Things used in this project

Hardware components:
Ard lilypadmain
Arduino LilyPad Main Board
×1
10081 01
SparkFun LilyPad LED White (5pcs)
×8
Adafruit industries ada640 image 75px
Sewable Conductive Thread
×1
266 04
Female/Female Jumper Wires
×1
Adafruit industries ada592 image 75px
USB-A to Micro-USB Cable
×1

Schematics

Shirt Schematic
This is view of the matrix of lilypad LEDs from the inside of the shirt
Shirt 437ioznjxk

Code

Shirt CodeArduino
I have some basic methods to show off the shirt, a method that will display a randomly generated "equalizer" and randomly modify it for a set duration, and a couple of methods that "scroll" a word across the screen.
It's not well documented but it works.
//Maddy McGee
unsigned long prevMillis = 0;
unsigned long currentMillis = 0;
const int xAxis[6] = {2,3,4,5,6,7};//HIGH is on
const int yAxis[6] = {8,9,10,11,12,13};//LOW is on
void setup() {
  pinMode(2, OUTPUT);
  pinMode(3, OUTPUT);
  pinMode(4, OUTPUT);
  pinMode(5, OUTPUT);
  pinMode(6, OUTPUT);
  pinMode(7, OUTPUT);
  pinMode(8, OUTPUT);
  pinMode(9, OUTPUT);
  pinMode(10, OUTPUT);
  pinMode(11, OUTPUT);
  pinMode(12, OUTPUT);
  pinMode(13, OUTPUT);
}

void loop() {
  allOn();
  delay(2000);
  allOff();
  delay(500);
  ex();
  boxesIn(1000);
  boxesOut(500);
  equilizer(100,60);
  //ohio(1000);
  //ohioScroll(250);
  //delay(100);
  //IHeartArt(250);
}

void allOn()
{
  digitalWrite(2, HIGH);
  digitalWrite(3, HIGH);
  digitalWrite(4, HIGH);
  digitalWrite(5, HIGH);
  digitalWrite(6, HIGH);
  digitalWrite(7, HIGH);
  digitalWrite(8,LOW);
  digitalWrite(9,LOW);
  digitalWrite(10,LOW);
  digitalWrite(11,LOW);
  digitalWrite(12,LOW);
  digitalWrite(13,LOW);
}
void allOff()
{
  digitalWrite(2, LOW);
  digitalWrite(3, LOW);
  digitalWrite(4, LOW);
  digitalWrite(5, LOW);
  digitalWrite(6, LOW);
  digitalWrite(7, LOW);
  digitalWrite(8,HIGH);
  digitalWrite(9,HIGH);
  digitalWrite(10,HIGH);
  digitalWrite(11,HIGH);
  digitalWrite(12,HIGH);
  digitalWrite(13,HIGH);
}

void XYOn(int x, int y)//0 == far left/bottom, 6 == far right/top
{
  for(int cnt = 0; cnt < 6; cnt++)
  {
    if(cnt == x){
      digitalWrite(xAxis[cnt], HIGH);
      }
    else
      digitalWrite(xAxis[cnt], LOW);
  }
  for(int cnt = 0; cnt < 6; cnt++)
  {
    if(cnt == y){
      digitalWrite(yAxis[cnt], LOW);
      }
    else
      digitalWrite(yAxis[cnt], HIGH);
  }
}

void XOn(int x)
{
  for(int cnt = 0; cnt < 6; cnt++)
  {
    if(cnt == x){
      digitalWrite(xAxis[cnt], HIGH);
      }
    else
      digitalWrite(xAxis[cnt], LOW);
  }
}

void YOn(int y)
{
  for(int cnt = 0; cnt < 6; cnt++)
  {
    if(cnt == y){
      digitalWrite(yAxis[cnt], HIGH);
      }
    else
      digitalWrite(yAxis[cnt], LOW);
  }
}

void bihScroll()
{
  allOff();
  //unsigned long start = currentMillis;
  boolean done = false;
  int count = 0;
  while(count<500)//(currentMillis - start < 100)
  {
    count++;
    currentMillis = millis();
    digitalWrite(yAxis[0], LOW);
    digitalWrite(yAxis[1], LOW);
    digitalWrite(yAxis[2], LOW);
    digitalWrite(yAxis[3], LOW);
    digitalWrite(yAxis[4], LOW);
    digitalWrite(yAxis[5], LOW);
    XOn(5);
    delay(1);
  }
  while(count<1000)//(currentMillis - start < 200)
  {
    count++;
    allOff();
    currentMillis = millis();
    if(count%2==0)//(currentMillis%2==0)
    {
      digitalWrite(yAxis[0], LOW);
      digitalWrite(yAxis[1], LOW);
     digitalWrite(yAxis[2], LOW);
      digitalWrite(yAxis[3], LOW);
      digitalWrite(yAxis[4], LOW);
      digitalWrite(yAxis[5], LOW);
      XOn(4);
    }
    else
    {
      digitalWrite(xAxis[5], HIGH);
      digitalWrite(yAxis[0], LOW);
      digitalWrite(yAxis[2], LOW);
      digitalWrite(yAxis[3], LOW);
      digitalWrite(yAxis[5], LOW);
    }
    delay(1);
   }
   while(count<1500)//(currentMillis - start < 300)
   {
    count++;
    allOff();
    if(count%3==0)//(currentMillis%3==0)
    {
      digitalWrite(yAxis[0], LOW);
      digitalWrite(yAxis[1], LOW);
      digitalWrite(yAxis[2], LOW);
      digitalWrite(yAxis[3], LOW);
      digitalWrite(yAxis[4], LOW);
      digitalWrite(yAxis[5], LOW);
       XOn(3);

