Hardware components | ||||||
| × | 1 |
Our mission when creating this project was :
• Teach ALL kids the fundamentals of AI and machine learning
• Bring AI to life with games and hardware and software creation activities
• Send kids home with a computer they assembled and a machine learning application they trained
• AI fundamentals distilled into hardware and software design
• Consciously designed to be understandable by using simple peripherals – LEDs, buttons, dials, simple text…
• AI application software built around the concept of training a robot to work in a Box Factory
• Kids took home the box they built with access to the software and teaching materials
We worked closely with a middle school administration to identify talented kids who can not typically afford an expensive coding camp, found a corporate sponsor to underwrite the camp (many thanks Arm Inc!), and delivered the most advanced possible week-long computer science camp with no cost to the kids families.
Find out more at: www.fryden-learning.com
AI basics as a games: http://www.fryden-learning.com/be-the-machine
Advanced AI for kids: http://www.fryden-learning.com/fryden-machine-learning-class
Making the hardware: http://www.fryden-learning.com/fryden-assembly-instructions
The AI teaching application: http://www.fryden-learning.com/box-factory
...and most importantly the kids comments and testimonials:Other games that teachers make, they would say it’s fun and educational but turns out to be really boring. I’m usually telling my parents that I hate summer schools because they take out time of my summer, but this time, I think it was really worth it.
I loved this camp because it is one of a kind due to the teachers and what we did like soldering, code an Arduino, and put together the computer and see the parts of one so over all I LOVED! My favorite part probably was the solding and the compettitions and also spending time with the classmates and teachers. Spending time with them was very funny and enjoyable.
I love building the fryden box because I like Lego.
I would say machine learning is the process of a machine learning from its mistakes and improving its accuracy at doing its objectives.
Well the camp was so fun is my favorite summer camp I had not be that fun since school ended, this camp is the best.
I loved soldering because it had a little danger to it
Errors are a good thing in machine learning because you can figure what which area your machine needs training on so it won’t make that error again
I have told all my friends about this but they all say it is bored and they rather stay at home but they are wrong, I spent a whole worth it week on this and I realllllllllllllllllly love it!
I was kinda of upset today because I was the sorter today and one of teammate was taking serious during the training mode and work mode worksheet so he kept saying do quick math in your head but I can’t do quick in my head but I tried my on the training mode and work mode, its just that I can’t do quick math in my head.
A one-dimensional problem could be a number line where you can split between the weights of steel weights(exercise weights.) A two-dimensional problem would be a graph of income on they axis and the months on the x axis. A three-dimensional problem would be a 3D graph of the world population, age, and the income of each person.
fryden-due-boxfactory-camp-v1.76.ino
C/C++String verNum = "v1.76";
// FIXED camp errors
// *********TODO due
// use json or xml to send data to the simulator
//
// test the serial tx state machine with random delays and noise
// fix reset mode - make sure everything resets so we dont have to pull the flash card
// (text for red to exit? on training/work modes)
// plan to prep all the flash cards...(delete settings file to ensure it boots)
// autodect i2c address and auto config on boot - not sure this is possible
// calibrate dials to 512 at the center
// screen save - bunches at the top?
// instructions text into the mode OR pull instructions mode.
// comment blocks above all functions and names at the top to search against
// boing score - capture 2 scorws based on length of rally and who dropped the ball
// NOT DONE - wav - files placeholders for all - welcome to the fryden audio
// NOT DONE - wav - audio interupt collisions when using the wavfile palyer and the tone lib....
// NOT DONE - wav - remember playwavs in the settings
// NOT DONE - tricky - shape the colors to make the mid case of orange better to see - less green...
// DONE - BUG - setting guild POT selects a blank option.
// DONE - BUG - entername - clear screen
// DONE - stop sending after 5 upload attemts
// DONE - redesign a safer state machine for the recieve bytes
// DONE - placeholder for welcome tune.
