Remember those Summer Vacations when you and your cousins used to compete with each on the evergreen gaming console of Tetris?!
Well guess what, you can make the same thing but a little better using just an Arduino and a LED display matrix!
Let’s move on to the project details.The major components I used were an Arduino Nano, a MAX7219 LED Matrix Display and HC-05 for wireless connectivity.The Main features of this Gaming Console are:1. Wireless Connectivity through an android app created on MIT App Inventor2. Brightness Control3. High Score and Current Score Saving4. Iconic Background Music and a special Indicator sound when a Line is cleared.5. Special Levels, difficulty increases with score.
ComponentsLet’s start with the components.
MAX7219 LED Matrix Display We used a 4-daisy chained LED Matrix where two of them were used as the gaming area and one for High Score and Current Score Evaluation and the last one for Animations etc.We can find libraries in using which we can very easily control the LED Matrix and do various functions like scrolling, displaying shapes etc.We designed the gameplay UI and experience according the old generic game and tried to enhance it using features of our own.
HC-05 Bluetooth ModuleThis is a very efficient device used for wireless connections as it is economical and simple to use. This uses UART protocol to communicate with the microcontroller hence uses only 4 pins, namely VCC, GND, RX, TX.An android app was made and was interfaced with the HC-05 through Arduino to control the gaming console using an Android Device.
Arduino Nano
A compact and a highly efficient Microcontroller.
Arduino provides us with an easy UI and a coding environment so we can write the functions easily. You can find the code written in Arduino IDE below.
The circuitNow let’s take a look at the circuit!
We used a zero PCB board and copper cladded wires and a solder machine to make the whole circuit. We didn’t have fabrication facilities at the time or else we could have made the whole custom PCB in Eagle CAD. If you want it can be done quite easily.But I gues you can get and idea about the circuit from this image above.
We designed and made the whole circuit in my hostel room. You can see the arrangement below…
Just to mention a few things, we didn’t use any onboard memory to save the high score, we just used the Arduino’s EEPROM to save the score so that we can access the score even after plugging off the power and turning it on again. You can find the EEPROM configuration in the code attached.And we could have a used an OLED or a LCD display separately to display score etc and made the device more compact but as we had 4 Dasiy Chained Display Matrix we decided to go with it. You can change the code and configure it according to your needs etc.
So, this was a quick overview of how we made our very own Gaming Console using some easy electronics and a bit of coding! Have fun. :)
#include "LedControl.h"
#include "SPI.h"
#include "MaxMatrix.h"
#include "avr/pgmspace.h"
#include<EEPROM.h>
#include<SoftwareSerial.h>
SoftwareSerial BT(11, 10);
String readdata = "";
short block_number;
int high_score;
int delay_start = 700;
int coming_block[16][8];
int arranged_blocks[16][8];
long int timePassed = 0;
long delays = 0;
int delay_ = 700;
long bdelay = 0;
PROGMEM const short buttondelay = 150;
PROGMEM const short btdowndelay = 30;
PROGMEM const short btsidedelay = 80;
int next = 0;
///DISPLAY SETTINGS
PROGMEM const short DATA_PIN = 7;
PROGMEM const short CLK_PIN = 6;
PROGMEM const short CS_PIN = 5;
PROGMEM const short DISPLAYS = 4;
short screen_intensity = 3;
//pins alloted to various movements.
PROGMEM const short buttonRotate = A3; //Rotate in either direction.
