighting. Print/visualize the mask and tweak if it picks up noise.
    lower_blue = np.array([90, 80, 40])
    upper_blue = np.array([130, 255, 255])
    mask = cv2.inRange(hsv, lower_blue, upper_blue)

    # Edges of the masked lane region - input to the Hough transform.
    edges = cv2.Canny(mask, 50, 100)
    return edges


def region_of_interest(edges):
    """Keep only the lower portion of the frame where the lane lives."""
    height, width = edges.shape
    mask = np.zeros_like(edges)
    # A trapezoid focused on the lower half ignores ceiling/desk noise.
    polygon = np.array([[
        (0, height),
        (0, height * 1 // 2),
        (width, height * 1 // 2),
        (width, height),
    ]], np.int32)
    cv2.fillPoly(mask, polygon, 255)
    return cv2.bitwise_and(edges, mask)


def detect_line_segments(cropped_edges):
    """Hough transform to find candidate lane-line segments."""
    # TODO: tune these Hough parameters for your camera/resolution.
    rho = 1
    angle = np.pi / 180
    min_threshold = 10
    return cv2.HoughLinesP(
        cropped_edges, rho, angle, min_threshold,
        np.array([]), minLineLength=8, maxLineGap=4
    )


def average_slope_intercept(frame, line_segments):
    """Cluster Hough segments into a single left and right lane line."""
    # If no segments at all, we have no lane info this frame.
    if line_segments is None:
        return []

    height, width, _ = frame.shape
    left_fit, right_fit = [], []
    # Only consider segments whose endpoints fall in the appropriate
    # half of the frame (left line on the left, right line on the right).
    boundary = 1 / 3
    left_region_boundary = width * (1 - boundary)
    right_region_boundary = width * boundary

    for segment in line_segments:
        for x1, y1, x2, y2 in segment:
            # Skip vertical lines - slope is undefined.
            if x1 == x2:
                continue
            fit = np.polyfit((x1, x2), (y1, y2), 1)
            slope, intercept = fit[0], fit[1]
            # Negative slope = left line, positive slope = right line
            # (because y axis is flipped in image coordinates).
            if slope < 0 and x1 < left_region_boundary and x2 < left_region_boundary:
                left_fit.append((slope, intercept))
            elif slope > 0 and x1 > right_region_boundary and x2 > right_region_boundary:
                right_fit.append((slope, intercept))

    # Average the candidate fits and convert back to (x1,y1,x2,y2).
    lane_lines = []
    if left_fit:
        lane_lines.append(make_points(frame, np.average(left_fit, axis=0)))
    if right_fit:
        lane_lines.append(make_points(frame, np.average(right_fit, axis=0)))
    return lane_lines


def make_points(frame, line):
    """Convert (slope, intercept) to two endpoints spanning the ROI."""
    height, width, _ = frame.shape
    slope, intercept = line
    # Bottom of the frame down to the ROI top edge.
    y1 = height
    y2 = int(y1 * 1 / 2)
    # Solve x = (y - b) / m, clamped to the frame width.
    x1 = max(-width, min(2 * width, int((y1 - intercept) / slope)))
    x2 = max(-width, min(2 * width, int((y2 - intercept) / slope)))
    return [[x1, y1, x2, y2]]


def compute_steering_angle(frame, lane_lines):
    """Return the desired heading angle in degrees (90 = straight ahead)."""
    # No lanes seen - tell the caller to hold the previous angle.
    if len(lane_lines) == 0:
        return -1
    height, width, _ = frame.shape

    if len(lane_lines) == 1:
        # Only one line visible - aim parallel to it.
        x1, _, x2, _ = lane_lines[0][0]
        x_offset = x2 - x1
    else:
        # Two lines - aim at their midpoint at the top of the ROI.
        _, _, left_x2, _ = lane_lines[0][0]
        _, _, right_x2, _ = lane_lines[1][0]
        mid = int(width / 2)
        x_offset = (left_x2 + right_x2) / 2 - mid

    y_offset = int(height / 2)
    # Convert pixel offset to a steering angle relative to straight-ahead.
    angle_to_mid_radian = np.arctan(x_offset / y_offset)
    angle_to_mid_deg = int(angle_to_mid_radian * 180.0 / np.pi)
    return angle_to_mid_deg + 90