    }
    else if(count%2==0)//(currentMillis%2==0)
    {
      digitalWrite(xAxis[4], HIGH);
      digitalWrite(yAxis[0], LOW);
      digitalWrite(yAxis[2], LOW);
      digitalWrite(yAxis[3], LOW);
      digitalWrite(yAxis[5], LOW);
    }
    else
    {
      digitalWrite(xAxis[5], HIGH);
      digitalWrite(yAxis[1], LOW);
      digitalWrite(yAxis[4], LOW);
    }
   delay(1);
  }
  while(count<2000)
  {
    count++;
    allOff();
    if(count%4==0)
    {
      digitalWrite(yAxis[0], LOW);
      digitalWrite(yAxis[1], LOW);
      digitalWrite(yAxis[2], LOW);
      digitalWrite(yAxis[3], LOW);
      digitalWrite(yAxis[4], LOW);
      digitalWrite(yAxis[5], LOW);
       XOn(2);
    }
    else if(count%3==0)
    {
      digitalWrite(xAxis[3], HIGH);
      digitalWrite(yAxis[0], LOW);
      digitalWrite(yAxis[2], LOW);
      digitalWrite(yAxis[3], LOW);
      digitalWrite(yAxis[5], LOW);
    }
    else if(count%2==0)
    {
      digitalWrite(xAxis[4], HIGH);
      digitalWrite(yAxis[1], LOW);
      digitalWrite(yAxis[4], LOW);
    }
    else
    {
      digitalWrite(xAxis[5],HIGH);
      digitalWrite(yAxis[0],LOW);
      digitalWrite(yAxis[5],LOW);
    }
    delay(1);
  }
  while(count<2500)
  {
    count++;
    allOff();
    if(count%4==0)
    {
      digitalWrite(yAxis[0], LOW);
      digitalWrite(yAxis[1], LOW);
      digitalWrite(yAxis[2], LOW);
      digitalWrite(yAxis[3], LOW);
      digitalWrite(yAxis[4], LOW);
      digitalWrite(yAxis[5], LOW);
       XOn(1);
       XOn(5);
    }
    else if(count%3==0)
    {
      digitalWrite(xAxis[2], HIGH);
      digitalWrite(yAxis[0], LOW);
      digitalWrite(yAxis[2], LOW);
      digitalWrite(yAxis[3], LOW);
      digitalWrite(yAxis[5], LOW);
    }
    else if(count%2==0)
    {
      digitalWrite(xAxis[3], HIGH);
      digitalWrite(yAxis[1], LOW);
      digitalWrite(yAxis[4], LOW);
    }
    else
    {
      digitalWrite(xAxis[4],HIGH);
      digitalWrite(yAxis[0],LOW);
      digitalWrite(yAxis[5],LOW);
    }
    delay(1);
  }
  while(count<3000)
  {
    count++;
    allOff();
    if(count%4==0)
    {
      digitalWrite(yAxis[0], LOW);
      digitalWrite(yAxis[1], LOW);
      digitalWrite(yAxis[2], LOW);
      digitalWrite(yAxis[3], LOW);
      digitalWrite(yAxis[4], LOW);
      digitalWrite(yAxis[5], LOW);
       XOn(0);
       XOn(4);
    }
    else if(count%3==0)
    {
      digitalWrite(xAxis[1], HIGH);
      digitalWrite(yAxis[0], LOW);
      digitalWrite(yAxis[2], LOW);
      digitalWrite(yAxis[3], LOW);
      digitalWrite(yAxis[5], LOW);
    }
    else if(count%2==0)
    {
      digitalWrite(xAxis[2], HIGH);
      digitalWrite(yAxis[1], LOW);
      digitalWrite(yAxis[4], LOW);
    }
    else
    {
      digitalWrite(xAxis[3],HIGH);
      digitalWrite(xAxis[5],HIGH);
      digitalWrite(yAxis[0],LOW);
      digitalWrite(yAxis[5],LOW);
    }
    delay(1);
  }
  while(count<3500)
  {
    count++;
    allOff();
    if(count%4==0)
    {
      digitalWrite(yAxis[0], LOW);
      digitalWrite(yAxis[1], LOW);
      digitalWrite(yAxis[2], LOW);
      digitalWrite(yAxis[3], LOW);
      digitalWrite(yAxis[4], LOW);
      digitalWrite(yAxis[5], LOW);
       XOn(3);
       XOn(5);
    }
    else if(count%3==0)
    {
      digitalWrite(xAxis[0], HIGH);
      digitalWrite(yAxis[0], LOW);
      digitalWrite(yAxis[2], LOW);
      digitalWrite(yAxis[3], LOW);
      digitalWrite(yAxis[5], LOW);
    }
    else if(count%2==0)
    {
      digitalWrite(xAxis[1], HIGH);
      digitalWrite(yAxis[1], LOW);
      digitalWrite(yAxis[4], LOW);
    }
    else
    {
      digitalWrite(xAxis[2],HIGH);
      digitalWrite(xAxis[4],HIGH);
      digitalWrite(yAxis[0],LOW);
      digitalWrite(yAxis[5],LOW);
    }
    delay(1);
  }
  while(count<4000)
  {
    count++;
    allOff();
    if(count%4==0)
    {
      digitalWrite(yAxis[0], LOW);
      digitalWrite(yAxis[1], LOW);
      digitalWrite(yAxis[2], LOW);
      digitalWrite(yAxis[3], LOW);
      digitalWrite(yAxis[4], LOW);
      digitalWrite(yAxis[5], LOW);
       XOn(2);
       XOn(4);
    }
    else if(count%3==0)
    {
      XYOn(5,3);
    }
    else if(count%2==0)
    {
      digitalWrite(xAxis[0], HIGH);
      digitalWrite(yAxis[1], LOW);
      digitalWrite(yAxis[4], LOW);
    }
    else
    {
      digitalWrite(xAxis[1],HIGH);
      digitalWrite(xAxis[3],HIGH);
      digitalWrite(yAxis[0],LOW);
      digitalWrite(yAxis[5],LOW);
    }
    delay(1);
  }
  while(count<4500)
  {
    count++;
    allOff();
    if(count%3==0)
    {
      digitalWrite(yAxis[0], LOW);
      digitalWrite(yAxis[1], LOW);
      digitalWrite(yAxis[2], LOW);
      digitalWrite(yAxis[3], LOW);
      digitalWrite(yAxis[4], LOW);
      digitalWrite(yAxis[5], LOW);
       XOn(1);
       XOn(3);
       XOn(5);
    }
    else if(count%2==0)
    {
      XYOn(4,3);
    }
    else
    {
      digitalWrite(xAxis[0],HIGH);
      digitalWrite(xAxis[2],HIGH);
      digitalWrite(yAxis[0],LOW);
      digitalWrite(yAxis[5],LOW);
    }
    delay(1);
  }
  while(count<5000)
  {
    count++;
    allOff();
    if(count%3==0)
    {
      digitalWrite(yAxis[0], LOW);
      digitalWrite(yAxis[1], LOW);
      digitalWrite(yAxis[2], LOW);
      digitalWrite(yAxis[3], LOW);
      digitalWrite(yAxis[4], LOW);
      digitalWrite(yAxis[5], LOW);
       XOn(0);
       XOn(2);
       XOn(4);
    }
    else if(count%2==0)
    {
      XYOn(3,3);
    }
    else
    {
      digitalWrite(xAxis[1],HIGH);
      digitalWrite(yAxis[0],LOW);
      digitalWrite(yAxis[5],LOW);
    }
    delay(1);
  }
  while(count<5500)
  {
    count++;
    allOff();
    if(count%3==0)
    {
      digitalWrite(yAxis[0], LOW);
      digitalWrite(yAxis[1], LOW);
      digitalWrite(yAxis[2], LOW);
      digitalWrite(yAxis[3], LOW);
      digitalWrite(yAxis[4], LOW);
      digitalWrite(yAxis[5], LOW);
       XOn(1);
       XOn(3);
    }
    else if(count%2==0)
    {
      XYOn(2,3);
    }
    else
    {
      digitalWrite(xAxis[0],HIGH);
      digitalWrite(yAxis[0],LOW);
      digitalWrite(yAxis[5],LOW);
    }
    delay(1);
  }
  while(count<6000)
  {
    count++;
    allOff();
    if(count%2==0)
    {
      digitalWrite(yAxis[0], LOW);
      digitalWrite(yAxis[1], LOW);
      digitalWrite(yAxis[2], LOW);
      digitalWrite(yAxis[3], LOW);
      digitalWrite(yAxis[4], LOW);
      digitalWrite(yAxis[5], LOW);
       XOn(0);
       XOn(2);
    }
    else
    {
      XYOn(1,3);
    }
    delay(1);
  }
  while(count<6500)
  {
    count++;
    allOff();
    if(count%2==0)
    {
      digitalWrite(yAxis[0], LOW);
      digitalWrite(yAxis[1], LOW);
      digitalWrite(yAxis[2], LOW);
      digitalWrite(yAxis[3], LOW);
      digitalWrite(yAxis[4], LOW);
      digitalWrite(yAxis[5], LOW);
       XOn(1);
    }
    else
    {
      XYOn(0,3);
    }
    delay(1);
  }
  while(count<7000)
  {
    count++;
    allOff();
      digitalWrite(yAxis[0], LOW);
      digitalWrite(yAxis[1], LOW);
      digitalWrite(yAxis[2], LOW);
      digitalWrite(yAxis[3], LOW);
      digitalWrite(yAxis[4], LOW);
      digitalWrite(yAxis[5], LOW);
       XOn(0);
    delay(1);
  }
  allOff();
  delay(500);
}

void ex()
{
  allOff();
  digitalWrite(xAxis[0],HIGH);
  digitalWrite(xAxis[5],HIGH);
  digitalWrite(yAxis[0],LOW);
  digitalWrite(yAxis[5],LOW);
  delay(300);
  allOff();
  digitalWrite(xAxis[1],HIGH);
  digitalWrite(xAxis[4],HIGH);
  digitalWrite(yAxis[1],LOW);
  digitalWrite(yAxis[4],LOW);
  delay(300);
  allOff();
  digitalWrite(xAxis[2],HIGH);
  digitalWrite(xAxis[3],HIGH);
  digitalWrite(yAxis[2],LOW);
  digitalWrite(yAxis[3],LOW);
  delay(500);
  int count =0;
  while(count<700)
  {
    allOff();
    count++;
    if(count%2==0)
    {
      digitalWrite(xAxis[1],HIGH);
      digitalWrite(xAxis[4],HIGH);
      digitalWrite(yAxis[1],LOW);
      digitalWrite(yAxis[4],LOW);
    }
    else
    {
      digitalWrite(xAxis[2],HIGH);
      digitalWrite(xAxis[3],HIGH);
      digitalWrite(yAxis[2],LOW);
      digitalWrite(yAxis[3],LOW);
    }
  }
  while(count<2000)
  {
    allOff();
    count++;
    if(count%3==0)
    {
      digitalWrite(xAxis[0],HIGH);
      digitalWrite(xAxis[5],HIGH);
      digitalWrite(yAxis[0],LOW);
      digitalWrite(yAxis[5],LOW);
    }
    else if(count %2 ==0)
    {
      digitalWrite(xAxis[1],HIGH);
      digitalWrite(xAxis[4],HIGH);
      digitalWrite(yAxis[1],LOW);
      digitalWrite(yAxis[4],LOW);
    }
    else
    {
      digitalWrite(xAxis[2],HIGH);
      digitalWrite(xAxis[3],HIGH);
      digitalWrite(yAxis[2],LOW);
      digitalWrite(yAxis[3],LOW);
    }
    delay(1);
  }
}