PROGMEM const short buttonRight = A2; //translate right
PROGMEM const short buttonLeft = A0; //translate left
PROGMEM const short buttonDown = A1; //translate down
PROGMEM const short buttonPlay = A4;
PROGMEM const short buttonPause = A5;
PROGMEM const short buttonReset = A6;
LedControl lc = LedControl(DATA_PIN, CLK_PIN, CS_PIN, DISPLAYS);
void LEDRefresh();
void block_predictor(int next);
short readBut()
{
readdata = "";
while (BT.available())
{
delay(1);
char c = BT.read();
readdata += c;
}
if (analogRead(buttonLeft) < 500 || readdata == "left")
{
//left
bdelay = millis() + btsidedelay;
return 2;
}
if (analogRead(buttonDown) < 500 || readdata == "down")
{
//down
bdelay = millis() + btdowndelay;
return 4;
}
if (analogRead(buttonRight) < 500 || readdata == "right")
{
//right
bdelay = millis() + btsidedelay;
return 3;
}
if (analogRead(buttonRotate) < 500 || readdata == "rotate")
{
//rotate
bdelay = millis() + buttondelay;
return 1;
}
if (analogRead(buttonPlay) < 500 || readdata == "play")
{
//rotate
bdelay = millis() + buttondelay;
return 5;
}
if (analogRead(buttonPause) < 500 || readdata == "pause")
{
//rotate
bdelay = millis() + buttondelay;
return 6;
}
if (analogRead(buttonReset) < 500 || readdata == "reset")
{
//rotate
bdelay = millis() + buttondelay;
return 7;
}
return 0;
}
void set_arrays_zero(int given_array[20][8], int n, int m)
{
for (int i = 0; i < n; i++)
{
for (int j = 0; j < m; j++)
{
given_array[i][j] = 0;
}
}
return;
}
void set_arrays_zero12(int given_array[20][12], int n, int m)
{
for (int i = 0; i < n; i++)
{
for (int j = 0; j < m; j++)
{
given_array[i][j] = 0;
}
}
return;
}
bool check_space(int temporary_block[20][12])
{
for (int i = 0; i < 2; i++)
{
for (int j = 0; j < 12; j++)
{
if (temporary_block[i][j] != 0)
{
return false;
}
}
}
for (int i = 18; i < 20; i++)
{
for (int j = 0; j < 12; j++)
{
if (temporary_block[i][j] != 0)
{
return false;
}
}
}
for (int i = 0; i < 20; i++)
{
for (int j = 0; j < 2; j++)
{
if (temporary_block[i][j] != 0)
{
return false;
}
}
}
for (int i = 0; i < 20; i++)
{
for (int j = 10; j < 12; j++)
{
if (temporary_block[i][j] != 0)
{
return false;
}
}
}
for (int i = 2; i < 18; i++)
{
for (int j = 2; j < 10; j++)
{
if (arranged_blocks[i - 2][j - 2] != 0 && temporary_block[i][j] != 0)
{
return false;
}
}
}
return true;
}
bool play = 1;
bool pause = 0;
int score = 0;
int block_blueprint[7][5][5] = {0};
void rotate()
{
Serial.println(F("In Rotate Function"));
if (block_number == 3)
{
return;
}
int temp[5][5] = {0};
bool flag = 0;
short x, y = 0; //used to find i and j where coming_block[i][j]==3 (center)
for (int i = 0; i < 16; i++)
{
for (int j = 0; j < 8; j++)
{
if (coming_block[i][j] == 3)
{
x = i;
y = j;
flag = 1;
break;
}
}
if (flag == 1)
{
break;
}
}
//to put the matrix in a 5X5 temp matrix
for (int i = x - 2; i < x + 3; i++)
{
for (int j = y - 2; j < y + 3; j++)
{
temp[i - x + 2][j - y + 2] = coming_block[i][j];
}
}
for (int i = 0; i <= 2; i++)
{
for (int j = i; j < 4 - i; j++)
{
int mat = temp[i][j];
temp[i][j] = temp[j][4 - i];
temp[j][4 - i] = temp[4 - i][4 - j];
temp[4 - i][4 - j] = temp[4 - j][i];
temp[4 - j][i] = mat;
}
}
//new thing
int temporary_block[20][12] = {0};
for (int i = x - 2; i < x + 3; i++)
{
for (int j = y - 2; j < y + 3; j++)
{
temporary_block[i + 2][j + 2] = temp[i - x + 2][j - y + 2];
}
}
bool check = check_space(temporary_block);
if (check == true)
{
for (int i = 0; i < 16; i++)
{
for (int j = 0; j < 8; j++)
{
coming_block[i][j] = temporary_block[i + 2][j + 2];
}
}
}
updating_arranged_blocks();
LEDRefresh();
}
void translate_right()
{
Serial.println(F("In Translate Right Function"));
int temporary_block[20][12] = {0};
for (int i = 0; i < 16; i++)
{
for (int j = 0; j < 8; j++)
{
temporary_block[i + 2][j + 3] = coming_block[i][j];
}
}
bool check = check_space(temporary_block);
if (check == true)
{
set_arrays_zero(coming_block, 16, 8);
for (int i = 0; i < 16; i++)
{
for (int j = 0; j < 8; j++)
{
coming_block[i][j] = temporary_block[i + 2][j + 2];
}
}
}
updating_arranged_blocks();
LEDRefresh();
}
void translate_down()
{
Serial.println(F("In Translate Down Function"));
int temporary_block[20][12] = {0};
for (int i = 0; i < 16; i++)
{
for (int j = 0; j < 8; j++)
{
temporary_block[i + 3][j + 2] = coming_block[i][j];
}
}
bool check = check_space(temporary_block);
if (check == true)
{
set_arrays_zero(coming_block, 16, 8);
for (int i = 0; i < 16; i++)
{
for (int j = 0; j < 8; j++)
{
coming_block[i][j] = temporary_block[i + 2][j + 2];
}
}
}
else
{
//Merging arranged blocks with coming blocks because the block can't go further down.
