Computer Vision for Multi-Core Fiber Alignment

Automating multi-core optical fiber alignment inspection using computer vision for faster, more accurate quality control

IntermediateShowcase (no instructions)5 hours4

Computer Vision for Multi-Core Fiber Alignment

Things used in this project

Software apps and online services

Microsoft VS Code

Story

Introduction

The rapid growth of high-speed communication networks has driven the development of Multi-core Optical Fiber (MCF) as a promising technology to overcome the transmission capacity limitations of conventional single-core fibers. By integrating multiple optical cores within a single cladding, MCF significantly increases data throughput while reducing the physical size of optical cables.

One of the most critical factors affecting the performance of MCF is the precision of core alignment. During manufacturing, even slight deviations in core positions can lead to increased insertion loss, higher inter-core crosstalk, reduced coupling efficiency, and degraded communication performance. Therefore, accurate inspection of core alignment is essential for ensuring manufacturing quality and long-term reliability.

Traditional inspection methods typically rely on manual observation through optical microscopes or specialized measurement systems. These approaches are labor-intensive, time-consuming, operator-dependent, and often unsuitable for real-time industrial applications.

Recent advances in computer vision provide an opportunity to automate the inspection process. Image processing algorithms can accurately identify fiber cores, determine their positions, calculate alignment errors, and provide objective quality assessments. This research proposes the development of a computer vision system capable of performing automatic core alignment evaluation for multi-core optical fibers with high precision and efficiency.

Problem Statement

The manufacturing process of multi-core optical fibers faces several challenges related to quality inspection:

* Manual inspection requires skilled operators and is prone to human error.

* Commercial optical inspection systems are expensive and difficult to customize.

* Inspection speed is insufficient for high-volume manufacturing.

* Measurement repeatability varies among operators.

* Real-time quality monitoring is difficult to implement.

These limitations motivate the development of an automated computer vision system that can accurately evaluate core alignment while reducing inspection time and operational costs.

Workflow

The proposed software architecture follows a modular image-processing pipeline.

Image Acquisition --> Load Fiber Image --> Image Pr-processing (Gray Scale, Noise Filtering, Contrast Enhancement) --> Fiber Boundary Detection --> Determine Fiber Center --> Core Detection (Hough Circle / Blob Detection /Threshold / Contour Analysis) --> Calculate Core Coordinates --> Calculate Alignment Error -->Tolerance Evaluation (PASS / WARNING / FAIL) --> Visualization (Core Labels, Offset Vector, Alignment Report) --> Save Results

Result

Analysis

The proposed computer vision system performs automatic quantitative evaluation of core alignment by measuring the positional deviation of each optical core relative to the fiber center. Image preprocessing significantly improves detection robustness by reducing noise and enhancing contrast, enabling reliable segmentation of individual cores. Accurate centrist estimation allows precise measurement of radial and angular deviations.

The alignment error for each core can be expressed as:

Offset = √((x − x₀)² + (y − y₀)²)**

where:

* (x₀, y₀) = ideal core position

* (x, y) = detected core position

The calculated offsets are compared against predefined manufacturing tolerances. The inspection system automatically classifies each fiber into quality categories such as PASS, WARNING, or FAIL. Compared with manual inspection, the proposed system offers several advantages:

* Higher measurement repeatability.

* Reduced operator dependency.

* Faster inspection speed.

* Objective quantitative measurements.

* Easier integration into automated production lines.

Furthermore, the modular software architecture allows future integration with deep learning models for defect detection, anomaly classification, and predictive quality control.

Conclusion

This research presents the development of a computer vision system for automatic core alignment evaluation in multi-core optical fibers. The proposed approach integrates image acquisition, preprocessing, core detection, coordinate extraction, alignment measurement, and quality assessment into a unified inspection framework.

The system is expected to improve inspection accuracy, consistency, and efficiency while reducing human intervention and operational costs. Its modular design also enables future integration with artificial intelligence and Industry 4.0 manufacturing platforms.

The proposed solution has strong potential for deployment in optical fiber manufacturing facilities, research laboratories, and automated quality control systems, contributing to the production of high-performance multi-core optical fibers for next-generation communication networks.

