Things used in this project

Code

app.RR
Dashboard for displaying sensor data.

Runs on EC2 instance on AWS or local machine
#Dashboard to Project Wildfire, runs on EC2 instance with Shiny R Server

library(shiny)
library(shinydashboard)

ui <- dashboardPage(
  dashboardHeader(title = "Virtual Forest"),
  dashboardSidebar(
    sidebarMenu(
      menuItem("Dashboard", tabName = "dashboard", icon = icon("dashboard")),
      menuItem("Widgets", tabName = "widgets", icon = icon("th"))
    )
  ),
  dashboardBody(
    tabItems(
      # First tab content
      tabItem(tabName = "dashboard",
              fluidRow(
                box(plotOutput("plot1", height = 250)),

                box(
                  title = "Controls",
                  sliderInput("slider", "Number of observations:", 1, 100, 50)
                )
              )
      ),

      # Second tab content
      tabItem(tabName = "widgets",
              h2("Widgets tab content")
      )
    )
  ))

server <- function(input, output) {

  DATA <- data.frame(matrix(ncol = 3, nrow=0))
  colnames(DATA) <- c("MQ5", "MQ7", "Tempurature (Celsius)")

  con <- socketConnection(host="ENTER IP ADDRESS", port = "ENTER PORT", blocking=TRUE,
                          server=TRUE, open="r+")

  observe({
    data <- read.csv(text = readLines(con, 1), sep=",", header = FALSE)
    colnames(data) <- c("MQ5", "MQ7", "Tempurature (Celsius)")
    DATA <- rbind(DATA, data)
    print(DATA)
    output$plot1 <- renderPlot({plot(DATA)})
  })
}

shinyApp(ui, server)
retrieveSensorData.pyPython
Python code that runs on Intel Edison which retrieves sensor data (gas and temperature). The data is sent either to AWS IoT or to client.
#Runs on Intel Edison

import socket                       #Socket/ Server Library
import time, sys, signal, atexit
import pyupm_gas as upmGas          #MQ Gas Sensor Libraries
import pyupm_grove as grove         #For tempurature sensor

##############################################################################
#       					Set Up Client Code                                         #
##############################################################################
s = socket.socket(socket.AF_INET, socket.SOCK_STREAM)
host = "ENTER IP ADDRESS"
port = "ENTER PORT"
s.connect((host,port))

def SendGas(str):
   s.send(str)
   data = ''
   data = s.recv(5000).decode()

##############################################################################
#       					Collect Gas Data & Temp Data                               #
##############################################################################

# Sensors
myTemp = grove.GroveTemp(0)  #AIO1 [Grove Tempurature Sensor]
myMQ7  = upmGas.MQ7(1);      #AIO2 [MQ7 Gas Sensor: Carbon Monoxide (CO)]
myMQ5  = upmGas.MQ5(2);      #AIO3 [MQ5 Gas Senosr: H2, LPG, CH4, CO, Alcohol]

## Exit handlers ##
# This function stops python from printing a stacktrace when you hit control-C
def SIGINTHandler(signum, frame):
    raise SystemExit

# This function lets you run code on exit, including functions from myMQ2
def exitHandler():
    print "Exiting"
    sys.exit(0)

# Register exit handlers
atexit.register(exitHandler)
signal.signal(signal.SIGINT, SIGINTHandler)

# Infinite loop, ends when script is cancelled
# Repeatedly, take a sample every 2 microseconds;
# find the average of 128 samples; and
myMQ5Buffer = upmGas.uint16Array(128)
myMQ7Buffer = upmGas.uint16Array(128)

while(1):
    myMQ5Data  = myMQ5.getSample() #Collect MQ5 gas Data
    myMQ7Data  = myMQ7.getSample() #Collect MQ7 gas Data
    myTempData = myTemp.value()    #Tempurature in celsius

    message = "" + str(myMQ5Data) + "," + str(myMQ7Data) + "," + str(myTempData) + "\n"
    SendGas(message)
    time.sleep(1)

s.close()
Intel_Edison_AWS_IoT.pyPython
Interfaces Intel Edison Sensors with AWS IoT to upload data.
'''
/*
 * Copyright 2010-2016 Amazon.com, Inc. or its affiliates. All Rights Reserved.
 *
 * Licensed under the Apache License, Version 2.0 (the "License").
 * You may not use this file except in compliance with the License.
 * A copy of the License is located at
 *
 *  http://aws.amazon.com/apache2.0
 *
 * or in the "license" file accompanying this file. This file is distributed
 * on an "AS IS" BASIS, WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either
 * express or implied. See the License for the specific language governing
 * permissions and limitations under the License.
 */
 '''

from AWSIoTPythonSDK.MQTTLib import AWSIoTMQTTClient
import sys
import logging
import time
import getopt
import signal
import atexit

# Custom MQTT message callback
def customCallback(client, userdata, message):
	print("Received a new message: ")
	print(message.payload)
	print("from topic: ")
	print(message.topic)
	print("--------------\n\n")