# ============================================================
# DISPLAY FOR DEBUGGING
# ============================================================

def display_lines(frame, lines, line_color=(0, 255, 0), line_width=6):
    """Overlay detected lane lines onto the frame."""
    line_image = np.zeros_like(frame)
    if lines is not None:
        for line in lines:
            for x1, y1, x2, y2 in line:
                cv2.line(line_image, (x1, y1), (x2, y2), line_color, line_width)
    return cv2.addWeighted(frame, 0.8, line_image, 1, 1)


def display_heading_line(frame, steering_angle, line_color=(0, 0, 255), line_width=5):
    """Draw the computed heading direction onto the frame."""
    heading_image = np.zeros_like(frame)
    height, width, _ = frame.shape
    steering_angle_radian = steering_angle / 180.0 * np.pi
    x1 = int(width / 2)
    y1 = height
    x2 = int(x1 - height / 2 / np.tan(steering_angle_radian))
    y2 = int(height / 2)
    cv2.line(heading_image, (x1, y1), (x2, y2), line_color, line_width)
    return cv2.addWeighted(frame, 0.8, heading_image, 1, 1)

# ============================================================
# RED STOP BOX DETECTION
# ============================================================

def detect_red_stop_box(frame):
    """Return True if a sufficiently large red region is in view."""
    hsv = cv2.cvtColor(frame, cv2.COLOR_BGR2HSV)
    # Red wraps around the hue circle, so we need two ranges and OR them.
    mask1 = cv2.inRange(hsv, np.array([0, 120, 70]),   np.array([10, 255, 255]))
    mask2 = cv2.inRange(hsv, np.array([170, 120, 70]), np.array([180, 255, 255]))
    red_mask = cv2.bitwise_or(mask1, mask2)
    # Only count red in the lower half - the stop paper is on the ground.
    h = red_mask.shape[0]
    red_count = cv2.countNonZero(red_mask[h // 2 :, :])
    return red_count > RED_PIXEL_THRESHOLD


# ============================================================
# ENCODER (reads from kernel driver via sysfs)
# ============================================================

def read_encoder_period_ns():
    """Return the latest encoder edge-to-edge period in nanoseconds."""
    # The kernel module writes the most recent period to this sysfs file.
    # If the file is missing or empty, return None to signal "unknown".
    try:
        with open(ENCODER_SYSFS_PATH, "r") as f:
            return int(f.read().strip())
    except (OSError, ValueError):
        return None


# ============================================================
# MAIN LOOP
# ============================================================

def main():
    # Open the webcam. Device index may need to change on your Pi.
    cap = cv2.VideoCapture(0)
    cap.set(cv2.CAP_PROP_FRAME_WIDTH,  FRAME_WIDTH)
    cap.set(cv2.CAP_PROP_FRAME_HEIGHT, FRAME_HEIGHT)
    if not cap.isOpened():
        print("ERROR: could not open webcam")
        return

    # Install a bare-bones SIGINT handler BEFORE constructing MotorController.
    # MotorController.__init__ sleeps ~2s while the ESC arms, and a Ctrl+C
    # during that window would otherwise skip cleanup entirely. SystemExit
    # raised here unwinds into the try/finally below so motors still stop.
    signal.signal(signal.SIGINT, lambda *_: sys.exit(0))

    # Initialize to None so the finally clause can tell what was set up.
    # If MotorController() raises (e.g., PWM overlay missing), we still
    # want cap.release() to run.
    motors = None
    log_file = None

    # try/finally guarantees motors.cleanup() runs no matter what raises
    # inside the loop - bad webcam frame, OpenCV assertion, sysfs I/O
    # error, etc. The rubric warns explicitly: an uncaught exception with
    # the ESC still driving is the worst failure mode for this project.
    try:
        motors = MotorController()

        # Once motors exist, swap in a graceful handler that flips a flag
        # rather than calling sys.exit(). The main loop sees the flag,
        # exits normally, and the finally block runs - which closes the
        # CSV log so partial runs are still debuggable.
        running = [True]
        def request_shutdown(*_):
            running[0] = False
        signal.signal(signal.SIGINT, request_shutdown)