Visual Code

import cv2
import numpy as np
import math

# Video capture (ganti ke 0 untuk webcam)
cap = cv2.VideoCapture('MCF_sample.mp4')

# Cek ukuran frame video
frame_width = int(cap.get(cv2.CAP_PROP_FRAME_WIDTH))
frame_height = int(cap.get(cv2.CAP_PROP_FRAME_HEIGHT))
fps = int(cap.get(cv2.CAP_PROP_FPS))

# Video writer untuk simpan hasil
fourcc = cv2.VideoWriter_fourcc(*'mp4v')
out = cv2.VideoWriter('output_result.mp4', fourcc, fps, (frame_width, frame_height))

# Data referensi (x, y, r)
reference_data = {
    'Core 1': (157, 275, 17),
    'Core 2': (280, 157, 17),
    'Core 3': (277, 397, 18),
    'Core 4': (401, 278, 19),
    'Marker C': (401, 105, 15)
}

kecepatan_derajat_per_detik = 180

while cap.isOpened():
    ret, img = cap.read()
    if not ret:
        break

    output = img.copy()
    gray = cv2.cvtColor(img, cv2.COLOR_BGR2GRAY)
    gray_blur = cv2.GaussianBlur(gray, (9, 9), 2)

    circles = cv2.HoughCircles(
        gray_blur,
        cv2.HOUGH_GRADIENT,
        dp=1.2,
        minDist=40,
        param1=50,
        param2=30,
        minRadius=10,
        maxRadius=30
    )

    center_x, center_y = img.shape[1] // 2, img.shape[0] // 2

    if circles is not None:
        circles = np.uint16(np.around(circles))
        circle_list = []

        for i in circles[0, :]:
            x, y, r = i[0], i[1], i[2]
            distance = math.hypot(x - center_x, y - center_y)
            circle_list.append((x, y, r, distance))

            cv2.circle(output, (x, y), r, (0, 255, 0), 2)
            cv2.circle(output, (x, y), 2, (0, 0, 255), 3)

        circle_list.sort(key=lambda x: x[3])

        labels = ['Core 1', 'Core 2', 'Core 3', 'Core 4', 'Marker C']

        selisih_sudut_total = 0
        jumlah_sudut = 0

        for idx, (x, y, r, d) in enumerate(circle_list):
            label = labels[idx] if idx < len(labels) else f'Unknown {idx}'

            if label in reference_data:
                ref_x, ref_y, ref_r = reference_data[label]
                diff_x = x - ref_x
                diff_y = y - ref_y
                diff_r = r - ref_r

                theta_ref = math.degrees(math.atan2(ref_y - center_y, ref_x - center_x))
                theta_now = math.degrees(math.atan2(y - center_y, x - center_x))
                selisih_sudut = theta_now - theta_ref

                if selisih_sudut > 180:
                    selisih_sudut -= 360
                elif selisih_sudut < -180:
                    selisih_sudut += 360

                selisih_sudut_total += selisih_sudut
                jumlah_sudut += 1

                cv2.putText(output, label, (x-40, y-30), cv2.FONT_HERSHEY_SIMPLEX, 0.6, (255, 255, 255), 2)

        if jumlah_sudut > 0:
            rata2_selisih_sudut = selisih_sudut_total / jumlah_sudut

            if rata2_selisih_sudut > 0:
                arah = 'CW'
            elif rata2_selisih_sudut < 0:
                arah = 'CCW'
            else:
                arah = 'OK'

            waktu_rotasi_detik = abs(rata2_selisih_sudut) / kecepatan_derajat_per_detik

            rekom_text_y = img.shape[0] - 20
            text = f"{rata2_selisih_sudut:.2f} deg | {arah} | {waktu_rotasi_detik:.3f} s "
            font = cv2.FONT_HERSHEY_SIMPLEX
            font_scale = 0.5
            thickness = 1
            (text_width, text_height), _ = cv2.getTextSize(text, font, font_scale, thickness)
            rekom_text_x = (img.shape[1] - text_width) // 2
            cv2.putText(output, text, (rekom_text_x, rekom_text_y), font, font_scale, (255, 255, 255), thickness)

    # Tampilkan hasil
    cv2.imshow("MCF Detector Video", output)

    # Simpan ke video
    out.write(output)

    if cv2.waitKey(1) & 0xFF == ord('q'):
        break

# Release semuanya
cap.release()
out.release()
cv2.destroyAllWindows()