void boxesIn(int rate)
{
  int count = 0;
  while(count<rate)
  {
    allOff();
    count++;
    if(count%2==0)
    {
      digitalWrite(xAxis[0],HIGH);
      digitalWrite(xAxis[5],HIGH);
      digitalWrite(yAxis[0],LOW);
      digitalWrite(yAxis[1],LOW);
      digitalWrite(yAxis[2],LOW);
      digitalWrite(yAxis[3],LOW);
      digitalWrite(yAxis[4],LOW);
      digitalWrite(yAxis[5],LOW);
    }
    else
    {
      digitalWrite(xAxis[0],HIGH);
      digitalWrite(xAxis[1],HIGH);
      digitalWrite(xAxis[2],HIGH);
      digitalWrite(xAxis[3],HIGH);
      digitalWrite(xAxis[4],HIGH);
      digitalWrite(xAxis[5],HIGH);
      digitalWrite(yAxis[0],LOW);
      digitalWrite(yAxis[5],LOW);
    }
    delay(1);
  }
  while(count<(2*rate))
  {
    allOff();
    count++;
    if(count%2==0)
    {
      digitalWrite(xAxis[1],HIGH);
      digitalWrite(xAxis[4],HIGH);
      digitalWrite(yAxis[1],LOW);
      digitalWrite(yAxis[2],LOW);
      digitalWrite(yAxis[3],LOW);
      digitalWrite(yAxis[4],LOW);
    }
    else
    {
      digitalWrite(xAxis[1],HIGH);
      digitalWrite(xAxis[2],HIGH);
      digitalWrite(xAxis[3],HIGH);
      digitalWrite(xAxis[4],HIGH);
      digitalWrite(yAxis[1],LOW);
      digitalWrite(yAxis[4],LOW);
    }
    delay(1);
  }
  while(count<(3*rate))
  {
    allOff();
    count++;
      digitalWrite(xAxis[2],HIGH);
      digitalWrite(xAxis[3],HIGH);
      digitalWrite(yAxis[2],LOW);
      digitalWrite(yAxis[3],LOW);
    delay(1);
  }
}

void boxesOut(int rate)
{
  int count = 0;
  while(count<rate)
  {
    allOff();
    count++;
      digitalWrite(xAxis[2],HIGH);
      digitalWrite(xAxis[3],HIGH);
      digitalWrite(yAxis[2],LOW);
      digitalWrite(yAxis[3],LOW);
    delay(1);
  }
  while(count<(2*rate))
  {
    allOff();
    count++;
    if(count%2==0)
    {
      digitalWrite(xAxis[1],HIGH);
      digitalWrite(xAxis[4],HIGH);
      digitalWrite(yAxis[1],LOW);
      digitalWrite(yAxis[2],LOW);
      digitalWrite(yAxis[3],LOW);
      digitalWrite(yAxis[4],LOW);
    }
    else
    {
      digitalWrite(xAxis[1],HIGH);
      digitalWrite(xAxis[2],HIGH);
      digitalWrite(xAxis[3],HIGH);
      digitalWrite(xAxis[4],HIGH);
      digitalWrite(yAxis[1],LOW);
      digitalWrite(yAxis[4],LOW);
    }
    delay(1);
  }
  while(count<(3*rate))
  {
    allOff();
    count++;
    if(count%2==0)
    {
      digitalWrite(xAxis[0],HIGH);
      digitalWrite(xAxis[5],HIGH);
      digitalWrite(yAxis[0],LOW);
      digitalWrite(yAxis[1],LOW);
      digitalWrite(yAxis[2],LOW);
      digitalWrite(yAxis[3],LOW);
      digitalWrite(yAxis[4],LOW);
      digitalWrite(yAxis[5],LOW);
    }
    else
    {
      digitalWrite(xAxis[0],HIGH);
      digitalWrite(xAxis[1],HIGH);
      digitalWrite(xAxis[2],HIGH);
      digitalWrite(xAxis[3],HIGH);
      digitalWrite(xAxis[4],HIGH);
      digitalWrite(xAxis[5],HIGH);
      digitalWrite(yAxis[0],LOW);
      digitalWrite(yAxis[5],LOW);
    }
    delay(1);
  }
}

void equilizer(int duration, int times)
{
  int zero, one, two, three, four, five;
  zero = random(1,6);
  one = random(1,6);
  two = random(1,6);
  three = random(1,6);
  four = random(1,6);
  five = random(1,6);
  for(int l = 0; l < times; l++)
  {
  int count = 0;
  while(count < duration)
  {
    allOff();
    count++;
    if(count%6 == 0)
    {
      digitalWrite(xAxis[0],HIGH);
      for(int h = 0; h < zero; h++)
      {
        digitalWrite(yAxis[h], LOW);
      }
    }
    else if(count%5 == 0)
    {
      digitalWrite(xAxis[1],HIGH);
      for(int h = 0; h < one; h++)
      {
        digitalWrite(yAxis[h], LOW);
      }
    }
    else if(count%4 == 0)
    {
     digitalWrite(xAxis[2],HIGH);
      for(int h = 0; h < two; h++)
      {
        digitalWrite(yAxis[h], LOW);
      }
    }
    else if(count%3 == 0)
    {
     digitalWrite(xAxis[3],HIGH);
      for(int h = 0; h < three; h++)
      {
        digitalWrite(yAxis[h], LOW);
      }
    }
    else if(count%2 == 0)
    {
      digitalWrite(xAxis[4],HIGH);
      for(int h = 0; h < four; h++)
      {
        digitalWrite(yAxis[h], LOW);
      }
    }
    else
    {
     digitalWrite(xAxis[5],HIGH);
      for(int h = 0; h < five; h++)
      {
        digitalWrite(yAxis[h], LOW);
      }
    }
    delay(1);
  }
  int add = random(-1,2);
  if(add + zero >= 0 && add + zero <6)
  {
    zero+=add;
  }
  add = random(-1,2);
  if(add + one >= 0 && add + one <6)
  {
    one+=add;
  }
  add = random(-1,2);
  if(add + two >= 0 && add + two <6)
  {
    two+=add;
  }
  add = random(-1,2);
  if(add + three >= 0 && add + three <6)
  {
    three+=add;
  }
  add = random(-1,2);
  if(add + four >= 0 && add + four <6)
  {
    four+=add;
  }
  add = random(-1,2);
  if(add + five >= 0 && add + five <6)
  {
    five+=add;
  }
  }
}

void ohio(int duration)
{
  int count = 0;
  while(count < duration)
  {
    allOff();
    count ++;
    if(count%4 == 0)
    {
      digitalWrite(xAxis[0],HIGH);
      digitalWrite(xAxis[2],HIGH);
      digitalWrite(yAxis[1], LOW);
      digitalWrite(yAxis[2], LOW);
      digitalWrite(yAxis[3], LOW);
      digitalWrite(yAxis[4], LOW);
    }
    else if(count%3==0)
    {
      digitalWrite(xAxis[1], HIGH);
      digitalWrite(yAxis[0], LOW);
      digitalWrite(yAxis[5],LOW);
    }
    else if(count%2==0)
    {
      digitalWrite(xAxis[3],HIGH);
      digitalWrite(xAxis[5],HIGH);
      digitalWrite(yAxis[0],LOW);
      digitalWrite(yAxis[1], LOW);
      digitalWrite(yAxis[2], LOW);
      digitalWrite(yAxis[3], LOW);
      digitalWrite(yAxis[4], LOW);
      digitalWrite(yAxis[5],LOW);
    }
    else
    {
      XYOn(4,2);
    }
    delay(1);
  }
  allOff();
  delay(10);
   while(count < duration *2)
  {
    allOff();
    count ++;
    if(count%3 == 0)
    {
      digitalWrite(xAxis[3],HIGH);
      digitalWrite(xAxis[5],HIGH);
      digitalWrite(yAxis[1], LOW);
      digitalWrite(yAxis[2], LOW);
      digitalWrite(yAxis[3], LOW);
      digitalWrite(yAxis[4], LOW);
    }
    else if(count%2==0)
    {
      digitalWrite(xAxis[0],HIGH);
      digitalWrite(xAxis[2], HIGH);
      digitalWrite(xAxis[4], HIGH);
      digitalWrite(yAxis[0], LOW);
      digitalWrite(yAxis[5],LOW);
    }
    else
    {
      digitalWrite(xAxis[1],HIGH);
      digitalWrite(yAxis[0],LOW);
      digitalWrite(yAxis[1], LOW);
      digitalWrite(yAxis[2], LOW);
      digitalWrite(yAxis[3], LOW);
      digitalWrite(yAxis[4], LOW);
      digitalWrite(yAxis[5],LOW);
    }
    delay(1);
  }
}