for (int i = 0; i < 16; i++)
{
for (int j = 0; j < 8; j++)
{
if (arranged_blocks[i][j] != 0 || coming_block[i][j] != 0)
{
arranged_blocks[i][j] = 1;
}
}
}
set_arrays_zero(coming_block, 16, 8);
newBlock();
}
updating_arranged_blocks();
LEDRefresh();
}
void translate_left()
{
Serial.println(F("In Translate Left Function"));
int temporary_block[20][12] = {0};
for (int i = 0; i < 16; i++)
{
for (int j = 0; j < 8; j++)
{
temporary_block[i + 2][j + 1] = coming_block[i][j];
}
}
bool check = check_space(temporary_block);
if (check == true)
{
set_arrays_zero(coming_block, 16, 8);
for (int i = 0; i < 16; i++)
{
for (int j = 0; j < 8; j++)
{
coming_block[i][j] = temporary_block[i + 2][j + 2];
}
}
}
updating_arranged_blocks();
LEDRefresh();
}
//Handling the new block that will be made available .
void newBlock()
{
Serial.println(F("New Block"));
delay(100);
bool finish_game = is_the_game_over();
if (finish_game == true)
{
play = 1;
pause = 1;
return;
}
block_number = next;
next = random(7);
Serial.println(F("Next:"));
Serial.println(next);
block_predictor(next);
set_arrays_zero(coming_block, 16, 8);
for (int i = 0; i < 5; i++)
{
for (int j = 0; j < 5; j++)
{
coming_block[i][j + 2] = block_blueprint[block_number][i][j];
}
}
return;
}
void updating_arranged_blocks()
{
/*int i;
int j;
int number_of_lines_cleared = 0;
for (i = 15; i >= 0; i--)
{
int count = 0;
for (j = 0; j < 8; j++)
{
if (arranged_blocks[i][j]!=0)
{
count++;
}
}
if (count == 8)
{
num_of_lines_cleared++;
score++;
if (score % 5 == 0)
{
delay_ = delay_ * 0.9;
}
for (j = 0; j < 8; j++)
{
arranged_blocks[i][j] = 0;
}
delay(50);
int k;
for (k = i; k >=0; k--)
{
for (j = 0; j < 8; j++)
{
arranged_blocks[i][j] = arranged_blocks[i - 1][j];
}
}
for (j = 0; j < 8; j++)
{
arranged_blocks[k][j] = 0;
}
delay(50);
i++;
}
}*/
Serial.println(F("In updating arranged blocks function"));
delay(100);
int i;
int j;
int number_of_lines_cleared = 0;
for (i = 15; i >= 0; i--)
{
int count = 0;
for (j = 0; j < 8; j++)
{
if (arranged_blocks[i][j] != 0)
{
count++;
}
}
if (count == 8)
{
//clear the row
number_of_lines_cleared++;
for (j = 0; j < 4; j++)
{
arranged_blocks[i][j] = 0;
arranged_blocks[i][7 - j] = 0;
LEDRefresh();
}
buzzer1();
int k;
for (k = i; k > 0; k--)
{
for (j = 0; j < 8; j++)
{
arranged_blocks[k][j] = arranged_blocks[k - 1][j];
}
}
for (j = 0; j < 8; j++)
{
arranged_blocks[0][j] = 0;
}
i++;
LEDRefresh();
}
}
score = score + number_of_lines_cleared;
//bonus
if (number_of_lines_cleared == 2)
{
score = score + 1;
}
else if (number_of_lines_cleared == 3)
{
score = score + 2;
}