// DONE - all params to file ser/de-ser accross the serial link inc. glyphs
// DONE - names - ZAPPA SYNTH & boing
// DONE - make the binary save to file for if we want to save edited glyphs
// DONE - lock symbols over write the menu bar by wrapping around
// DONE - lock symbol appears on stettings menu
// DONE - ligthening spelt wrong
// DONE - screen save x secs after the menu interactions
// DONE - more phrases into the "thanks for teaching me" "yes i know..."
// DONE - pong sounds
// DONE - dial for 0.8 to 1.4 = be able to change learning rate and gbRadius by settings - gbradius makes the game harder
// DONE - make the glyph colors constants.
// DONE - basic sysnth code needs adding
// DONE - synth - make 2 on the joystick...
// DONE - screen save messages - code and vocab answers
// DONE - custom glyph on start screen & LED matrix.
// DONE - add the guild names to the name / description all the way through to the simluator / guild comes after naming
// DONE - enter custom name in settings -- // settings - add name from a file // add you own name for custom names - reset - if never set then set it
// DONE - name flow - unnamed - must force naming after reset
// DONE - guild name into settings
// DONE - on power up and flash the guild symbols and say "I am..." of the
// DONE - clear the neo pixel on start up
// DONE - put Mr Brydens glyphs in.
// **********Notes and other less critical todo's
// BOER - needs a factory restet to be reprogrammed....
// Crash on processing APP if it reads corruot data - needs to recover
// upgrade two protos to work on PCB versions
// State of mind crashed for some reason - may have been the ~~ name markers?
// NOTE - 5 traing sets at 0.0001, 1.2 to get 100%
// design and doc the fastest test plan at this rate.
// add a factory reset - on boot - to reset the file system
// idelly make a split20 function for easier text creation - hard - needs to find spaces
// lineraize joystick map potends 2-1020
// redo all the sounds to avoid low freq's // make new learning sound for the nn's
// change nn to perceptron - text and code
// make sure you cant add more than 16 menus or 32 pages lines - and test it
// find and remove all debug printlns // check the serial port for actvitity
// test SD card init fail message on LCD
// function grouping, coding, commenting and tidying
// go all through delay and costants in the code and #define
// Perceprotn notes: prediction 1 = large red -1 = small green
// box size/color ranges
// boxSize = 0..31 ; 32 steps ; 8 leds x 4 level of brigthness
// colVal = max 32 + 128 = 32..159 ; works best for neopixel display
String boxName = "BRAIN BOX";
String boxGuild = "NINJA";
//Due board/shield IO
#define potLeft A0
#define potCenter A1
#define potRight A2
#define redButton 4
#define greenButton 3
#define blueButton 2
#define joyH A4
#define joyButton 5
#define joyV A5
#define ampEnable A3
#define sdCs 38
#define neoPinMatrix 7
#define neoPinSingle 6
// app params
#define buttonReleaseDelay 150
#define LCDscrollSpeed 200
#define NEOscrollSpeed 75
#define makeBoxDuration 2000
#define makeBoxDurationBy2 1000
//#define makeSound true
#define analyzeBoxDuration 1500
//#define analyzeBoxDurationBy2 750
#define trainBoxDuration 2000
//#define trainBoxDurationBy2 750