void ohioScroll(int duration)
{
  int count = 0;
  while(count < duration)
  {
    allOff();
    count++;
     digitalWrite(xAxis[5],HIGH);
     digitalWrite(yAxis[1], LOW);
     digitalWrite(yAxis[2], LOW);
     digitalWrite(yAxis[3], LOW);
     digitalWrite(yAxis[4], LOW);
    delay(1);
  }
  count = 0;
  while(count < duration)
  {
    allOff();
    count++;
    if(count%2==0)
    {
      digitalWrite(xAxis[4],HIGH);
     digitalWrite(yAxis[1], LOW);
     digitalWrite(yAxis[2], LOW);
     digitalWrite(yAxis[3], LOW);
     digitalWrite(yAxis[4], LOW);
    }
    else
    {
      digitalWrite(xAxis[5], HIGH);
      digitalWrite(yAxis[0], LOW);
      digitalWrite(yAxis[5],LOW);
    }
    delay(1);
  }
  count = 0;
  while(count < duration)
  {
    allOff();
    count++;
    if(count%2==0)
    {
     digitalWrite(xAxis[3],HIGH);
     digitalWrite(xAxis[5],HIGH);
     digitalWrite(yAxis[1], LOW);
     digitalWrite(yAxis[2], LOW);
     digitalWrite(yAxis[3], LOW);
     digitalWrite(yAxis[4], LOW);
    }
    else
    {
      digitalWrite(xAxis[4], HIGH);
      digitalWrite(yAxis[0], LOW);
      digitalWrite(yAxis[5],LOW);
    }
    delay(1);
  }
  count = 0;
  while(count < duration)
  {
    allOff();
    count++;
    if(count%2==0)
    {
     digitalWrite(xAxis[2],HIGH);
     digitalWrite(xAxis[4],HIGH);
     digitalWrite(yAxis[1], LOW);
     digitalWrite(yAxis[2], LOW);
     digitalWrite(yAxis[3], LOW);
     digitalWrite(yAxis[4], LOW);
    }
    else
    {
      digitalWrite(xAxis[3], HIGH);
      digitalWrite(yAxis[0], LOW);
      digitalWrite(yAxis[5],LOW);
    }
    delay(1);
  }
  count = 0;
  while(count < duration)
  {
    allOff();
    count++;
    if(count%3==0)
    {
     digitalWrite(xAxis[1],HIGH);
     digitalWrite(xAxis[3],HIGH);
     digitalWrite(yAxis[1], LOW);
     digitalWrite(yAxis[2], LOW);
     digitalWrite(yAxis[3], LOW);
     digitalWrite(yAxis[4], LOW);
    }
    else if(count%2==0)
    {
      digitalWrite(xAxis[2], HIGH);
      digitalWrite(yAxis[0], LOW);
      digitalWrite(yAxis[5],LOW);
    }
    else
    {
      digitalWrite(xAxis[5],HIGH);
      digitalWrite(yAxis[0],LOW);
      digitalWrite(yAxis[1], LOW);
      digitalWrite(yAxis[2], LOW);
      digitalWrite(yAxis[3], LOW);
      digitalWrite(yAxis[4], LOW);
      digitalWrite(yAxis[5],LOW);
    }
    delay(1);
  }
  count = 0;
  while(count < duration)
  {
    allOff();
    count++;
    if(count%4==0)
    {
     digitalWrite(xAxis[0],HIGH);
     digitalWrite(xAxis[2],HIGH);
     digitalWrite(yAxis[1], LOW);
     digitalWrite(yAxis[2], LOW);
     digitalWrite(yAxis[3], LOW);
     digitalWrite(yAxis[4], LOW);
    }
    else if(count%3==0)
    {
      digitalWrite(xAxis[1], HIGH);
      digitalWrite(yAxis[0], LOW);
      digitalWrite(yAxis[5],LOW);
    }
    else if(count%2==0)
    {
      digitalWrite(xAxis[4],HIGH);
      digitalWrite(yAxis[0],LOW);
      digitalWrite(yAxis[1], LOW);
      digitalWrite(yAxis[2], LOW);
      digitalWrite(yAxis[3], LOW);
      digitalWrite(yAxis[4], LOW);
      digitalWrite(yAxis[5],LOW);
    }
    else
    {
      XYOn(5,2);
    }
    delay(1);
  }
  count = 0;
  while(count < duration)
  {
    allOff();
    count++;
    if(count%4==0)
    {
     digitalWrite(xAxis[1],HIGH);
     digitalWrite(yAxis[1], LOW);
     digitalWrite(yAxis[2], LOW);
     digitalWrite(yAxis[3], LOW);
     digitalWrite(yAxis[4], LOW);
    }
    else if(count%3==0)
    {
      digitalWrite(xAxis[0], HIGH);
      digitalWrite(yAxis[0], LOW);
      digitalWrite(yAxis[5],LOW);
    }
    else if(count%2==0)
    {
      digitalWrite(xAxis[3],HIGH);
      digitalWrite(xAxis[5],HIGH);
      digitalWrite(yAxis[0],LOW);
      digitalWrite(yAxis[1], LOW);
      digitalWrite(yAxis[2], LOW);
      digitalWrite(yAxis[3], LOW);
      digitalWrite(yAxis[4], LOW);
      digitalWrite(yAxis[5],LOW);
    }
    else
    {
      XYOn(4,2);
    }
    delay(1);
  }
  count = 0;
  while(count < duration)
  {
    allOff();
    count++;
    if(count%3==0)
    {
     digitalWrite(xAxis[0],HIGH);
     digitalWrite(yAxis[1], LOW);
     digitalWrite(yAxis[2], LOW);
     digitalWrite(yAxis[3], LOW);
     digitalWrite(yAxis[4], LOW);
    }
    else if(count%2==0)
    {
      digitalWrite(xAxis[2],HIGH);
      digitalWrite(xAxis[4],HIGH);
      digitalWrite(yAxis[0],LOW);
      digitalWrite(yAxis[1], LOW);
      digitalWrite(yAxis[2], LOW);
      digitalWrite(yAxis[3], LOW);
      digitalWrite(yAxis[4], LOW);
      digitalWrite(yAxis[5],LOW);
    }
    else
    {
      XYOn(3,2);
    }
    delay(1);
  }
  count = 0;
  while(count < duration)
  {
    allOff();
    count++;
    if(count%3==0)
    {
      digitalWrite(xAxis[5], HIGH);
      digitalWrite(yAxis[0], LOW);
      digitalWrite(yAxis[5],LOW);
    }
    else if(count%2==0)
    {
      digitalWrite(xAxis[1],HIGH);
      digitalWrite(xAxis[3],HIGH);
      digitalWrite(yAxis[0],LOW);
      digitalWrite(yAxis[1], LOW);
      digitalWrite(yAxis[2], LOW);
      digitalWrite(yAxis[3], LOW);
      digitalWrite(yAxis[4], LOW);
      digitalWrite(yAxis[5],LOW);
    }
    else
    {
      XYOn(2,2);
    }
    delay(1);
  }
   count = 0;
  while(count < duration)
  {
    allOff();
    count++;
    if(count%3==0)
    {
      digitalWrite(xAxis[4], HIGH);
      digitalWrite(yAxis[0], LOW);
      digitalWrite(yAxis[5],LOW);
    }
    else if(count%2==0)
    {
      digitalWrite(xAxis[0],HIGH);
      digitalWrite(xAxis[2],HIGH);
      digitalWrite(xAxis[5],HIGH);
      digitalWrite(yAxis[0],LOW);
      digitalWrite(yAxis[1], LOW);
      digitalWrite(yAxis[2], LOW);
      digitalWrite(yAxis[3], LOW);
      digitalWrite(yAxis[4], LOW);
      digitalWrite(yAxis[5],LOW);
    }
    else
    {
      XYOn(1,2);
    }
    delay(1);
  }
  count = 0;
  while(count < duration)
  {
    allOff();
    count++;
    if(count%3==0)
    {
      digitalWrite(xAxis[3], HIGH);
      digitalWrite(xAxis[5], HIGH);
      digitalWrite(yAxis[0], LOW);
      digitalWrite(yAxis[5],LOW);
    }
    else if(count%2==0)
    {
      digitalWrite(xAxis[1],HIGH);
      digitalWrite(xAxis[4],HIGH);
      digitalWrite(yAxis[0],LOW);
      digitalWrite(yAxis[1], LOW);
      digitalWrite(yAxis[2], LOW);
      digitalWrite(yAxis[3], LOW);
      digitalWrite(yAxis[4], LOW);
      digitalWrite(yAxis[5],LOW);
    }
    else
    {
      XYOn(0,2);
    }
    delay(1);
  }
  count = 0;
  while(count < duration)
  {
    allOff();
    count++;
    if(count%2==0)
    {
      digitalWrite(xAxis[2], HIGH);
      digitalWrite(xAxis[4], HIGH);
      digitalWrite(yAxis[0], LOW);
      digitalWrite(yAxis[5],LOW);
    }
    else
    {
      digitalWrite(xAxis[0],HIGH);
      digitalWrite(xAxis[3],HIGH);
      digitalWrite(yAxis[0],LOW);
      digitalWrite(yAxis[1], LOW);
      digitalWrite(yAxis[2], LOW);
      digitalWrite(yAxis[3], LOW);
      digitalWrite(yAxis[4], LOW);
      digitalWrite(yAxis[5],LOW);
    }
    delay(1);
  }
  count = 0;
  while(count < duration)
  {
    allOff();
    count++;
    if(count%3==0)
    {
      digitalWrite(xAxis[1], HIGH);
      digitalWrite(xAxis[3], HIGH);
      digitalWrite(yAxis[0], LOW);
      digitalWrite(yAxis[5],LOW);
    }
    else if(count%2==0)
    {
      digitalWrite(xAxis[2],HIGH);
      digitalWrite(yAxis[0],LOW);
      digitalWrite(yAxis[1], LOW);
      digitalWrite(yAxis[2], LOW);
      digitalWrite(yAxis[3], LOW);
      digitalWrite(yAxis[4], LOW);
      digitalWrite(yAxis[5],LOW);
    }
    else
    {
     digitalWrite(xAxis[5],HIGH);
     digitalWrite(yAxis[1], LOW);
     digitalWrite(yAxis[2], LOW);
     digitalWrite(yAxis[3], LOW);
     digitalWrite(yAxis[4], LOW);
    }
    delay(1);
  }
  count = 0;
  while(count < duration)
  {
    allOff();
    count++;
    if(count%3==0)
    {
      digitalWrite(xAxis[0], HIGH);
      digitalWrite(xAxis[2], HIGH);
      digitalWrite(xAxis[5], HIGH);
      digitalWrite(yAxis[0], LOW);
      digitalWrite(yAxis[5],LOW);
    }
    else if(count%2==0)
    {
      digitalWrite(xAxis[1],HIGH);
      digitalWrite(yAxis[0],LOW);
      digitalWrite(yAxis[1], LOW);
      digitalWrite(yAxis[2], LOW);
      digitalWrite(yAxis[3], LOW);
      digitalWrite(yAxis[4], LOW);
      digitalWrite(yAxis[5],LOW);
    }
    else
    {
     digitalWrite(xAxis[4],HIGH);
     digitalWrite(yAxis[1], LOW);
     digitalWrite(yAxis[2], LOW);
     digitalWrite(yAxis[3], LOW);
     digitalWrite(yAxis[4], LOW);
    }
    delay(1);
  }
  count = 0;
  while(count < duration)
  {
    allOff();
    count++;
    if(count%3==0)
    {
      digitalWrite(xAxis[1], HIGH);
      digitalWrite(xAxis[4], HIGH);
      digitalWrite(yAxis[0], LOW);
      digitalWrite(yAxis[5],LOW);
    }
    else if(count%2==0)
    {
      digitalWrite(xAxis[0],HIGH);
      digitalWrite(yAxis[0],LOW);
      digitalWrite(yAxis[1], LOW);
      digitalWrite(yAxis[2], LOW);
      digitalWrite(yAxis[3], LOW);
      digitalWrite(yAxis[4], LOW);
      digitalWrite(yAxis[5],LOW);
    }
    else
    {
     digitalWrite(xAxis[3],HIGH);
     digitalWrite(xAxis[5],HIGH);
     digitalWrite(yAxis[1], LOW);
     digitalWrite(yAxis[2], LOW);
     digitalWrite(yAxis[3], LOW);
     digitalWrite(yAxis[4], LOW);
    }
    delay(1);
  }
  count = 0;
  while(count < duration)
  {
    allOff();
    count++;
    if(count%2==0)
    {
      digitalWrite(xAxis[0], HIGH);
      digitalWrite(xAxis[3], HIGH);
      digitalWrite(yAxis[0], LOW);
      digitalWrite(yAxis[5],LOW);
    }
    else
    {
     digitalWrite(xAxis[2],HIGH);
     digitalWrite(xAxis[4],HIGH);
     digitalWrite(yAxis[1], LOW);
     digitalWrite(yAxis[2], LOW);
     digitalWrite(yAxis[3], LOW);
     digitalWrite(yAxis[4], LOW);
    }
    delay(1);
  }
  count = 0;
  while(count < duration)
  {
    allOff();
    count++;
    if(count%2==0)
    {
      digitalWrite(xAxis[2], HIGH);
      digitalWrite(yAxis[0], LOW);
      digitalWrite(yAxis[5],LOW);
    }
    else
    {
     digitalWrite(xAxis[1],HIGH);
     digitalWrite(xAxis[3],HIGH);
     digitalWrite(yAxis[1], LOW);
     digitalWrite(yAxis[2], LOW);
     digitalWrite(yAxis[3], LOW);
     digitalWrite(yAxis[4], LOW);
    }
    delay(1);
  }
  count = 0;
  while(count < duration)
  {
    allOff();
    count++;
    if(count%2==0)
    {
      digitalWrite(xAxis[1], HIGH);
      digitalWrite(yAxis[0], LOW);
      digitalWrite(yAxis[5],LOW);
    }
    else
    {
     digitalWrite(xAxis[0],HIGH);
     digitalWrite(xAxis[2],HIGH);
     digitalWrite(yAxis[1], LOW);
     digitalWrite(yAxis[2], LOW);
     digitalWrite(yAxis[3], LOW);
     digitalWrite(yAxis[4], LOW);
    }
    delay(1);
  }
  count = 0;
  while(count < duration)
  {
    allOff();
    count++;
    if(count%2==0)
    {
      digitalWrite(xAxis[0], HIGH);
      digitalWrite(yAxis[0], LOW);
      digitalWrite(yAxis[5],LOW);
    }
    else
    {
     digitalWrite(xAxis[1],HIGH);
     digitalWrite(yAxis[1], LOW);
     digitalWrite(yAxis[2], LOW);
     digitalWrite(yAxis[3], LOW);
     digitalWrite(yAxis[4], LOW);
    }
    delay(1);
  }
  count = 0;
  while(count < duration)
  {
    allOff();
    count++;
     digitalWrite(xAxis[0],HIGH);
     digitalWrite(yAxis[1], LOW);
     digitalWrite(yAxis[2], LOW);
     digitalWrite(yAxis[3], LOW);
     digitalWrite(yAxis[4], LOW);
    delay(1);
  }
}