else if (number_of_lines_cleared == 4)
{
score = score + 3;
}
if (number_of_lines_cleared)
{
if (score > high_score)
{
int new_score = score;
int score1 = new_score / 1000;
new_score = new_score % 1000;
int score2 = new_score / 100;
new_score = new_score % 100;
int score3 = new_score / 10;
new_score = new_score % 10;
int score4 = new_score;
score1 = score1 * 10 + score2;
score3 = score3 * 10 + score4;
EEPROM.write(0, score1);
EEPROM.write(1, score3);
high_score = score;
}
update_delay();
}
}
void update_delay()
{
if (score <= 5)
{
delay_ = delay_start;
}
else if (score > 5 && score <= 10)
{
delay_ = (int) delay_start * 0.9;
}
else if (score > 10 && score <= 15)
{
delay_ = (int) delay_start * 0.9 * 0.9;
}
else if (score > 15 && score <= 20)
{
delay_ = (int) delay_start * 0.9 * 0.9 * 0.9;
}
else if (score > 20 && score <= 25)
{
delay_ = (int) delay_start * 0.9 * 0.9 * 0.9 * 0.9;
}
else if (score > 25 && score <= 30)
{
delay_ = (int) delay_start * 0.9 * 0.9 * 0.9 * 0.9 * 0.9;
}
else if (score > 30 && score <= 35)
{
delay_ = (int) delay_start * 0.9 * 0.9 * 0.9 * 0.9 * 0.9 * 0.9;
}
else if (score > 35 && score <= 40)
{
delay_ = (int) delay_start * 0.9 * 0.9 * 0.9 * 0.9 * 0.9 * 0.9 * 0.9;
}
else if (score > 40 && score <= 45)
{
delay_ = (int) delay_start * 0.9 * 0.9 * 0.9 * 0.9 * 0.9 * 0.9 * 0.9 * 0.9;
}
}
bool is_the_game_over()
{
Serial.println(F("In Is_the_game_over function"));
updating_arranged_blocks();
for (int i = 0; i < 8; i++)
{
if (arranged_blocks[1][i])
{
Serial.println(F("GAME OVER"));
return true;
}
}
return false;
}
void display_design_on_pause()
{
/////01234567
//0//........
//1//.11..11.
//2//.11..11.
//3//........
//4//........
//5//1......1
//6//.1....1.
//7//..1111..
dis(3, 1, 1);
dis(3, 1, 2);
dis(3, 1, 5);
dis(3, 1, 6);
dis(3, 2, 1);
dis(3, 2, 2);
dis(3, 2, 5);
dis(3, 2, 6);
dis(3, 5, 0);
dis(3, 5, 7);
dis(3, 6, 1);
dis(3, 6, 6);
dis(3, 7, 2);
dis(3, 7, 3);
dis(3, 7, 4);
dis(3, 7, 5);
}
void dis(int screen, int i, int j)
{
int k = 7 - i + 8 * j;
int x = k / 8;
int y = k % 8;
lc.setLed(screen, 7 - x, 7 - y, true);
}
void display_on_pause2(int screen , int score)
{
int score1 = score / 100;
score = score % 100;
int score2 = score / 10;
score = score % 10;
int score3 = score;
//first_digit
for (int i = 0; i < score1; i++)
{
dis(screen, 7, i);
}
int k = 1;
int l = 0;
if (score2 == 0)
{
//dis(screen,x,y);
dis(screen, 0 + k, 0 + l);
dis(screen, 0 + k, 1 + l);
dis(screen, 0 + k, 2 + l);
dis(screen, 1 + k, 0 + l);
dis(screen, 1 + k, 2 + l);
dis(screen, 2 + k, 0 + l);
dis(screen, 2 + k, 2 + l);
dis(screen, 3 + k, 0 + l);
