This is a very useful yet easy to make project. This will determine the water level in a container and prevents the overflow of water. This device needs minimal maintenance. This device sends an alert to let you know water is too high or too low. Normally, regulating water levels can consume electricity and wastewater. However, with automatic controllers, the electricity usage is limited as well as less water needed to regulate supply. It helps in saving money by limiting the waste of water and electricity.
We call it " Water Level Indicator ".
- By following this guide, you will be able to know and make your Water Level indicator This project guide contains the files necessary to help you step by step produce your own Water Level indicator. Please follow the steps of the project to get a positive result.
Step 1:- Get your PCB ready!
Talking about electronics
- After making the circuit diagram I transformed it into a PCB design to produce it, to produce the PCB, I have chosen JLCPCB the best PCB supplier and the cheapest PCB provider to order my circuit. with the reliable platform, all I need to do is some simple clicks to upload the Gerber file and set some parameters like the PCB thickness color and quantity. I’ve paid just 2 Dollars to get my PCB after five days only, what I have noticed about JLCPCB this time is the "out-of-charge PCB color" which means you will pay only 2 USD for any PCB color you choose.
- As you can see in the pictures above the PCB is very well manufactured and I’ve got the same PCB design that we’ve made for our main board and all the labels and logos are there to guide me during the soldering steps. You can also download the Gerber file for this circuit from the download link below in case you want to place an order for the same circuit design.
Step 2: Get all the Components Listed below images.
Step 3: Place all the components on PCB and solder it properly.
Step 4:- Stick the PCB in custom designed box with the help of glue gun and also stick a 12 volt socket for power supply.
Final step:- Cover the box and place all the components of PCB on their respective holes or places and your Water Level indicator is now ready to use.
New users will also get some coupons while registering at JLCPCB via this blue link.
Thank you for reading this guide, hopefully, this guide provides full steps to help you to create your own Water level indicator. If you have any questions please post them in the comment section below.