void IHeartArt(int duration)
{
  int count = 0;
  while(count < duration)
  {
    allOff();
    count++;
    digitalWrite(xAxis[5], HIGH);
    digitalWrite(yAxis[0], LOW);
    digitalWrite(yAxis[5], LOW);
    delay(1);
  }
  count = 0;
  while(count < duration)
  {
    allOff();
    count++;
    if(count%2 == 0)
    {
      digitalWrite(xAxis[4], HIGH);
      digitalWrite(yAxis[0], LOW);
      digitalWrite(yAxis[5], LOW);
    }
    else
    {
      digitalWrite(xAxis[5], HIGH);
      digitalWrite(yAxis[0], LOW);
      digitalWrite(yAxis[1], LOW);
      digitalWrite(yAxis[2], LOW);
      digitalWrite(yAxis[3], LOW);
      digitalWrite(yAxis[4], LOW);
      digitalWrite(yAxis[5], LOW);
    }
    delay(1);
  }
  count = 0;
  while(count < duration)
  {
    allOff();
    count++;
    if(count%2 == 0)
    {
      digitalWrite(xAxis[3], HIGH);
      digitalWrite(xAxis[5], HIGH);
      digitalWrite(yAxis[0], LOW);
      digitalWrite(yAxis[5], LOW);
    }
    else
    {
      digitalWrite(xAxis[4], HIGH);
      digitalWrite(yAxis[0], LOW);
      digitalWrite(yAxis[1], LOW);
      digitalWrite(yAxis[2], LOW);
      digitalWrite(yAxis[3], LOW);
      digitalWrite(yAxis[4], LOW);
      digitalWrite(yAxis[5], LOW);
    }
    delay(1);
  }
  count = 0;
  while(count < duration)
  {
    allOff();
    count++;
    if(count%2 == 0)
    {
      digitalWrite(xAxis[2], HIGH);
      digitalWrite(xAxis[4], HIGH);
      digitalWrite(yAxis[0], LOW);
      digitalWrite(yAxis[5], LOW);
    }
    else
    {
      digitalWrite(xAxis[3], HIGH);
      digitalWrite(yAxis[0], LOW);
      digitalWrite(yAxis[1], LOW);
      digitalWrite(yAxis[2], LOW);
      digitalWrite(yAxis[3], LOW);
      digitalWrite(yAxis[4], LOW);
      digitalWrite(yAxis[5], LOW);
    }
    delay(1);
  }
  count = 0;
  while(count < duration)
  {
    allOff();
    count++;
    if(count%3 == 0)
    {
      digitalWrite(xAxis[1], HIGH);
      digitalWrite(xAxis[3], HIGH);
      digitalWrite(yAxis[0], LOW);
      digitalWrite(yAxis[5], LOW);
    }
    else if(count%2 == 0)
    {
      digitalWrite(xAxis[2], HIGH);
      digitalWrite(yAxis[0], LOW);
      digitalWrite(yAxis[1], LOW);
      digitalWrite(yAxis[2], LOW);
      digitalWrite(yAxis[3], LOW);
      digitalWrite(yAxis[4], LOW);
      digitalWrite(yAxis[5], LOW);
    }
    else
    {
      digitalWrite(xAxis[5], HIGH);
      digitalWrite(yAxis[3], LOW);
      digitalWrite(yAxis[4], LOW);
    }
    delay(1);
  }
  count = 0;
  while(count < duration)
  {
    allOff();
    count++;
    if(count%4 == 0)
    {
      digitalWrite(xAxis[0], HIGH);
      digitalWrite(xAxis[2], HIGH);
      digitalWrite(yAxis[0], LOW);
      digitalWrite(yAxis[5], LOW);
    }
    else if(count%3 == 0)
    {
      digitalWrite(xAxis[1], HIGH);
      digitalWrite(yAxis[0], LOW);
      digitalWrite(yAxis[1], LOW);
      digitalWrite(yAxis[2], LOW);
      digitalWrite(yAxis[3], LOW);
      digitalWrite(yAxis[4], LOW);
      digitalWrite(yAxis[5], LOW);
    }
    else if(count%2 == 0)
    {
      digitalWrite(xAxis[4], HIGH);
      digitalWrite(yAxis[3], LOW);
      digitalWrite(yAxis[4], LOW);
    }
    else
    {
      digitalWrite(xAxis[5], HIGH);
      digitalWrite(yAxis[1], LOW);
      digitalWrite(yAxis[2], LOW);
      digitalWrite(yAxis[3], LOW);
      digitalWrite(yAxis[4], LOW);
      digitalWrite(yAxis[5], LOW);
    }
    delay(1);
  }
  count = 0;
  while(count < duration)
  {
    allOff();
    count++;
    if(count%5 == 0)
    {
      digitalWrite(xAxis[1], HIGH);
      digitalWrite(yAxis[0], LOW);
      digitalWrite(yAxis[5], LOW);
    }
    else if(count%4 == 0)
    {
      digitalWrite(xAxis[0], HIGH);
      digitalWrite(yAxis[0], LOW);
      digitalWrite(yAxis[1], LOW);
      digitalWrite(yAxis[2], LOW);
      digitalWrite(yAxis[3], LOW);
      digitalWrite(yAxis[4], LOW);
      digitalWrite(yAxis[5], LOW);
    }
    else if(count%3 == 0)
    {
      digitalWrite(xAxis[3], HIGH);
      digitalWrite(yAxis[3], LOW);
      digitalWrite(yAxis[4], LOW);
    }
    else if(count%2 == 0)
    {
      digitalWrite(xAxis[4], HIGH);
      digitalWrite(yAxis[1], LOW);
      digitalWrite(yAxis[2], LOW);
      digitalWrite(yAxis[3], LOW);
      digitalWrite(yAxis[4], LOW);
      digitalWrite(yAxis[5], LOW);
    }
    else
    {
      digitalWrite(xAxis[5], HIGH);
      digitalWrite(yAxis[0], LOW);
      digitalWrite(yAxis[1], LOW);
      digitalWrite(yAxis[2], LOW);
      digitalWrite(yAxis[3], LOW);
      digitalWrite(yAxis[4], LOW);
    }
    delay(1);
  }
  count = 0;
  while(count < duration)
  {
    allOff();
    count++;
    if(count%4 == 0)
    {
      digitalWrite(xAxis[0], HIGH);
      digitalWrite(yAxis[0], LOW);
      digitalWrite(yAxis[5], LOW);
    }
    else if(count%3 == 0)
    {
      digitalWrite(xAxis[2], HIGH);
      digitalWrite(yAxis[3], LOW);
      digitalWrite(yAxis[4], LOW);
    }
    else if(count%2 == 0)
    {
      digitalWrite(xAxis[3], HIGH);
      digitalWrite(xAxis[5], HIGH);
      digitalWrite(yAxis[1], LOW);
      digitalWrite(yAxis[2], LOW);
      digitalWrite(yAxis[3], LOW);
      digitalWrite(yAxis[4], LOW);
      digitalWrite(yAxis[5], LOW);
    }
    else
    {
      digitalWrite(xAxis[4], HIGH);
      digitalWrite(yAxis[0], LOW);
      digitalWrite(yAxis[1], LOW);
      digitalWrite(yAxis[2], LOW);
      digitalWrite(yAxis[3], LOW);
      digitalWrite(yAxis[4], LOW);
    }
    delay(1);
  }
  count = 0;
  while(count < duration)
  {
    allOff();
    count++;
    if(count%3 == 0)
    {
      digitalWrite(xAxis[1], HIGH);
      digitalWrite(xAxis[5], HIGH);
      digitalWrite(yAxis[3], LOW);
      digitalWrite(yAxis[4], LOW);
    }
    else if(count%2 == 0)
    {
      digitalWrite(xAxis[2], HIGH);
      digitalWrite(xAxis[4], HIGH);
      digitalWrite(yAxis[1], LOW);
      digitalWrite(yAxis[2], LOW);
      digitalWrite(yAxis[3], LOW);
      digitalWrite(yAxis[4], LOW);
      digitalWrite(yAxis[5], LOW);
    }
    else
    {
      digitalWrite(xAxis[3], HIGH);
