Lock Unlock and Intruder Alert System using BOLT IOT

Want to unlock a particular lock with the help of your face? This project deals with real time face detection set up for a single owner.

IntermediateWork in progress1,916
Lock Unlock and Intruder Alert System using BOLT IOT

Things used in this project

Hardware components

Bolt WiFi Module
Bolt IoT Bolt WiFi Module
×1
Buzzer
Buzzer
×1
LED (generic)
LED (generic)
×1
Jumper wires (generic)
Jumper wires (generic)
×1
Breadboard (generic)
Breadboard (generic)
×1

Software apps and online services

Bolt Cloud
Bolt IoT Bolt Cloud
Ip webcam app
OpenCV
OpenCV
VM Ware virtual setup
Ubuntu Core
Ubuntu Core
SMS Messaging API
Twilio SMS Messaging API
Mailgun

Story

Read more

Code

facetry.py

Python
# import the necessary packages
from scipy.spatial import distance as dist
from imutils.video import FileVideoStream
from imutils.video import VideoStream
from imutils import face_utils
import numpy as np
import imutils
import time
import dlib
import cv2
import face_recognition
import conf, econf
from boltiot import Bolt, Sms, Email
import requests

model = "shape_predictor_68_face_landmarks.dat"


def eye_aspect_ratio(eye):
    # compute the euclidean distances between the two sets of
    # vertical eye landmarks (x, y)-coordinates
    A = dist.euclidean(eye[1], eye[5])
    B = dist.euclidean(eye[2], eye[4])

    # compute the euclidean distance between the horizontal
    # eye landmark (x, y)-coordinates
    C = dist.euclidean(eye[0], eye[3])

    # compute the eye aspect ratio
    ear = (A + B) / (2.0 * C)

    # return the eye aspect ratio
    return ear


# define two constants, one for the eye aspect ratio to indicate
# blink and then a second constant for the number of consecutive
# frames the eye must be below the threshold
EYE_AR_THRESH = 0.3
EYE_AR_CONSEC_FRAMES = 3

# initialize the frame counters and the total number of blinks
COUNTER = 0
TOTAL = 0

# initialize dlib's face detector (HOG-based) and then create
# the facial landmark predictor
print("[INFO] loading facial landmark predictor...")
detector = dlib.get_frontal_face_detector()
predictor = dlib.shape_predictor(model)

# grab the indexes of the facial landmarks for the left and
# right eye, respectively
(lStart, lEnd) = face_utils.FACIAL_LANDMARKS_IDXS["left_eye"]
(rStart, rEnd) = face_utils.FACIAL_LANDMARKS_IDXS["right_eye"]
# Read the users data and create face encodings

image = face_recognition.load_image_file("esco.jpg")
mface_encoding = face_recognition.face_encodings(image)[0]


known_names = ['OWNER']
known_encods = [mface_encoding]


# BOLT IOT module key and mailgun id to send email alert
mybolt=Bolt(conf.API_KEY,conf.DEVICE_ID)
mailer = Email(econf.MAILGUN_API_KEY, econf.SANDBOX_URL, econf.SENDER_EMAIL, econf.RECIPIENT_EMAIL)
sms_whatsapp = Sms(conf.SID, conf.AUTH_TOKEN, conf.TO_WHATSAPP, conf.FROM_WHATSAPP)

# start the video stream thread
print("[INFO] starting video stream thread...")
fileStream = True
vs = VideoStream(src='http://192.168.0.0:8080/video').start()
# vs = VideoStream(usePiCamera=True).start()
time.sleep(1.0)
# Initialize some variables
face_locations = []
face_encodings = []
face_names = []

# loop over frames from the video stream
while True:
    # grab the frame from the threaded video file stream, resize
    # it, and convert it to grayscale
    # channels)
    frame = vs.read()
    frame = imutils.resize(frame, width=450)
    gray = cv2.cvtColor(frame, cv2.COLOR_BGR2GRAY)
    rgb = cv2.cvtColor(frame, cv2.COLOR_BGR2RGB)
    small_frame = cv2.resize(rgb, (0, 0), fx=0.25, fy=0.25)

    # Find all the faces and face encodings in the current frame of video
    face_locations = face_recognition.face_locations(small_frame)
    face_encodings = face_recognition.face_encodings(small_frame, face_locations)
    name = "Unknown"
    face_names = []
    for face_encoding in face_encodings:
        #for i in range(len(known_encods)):
          # See if the face is a match for the known face(s)
        match = face_recognition.compare_faces(known_encods, face_encoding)

        if match[0]:
             name = known_names[0]

        face_names.append(name)