#define cMax 400
#define learningRate 0.0001
#include <Wire.h>
#include <LiquidCrystal_PCF8574.h>
#include <Adafruit_NeoMatrix.h>
#include <Adafruit_NeoPixel.h>
#include <SD.h>
#include <SPI.h>
#include <Audio.h>
enum potPostion {
left,
right,
center
};
enum buttonColor {
blue,
red,
green,
joy,
any
};
//JF-
LiquidCrystal_PCF8574 lcd(0x3F); // set the LCD address
//LiquidCrystal_PCF8574 lcd(0x27); // set the LCD address
Adafruit_NeoMatrix matrix = Adafruit_NeoMatrix(8, 8, neoPinMatrix,
NEO_MATRIX_LEFT + NEO_MATRIX_TOP +
NEO_MATRIX_ROWS + NEO_MATRIX_PROGRESSIVE,
NEO_GRB + NEO_KHZ800);
Adafruit_NeoPixel leds = Adafruit_NeoPixel(1, neoPinSingle, NEO_RGB + NEO_KHZ800);
unsigned long scrollNEOMilliSec;
String scrollNEOMessage = "............................................";
int scrollNEOMessageReset;
int scrollNEOMessagePos;
uint16_t scrollNEOColor;
unsigned long lastPressed;
float goodBoxRadius = 1.1;
int trainCycles = 0;
int totalTrainingExamples = 0;
int totalCorrect = 0;
float workModeAverage = 0;
int workModeBest = 0;
// menu & text-pages globals
unsigned long lastRead = 0;
enum joyVDir {
down,
up,
middle
};
String bs = " ";
joyVDir posNow = middle;
joyVDir posLast = middle;
int entrySel=0;
int menuNumEntries=0;
String menuEntries[16] = {bs,bs,bs,bs,bs,bs,bs,bs,bs,bs,bs,bs,bs,bs,bs,bs};;
String menuHeading;
boolean menuUpdateLCD;
int pageNumEntries=0;
String pageEntries[32] = {bs,bs,bs,bs,bs,bs,bs,bs,bs,bs,bs,bs,bs,bs,bs,bs,bs,bs,bs,bs,bs,bs,bs,bs,bs,bs,bs,bs,bs,bs,bs,bs};
String pageHeading;
boolean pageUpdateLCD;
// initialize the neural net waits and learning constant
float nnWeights[3] = {-1.0,1.0,0.0};
float nnLearningC = learningRate;
// main menu options
#define mainMenuSize 9
//"-----------------" 17 char ref
String mainMenuEntries[mainMenuSize] = {
"Show brain state",
"Training mode",
"Work mode",
"Upload to factory",
"Analyze mode",
"Play Boing",
"Zappa Synth",
"Instructions",
"Settings"
};
boolean menuLocks[mainMenuSize] = {0,0,0,0,0,1,1,0,0};
//boolean menuLocks[mainMenuSize] = {0,0,0,0,0,0,0,0,0};
#define pongLock 5
#define synthLock 6
//"-----------------" 17 char ref
#define settingsMenuSize 6
String settingsMenuEntries[mainMenuSize] = {
"Volume",
"Set difficulty",
"Name the brain",
"Reset brain",
"About",
"Main menu"
};
enum modeType {
welcome,
work,
brainstate,
menu,
train,
analyze,
factory,
settings,
instructions,
pong,
synth
};
modeType mode = welcome;
String modeDesc;
#define SINE_SAMPLES 882 // 44.1khz / 50hz = 882 samples need for a full 50 hz sine wave
uint16_t sineWave[SINE_SAMPLES];
// the phase accumulator points to the current sample in our wavetable
uint32_t ulPhaseAccumulatorA = 0;
uint32_t ulPhaseAccumulatorB = 0;
// the phase increment controls the rate at which we move through the wave table
// higher values = higher frequencies
volatile uint32_t ulPhaseIncrementA = 0; // 32 bit phase increment, see below
volatile uint32_t ulPhaseIncrementB = 0; // 32 bit phase increment, see below
// full waveform = 0 to SAMPLES_PER_CYCLE
// Phase Increment for 1 Hz =(SAMPLES_PER_CYCLE_FIXEDPOINT/SAMPLE_RATE) = 1Hz
// Phase Increment for frequency F = (SAMPLES_PER_CYCLE/SAMPLE_RATE)*F
#define SAMPLE_RATE 44100.0
#define SAMPLES_PER_CYCLE 882
#define SAMPLES_PER_CYCLE_FIXEDPOINT (SAMPLES_PER_CYCLE<<20)