      digitalWrite(yAxis[0], LOW);
      digitalWrite(yAxis[1], LOW);
      digitalWrite(yAxis[2], LOW);
      digitalWrite(yAxis[3], LOW);
      digitalWrite(yAxis[4], LOW);
    }
    delay(1);
  }
  count = 0;
  while(count < duration)
  {
    allOff();
    count++;
    if(count%3 == 0)
    {
      digitalWrite(xAxis[0], HIGH);
      digitalWrite(xAxis[4], HIGH);
      digitalWrite(yAxis[3], LOW);
      digitalWrite(yAxis[4], LOW);
    }
    else if(count%2 == 0)
    {
      digitalWrite(xAxis[1], HIGH);
      digitalWrite(xAxis[3], HIGH);
      digitalWrite(yAxis[1], LOW);
      digitalWrite(yAxis[2], LOW);
      digitalWrite(yAxis[3], LOW);
      digitalWrite(yAxis[4], LOW);
      digitalWrite(yAxis[5], LOW);
    }
    else
    {
      digitalWrite(xAxis[2], HIGH);
      digitalWrite(yAxis[0], LOW);
      digitalWrite(yAxis[1], LOW);
      digitalWrite(yAxis[2], LOW);
      digitalWrite(yAxis[3], LOW);
      digitalWrite(yAxis[4], LOW);
    }
    delay(1);
  }
  count = 0;
  while(count < duration)
  {
    allOff();
    count++;
    if(count%2 == 0)
    {
      digitalWrite(xAxis[0], HIGH);
      digitalWrite(xAxis[2], HIGH);
      digitalWrite(yAxis[1], LOW);
      digitalWrite(yAxis[2], LOW);
      digitalWrite(yAxis[3], LOW);
      digitalWrite(yAxis[4], LOW);
      digitalWrite(yAxis[5], LOW);
    }
    else
    {
      digitalWrite(xAxis[1], HIGH);
      digitalWrite(xAxis[5], HIGH);
      digitalWrite(yAxis[0], LOW);
      digitalWrite(yAxis[1], LOW);
      digitalWrite(yAxis[2], LOW);
      digitalWrite(yAxis[3], LOW);
      digitalWrite(yAxis[4], LOW);
    }
    delay(1);
  }
  count = 0;
  while(count < duration)
  {
    allOff();
    count++;
    if(count%3 == 0)
    {
      digitalWrite(xAxis[1], HIGH);
      digitalWrite(yAxis[1], LOW);
      digitalWrite(yAxis[2], LOW);
      digitalWrite(yAxis[3], LOW);
      digitalWrite(yAxis[4], LOW);
      digitalWrite(yAxis[5], LOW);
    }
    else if(count%2 == 0)
    {
      digitalWrite(xAxis[0], HIGH);
      digitalWrite(xAxis[4], HIGH);
      digitalWrite(yAxis[0], LOW);
      digitalWrite(yAxis[1], LOW);
      digitalWrite(yAxis[2], LOW);
      digitalWrite(yAxis[3], LOW);
      digitalWrite(yAxis[4], LOW);
    }
    else
    {
      digitalWrite(xAxis[5], HIGH);
      digitalWrite(yAxis[2], LOW);
      digitalWrite(yAxis[5], LOW);
    }
    delay(1);
  }
  count = 0;
  while(count < duration)
  {
    allOff();
    count++;
    if(count%3 == 0)
    {
      digitalWrite(xAxis[0], HIGH);
      digitalWrite(yAxis[1], LOW);
      digitalWrite(yAxis[2], LOW);
      digitalWrite(yAxis[3], LOW);
      digitalWrite(yAxis[4], LOW);
      digitalWrite(yAxis[5], LOW);
    }
    else if(count%2 == 0)
    {
      digitalWrite(xAxis[3], HIGH);
      digitalWrite(xAxis[5], HIGH);
      digitalWrite(yAxis[0], LOW);
      digitalWrite(yAxis[1], LOW);
      digitalWrite(yAxis[2], LOW);
      digitalWrite(yAxis[3], LOW);
      digitalWrite(yAxis[4], LOW);
    }
    else
    {
      digitalWrite(xAxis[4], HIGH);
      digitalWrite(yAxis[2], LOW);
      digitalWrite(yAxis[5], LOW);
    }
    delay(1);
  }
  count = 0;
  while(count < duration)
  {
    allOff();
    count++;
    if(count%2 == 0)
    {
      digitalWrite(xAxis[2], HIGH);
      digitalWrite(xAxis[4], HIGH);
      digitalWrite(yAxis[0], LOW);
      digitalWrite(yAxis[1], LOW);
      digitalWrite(yAxis[2], LOW);
      digitalWrite(yAxis[3], LOW);
      digitalWrite(yAxis[4], LOW);
    }
    else
    {
      digitalWrite(xAxis[3], HIGH);
      digitalWrite(yAxis[2], LOW);
      digitalWrite(yAxis[5], LOW);
    }
    delay(1);
  }
  count = 0;
  while(count < duration)
  {
    allOff();
    count++;
    if(count%3 == 0)
    {
      digitalWrite(xAxis[1], HIGH);
      digitalWrite(xAxis[3], HIGH);
      digitalWrite(yAxis[0], LOW);
      digitalWrite(yAxis[1], LOW);
      digitalWrite(yAxis[2], LOW);
      digitalWrite(yAxis[3], LOW);
      digitalWrite(yAxis[4], LOW);
    }
    else if(count%2 == 0)
    {
      digitalWrite(xAxis[2], HIGH);
      digitalWrite(yAxis[2], LOW);
      digitalWrite(yAxis[5], LOW);
    }
    else
    {
      digitalWrite(xAxis[5], HIGH);
      digitalWrite(yAxis[0], LOW);
      digitalWrite(yAxis[1], LOW);
      digitalWrite(yAxis[2], LOW);
      digitalWrite(yAxis[3], LOW);
      digitalWrite(yAxis[4], LOW);
      digitalWrite(yAxis[5], LOW);
    }
    delay(1);
  }
  count = 0;
  while(count < duration)
  {
    allOff();
    count++;
    if(count%3 == 0)
    {
      digitalWrite(xAxis[0], HIGH);
      digitalWrite(xAxis[2], HIGH);
      digitalWrite(yAxis[0], LOW);
      digitalWrite(yAxis[1], LOW);
      digitalWrite(yAxis[2], LOW);
      digitalWrite(yAxis[3], LOW);
      digitalWrite(yAxis[4], LOW);
    }
    else if(count%2 == 0)
    {
      digitalWrite(xAxis[1], HIGH);
      digitalWrite(xAxis[5], HIGH);
      digitalWrite(yAxis[2], LOW);
      digitalWrite(yAxis[5], LOW);
    }
    else
    {
      digitalWrite(xAxis[4], HIGH);
      digitalWrite(yAxis[0], LOW);
      digitalWrite(yAxis[1], LOW);
      digitalWrite(yAxis[2], LOW);
      digitalWrite(yAxis[3], LOW);
      digitalWrite(yAxis[4], LOW);
      digitalWrite(yAxis[5], LOW);
    }
    delay(1);
  }
  count = 0;
  while(count < duration)
  {
    allOff();
    count++;
    if(count%4 == 0)
    {
      digitalWrite(xAxis[1], HIGH);
      digitalWrite(yAxis[0], LOW);
      digitalWrite(yAxis[1], LOW);
      digitalWrite(yAxis[2], LOW);
      digitalWrite(yAxis[3], LOW);
      digitalWrite(yAxis[4], LOW);
    }
    else if(count%3 == 0)
    {
      digitalWrite(xAxis[0], HIGH);
      digitalWrite(xAxis[4], HIGH);
      digitalWrite(yAxis[2], LOW);
      digitalWrite(yAxis[5], LOW);
    }
    else if(count%2 == 0)
    {
      digitalWrite(xAxis[3], HIGH);
      digitalWrite(yAxis[0], LOW);
      digitalWrite(yAxis[1], LOW);
      digitalWrite(yAxis[2], LOW);
      digitalWrite(yAxis[3], LOW);
      digitalWrite(yAxis[4], LOW);
      digitalWrite(yAxis[5], LOW);
