NodeMCU is one of the most popular IoT development platforms for students and use by the thousands of developers worldwide. What is more attractive is that it can run on the even more popular Arduino IDE.
The goal of this tutorial is to enable you to send capture and send data to cloud from your NodeMCU device. Before starting this tutorial make sure you have your NodeMCU and LM35 temperature sensor handy, so that this tutorial should go smoothly.
Also make sure you have created an account on https://thingsio.ai.
If you have done the above, you should have your sensor in cloud under 10 minutes.
if you have any questions, you can post it on the support forum: http://discuss.thingsio.ai.
#include <SoftwareSerial.h>
SoftwareSerial mySerial(12, 13); // RX, TX
#include <ESP8266WiFi.h> //https://github.com/esp8266/Arduino
#include <DNSServer.h>
#include <ESP8266WebServer.h>
#include "WiFiManager.h" //https://github.com/tzapu/WiFiManager
int count=0,i,m,j,k;
int t,t1,t2,t3;
int outputpin= A0;//ds18b20
//////////////////////////////////////// ALL DECLARATIONS for CLOUD //////////////////////////////
const char* host = "api.thingsio.ai"; // OR host = devapi2.thethingscloud.com
const char* post_url = "/devices/deviceData"; // OR /api/v2/thingscloud2/_table/data_ac
const char* time_server = "baas.thethingscloud.com"; //this is to convert timestamp
const int httpPort = 80;
char timestamp[10];
WiFiClient client;
/////////////////////////////////////////////////////////////////////////////////////////////////////////
void configModeCallback (WiFiManager *myWiFiManager)
{
Serial.println("Entered config mode"); //*-*-*-*-*-*-*-*-*-*-*-*-*-*if control enters this function then net is not connected
Serial.println(WiFi.softAPIP()); // "WiFi.softAPIP() is for AP" , "WiFi.localIP() is for STA",
Serial.println(myWiFiManager->getConfigPortalSSID()); //if you used auto generated SSID, print it
}
/////////////////////////////////////// TIMESTAMP CALCULATION function///////////////////////////////////////
int GiveMeTimestamp()
{
unsigned long timeout = millis();
while (client.available() == 0)
{
if (millis() - timeout > 50000)
{
client.stop();
return 0;
}
}
while (client.available())
{
String line = client.readStringUntil('\r'); //indexOf() is a funtion to search for smthng , it returns -1 if not found
int pos = line.indexOf("\"timestamp\""); //search for "\"timestamp\"" from beginning of response got and copy all data after that , it'll be your timestamp
if (pos >= 0)
{
int j = 0;
for(j=0;j<10;j++)
{
timestamp[j] = line[pos + 12 + j];
}
}
}
}
////////////////////////////////////////////////////////////////////////////////////////////////////////
void setup()
{
Serial.begin(115200); //(19200,SERIAL_8E1) - data size = 8 bits , parity = Even , stop bit = 1bit
mySerial.begin(115200);
WiFiManager wifiManager;
wifiManager.setAPCallback(configModeCallback);
if(!wifiManager.autoConnect("ThingsIO1","qwerty123")) //wifiManager.autoConnect("AP-NAME", "AP-PASSWORD"); (OR) wifiManager.autoConnect("AP-NAME"); only ID no password (OR) wifiManager.autoConnect(); this will generate a ID by itself
{
Serial.println("failed to connect and hit timeout"); //control comes here after long time of creating Access point "NodeMCU" by NodeMCU and still it has not connected
//reset and try again, or maybe put it to deep sleep
ESP.reset();
delay(1000);
}
//if you come here you have connected to the WiFi
Serial.println("connected...yeey :");
}
void loop()
{
int analogValue = analogRead(outputpin);
{
/////////////////////////////////////// SEND THE QUERY AND RECEIVE THE RESPONSE///////////////////////
t1=(analogValue/1024.0) *5000;
Serial.print("temp: ");
Serial.println(t1);
t2=(t1/10);
Serial.print("celc: ");
Serial.println(t2);
t3=((t2 * 9)/5 + 32);
Serial.print("fhrn: ");
Serial.println(t3); //break;
Serial.print("connecting to ");
Serial.println(host); //defined upside :- host = devapi2.thethingscloud.com or 139.59.26.117
///////////////////////////////////// TIMESTAMP CODE SNIPPET /////////////////////////
Serial.println("inside get timestamp\n");
if (!client.connect(time_server, httpPort))
{
return; //*-*-*-*-*-*-*-*-*-*
}
client.println("GET /api/timestamp HTTP/1.1"); //Whats this part doing, i didnt get
client.println("Host: baas.thethingscloud.com");
client.println("Cache-Control: no-cache");
client.println("Postman-Token: ea3c18c6-09ba-d049-ccf3-369a22a284b8");
client.println();
GiveMeTimestamp(); //it'll call the function which will get the timestamp response from the server
Serial.println("timestamp receieved");
Serial.println(timestamp);
///////////////////////////////////////////////////////////////////////////////
// Use WiFiClient class to create TCP connections
if (!client.connect(host, httpPort)) //host = devapi2.thethingscloud.com , port = 80
{
Serial.println("connection failed"); // *-*-*-*-*-*--*-*-*-*-*-*-*-*-*-*-*-*-
return;
}
client.print("Content-Length: ");
client.println();
unsigned long timeout = millis();
while (client.available() == 0)
{
if (millis() - timeout > 50000)
{
Serial.println(">>> Client Timeout !");
client.stop();
return;
}
}
Serial.println("***********************************************");
Serial.println();
Serial.println("closing connection");
Serial.println("inside ThingsCloudPost");
int timestamp1 =0;
timestamp1 = 1542800778;
String PostValue = "{\"device_id\": 209251, \"slave_id\": 2";
PostValue = PostValue + ",\"dts\":" +timestamp;
PostValue = PostValue +",\"data\":{\"celc\":" + t2 +",\"fahr\":" + t3 +"}"+"}";
Serial.println(PostValue);
//////////////////////////////// try to connect to server again and POST the data on the cloud //////////////////////////
if (!client.connect(host, httpPort))
{
return;
}
client.print("POST ");
client.print(post_url); /// POST api/device-datas HTTP/1.1 Host: baas.thethingscloud.com Content-Type: application/json Cache-Control: no-cache
client.println(" HTTP/1.1"); //Authorization: Content-Length:
client.print("Host: ");
client.println(host);
client.println("Content-Type: application/json");
client.println("Cache-Control: no-cache");
client.print("Authorization: Bearer eyJ0eXAiOiJKV1QiLCJhbGciOiJIUzI1NiJ9.IjViMTI2OGIzM2FhNTNiMjBlNWFjOTEzOCI.I1moNBMEO3zKCrtY-nW7z-Zmj2fzyOsOT5XgEbxmEW8");
client.println();
client.print("Content-Length: ");
client.println(PostValue.length());
client.println();
client.println(PostValue);
//////////////////////////////////POSTING the data on to the cloud is done and now get the response form cloud server//////////////////
while (client.available() == 0)
{
if (millis() - timeout > 50000)
{
Serial.println(">>> Client Timeout !");
client.stop();
return;
}
}
Serial.println("Response From Server");
while(client.available())
{
String line2 = client.readStringUntil('\r');
Serial.print(line2);
}
Serial.println("////////////////////// THE END /////////////////////");
delay(3000);
}
}
