This is a very advantageous yet easy to make project.
We call it " Smart Electric Board ".
Benefits :-
This device is extremely convenient and affordable. You can make this device for your office as well as for your home also. This device will make your life way easier. By using this Smart Electric Board, you will be no longer dealing with those hassling wires. By using this Smart device, you can switch off lights or fans without moving from your position which will save your energy and electric bills. So, This device is also a powerful Energy-saving Solution.
By following this guide, you will be able to know and make your Smart Electric Board. This project guide contains the files necessary to help you step by step produce your own Smart Electric Board. Please follow the steps of the project to get a positive result.
Step 1:- Get your PCB ready!
Talking about electronics
After making the circuit diagram I transformed it into a PCB design to produce it, to produce the PCB, I have chosen JCLPCB the best PCB supplier and the cheapest PCB provider to order my circuit. with the reliable platform, all I need to do is some simple clicks to upload the Gerber file and set some parameters like the PCB thickness color and quantity. I’ve paid just 2 Dollars to get my PCB after five days only, what I have noticed about JCLPCB this time is the "out-of-charge PCB color" which means you will pay only 2 USD for any PCB color you choose.
As you can see in the pictures above the PCB is very well manufactured and I’ve got the same PCB design that we’ve made for our main board and all the labels and logos are there to guide me during the soldering steps. You can also download the Gerber file for this circuit from the download link below in case you want to place an order for the same circuit design.
Step 2: Get all the Components Listed below images.
Step 3: Place all the components on PCB and solder it properly.
Step 4 :- Now, we will make a electric board.
Step 5 :- We will connect all these sockets to each other.
- We will take one point common from each socket whose input will be connected to main power supply.
- And, We will connect one-one wire to empty point of each socket which will connect to our Relay module.
- A power supply wire will be connected to one point of switch.
Step 6 :- Now, We will connect our module to the board.
- We will take one point common in our module same as we have done in extension board.
- In second point, we will connect our extra wires that we have drawn out from the extension board.
- And the common wire will connect to one of the point of switch.
- We will connect one wire of main supply to common point of socket and second wire to empty point of switch.
- Now, We will connect our RGB controller to module and we will use 12 volt adaptor (circuit) for power supply.
- We will connect this circuit to the main supply.
Step 7 :- Stick the circuit to your Custom designed box with the help of Glue Gun.
Final step:- Cover the box and place all the components of PCB on their respective holes or places.
Now your ownSmart Electric Boardis ready to use.
Testing :-
For testing purpose I am using 220 watt bulbs of different colors. As you can see below in the images that we can operate our board with the use of our remote. Our Smart Electric Board works well. Now, we can attach it with our prototype.
New users will also get some coupons while registering at JCLPCBvia this blue link.
Thank you for reading this guide, hopefully, this guide provides full steps to help you to create your ownSmart Electric Board.If you have any questions please post them in the comment section below.