#define TICKS_PER_CYCLE (float)((float)SAMPLES_PER_CYCLE_FIXEDPOINT/(float)SAMPLE_RATE)
#define MIDI_NOTES 128
uint32_t nMidiPhaseIncrement[MIDI_NOTES];
float toneMixA;
float toneMixB;
boolean playDual = false;
unsigned long tTime;
int tDuration;
boolean toneActive = false;
boolean sdInit = false;
#define paramLen 40
byte params[paramLen];
boolean loadedSettings = false;
int volume = 3;
String guildNames[3] = {"NINJA","PHOENIX","LIGHTNING"};
const uint32_t gRed = matrix.Color(128,0,0); // R
const uint32_t gOrange = matrix.Color(120,40,2); // O
const uint32_t gYellow = matrix.Color(100,80,0); // Y
const uint32_t gBlue = matrix.Color(0,0,128); // B
const uint32_t gPurple = matrix.Color(128,0,128); // P
const uint32_t gGreen = matrix.Color(0,128,0); // G
const uint32_t gTeal = matrix.Color(32,64,64); // T
const uint32_t gBlack = matrix.Color(0,0,0); // B
const uint32_t gWhite = matrix.Color(100,80,100); // W
char guildGlyphs[3][8][8] = {{
{'O','O','O','O',' ',' ',' ','O'},
{' ','O','O','O','O',' ','O','O'},
{' ',' ','O','O','O','O','O','O'},
{' ','O','O',' ',' ','O','O','O'},
{'O','O','O',' ',' ','O','O',' '},
{'O','O','O','O','O','O',' ',' '},
{'O','O',' ','O','O','O','O',' '},
{'O',' ',' ',' ','O','O','O','O'}
},{
{' ',' ',' ',' ',' ',' ',' ',' '},
{' ',' ',' ',' ','R',' ',' ',' '},
{' ',' ',' ','R','R',' ',' ',' '},
{' ','R',' ','R','R',' ','R',' '},
{' ','R','R','R','O','R','R',' '},
{' ','R','O','O','Y','O','R',' '},
{' ','R','Y','Y','Y','Y','R',' '},
{' ',' ','R','Y','Y','Y','R',' '}
},{
{' ',' ',' ',' ','B','T','B',' '},
{' ',' ',' ','B','T','B',' ',' '},
{' ',' ','B','T','B',' ',' ',' '},
{' ','B','T','T','T','T','T','B'},
{'B','T','T','T','T','T','B',' '},
{' ',' ',' ','B','T','B',' ',' '},
{' ',' ','B','T','B',' ',' ',' '},
{' ','B','T','B',' ',' ',' ',' '}
}};
int tile[8][8];
boolean moved[8][8];
byte lock[8] = {
B01110,
B11011,
B10001,
B10001,
B11111,
B11011,
B11011,
B11111
};
#define screenSaverTime 60000
#define saverTextMinShow 5000
#define saverTextNum 33
String saverText[33][4] = {
{"PERCEPTRON: is a one","NODE NEURAL NETWORK","that can CLASSIFY", "LINEAR SEPARATE DATA"},
{"CLASSIFY: sort data","into different","categories or types","by giving it a name"},
{"LINEAR SEPARATE","DATA: data that can","separated by a line","drawn on a graph"},
{"NEURAL NETWORK: is a","simple model of how","biological neurons","cooperate in a brain"},
{"NEURAL NETWORK: can","learn by TRAINING to","perform tasks by","being shown examples"},
{"NEURAL NETWORK: is a","network of NODES","that are connected","together by WEIGHTS"},
{"WEIGHT MEMORY: is a","store of WEIGHTS","that acts as long","term memory"},
{"WEIGHTS: numbers","that show a strength","of connection","between the NODES"},
{"WEIGHTS: are learnt","and adjusted during","TRAINING and connect","NODES together"},
{"NODES: are single","processing units","that mimic a real","biological neuron"},
{"NODES: calculate","-inputs X WEIGHTS-","and outputs a signal","to other nodes"},
{"NODES: fires an","output signal when","the sum of its input","exceeds a THRESHOLD"},
{"THRESHOLD: a number","to compare against","to say what category","something is"},
{"MAPPING: turns real","world data like","color and size into","INPUT SIGNALS"},
