Implementing Chart. js in Your Angular Application

Install the library

First, you'll need to install the Chart.js library:

npm install chart.js --save

Next, import the module in your Component:

import { Chart } from 'chart.js';

Prepare your data

To render your chart, each dataset should be an array of numbers, or an array of objects formatted like the below, where x and y refer to the axes of the chart:

[{
    x: 1,
    y: 10
},{
    x: 2,
    y: 20
}]

You can substitute the x or y properties with t if you're using the time scale. Use the Array.map() methodto structure your data for Chart.js.

You can also specify labels for the x axis - this must also be an array.

The template

In your Component's template, add a canvas element with a reference variableof your choice. Inside the canvas element, bind to the variable chart. We'll create the variable in the next step.

<canvas #lineChart>{{ chart }}</canvas>

Configuring the chart

Back in your Component, import ViewChild from angular core and add the reference to your canvas element as a private member. Then, add a public variable chart - this will be assigned to a Chart.js instance and will be binded to our template:

import

 @Component({
 ...
 })
 export class myComponent implements OnInit {
   @ViewChild('lineChart') private chartRef;
   chart: any;
   ...

  }

Now that you have your data prepared, and a reference to your canvas element, let's add the basic Chart.js configuration for a line chart with the code below labeled `Chart.js`

Notice that the data.datasets option takes an array - you can have many datasets displaying on the same line chart.

The chart will now display on your page. If you want to fit your chart into a container, you can set the maintainAspectRatio option to false. See the Chart.js documentationfor more configuration options!
