#include <TimeLib.h> // for Date/Time operations
#include <ESP8266WiFi.h> // for WiFi
#include <WiFiUdp.h> // for UDP NTP
#include <Adafruit_GFX.h> // Core graphics library
#include <Adafruit_ST7735.h> // Hardware-specific library
#include <SPI.h> // Serial Peripheral Interface
#define TFT_CS 15
#define TFT_RST 0
#define TFT_DC 5
// Option 1 (recommended): must use the hardware SPI pins
// (for UNO thats sclk = 13 and sid = 11) and pin 10 must be
// an output. This is much faster - also required if you want
// to use the microSD card (see the image drawing example)
Adafruit_ST7735 tft = Adafruit_ST7735(TFT_CS, TFT_DC, TFT_RST);
// Option 2: use any pins but a little slower!
#define TFT_SCLK 13 // set these to be whatever pins you like!
#define TFT_MOSI 11 // set these to be whatever pins you like!
//Adafruit_ST7735 tft = Adafruit_ST7735(TFT_CS, TFT_DC, TFT_MOSI, TFT_SCLK, TFT_RST);
const int softoffPin = 4;
int softoffState = HIGH;
const int maxLoopsBeforeSoftoff = 10;
char ssid[] = "************"; // your network SSID (name)
char pass[] = "************"; // your network password
// NTP Servers:
IPAddress timeServer(195, 186, 4, 101); // 195.186.4.101 (bwntp2.bluewin.ch)
const char* ntpServerName = "ch.pool.ntp.org";
const int timeZone = 2; // Central European Time (summer time)
WiFiUDP Udp;
unsigned int localPort = 8888; // local port to listen for UDP packets
void setup(void) {
pinMode(softoffPin, OUTPUT);
Serial.begin(115200);
Serial.print("Connecting to wifi ");
Serial.println(ssid);
WiFi.begin(ssid, pass);
while (WiFi.status() != WL_CONNECTED) {
delay(500);
Serial.print(".");
}
Serial.print("IP number assigned by DHCP is ");
Serial.println(WiFi.localIP());
Serial.println("Starting UDP");
Udp.begin(localPort);
Serial.print("Local port: ");
Serial.println(Udp.localPort());
Serial.print("Using NTP Server ");
Serial.println(ntpServerName);
//get a random server from the pool
WiFi.hostByName(ntpServerName, timeServer);
Serial.print("NTP Server IP ");
Serial.println(timeServer);
Serial.println("waiting for sync");
setSyncProvider(getNtpTime);
setSyncInterval(60);
/*
time_t t = getNtpTime();
setTime(t);
*/
digitalClockDisplay();
tft.initR(INITR_144GREENTAB); // initialize a ST7735S chip, black tab
Serial.println("TFT Initialized");
digitalClockDisplayToTft();
Serial.println("Output to TFT done");
}
int counter = 0;
void loop() {
if (counter == maxLoopsBeforeSoftoff) {
Serial.println("System Shutdown");
digitalWrite(softoffPin, softoffState);
}
digitalClockDisplayToTft();
//time = millis() - time;
//Serial.println(time, DEC);
counter ++;
delay(850);
}
/*-------- TFT code ----------*/
void digitalClockDisplayToTft() {
// digital clock display of the time at the TFT
tft.setTextWrap(false);
tft.fillScreen(ST7735_BLACK);
tft.setCursor(0, 20);
tft.setTextColor(ST7735_RED);
tft.setTextSize(1);
tft.println(" NTP Time CH");
tft.setTextColor(ST7735_BLUE);
tft.println("");
tft.println("");
tft.setTextSize(2);
tft.print(" ");
tft.print(hour());
printDigitsToTft(minute());
printDigitsToTft(second());
tft.println("");
tft.println("");
tft.setTextColor(ST7735_GREEN);
tft.setTextSize(2);
tft.print(" ");
tft.print(day());
tft.print(".");
tft.print(month());
tft.print(".");
tft.print(year());
tft.println();
}
void printDigitsToTft(int digits) {
// utility for digital clock display: prints preceding colon and leading 0
tft.print(":");
if (digits < 10)
tft.print('0');
tft.print(digits);
}
/*-------- Serial Debug Code ----------*/
void digitalClockDisplay() {
// digital clock display of the time
Serial.print(hour());
printDigits(minute());
printDigits(second());
Serial.print(" ");
Serial.print(day());
Serial.print(".");
Serial.print(month());
Serial.print(".");
Serial.print(year());
Serial.println("");
}
void printDigits(int digits) {
// utility for digital clock display: prints preceding colon and leading 0
Serial.print(":");
if (digits < 10)
Serial.print('0');
Serial.print(digits);
}
/*-------- NTP code ----------*/
const int NTP_PACKET_SIZE = 48; // NTP time is in the first 48 bytes of message
byte packetBuffer[NTP_PACKET_SIZE]; //buffer to hold incoming & outgoing packets
time_t getNtpTime()
{
while (Udp.parsePacket() > 0) ; // discard any previously received packets
Serial.println("Transmit NTP Request");
sendNTPpacket(timeServer);
uint32_t beginWait = millis();
while (millis() - beginWait < 1500) {
int size = Udp.parsePacket();
if (size >= NTP_PACKET_SIZE) {
Serial.println("Receive NTP Response");
Udp.read(packetBuffer, NTP_PACKET_SIZE); // read packet into the buffer
unsigned long secsSince1900;
// convert four bytes starting at location 40 to a long integer
secsSince1900 = (unsigned long)packetBuffer[40] << 24;
secsSince1900 |= (unsigned long)packetBuffer[41] << 16;
secsSince1900 |= (unsigned long)packetBuffer[42] << 8;
secsSince1900 |= (unsigned long)packetBuffer[43];
return secsSince1900 - 2208988800UL + timeZone * SECS_PER_HOUR;
}
}
Serial.println("No NTP Response :-(");
return 0; // return 0 if unable to get the time
}
// send an NTP request to the time server at the given address
void sendNTPpacket(IPAddress &address)
{
// set all bytes in the buffer to 0
memset(packetBuffer, 0, NTP_PACKET_SIZE);
// Initialize values needed to form NTP request
// (see URL above for details on the packets)
packetBuffer[0] = 0b11100011; // LI, Version, Mode
packetBuffer[1] = 0; // Stratum, or type of clock
packetBuffer[2] = 6; // Polling Interval
packetBuffer[3] = 0xEC; // Peer Clock Precision
// 8 bytes of zero for Root Delay & Root Dispersion
packetBuffer[12] = 49;
packetBuffer[13] = 0x4E;
packetBuffer[14] = 49;
packetBuffer[15] = 52;
// all NTP fields have been given values, now
// you can send a packet requesting a timestamp:
Udp.beginPacket(address, 123); //NTP requests are to port 123
Udp.write(packetBuffer, NTP_PACKET_SIZE);
Udp.endPacket();
}