# Usage
usageInfo = """Usage:
Use certificate based mutual authentication:
python basicPubSub.py -e <endpoint> -r <rootCAFilePath> -c <certFilePath> -k <privateKeyFilePath>
Use MQTT over WebSocket:
python basicPubSub.py -e <endpoint> -r <rootCAFilePath> -w
Type "python basicPubSub.py -h" for available options.
"""
# Help info
helpInfo = """-e, --endpoint
	Your AWS IoT custom endpoint
-r, --rootCA
	Root CA file path
-c, --cert
	Certificate file path
-k, --key
	Private key file path
-w, --websocket
	Use MQTT over WebSocket
-h, --help
	Help information
"""

# Read in command-line parameters
useWebsocket = False
host = ""
rootCAPath = ""
certificatePath = ""
privateKeyPath = ""
try:
	opts, args = getopt.getopt(sys.argv[1:], "hwe:k:c:r:", ["help", "endpoint=", "key=","cert=","rootCA=", "websocket"])
	if len(opts) == 0:
		raise getopt.GetoptError("No input parameters!")
	for opt, arg in opts:
		if opt in ("-h", "--help"):
			print(helpInfo)
			exit(0)
		if opt in ("-e", "--endpoint"):
			host = arg
		if opt in ("-r", "--rootCA"):
			rootCAPath = arg
		if opt in ("-c", "--cert"):
			certificatePath = arg
		if opt in ("-k", "--key"):
			privateKeyPath = arg
		if opt in ("-w", "--websocket"):
			useWebsocket = True
except getopt.GetoptError:
	print(usageInfo)
	exit(1)

# Missing configuration notification
missingConfiguration = False
if not host:
	print("Missing '-e' or '--endpoint'")
	missingConfiguration = True
if not rootCAPath:
	print("Missing '-r' or '--rootCA'")
	missingConfiguration = True
if not useWebsocket:
	if not certificatePath:
		print("Missing '-c' or '--cert'")
		missingConfiguration = True
	if not privateKeyPath:
		print("Missing '-k' or '--key'")
		missingConfiguration = True
if missingConfiguration:
	exit(2)

# Configure logging
logger = logging.getLogger("AWSIoTPythonSDK.core")
logger.setLevel(logging.DEBUG)
streamHandler = logging.StreamHandler()
formatter = logging.Formatter('%(asctime)s - %(name)s - %(levelname)s - %(message)s')
streamHandler.setFormatter(formatter)
logger.addHandler(streamHandler)

# Init AWSIoTMQTTClient
myAWSIoTMQTTClient = None
if useWebsocket:
	myAWSIoTMQTTClient = AWSIoTMQTTClient("basicPubSubGasSensor", useWebsocket=True)
	myAWSIoTMQTTClient.configureEndpoint(host, 443)
	myAWSIoTMQTTClient.configureCredentials(rootCAPath)
else:
	myAWSIoTMQTTClient = AWSIoTMQTTClient("basicPubSubGasSensor")
	myAWSIoTMQTTClient.configureEndpoint(host, 8883)
	myAWSIoTMQTTClient.configureCredentials(rootCAPath, privateKeyPath, certificatePath)

# AWSIoTMQTTClient connection configuration
myAWSIoTMQTTClient.configureAutoReconnectBackoffTime(1, 32, 20)
myAWSIoTMQTTClient.configureOfflinePublishQueueing(-1)  # Infinite offline Publish queueing
myAWSIoTMQTTClient.configureDrainingFrequency(2)  # Draining: 2 Hz
myAWSIoTMQTTClient.configureConnectDisconnectTimeout(10)  # 10 sec
myAWSIoTMQTTClient.configureMQTTOperationTimeout(5)  # 5 sec

#gas sensor code
#######################
# Attach gas sensor to AIO1
myMQ2 = upmGas.MQ7(1);

## Exit handlers ##
# This function stops python from printing a stacktrace when you hit control-C
def SIGINTHandler(signum, frame):
    raise SystemExit

# This function lets you run code on exit, including functions from myMQ2
def exitHandler():
    print "Exiting"
    sys.exit(0)

# Register exit handlers
atexit.register(exitHandler)
signal.signal(signal.SIGINT, SIGINTHandler)

# Connect and subscribe to AWS IoT
myAWSIoTMQTTClient.connect()
myAWSIoTMQTTClient.subscribe("test/gasSensor", 1, customCallback)
time.sleep(2)

threshContext = upmGas.thresholdContext()
threshContext.averageReading = 0
threshContext.runningAverage = 0
threshContext.averagedOver = 2

# Publish to the same topic in a loop forever
loopCount = 0
mybuffer = upmGas.uint16Array(128)

while True:
	samplelen = myMQ2.getSampledWindow(2, 128, mybuffer)
	myAWSIoTMQTTClient.publish("test/gasSensor", "New Message " + str(loopCount), 1)
	if samplelen:
        thresh = myMQ2.findThreshold(threshContext, 30, mybuffer, samplelen)
        myMQ2.printGraph(threshContext, 5)
        if(thresh):
			myAWSIoTMQTTClient.publish("test/gasSensor", "Threshold is " + thresh, 1)
	loopCount += 1
	time.sleep(1)

Credits

Dbb925ae4ebe313f35a035afc593e688
Sarah Watanabe

I am from California in Tech. Currently, I am living in NYC