dis(screen, 3 + k, 2 + l);
dis(screen, 4 + k, 0 + l);
dis(screen, 4 + k, 1 + l);
dis(screen, 4 + k, 2 + l);
}
else if (score2 == 1)
{
dis(screen, 0 + k, 2 + l);
dis(screen, 1 + k, 2 + l);
dis(screen, 2 + k, 2 + l);
dis(screen, 3 + k, 2 + l);
dis(screen, 4 + k, 2 + l);
}
else if (score2 == 2)
{
dis(screen, 0 + k, 0 + l);
dis(screen, 0 + k, 1 + l);
dis(screen, 0 + k, 2 + l);
dis(screen, 1 + k, 2 + l);
dis(screen, 2 + k, 0 + l);
dis(screen, 2 + k, 1 + l);
dis(screen, 2 + k, 2 + l);
dis(screen, 3 + k, 0 + l);
dis(screen, 4 + k, 0 + l);
dis(screen, 4 + k, 1 + l);
dis(screen, 4 + k, 2 + l);
}
else if (score2 == 3)
{
dis(screen, 0 + k, 0 + l);
dis(screen, 0 + k, 1 + l);
dis(screen, 0 + k, 2 + l);
dis(screen, 1 + k, 2 + l);
dis(screen, 2 + k, 0 + l);
dis(screen, 2 + k, 1 + l);
dis(screen, 2 + k, 2 + l);
dis(screen, 3 + k, 2 + l);
dis(screen, 4 + k, 0 + l);
dis(screen, 4 + k, 1 + l);
dis(screen, 4 + k, 2 + l);
}
else if (score2 == 4)
{
dis(screen, 0 + k, 0 + l);
dis(screen, 0 + k, 2 + l);
dis(screen, 1 + k, 0 + l);
dis(screen, 1 + k, 2 + l);
dis(screen, 2 + k, 0 + l);
dis(screen, 2 + k, 1 + l);
dis(screen, 2 + k, 2 + l);
dis(screen, 3 + k, 2 + l);
dis(screen, 4 + k, 2 + l);
}
else if (score2 == 5)
{
dis(screen, 0 + k, 0 + l);
dis(screen, 0 + k, 1 + l);
dis(screen, 0 + k, 2 + l);
dis(screen, 1 + k, 0 + l);
dis(screen, 2 + k, 0 + l);
dis(screen, 2 + k, 1 + l);
dis(screen, 2 + k, 2 + l);
dis(screen, 3 + k, 2 + l);
dis(screen, 4 + k, 0 + l);
dis(screen, 4 + k, 1 + l);
dis(screen, 4 + k, 2 + l);
}
else if (score2 == 6)
{
dis(screen, 0 + k, 0 + l);
dis(screen, 0 + k, 0 + l);
dis(screen, 0 + k, 0 + l);
dis(screen, 1 + k, 0 + l);
dis(screen, 2 + k, 0 + l);
dis(screen, 2 + k, 1 + l);
dis(screen, 2 + k, 2 + l);
dis(screen, 3 + k, 0 + l);
dis(screen, 3 + k, 2 + l);
dis(screen, 4 + k, 0 + l);
dis(screen, 4 + k, 1 + l);
dis(screen, 4 + k, 2 + l);
}
else if (score2 == 7)
{
dis(screen, 0 + k, 0 + l);
dis(screen, 0 + k, 0 + l);
dis(screen, 0 + k, 1 + l);
dis(screen, 0 + k, 2 + l);
dis(screen, 1 + k, 2 + l);
dis(screen, 2 + k, 2 + l);
dis(screen, 3 + k, 2 + l);
dis(screen, 4 + k, 2 + l);
}
else if (score2 == 8)
{
dis(screen, 0 + k, 0 + l);
dis(screen, 0 + k, 1 + l);
dis(screen, 0 + k, 2 + l);
dis(screen, 1 + k, 0 + l);
dis(screen, 1 + k, 2 + l);
dis(screen, 2 + k, 0 + l);
dis(screen, 2 + k, 1 + l);
dis(screen, 2 + k, 2 + l);
dis(screen, 3 + k, 0 + l);
dis(screen, 3 + k, 2 + l);
dis(screen, 4 + k, 0 + l);
dis(screen, 4 + k, 1 + l);
dis(screen, 4 + k, 2 + l);
}
else if (score2 == 9)
{
dis(screen, 0 + k, 0 + l);
dis(screen, 0 + k, 1 + l);