{"MAPPING: turns the","OUTPUT SIGNALS","into real world data","like -box type-"},
{"INPUT SIGNALS: are","numbers that feed","the inputs of a","NEURAL NETWORK"},
{"OUTPUT SIGNALS: are","calculated by the","NEURAL NETWORK to","CLASSIFY input data"},
{"LEARNING: getting","better at performing","a task by receiving","TRAINING"},
{"LEARNING: knowledge","gained by seeing","many good and bad","examples of a thing"},
{"LEARNING: NEURAL","NETWORKS learn by a","a method called BACK","PROPAGATION"},
{"TRAINING: a process","of structured","LEARNING that uses","TRAINING EXAMPLES"},
{"TRAINING EXAMPLES:","a pre-planned set of","good & bad examples","to teach with"},
{"BACK PROPAGATION:","uses an ERROR SIGNAL","to adjust the WEIGHT","MEMORY contents"},
{"BACK PROPAGATION: is","the type of LEARNING","used by a NEURAL","NETWORK"},
{"ERROR SIGNAL: is the","diff. between OUTPUT","SIGNALS and the","TRAINING EXAMPLES"},
{"ERROR SIGNAL: is a","way to tell a NEURAL","NETWORK if it is","correct or not"},
{"<box name> uses a","PERCEPTRON to","CLASSIFY different","size and color boxes"},
{"<box name> is a","simple example of","MACHINE LEARNING and","NEURAL NETWORKS"},
{"MACHINE LEARNING: is","a subset of AI and","is a branch of study","in Computer Science"},
{"MACHINE LEARNING:","allows machines to","learn new tasks","without programming"},
{"MACHINE LEARNING:","commonly uses NEURAL","NETWORKS as the main","form of intelligence"},
{"AI: aims to make","computers as smart","or smarter than a","human!"},
{"AI: uses MACHINE","LEARNING as a tool","to becoming more","intelligent"},
};
#define potMax 700
#define potMin 300
enum pongGameMode {
pongPlay,
pongShowScore,
pongWait,
pongExit
};
pongGameMode pongMode = pongWait;
int ballSpeed = 200;
int ballPosX;
int ballPosY;
int ballDirX;
int ballDirY;
int rightPaddlePos;
int leftPaddlePos;
boolean stickBallToPaddle;
int ballOnPaddle;
unsigned long lastBallUpdate;
boolean checkBall;
int pongLives;
unsigned long int pongScore;
unsigned long int pongScoreIncrement = 10;
String trainCorrect[5] = {
"YES, I knew it was",
"HA! as I thought, ",
"OH YEAH - that's",
"Thankyou. I know its",
"BOOM. I was right!"
};
String trainWrong[5] = {
"NO! I was sure its",
"OH, I thought it was",
"HUH I was wrong with",
"I'm shocked its not",
"Now I see its not"
};
void setup() {
Serial.begin(115200);
pinMode(potLeft, INPUT);
pinMode(potCenter, INPUT);
pinMode(potRight, INPUT);
pinMode(greenButton, INPUT);
pinMode(blueButton, INPUT);
pinMode(redButton, INPUT);
pinMode(joyButton, INPUT);
pinMode(joyH, INPUT);
pinMode(joyV, INPUT);
pinMode(ampEnable, OUTPUT);
// setup SD-card
if (!SD.begin(sdCs)) {
sdInit = false;
} else {
sdInit = true;
}
/* turn on the timer clock in the power management controller */
pmc_set_writeprotect(false);
pmc_enable_periph_clk(ID_TC4);
/* we want wavesel 01 with RC */
TC_Configure(/* clock */TC1,/* channel */1, TC_CMR_WAVE | TC_CMR_WAVSEL_UP_RC | TC_CMR_TCCLKS_TIMER_CLOCK2);
TC_SetRC(TC1, 1, 238); // sets <> 44.1 Khz interrupt rate
TC_Start(TC1, 1);
// enable timer interrupts on the timer
TC1->TC_CHANNEL[1].TC_IER=TC_IER_CPCS;
TC1->TC_CHANNEL[1].TC_IDR=~TC_IER_CPCS;
/* Enable the interrupt in the nested vector interrupt controller */
/* TC4_IRQn where 4 is the timer number * timer channels (3) + the channel number (=(1*3)+1) for timer1 channel1 */