    }
    else
    {
      digitalWrite(xAxis[5], HIGH);
      digitalWrite(yAxis[0], LOW);
      digitalWrite(yAxis[1], LOW);
      digitalWrite(yAxis[3], LOW);
      digitalWrite(yAxis[4], LOW);
    }
    delay(1);
  }
  count = 0;
  while(count < duration)
  {
    allOff();
    count++;
    if(count%4 == 0)
    {
      digitalWrite(xAxis[0], HIGH);
      digitalWrite(yAxis[0], LOW);
      digitalWrite(yAxis[1], LOW);
      digitalWrite(yAxis[2], LOW);
      digitalWrite(yAxis[3], LOW);
      digitalWrite(yAxis[4], LOW);
    }
    else if(count%3 == 0)
    {
      digitalWrite(xAxis[3], HIGH);
      digitalWrite(yAxis[2], LOW);
      digitalWrite(yAxis[5], LOW);
    }
    else if(count%2 == 0)
    {
      digitalWrite(xAxis[2], HIGH);
      digitalWrite(yAxis[0], LOW);
      digitalWrite(yAxis[1], LOW);
      digitalWrite(yAxis[2], LOW);
      digitalWrite(yAxis[3], LOW);
      digitalWrite(yAxis[4], LOW);
      digitalWrite(yAxis[5], LOW);
    }
    else
    {
      digitalWrite(xAxis[4], HIGH);
      digitalWrite(yAxis[0], LOW);
      digitalWrite(yAxis[1], LOW);
      digitalWrite(yAxis[3], LOW);
      digitalWrite(yAxis[4], LOW);
    }
    delay(1);
  }
  count = 0;
  while(count < duration)
  {
    allOff();
    count++;
    if(count%4 == 0)
    {
      digitalWrite(xAxis[5], HIGH);
      digitalWrite(yAxis[5], LOW);
    }
    else if(count%3 == 0)
    {
      digitalWrite(xAxis[2], HIGH);
      digitalWrite(yAxis[2], LOW);
      digitalWrite(yAxis[5], LOW);
    }
    else if(count%2 == 0)
    {
      digitalWrite(xAxis[1], HIGH);
      digitalWrite(yAxis[0], LOW);
      digitalWrite(yAxis[1], LOW);
      digitalWrite(yAxis[2], LOW);
      digitalWrite(yAxis[3], LOW);
      digitalWrite(yAxis[4], LOW);
      digitalWrite(yAxis[5], LOW);
    }
    else
    {
      digitalWrite(xAxis[3], HIGH);
      digitalWrite(yAxis[0], LOW);
      digitalWrite(yAxis[1], LOW);
      digitalWrite(yAxis[3], LOW);
      digitalWrite(yAxis[4], LOW);
    }
    delay(1);
  }
  count = 0;
  while(count < duration)
  {
    allOff();
    count++;
    if(count%4 == 0)
    {
      digitalWrite(xAxis[4], HIGH);
      digitalWrite(yAxis[5], LOW);
    }
    else if(count%3 == 0)
    {
      digitalWrite(xAxis[1], HIGH);
      digitalWrite(yAxis[2], LOW);
      digitalWrite(yAxis[5], LOW);
    }
    else if(count%2 == 0)
    {
      digitalWrite(xAxis[0], HIGH);
      digitalWrite(xAxis[5], HIGH);
      digitalWrite(yAxis[0], LOW);
      digitalWrite(yAxis[1], LOW);
      digitalWrite(yAxis[2], LOW);
      digitalWrite(yAxis[3], LOW);
      digitalWrite(yAxis[4], LOW);
      digitalWrite(yAxis[5], LOW);
    }
    else
    {
      digitalWrite(xAxis[2], HIGH);
      digitalWrite(yAxis[0], LOW);
      digitalWrite(yAxis[1], LOW);
      digitalWrite(yAxis[3], LOW);
      digitalWrite(yAxis[4], LOW);
    }
    delay(1);
  }
  count = 0;
  while(count < duration)
  {
    allOff();
    count++;
    if(count%4 == 0)
    {
      digitalWrite(xAxis[3], HIGH);
      digitalWrite(xAxis[5], HIGH);
      digitalWrite(yAxis[5], LOW);
    }
    else if(count%3 == 0)
    {
      digitalWrite(xAxis[0], HIGH);
      digitalWrite(yAxis[2], LOW);
      digitalWrite(yAxis[5], LOW);
    }
    else if(count%2 == 0)
    {
      digitalWrite(xAxis[4], HIGH);
      digitalWrite(yAxis[0], LOW);
      digitalWrite(yAxis[1], LOW);
      digitalWrite(yAxis[2], LOW);
      digitalWrite(yAxis[3], LOW);
      digitalWrite(yAxis[4], LOW);
      digitalWrite(yAxis[5], LOW);
    }
    else
    {
      digitalWrite(xAxis[1], HIGH);
      digitalWrite(yAxis[0], LOW);
      digitalWrite(yAxis[1], LOW);
      digitalWrite(yAxis[3], LOW);
      digitalWrite(yAxis[4], LOW);
    }
    delay(1);
  }
  count = 0;
  while(count < duration)
  {
    allOff();
    count++;
    if(count%3 == 0)
    {
      digitalWrite(xAxis[2], HIGH);
      digitalWrite(xAxis[4], HIGH);
      digitalWrite(yAxis[5], LOW);
    }
    else if(count%2 == 0)
    {
      digitalWrite(xAxis[3], HIGH);
      digitalWrite(yAxis[0], LOW);
      digitalWrite(yAxis[1], LOW);
      digitalWrite(yAxis[2], LOW);
      digitalWrite(yAxis[3], LOW);
      digitalWrite(yAxis[4], LOW);
      digitalWrite(yAxis[5], LOW);
    }
    else
    {
      digitalWrite(xAxis[0], HIGH);
      digitalWrite(yAxis[0], LOW);
      digitalWrite(yAxis[1], LOW);
      digitalWrite(yAxis[3], LOW);
      digitalWrite(yAxis[4], LOW);
    }
    delay(1);
  }
  count = 0;
  while(count < duration)
  {
    allOff();
    count++;
    if(count%2 == 0)
    {
      digitalWrite(xAxis[1], HIGH);
      digitalWrite(xAxis[3], HIGH);
      digitalWrite(yAxis[5], LOW);
    }
    else
    {
      digitalWrite(xAxis[2], HIGH);
      digitalWrite(yAxis[0], LOW);
      digitalWrite(yAxis[1], LOW);
      digitalWrite(yAxis[2], LOW);
      digitalWrite(yAxis[3], LOW);
      digitalWrite(yAxis[4], LOW);
      digitalWrite(yAxis[5], LOW);
    }
    delay(1);
  }
  count = 0;
  while(count < duration)
  {
    allOff();
    count++;
    if(count%2 == 0)
    {
      digitalWrite(xAxis[0], HIGH);
      digitalWrite(xAxis[2], HIGH);
      digitalWrite(yAxis[5], LOW);
    }
    else
    {
      digitalWrite(xAxis[1], HIGH);
      digitalWrite(yAxis[0], LOW);
      digitalWrite(yAxis[1], LOW);
      digitalWrite(yAxis[2], LOW);
      digitalWrite(yAxis[3], LOW);
      digitalWrite(yAxis[4], LOW);
      digitalWrite(yAxis[5], LOW);
    }
    delay(1);
  }
  count = 0;
  while(count < duration)
  {
    allOff();
    count++;
    if(count%2 == 0)
    {
      digitalWrite(xAxis[1], HIGH);
      digitalWrite(yAxis[5], LOW);
    }
    else
    {
      digitalWrite(xAxis[0], HIGH);
      digitalWrite(yAxis[0], LOW);
      digitalWrite(yAxis[1], LOW);
      digitalWrite(yAxis[2], LOW);
      digitalWrite(yAxis[3], LOW);
      digitalWrite(yAxis[4], LOW);
      digitalWrite(yAxis[5], LOW);
    }
    delay(1);
  }
  count = 0;
  while(count < duration)
  {
    allOff();
    count++;
    XYOn(0,5);
    delay(1);
  }
}

