Hand Gesture Controlled Robot Arm Using Arduino – A DIY Guide

In the field of robotics, the use of human gestures to control machines has always been a fascinating concept. With affordable sensors and microcontrollers available today, building a hand gesture-controlled robot arm is no longer just a dream. Techatronic’s project tutorial provides a step-by-step guide to creating a robotic arm that responds to your hand movements using Arduino and MPU6050, a motion tracking sensor.

Project Overview

This DIY project allows you to control a robotic arm simply by moving your hand. Instead of using remote controls or mobile apps, this system uses real-time motion data from the hand to drive servo motors attached to a robotic arm. The main components include an Arduino board, an MPU6050 accelerometer and gyroscope sensor, and a few servo motors.

The MPU6050 sensor reads the orientation and movement of your hand and sends this data to the Arduino, which interprets it and drives the robotic arm accordingly.

Components Required

To build this hand gesture-controlled robotic arm, you will need:

Arduino Uno

• Arduino Uno

MPU6050 sensor

• MPU6050 sensor

4 Servo motors (SG90)

• 4 Servo motors (SG90)

Jumper wires

• Jumper wires

Breadboard

• Breadboard

Glove (optional, for mounting the sensor)

• Glove (optional, for mounting the sensor)

Robotic arm frame (can be made from cardboard, acrylic, or 3D printed)

• Robotic arm frame (can be made from cardboard, acrylic, or 3D printed)

This project requires no complex hardware and can be assembled easily by hobbyists and students alike.

Working Principle

The heart of this project lies in the MPU6050 sensor. It includes a 3-axis gyroscope and a 3-axis accelerometer, making it perfect for detecting the tilt and movement of the hand. The sensor is attached to the back of the hand using a glove or strap.

When you tilt or move your hand, the sensor captures the motion in terms of X, Y, and Z axes. These values are read by the Arduino, which then converts the readings into angles to control each servo motor. Each motor in turn moves a joint of the robotic arm, mimicking the orientation of your hand.

Arduino Code and Sensor Calibration

The tutorial includes complete Arduino code, which is uploaded to the Uno board using the Arduino IDE. The code uses the I2C protocol to read data from the MPU6050 sensor and control the servo motors based on the movement values.

One key step is calibration—ensuring that the servo motors respond correctly to your hand gestures. You can adjust the thresholds in the code to match your natural hand movements.

Applications and Benefits

This project is more than just fun—it has real-world applications:

Prosthetics: Gesture-controlled robotic arms can assist people with physical disabilities.

• Prosthetics: Gesture-controlled robotic arms can assist people with physical disabilities.

Remote operations: Can be used in hazardous environments to operate machinery remotely.

• Remote operations: Can be used in hazardous environments to operate machinery remotely.

Education: Ideal for learning about sensors, Arduino programming, and robotics.

• Education: Ideal for learning about sensors, Arduino programming, and robotics.

Conclusion

Techatronic’s hand gesture-controlled robot arm project is an exciting way to get started with Arduino-based robotics. It’s a perfect blend of hardware and software that teaches core concepts of motion sensing, servo control, and real-world interfacing. Whether you're a student, hobbyist, or aspiring engineer, building this robot arm is both educational and rewarding.