NVIC_EnableIRQ(TC4_IRQn);
// make the look up tables
createNoteTable(SAMPLE_RATE);
makeSineWave();
//set up the dac
analogWriteResolution(12);
analogWrite(DAC1, 0);
lcd.begin(20, 4); // initialize the lcd
lcd.setBacklight(1);
lcd.createChar(0, lock);
matrix.begin();
matrix.setTextWrap(false);
matrix.setBrightness(60);
matrix.clear();
matrix.clear();
leds.begin();
leds.setBrightness(60);
leds.clear();
leds.show();
// JF-
// uncomment lines below if you need to delete a corrupt log file
//if (SD.exists("settings.txt"))
// SD.remove("settings.txt");
loadedSettings = readSettings();
seedRNG();
lastBallUpdate = millis();
checkBall = false;
readPaddlePosition();
stickBallToPaddle = true;
ballOnPaddle = random(2);
leds.clear();
leds.show();
Serial.print(boxName);
Serial.print(" flush serial port....");
Serial.flush();
}
void enterName() {
// 16 chars
// show cursor
// A-Z
// joy stick v - move cursor
// joy buuton to select - any othe button to finish
// middle dial to select guild
matrix.clear();
matrix.show();
lcd.clear();
lcd.setCursor(0,0);
lcd.print("Use the dials to ");
lcd.setCursor(0,1);
lcd.print("name your brain and");
lcd.setCursor(0,2);
lcd.print("select your guild.");
while(!buttonPressed(any)) {
}
lcd.clear();
int cPos = 0;
int cSel = 0;
int cPosLast = -1;
int cSelLast = -1;
int pv = 0;
String newName = padString(12,boxName);
boolean nameSet = false;
while(!nameSet) {
pv = analogRead(potRight);
pv = floor(pv/342);
// need to copy this if modded to welcome/set-name
for (int x=0; x<8; x++) {
for (int y=0; y<8; y++) {
uint32_t c = matrix.Color(0,0,0);
switch (guildGlyphs[pv][x][y]) {
case 'R':
c = gRed;
break;
case 'O':
c = gOrange;
break;
case 'Y':
c = gYellow;
break;
case 'B':
c = gBlue;
break;
case 'T':
c = gTeal;
break;
case 'G':
c = gGreen;
break;
case 'P':
c = gPurple;
break;
case 'W':
c = gWhite;
break;
case ' ':
c =gBlack;
break;
default:
c = gBlack;
break;
}
matrix.drawPixel(y,x,c);
}
}
cPos = analogRead(potLeft);
cPos = floor(cPos/86);
cSel = analogRead(potCenter);
cSel = floor(cSel/39);
if (cSel != cSelLast) {
char c = cSel + 65;
if (cSel == 26)
c = ' ';
newName.setCharAt(cPos,c);
lcd.setCursor(4,0);
lcd.print(newName);
}
if (cPos != cPosLast) {
lcd.setCursor(0,1);
lcd.print(padString(20," "));
lcd.setCursor(cPos+4,1);
lcd.print("^");
}
//lcd.noCursor();
lcd.setCursor(0,3);
lcd.print(padString(20,guildNames[pv]));
matrix.show();
cSelLast = cSel;
cPosLast = cPos;
if (buttonPressed(any))
nameSet = true;
}
boxName = newName;
boxName.trim();
boxGuild = guildNames[pv];
logSettings();
matrix.clear();
matrix.show();
}
void factoryMode() {
unsigned long t = 0;//millis();
union {byte b[4];float f;} temp;
byte * b;
logSettings();
lcd.clear();
lcd.setCursor(0,0);
lcd.print("Uploading brain");
lcd.setCursor(0,1);
lcd.print("to the box factory.");
int selected = 0;
selected = pageUpdate();
int i = 0;
while(!buttonPressed(any) && (i<5)) {
if (millis()-t > 5000) {
Serial.print("SoS");
Serial.flush();
Serial.print(padString(20,boxName));
Serial.flush();
Serial.print(padString(20,boxGuild));
int pv = 0;
if (boxGuild == "PHOENIX")
pv = 1;
if (boxGuild == "LIGHTNING")
pv = 2;
for (int x=0; x<8; x++) {
for (int y=0; y<8; y++) {
Serial.print(guildGlyphs[pv][x][y]);
}
Serial.flush();