dis(screen, 0 + k, 2 + l);
dis(screen, 1 + k, 0 + l);
dis(screen, 1 + k, 2 + l);
dis(screen, 2 + k, 0 + l);
dis(screen, 2 + k, 1 + l);
dis(screen, 2 + k, 2 + l);
dis(screen, 3 + k, 2 + l);
dis(screen, 4 + k, 2 + l);
}
l = 5;
if (score3 == 0)
{
//dis(screen,x,y);
dis(screen, 0 + k, 0 + l);
dis(screen, 0 + k, 1 + l);
dis(screen, 0 + k, 2 + l);
dis(screen, 1 + k, 0 + l);
dis(screen, 1 + k, 2 + l);
dis(screen, 2 + k, 0 + l);
dis(screen, 2 + k, 2 + l);
dis(screen, 3 + k, 0 + l);
dis(screen, 3 + k, 2 + l);
dis(screen, 4 + k, 0 + l);
dis(screen, 4 + k, 1 + l);
dis(screen, 4 + k, 2 + l);
}
else if (score3 == 1)
{
dis(screen, 0 + k, 2 + l);
dis(screen, 1 + k, 2 + l);
dis(screen, 2 + k, 2 + l);
dis(screen, 3 + k, 2 + l);
dis(screen, 4 + k, 2 + l);
}
else if (score3 == 2)
{
dis(screen, 0 + k, 0 + l);
dis(screen, 0 + k, 1 + l);
dis(screen, 0 + k, 2 + l);
dis(screen, 1 + k, 2 + l);
dis(screen, 2 + k, 0 + l);
dis(screen, 2 + k, 1 + l);
dis(screen, 2 + k, 2 + l);
dis(screen, 3 + k, 0 + l);
dis(screen, 4 + k, 0 + l);
dis(screen, 4 + k, 1 + l);
dis(screen, 4 + k, 2 + l);
}
else if (score3 == 3)
{
dis(screen, 0 + k, 0 + l);
dis(screen, 0 + k, 1 + l);
dis(screen, 0 + k, 2 + l);
dis(screen, 1 + k, 2 + l);
dis(screen, 2 + k, 0 + l);
dis(screen, 2 + k, 1 + l);
dis(screen, 2 + k, 2 + l);
dis(screen, 3 + k, 2 + l);
dis(screen, 4 + k, 0 + l);
dis(screen, 4 + k, 1 + l);
dis(screen, 4 + k, 2 + l);
}
else if (score3 == 4)
{
dis(screen, 0 + k, 0 + l);
dis(screen, 0 + k, 2 + l);
dis(screen, 1 + k, 0 + l);
dis(screen, 1 + k, 2 + l);
dis(screen, 2 + k, 0 + l);
dis(screen, 2 + k, 1 + l);
dis(screen, 2 + k, 2 + l);
dis(screen, 3 + k, 2 + l);
dis(screen, 4 + k, 2 + l);
}
else if (score3 == 5)
{
dis(screen, 0 + k, 0 + l);
dis(screen, 0 + k, 1 + l);
dis(screen, 0 + k, 2 + l);
dis(screen, 1 + k, 0 + l);
dis(screen, 2 + k, 0 + l);
dis(screen, 2 + k, 1 + l);
dis(screen, 2 + k, 2 + l);
dis(screen, 3 + k, 2 + l);
dis(screen, 4 + k, 0 + l);
dis(screen, 4 + k, 1 + l);
dis(screen, 4 + k, 2 + l);
}
else if (score3 == 6)
{
dis(screen, 0 + k, 0 + l);
dis(screen, 0 + k, 0 + l);
dis(screen, 0 + k, 0 + l);
dis(screen, 1 + k, 0 + l);
dis(screen, 2 + k, 0 + l);
dis(screen, 2 + k, 1 + l);
dis(screen, 2 + k, 2 + l);
dis(screen, 3 + k, 0 + l);
dis(screen, 3 + k, 2 + l);
dis(screen, 4 + k, 0 + l);
dis(screen, 4 + k, 1 + l);
dis(screen, 4 + k, 2 + l);
}
else if (score3 == 7)
{
dis(screen, 0 + k, 0 + l);
dis(screen, 0 + k, 0 + l);
dis(screen, 0 + k, 1 + l);
dis(screen, 0 + k, 2 + l);
dis(screen, 1 + k, 2 + l);
dis(screen, 2 + k, 2 + l);
dis(screen, 3 + k, 2 + l);
