Published June 11, 2019 © GPL3+

PHPoC - Access Built-In Real-Time Clock via Web

View and synchronize built-in RTC via web.

BeginnerFull instructions provided1 hour1,239

Things used in this project

Hardware components

PHPoC Blue

Story

I. Real-time clock

Real-time Clock may be a familiar term for many of us. A real-time clock (RTC) is a battery-powered clock that is included in an electrical circuit. Like any other clocks, it keeps track of the current time.

RTCs are present in almost any electronic device which needs to keep accurate time. Nowadays, built-in RTC is a common feature in IoT boards.

In this project, I make the RTC to be displayed and can be synchronized via web browser. For me, that way is much easier to access the RTC than following much more steps via other tools and software.

Web interface

II. Things I did:

PHPoC provides some functions to get RTC data, so that I can retrieve it and display it on a web page. Here I add another local-time clock so we can compare between them.

Note that RTC timing is not always accurate due to its hardware limitation. After all, it is built with modest hardware. For a long period, e.g, over the course of a month, an RTC may have few minutes differed compared to normal-working clocks.

Personally, I think that's okay with a built-in clock. Here, SYNC function is provided so that we can synchronize RTC time with the local time. By this way, we can manually keep the timing deviation as minimum as possible.

Source code includes two files, clock.php and clock_setup.php. clock.php is the main file that is used to retrieve and display RTC clock's data. clock_setup.php is the server side code that handles RTC synchronization request sent from web browser.

<?php

function rtc_get_date()
{
	$pid_rtc = pid_open("/mmap/rtc0");
	$date = pid_ioctl($pid_rtc, "get date");
	pid_close($pid_rtc);

	$rtc_time = substr($date, 0, 4) . "-" . substr($date, 4, 2) . "-" . substr($date, 6, 2) . " " . substr($date, 8, 2) . ":" . substr($date, 10, 2) . ":" . substr($date, 12, 2);
	return $rtc_time;
}

?>
<!DOCTYPE html>
<html>
	<head>
		<title>PHPoC Device</title>
		<meta charset="utf-8">
		<meta name="viewport" content="width=device-width, initial-scale=0.7, maximum-scale=1.0, minimum-scale=0.5, user-scalable=yes">
		<style type="text/css">

			body {
				font-family: verdana, Helvetica, Arial, sans-serif, gulim;
				text-align: center;
				font-size: 18.5px;
				margin: 0;
			}

			table {
				border-collapse: collapse;
				font-size: 15px;
				width: 350px;
				text-align: left;
				margin: 0 auto;
			}

			td {
				padding: 0;
			}

			tr {
				height: 50px;
				color: #898989;
			}

			.header {
				margin: 0 auto;
				position: relative;
				height: 130px;
				color: gray;
			}

			.header a {
				position: relative;
				top: 30px;
				text-decoration: none;
				color: #282828;
			}

			.title {
				font-weight: bold;
				font-size: 24pt;
			}

			.inline {
				display: inline-block;
				margin: 10px 0;
			}

			.nav-line {
				clear: both;
				width: 450px;
				border: 1px solid #efefef;
				position: relative;
				top: 58px;
				margin: 0 auto;
			}

			.theader {
				width: 120px;
				color: #282828;
				padding-left: 20px;
			}

			.btn {
				width: 150px;
				height: 40px;
				border-radius: 25px;
				text-decoration: none;
				line-height: 40px;
				cursor: pointer;
				margin: 0 auto;
				background-color: #898989;
				color: white;
			}

			.btn:hover {
				background-color: #282828;
			}

		</style>
	</head>
	<body onload="init()">
		<div class="header">
			<div class="title"><a href="https://www.phpoc.com/" target="_blank">Built-in Clock</a></div>
		<div class="nav-line"></div>
		</div>
		<form name="phpoc_setup" action="clock_setup.php" method="post">
			<div class="inline">
				<canvas id="rtc_clock"></canvas>
			</div>
			<div class="inline">
				<canvas id="local_clock"></canvas>
				<input type="hidden" name="host_time_txt">
			</div>
			<br>
			<table>
				<tr>
					<td class="theader">Last updated</td>
					<td><div id="sync_time"></div></td>
				</tr>
			</table>
			<div class="btn" onclick="time_sync()">SYNC</div>
		</form>
		<br>
	</body>
	<script>

		function get_time(timestamp, is_raw)
		{
			var now;
			if (timestamp != null)
				now = new Date(timestamp);
			else
				now = new Date();

			var year = now.getFullYear();

			var month = now.getMonth() + 1;
			if (month < 10)
				month = "0" + month;

			var day = now.getDate();
			if (day < 10)
				day = "0" + day;

			var h = now.getHours();
			if (h < 10)
				h = "0" + h;

			var m = now.getMinutes();
			if (m < 10)
				m = "0" + m;

			var s = now.getSeconds();
			if (s < 10)
				s = "0" + s;

			if (is_raw)
				return year.toString() + month.toString() + day.toString() + h.toString() + m.toString() + s.toString();

			return year + '-' + month + '-' + day + " " + h + ':' + m + ':' + s;
		}

		function get_current_time(is_raw)
		{
			return get_time(null, is_raw);
		}

		function time_sync()
		{
			var host_time = get_current_time(true);

			phpoc_setup.host_time_txt.value = host_time;
			phpoc_setup.submit();
		}

		function draw_hand(ctx, pos, length, width) {
			ctx.save();
			ctx.beginPath();
			ctx.lineWidth = width;
			ctx.lineCap = "round";
			ctx.rotate(pos);
			ctx.moveTo(0, length / 4);
			ctx.lineTo(0, -length);
			ctx.stroke();
			ctx.rotate(-pos);
			ctx.restore();
		}

		function draw_clock(ctx, timestamp) {
			var radius = ctx.canvas.clientHeight * 0.5;
			var date_time = (timestamp != null) ? new Date(timestamp) : new Date();
			var hour = date_time.getHours();
			var minute = date_time.getMinutes();
			var second = date_time.getSeconds();