        # PD controller state.
        last_error = 0
        last_steering_angle = 90  # 90 deg = straight

        # Stop-box state machine: count detections, cooldown, final stop.
        stop_count = 0
        stop_cooldown = 0
        stopped_permanently = False

        # CSV log for the two required plots.
        log_file = open(LOG_PATH, "w", newline="")
        log = csv.writer(log_file)
        log.writerow([
            "frame", "error", "p_response", "d_response",
            "steering_duty", "speed_duty", "encoder_period_ns",
        ])

        # The bounded loop is critical - never run unbounded or the ESC
        # may keep driving after Ctrl+C (per the project guidelines).
        for frame_num in range(MAX_FRAMES):
            # Honor a Ctrl+C from the SIGINT handler - exit the loop so
            # the finally block runs (motors neutral, log flushed, cam
            # released).
            if not running[0]:
                break
            ok, frame = cap.read()
            if not ok:
                break

            # ---------- LANE DETECTION ----------
            edges = detect_lane_edges(frame)
            roi = region_of_interest(edges)
            segments = detect_line_segments(roi)
            lane_lines = average_slope_intercept(frame, segments)
            new_angle = compute_steering_angle(frame, lane_lines)

            # If we lost the lane this frame, hold the last known angle
            # rather than snapping the wheel to some default.
            if new_angle == -1:
                new_angle = last_steering_angle
            last_steering_angle = new_angle

            # ---------- PD STEERING ----------
            # Error is degrees away from straight ahead.
            error = new_angle - 90
            d_error = error - last_error
            p_response = KP * error
            d_response = KD * d_error
            steering_duty = STEERING_NEUTRAL + p_response + d_response
            last_error = error
            motors.set_steering(steering_duty)

            # ---------- SPEED CONTROL ----------
            # Read the encoder rate from your kernel driver and nudge the
            # throttle toward the target period. If we have no reading
            # yet, just use the baseline throttle.
            period_ns = read_encoder_period_ns()
            if period_ns and not stopped_permanently:
                # Negative err => car too fast => slow down toward neutral.
                speed_err = period_ns - TARGET_ENCODER_PERIOD_NS
                speed_duty = THROTTLE_BASE + SPEED_KP * speed_err
            else:
                speed_duty = THROTTLE_BASE
            if not stopped_permanently:
                motors.set_throttle(speed_duty)

            # ---------- STOP BOX ----------
            # Only check every Nth frame, and only when not in cooldown.
            if (frame_num % RED_CHECK_EVERY_N_FRAMES == 0
                    and stop_cooldown == 0
                    and detect_red_stop_box(frame)):
                stop_count += 1
                motors.set_throttle(THROTTLE_NEUTRAL)
                if stop_count >= 2:
                    # Final stop box - shut down cleanly.
                    stopped_permanently = True
                    motors.neutral()
                    print("Final stop box reached.")
                    break
                # First stop box - pause, then resume with cooldown.
                print(f"Stop box #{stop_count} - pausing.")
                time.sleep(FIRST_STOP_DURATION_S)
                stop_cooldown = STOP_COOLDOWN_FRAMES

            if stop_cooldown > 0:
                stop_cooldown -= 1

            # ---------- LOG + DISPLAY ----------
            log.writerow([
                frame_num, error, p_response, d_response,
                motors.steering_duty, motors.throttle_duty,
                period_ns if period_ns else -1,
            ])

            # Show the lane overlay  the most useful single view for debugging.
            # Comment these out for final timed runs; imshow + X forwarding is slow.
            lane_image = display_lines(frame, lane_lines)
            heading_image = display_heading_line(lane_image, new_angle)
            cv2.imshow("Lane Detection", heading_image)

            # cv2.waitKey(1) is required for any imshow windows to update,
            # even if you aren't actively displaying anything. Without it
            # the OpenCV event loop never ticks.
            cv2.waitKey(1)

    finally:
        # Guaranteed cleanup, in safety order: motors first (the only
        # actuator that can hurt anything), then file handles, then cam.
        if motors is not None:
            motors.cleanup()
        if log_file is not None:
            log_file.close()
        cap.release()
        print("Run complete.")


if __name__ == "__main__":
    main()
