Foldable Drone

DJI F450 is the best frame, but the problem is that it is not easily transportable. So I decided to make my own foldable frame.

Step 1: Design

• Take the printout of the design
• Take two printout of body
• One printout of arm

Step 2: Making Body

• Paste the body print on acrylic sheet
• Cut it out
• You can also use wooden plates

Step 3: Making Arm

• I am using PVC pipe as the arm
• Burn the end and make it flat
• Make the hole for the motor mount
• https://www.instructables.com/id/The-Ultimate-PVC...
• Refer the link for more information

Step 4: Assembling

• Connect the arm and body using screw
• Use double side tape at the end to reduce vibration
• Drill the hole for mounting the flight controller

Step 5: Electronics

• I am using Pixhawk as the flight controller
• Using rewinded motors
• Using 30A esc
• Flysky i6 transmitter
• 8-inch propeller (8040)
• http://ardupilot.org/copter/docs/build-your-own-mu...
• Refer the above site for more information

Step 6: Making Landing Gear

• I am using 4-inch PVC coupler for landing gear
• Refer this video for more information

Step 7: Ready to Fly
