"id": "6051a0a58f8d8c1e",
"type": "tab",
"label": "Cloud Application",
"disabled": false,
"info": "",
"env": []
},
{
"id": "c1bdc2dc5a9b24de",
"type": "devicehub-device",
"z": "6051a0a58f8d8c1e",
"name": "Edgeberry Device 2",
"hub": "fc95fc9caa5364e5",
"deviceName": "EDGB-A096",
"x": 690,
"y": 200,
"wires": [
[]
]
},
{
"id": "93a64fa1969f4b39",
"type": "devicehub-device",
"z": "6051a0a58f8d8c1e",
"name": "Edgeberry Device 1",
"hub": "fc95fc9caa5364e5",
"deviceName": "EDGB-9179",
"x": 250,
"y": 200,
"wires": [
[
"b2fb118cc46ea818"
]
]
},
{
"id": "b2fb118cc46ea818",
"type": "function",
"z": "6051a0a58f8d8c1e",
"name": "Switch logic",
"func": "// Only pass telemetry\nif (msg.messageType === \"telemetry\" && msg.payload.data.device == \"switch\") {\n let newmsg = {};\n newmsg.action = \"sendMessage\";\n newmsg.payload = {\n value: msg.payload.data.value,\n device: msg.payload.data.device\n }\n\n return newmsg;\n}\nreturn null;",
"outputs": 1,
"timeout": 0,
"noerr": 0,
"initialize": "",
"finalize": "",
"libs": [],
"x": 470,
"y": 200,
"wires": [
[
"c1bdc2dc5a9b24de",
"9d7e86eedbd1c02d"
]
]
},
{
"id": "c91fcbdc83459b0f",
"type": "function",
"z": "6051a0a58f8d8c1e",
"name": "Direct Method formatting",
"func": "msg.action = \"callDirectMethod\";\nmsg.methodName = \"identify\";\nreturn msg;",
"outputs": 1,
"timeout": 0,
"noerr": 0,
"initialize": "",
"finalize": "",
"libs": [],
"x": 370,
"y": 100,
"wires": [
[
"c1bdc2dc5a9b24de"
]
]
},
{
"id": "2b2ffa9d730a7712",
"type": "ui-button",
"z": "6051a0a58f8d8c1e",
"group": "132c986ec22a160e",
"name": "Identify Device 2",
"label": "Identify Device 2",
"order": 10,
"width": 0,
"height": 0,
"emulateClick": false,
"tooltip": "",
"color": "",
"bgcolor": "",
"className": "",
"icon": "",
"iconPosition": "left",
"payload": "",
"payloadType": "str",
"topic": "topic",
"topicType": "msg",
"buttonColor": "",
"textColor": "",
"iconColor": "",
"enableClick": true,
"enablePointerdown": false,
"pointerdownPayload": "",
"pointerdownPayloadType": "str",
"enablePointerup": false,
"pointerupPayload": "",
"pointerupPayloadType": "str",
"x": 130,
"y": 100,
"wires": [
[
"c91fcbdc83459b0f"
]
]
},
{
"id": "4c69b8695a3953de",
"type": "function",
"z": "6051a0a58f8d8c1e",
"name": "Direct Method formatting",
"func": "msg.action = \"callDirectMethod\";\nmsg.methodName = \"identify\";\nreturn msg;",
"outputs": 1,
"timeout": 0,
"noerr": 0,
"initialize": "",
"finalize": "",
"libs": [],
"x": 370,
"y": 60,
"wires": [
[
"93a64fa1969f4b39"
]
]
},
{
"id": "b575e6e241118b86",
"type": "ui-button",
"z": "6051a0a58f8d8c1e",
"group": "132c986ec22a160e",
"name": "Identify Device 1",
"label": "Identify Device 1",
"order": 9,
"width": 0,
"height": 0,
"emulateClick": false,
"tooltip": "",
"color": "",
"bgcolor": "",
"className": "",
"icon": "",
"iconPosition": "left",
"payload": "",
"payloadType": "str",
"topic": "topic",
"topicType": "msg",
"buttonColor": "",
"textColor": "",
"iconColor": "",
"enableClick": true,
"enablePointerdown": false,
"pointerdownPayload": "",
"pointerdownPayloadType": "str",
"enablePointerup": false,
"pointerupPayload": "",
"pointerupPayloadType": "str",
"x": 130,
"y": 60,
"wires": [
[
"4c69b8695a3953de"
]
]
},
{
"id": "bf88dc30f04c6787",
"type": "function",
"z": "6051a0a58f8d8c1e",
"name": "Cloud-to-Device formatting",
"func": "msg.action = \"sendMessage\"\nmsg.payload = {\"testkey\":\"This is a Cloud-to-Device test message\"}\nreturn msg;",
"outputs": 1,
"timeout": 0,
"noerr": 0,
"initialize": "",
"finalize": "",
"libs": [],
"x": 360,
"y": 340,
"wires": [
[
"93a64fa1969f4b39"
]
]
},
{
"id": "ecdb2bbb675e9cd5",
"type": "ui-button",
"z": "6051a0a58f8d8c1e",
"group": "132c986ec22a160e",
"name": "Cloud-to-Device",
"label": "Cloud-to-Device",
"order": 8,
"width": 0,
"height": 0,
"emulateClick": false,
"tooltip": "",
"color": "",
"bgcolor": "",