dis(screen, 4 + k, 2 + l);
}
else if (score3 == 8)
{
dis(screen, 0 + k, 0 + l);
dis(screen, 0 + k, 1 + l);
dis(screen, 0 + k, 2 + l);
dis(screen, 1 + k, 0 + l);
dis(screen, 1 + k, 2 + l);
dis(screen, 2 + k, 0 + l);
dis(screen, 2 + k, 1 + l);
dis(screen, 2 + k, 2 + l);
dis(screen, 3 + k, 0 + l);
dis(screen, 3 + k, 2 + l);
dis(screen, 4 + k, 0 + l);
dis(screen, 4 + k, 1 + l);
dis(screen, 4 + k, 2 + l);
}
else if (score3 == 9)
{
dis(screen, 0 + k, 0 + l);
dis(screen, 0 + k, 1 + l);
dis(screen, 0 + k, 2 + l);
dis(screen, 1 + k, 0 + l);
dis(screen, 1 + k, 2 + l);
dis(screen, 2 + k, 0 + l);
dis(screen, 2 + k, 1 + l);
dis(screen, 2 + k, 2 + l);
dis(screen, 3 + k, 2 + l);
dis(screen, 4 + k, 2 + l);
}
}
void display_pause_symbol(int screen)
{
dis(screen, 1, 1);
dis(screen, 2, 1);
dis(screen, 3, 1);
dis(screen, 4, 1);
dis(screen, 5, 1);
dis(screen, 6, 1);
dis(screen, 1, 2);
dis(screen, 2, 2);
dis(screen, 3, 2);
dis(screen, 4, 2);
dis(screen, 5, 2);
dis(screen, 6, 2);
dis(screen, 1, 5);
dis(screen, 2, 5);
dis(screen, 3, 5);
dis(screen, 4, 5);
dis(screen, 5, 5);
dis(screen, 6, 5);
dis(screen, 1, 6);
dis(screen, 2, 6);
dis(screen, 3, 6);
dis(screen, 4, 6);
dis(screen, 5, 6);
dis(screen, 6, 6);
}
void display_reset_symbol(int screen)
{
dis(screen, 1, 1);
dis(screen, 2, 2);
dis(screen, 3, 3);
dis(screen, 4, 4);
dis(screen, 5, 5);
dis(screen, 6, 6);
dis(screen, 1, 6);
dis(screen, 2, 5);
dis(screen, 3, 4);
dis(screen, 4, 3);
dis(screen, 5, 2);
dis(screen, 6, 1);
}
void display_play_symbol(int screen)
{
dis(screen, 1, 2);
dis(screen, 2, 2);
dis(screen, 3, 2);
dis(screen, 4, 2);
dis(screen, 5, 2);
dis(screen, 6, 2);
dis(screen, 7, 2);
dis(screen, 2, 3);
dis(screen, 3, 3);
dis(screen, 4, 3);
dis(screen, 5, 3);
dis(screen, 6, 3);
dis(screen, 3, 4);
dis(screen, 4, 4);
dis(screen, 5, 4);
dis(screen, 4, 5);
}
void ppr(int n = 0)
{
if (n == 0)
{
Serial.println(F("In starting mode"));
set_arrays_zero(arranged_blocks, 16, 8);
//set_arrays_zero(coming_block, 16, 8);
char string[] = "~Tetris~ <press start to play>";
lc.clearDisplay(0);
lc.clearDisplay(1);
lc.clearDisplay(2);
lc.clearDisplay(3);
// 0 - Displaying Tetris and press start to play
// 1 - Blank
// 2 - High Score
// 3 - A tetris design
//3 - Displaying a block
display_design_on_pause();
//2 - Displaying High Score
display_on_pause2(2, high_score);
// 1 - Displaying Current Score
...
This file has been truncated, please download it to see its full contents.
Archiev Kumar
4 projects • 4 followers
“When you are backed against the wall, break the goddamn thing down.” – Harvey Specter
Comments