Credits

Replications

Did you replicate this project? Share it!

I made one

Love this project? Think it could be improved? Tell us what you think!

Give feedback

Comments

Similar projects you might like

Arduinomated Car Parking with Voice Assistance in Smartphone
Intermediate
  • 25
  • 3

Full instructions

Make an assistant which tells you about how much to drive backwards without any collision through your smartphone by Arduino and 1Sheeld.

Reducing Arduino Power Consumption
Intermediate
  • 39
  • 3

Full instructions

One the most important feature of portable electronics should be long battery life. We can reduce the current drawn by several ways.

Sigfox Forest Fire Detector
Intermediate
  • 1,824
  • 12

Full instructions

How to prevent forest from burning? A small Sigfox signal can prevent natural disasters. We will use an Arduino MKRFOX + a flame detector.

Analog-XY-Plotter-Output-to-HPGL-Translator
Intermediate
  • 140
  • 2

Translate analog X-Y plotter output to HPGL command stream.

From BT to WiFi: Creating WiFi Controlled Arduino Robot Car
Intermediate
  • 215
  • 3

Protip

NodeMCU ESP8266 in access point mode: the simplest way to make Wi-Fi controlled Robot Car from Bluetooth Arduino Robot Car + Android App.

Arduino Word Clock
Intermediate
  • 492
  • 8

Full instructions

A clock that let you read the time, for real!

Sign up / LoginProjectsPlatformsTopicsContestsLiveAppsBetaFree StoreBlog