    # detect faces in the grayscale frame
        rects = detector(gray, 0)

    # loop over the face detections
        for rect in rects:
            # determine the facial landmarks for the face region, then
            # convert the facial landmark (x, y)-coordinates to a NumPy
            # array
            shape = predictor(gray, rect)
            shape = face_utils.shape_to_np(shape)

            # extract the left and right eye coordinates, then use the
            # coordinates to compute the eye aspect ratio for both eyes
            leftEye = shape[lStart:lEnd]
            rightEye = shape[rStart:rEnd]
            leftEAR = eye_aspect_ratio(leftEye)
            rightEAR = eye_aspect_ratio(rightEye)

            # average the eye aspect ratio together for both eyes
            ear = (leftEAR + rightEAR) / 2.0

            # compute the convex hull for the left and right eye, then
            # visualize each of the eyes
            leftEyeHull = cv2.convexHull(leftEye)
            rightEyeHull = cv2.convexHull(rightEye)
            cv2.drawContours(frame, [leftEyeHull], -1, (0, 255, 0), 1)
            cv2.drawContours(frame, [rightEyeHull], -1, (0, 255, 0), 1)

            # check to see if the eye aspect ratio is below the blink
            # threshold, and if so, increment the blink frame counter
            if ear < EYE_AR_THRESH:
                COUNTER += 1

            # otherwise, the eye aspect ratio is not below the blink
            # threshold
            else:
                # if the eyes were closed for a sufficient number of
                # then increment the total number of blinks
                if COUNTER >= EYE_AR_CONSEC_FRAMES:
                    TOTAL += 1
                # reset the eye frame counter
                COUNTER = 0
            # draw the total number of blinks on the frame along with
            # the computed eye aspect ratio for the frame
            cv2.putText(frame, "Blinks: {}".format(TOTAL), (10, 30),
                        cv2.FONT_HERSHEY_SIMPLEX, 0.7, (0, 0, 255), 2)
            cv2.putText(frame, "EAR: {:.2f}".format(ear), (300, 30),
                        cv2.FONT_HERSHEY_SIMPLEX, 0.7, (0, 0, 255), 2)

    #Authorized= False
   # for n in face_names:

     #     if n != 'Unknown' and TOTAL>2 :
        #           Authorized=True



    # Display the results
    for (top, right, bottom, left), name in zip(face_locations, face_names):
            # Scale back up face locations since the frame we detected in was scaled to 1/4 size
            top *= 4
            right *= 4
            bottom *= 4
            left *= 4


            if face_names[0]!='Unknown':
               while TOTAL>=3:

                    # Draw a box around the face
                    cv2.rectangle(frame, (left, top), (right, bottom), (0, 0, 255), 2)
                    font = cv2.FONT_HERSHEY_DUPLEX
                     # Draw a label with a name below the face
                    cv2.rectangle(frame, (left, bottom - 35),
                          (right, bottom), (0, 0, 255), cv2.FILLED)

                    cv2.putText(frame, name, (left + 6, bottom - 6),

                        font, 1.0, (255, 255, 255), 1)
                    cv2.putText(frame, 'Authorized!!!', (frame.shape[1]//2, frame.shape[0]//2), font, 1.0, (0, 255, 0), 1)
                    response=mybolt.digitalWrite('1','HIGH')
                    time.sleep(5)
                    response=mybolt.digitalWrite('1','LOW')
                    break

            else:
                font = cv2.FONT_HERSHEY_DUPLEX
                cv2.putText(frame, 'Intruder!!!', (frame.shape[1]//2, frame.shape[0]//2), font, 1.0, (0, 0, 255), 1)

                print("\n[WARNING] Sending alert to owner INTRUDER DETECTED")
               # response = sms_whatsapp.send_sms("Intruder detected. Someone is trying to open the door.")

               # print("\n [WARNING] Sending e-mail to owner")
               # response = mailer.send_email("Alert", "Intruder Detected")
                response=mybolt.digitalWrite('2','HIGH')
                time.sleep(5)
                response=mybolt.digitalWrite('2','LOW')

    # show the frame
    cv2.imshow("Frame", frame)
    key = cv2.waitKey(1) & 0xFF

    # if the `q` key was pressed, break from the loop
    if key == ord("q"):
        break

# do a bit of cleanup
print("\n [INFO] Exiting Program and cleaning stuff")
cv2.destroyAllWindows()
vs.stop()