			// Draw clock's face
			ctx.clearRect(- radius, - radius, 2 * radius, 2 * radius);
			ctx.beginPath();
			ctx.arc(0, 0, radius * 0.8, 0, 2 * Math.PI);
			ctx.save();
			ctx.fillStyle = '#ffffff';
			ctx.fill();

			ctx.restore();
			ctx.lineWidth = radius * 0.07;
			ctx.stroke();

			// Hour marks
			ctx.lineWidth = radius * 0.02;
			ctx.lineCap = "round";
			ctx.save();
			for (var i = 0; i < 12; i++) {
				ctx.beginPath();
				ctx.rotate(Math.PI / 6);
				ctx.moveTo(radius * 0.74, 0);
				ctx.lineTo(radius * 0.68, 0);
				ctx.stroke();
			}
			ctx.restore();

			// Minute marks
			ctx.save();
			ctx.lineWidth = radius * 0.01;
			for (i = 0; i < 60; i++) {
				if (i % 5!= 0) {
					ctx.beginPath();
					ctx.moveTo(radius * 0.74, 0);
					ctx.lineTo(radius * 0.71, 0);
					ctx.stroke();
				}
				ctx.rotate(Math.PI / 30);
			}
			ctx.restore();


			// Draw number
			ctx.font = radius * 0.15 + "px arial";
			ctx.textBaseline = "middle";
			ctx.textAlign = "center";

			ctx.save();
			for(var num = 1; num < 13; num++){
				var ang = num * Math.PI / 6;
				ctx.rotate(ang);
				ctx.translate(0, -radius * 0.57);
				ctx.rotate(-ang);
				ctx.fillText(num.toString(), 0, 0);
				ctx.rotate(ang);
				ctx.translate(0, radius * 0.57);
				ctx.rotate(-ang);
			}
			ctx.restore();

			ctx.save();
			ctx.strokeStyle = '#2c3e50';

			// Draw time
			hour = hour % 12;
			hour = (hour * Math.PI / 6) + (minute * Math.PI / (6 * 60)) + (second * Math.PI / (360 * 60));
			draw_hand(ctx, hour, radius * 0.32, radius * 0.03);

			minute = (minute * Math.PI / 30) + (second * Math.PI / (30 * 60));
			draw_hand(ctx, minute, radius * 0.45, radius * 0.02);

			ctx.strokeStyle = '#c0392b';
			second = (second * Math.PI / 30);
			draw_hand(ctx, second, radius * 0.58, radius * 0.01);

			ctx.fillStyle = '#2c3e50';
			ctx.beginPath();
			ctx.arc(0, 0, radius * 0.04, 0, 2 * Math.PI);
			ctx.fill();

			ctx.restore();


			ctx.font = radius * 0.1 + "px arial";
			ctx.fillText(get_time(timestamp), 0, radius * 0.95);
			ctx.fillText(ctx.title, 0, -radius * 0.95);
		}

		function init_clock(id, size, color, title) {
			var canvas = document.getElementById(id);
			canvas.width = size;
			canvas.height = size;
			ctx = canvas.getContext("2d");
			ctx.translate(size * 0.5, size * 0.5);
			ctx.strokeStyle = color;
			ctx.fillStyle = color;
			ctx.title = title;
			return ctx;
		}

		function init() {
			var rtc_time = '<?echo rtc_get_date()?>';
			var cur_time = get_current_time();

			var sync_time_el = document.getElementById('sync_time');

			var offset = new Date().getTimezoneOffset();
			var offset_hrs = parseInt(Math.abs(offset / 60));
			var	offset_min = Math.abs(offset % 60);
			var	timezone;

			if(offset_hrs < 10)
				offset_hrs = '0' + offset_hrs;

			if(offset_min < 10)
				offset_min = '0' + offset_min;

			timezone = ((offset <= 0) ? '+' : '-') + offset_hrs + ':' + offset_min;

			var utc_timestamp = Date.parse(rtc_time.replace(' ', 'T') + timezone);

			sync_time_el.innerText = cur_time;

			var rtc_ctx = init_clock("rtc_clock", 350, '#2980b9', "RTC Time");
			var local_ctx = init_clock("local_clock", 300, '#16a085', "Local Time");

			draw_clock(rtc_ctx, utc_timestamp);
			draw_clock(local_ctx);

			setInterval(function() {
				utc_timestamp += 1000;
				draw_clock(rtc_ctx, utc_timestamp);
				draw_clock(local_ctx);
			}, 1000);
		}

	</script>
</html>

<?php
if(!_SERVER("HTTP_REFERER"))
{
	header('HTTP/1.1 403 Forbidden');

	$php_name = _SERVER("SCRIPT_NAME");

	echo "<html>\r\n",
		"<head><title>403 Forbidden</title></head>\r\n",
		"<body>\r\n",
		"<h1>Forbidden</h1>\r\n",
		"<p>You don't have permission to access /$php_name on this server.</p>\r\n",
		"</body></html>\r\n";

	return;
}

function rtc_set_date($date)
{
	$pid_rtc = pid_open("/mmap/rtc0");
	pid_ioctl($pid_rtc, "set date $date");
	pid_close($pid_rtc);
}

$host_time         = _POST("host_time_txt");

rtc_set_date($host_time);

?>
<script>
	window.self.location.replace("clock.php");
</script>