"className": "",
"icon": "",
"iconPosition": "left",
"payload": "",
"payloadType": "str",
"topic": "topic",
"topicType": "msg",
"buttonColor": "#0007FF",
"textColor": "",
"iconColor": "",
"enableClick": true,
"enablePointerdown": false,
"pointerdownPayload": "",
"pointerdownPayloadType": "str",
"enablePointerup": false,
"pointerupPayload": "",
"pointerupPayloadType": "str",
"x": 120,
"y": 340,
"wires": [
[
"bf88dc30f04c6787"
]
]
},
{
"id": "9d7e86eedbd1c02d",
"type": "ui-template",
"z": "6051a0a58f8d8c1e",
"group": "132c986ec22a160e",
"page": "",
"ui": "",
"name": "Indicator",
"order": 12,
"width": 0,
"height": 0,
"head": "",
"format": "<template>\n <v-card\n class=\"d-flex align-center justify-space-between pa-3 rounded-lg elevation-1 ff-state-card\"\n >\n <div class=\"text-body-2 text-medium-emphasis\">\n {{ label }}\n </div>\n\n <v-chip\n class=\"state-chip\"\n :color=\"isOn ? 'success' : 'error'\"\n :variant=\"isOn ? 'elevated' : 'flat'\"\n size=\"small\"\n >\n {{ isOn ? 'ON' : 'OFF' }}\n </v-chip>\n </v-card>\n</template>\n\n<script>\nexport default {\n data () {\n return {\n isOn: false,\n label: 'Switch'\n }\n },\n\n mounted () {\n this.updateFromMsg(this.msg)\n },\n\n watch: {\n msg: {\n handler (newMsg) {\n this.updateFromMsg(newMsg)\n },\n deep: true\n }\n },\n\n methods: {\n updateFromMsg (msg) {\n if (!msg || !msg.payload) return\n\n const raw = msg.payload.value\n const s = String(raw).trim().toLowerCase()\n\n // Accept 1/0, true/false, \"1\"/\"0\", \"on\"/\"off\"\n this.isOn =\n raw === true ||\n raw === 1 ||\n s === '1' ||\n s === 'true' ||\n s === 'on'\n\n // Optional label from payload/device/topic if you expand later\n if (msg.payload.device) this.label = msg.payload.device\n else if (msg.topic) this.label = msg.topic\n }\n }\n}\n</script>\n\n<style>\n.ff-state-card {\n min-width: 200px;\n}\n\n.state-chip {\n font-weight: 600;\n letter-spacing: 0.06em;\n}\n</style>",
"storeOutMessages": true,
"passthru": true,
"resendOnRefresh": true,
"templateScope": "local",
"className": "",
"x": 660,
"y": 260,
"wires": [
[]
]
},
{
"id": "fc95fc9caa5364e5",
"type": "devicehub-config",
"name": "",
"host": "localhost",
"port": "8090",
"secure": false
},
{
"id": "132c986ec22a160e",
"type": "ui-group",
"name": "IoT Demo",
"page": "e0cebea875c68ec6",
"width": 6,
"height": 1,
"order": 1,
"showTitle": true,
"className": "",
"visible": "true",
"disabled": "false",
"groupType": "default"
},
{
"id": "e0cebea875c68ec6",
"type": "ui-page",
"name": "IoT Demo",
"ui": "9d29ee82a1080a1e",
"path": "/",
"icon": "home",
"layout": "grid",
"theme": "0c6ddb724b9b3e45",
"breakpoints": [
{
"name": "Default",
"px": "0",
"cols": "3"
},
{
"name": "Tablet",
"px": "576",
"cols": "6"
},
{
"name": "Small Desktop",
"px": "768",
"cols": "9"
},
{
"name": "Desktop",
"px": "1024",
"cols": "12"
}
],
"order": 1,
"className": "",
"visible": "true",
"disabled": "false"
},
{
"id": "9d29ee82a1080a1e",
"type": "ui-base",
"name": "My Dashboard",
"path": "/dashboard",
"appIcon": "",
"includeClientData": true,
"acceptsClientConfig": [
"ui-notification",
"ui-control"
],
"showPathInSidebar": false,
"headerContent": "page",
"navigationStyle": "default",
"titleBarStyle": "default",
"showReconnectNotification": true,
"notificationDisplayTime": 1,
"showDisconnectNotification": true,
"allowInstall": false
},
{
"id": "0c6ddb724b9b3e45",
"type": "ui-theme",
"name": "Default Theme",
"colors": {
"surface": "#ffffff",
"primary": "#0094CE",
"bgPage": "#eeeeee",
"groupBg": "#ffffff",
"groupOutline": "#cccccc"
},
"sizes": {
"density": "default",
"pagePadding": "12px",
"groupGap": "12px",
"groupBorderRadius": "4px",
"widgetGap": "12px"
}
},
{
"id": "1f7619664704989e",
"type": "global-config",
"env": [],
"modules": {
"@edgeberry/devicehub-node-red-contrib": "1.8.1",
"@flowfuse/node-red-dashboard": "1.29.0"
}
}
]