}
for (int i=0; i<paramLen; i++) {
temp.b[i%4] = params[i];
if (i%4 == 3) {
b = (byte *) &temp.f;
Serial.write(b[0]);
Serial.write(b[1]);
Serial.write(b[2]);
Serial.write(b[3]);
Serial.flush();
}
}
i++;
lcd.setCursor(0,3);
lcd.print("sent:"+String(i));
t = millis();
}
}
mode = menu;
}
void loop() {
switch (mode) {
case welcome:
modeDesc = "Welcome Mode";
welcomeMode();
break;
case work:
modeDesc = "Work Mode";
workMode();
break;
case brainstate:
modeDesc = "State Mode";
stateOfMind();
break;
case menu:
modeDesc = "Menu Mode";
mainMenu();
break;
case train:
modeDesc = "Train Mode";
trainMode();
break;
case analyze:
modeDesc = "Analyze Mode";
analyzeMode();
break;
case factory:
modeDesc = "Factory Mode";
factoryMode();
break;
case settings:
modeDesc = "Settings Mode";
settingsMode();
break;
case instructions:
modeDesc = "Instr. Mode";
instructionsMode();
break;
case pong:
modeDesc = "Pong Mode";
pongLoop();
break;
case synth:
modeDesc = "Synth";
synthMode();
break;
}
}
// ***************************************************************************************
// stateOfMind
// ***************************************************************************************
void stateOfMind() {
lcd.clear();
pageClear();
pageAddHeading("----BRAIN--STATE----");
pageAddEntry(0, "I am " + boxName);
pageAddEntry(1, boxGuild + " guild");
pageAddEntry(2, "Training sets=" + String(trainCycles));
pageAddEntry(3, "Accuracy=" + String(workModeAverage,2));
pageAddEntry(4, "Best score=" + String(workModeBest));
pageAddEntry(5, "Perceptron weight:");
pageAddEntry(6, "--W0=" + String(nnWeights[0],13));
pageAddEntry(7, "--W1=" + String(nnWeights[1],13));
pageAddEntry(8, "--W2=" + String(nnWeights[2],13));
pageAddEntry(9, "Learning rate:");
pageAddEntry(10, "--rate="+ String(nnLearningC,11));
pageAddEntry(11, "Box generators:");
pageAddEntry(12, "--cMax=" + String(cMax));
pageAddEntry(13, "--gbRadius=" + String(goodBoxRadius,4));
int selected = 0;
selected = pageUpdate();
while(!buttonPressed(any)) {
selected = pageUpdate();
for (int x=0; x<8; x++) {
for (int y=0; y<8; y++) {
int xs = random(0, 100); //cmax*2 / 8 = 100
int ys = random(0, 100);
xs += (x-4)*100;
ys += (y-4)*100;
float prediction = (nnFeedForward(xs, ys) + 1.0)/2.0;
prediction *= 127.0;
uint16_t RGB = matrix.Color(prediction, 128-prediction, 0);
matrix.drawPixel(x, 7-y, RGB);
}
}
matrix.show();
}
/*
// map the learning state to a color: 50 or lower bad = red .... 100 good = green
float col = ((workModeAverage-50)/50)*128;
if (col < 0)
col = 0;
setNEOScrollMessage("SHOWING MY STATE OF MIND ",matrix.Color(128-col, col, 0));
int selected = 0;
while(!buttonPressed(any)) {
updateNEOScrollMessage();
selected = pageUpdate();
}*/
mode = menu;
}
void analyzeMode() {
lcd.clear();
matrix.clear();
matrix.show();
pageClear();
pageAddHeading("----ANALYZE-MODE----");
pageAddEntry(0,"Use the dials to");
pageAddEntry(1,"make colored");
pageAddEntry(2,"boxes .....");
//need nore
int selected = 0;
selected = pageUpdate();
while(!buttonPressed(any)) {
//updateNEOScrollMessage();
selected = pageUpdate();
}
lcd.clear();
float xs = 0;
float ys = 0;
// make a box until any button is pushed
while(!buttonPressed(blue)) {
xs = (((float)analogRead(potLeft) / 511.5)-1.0)*cMax;
if (xs < -374) xs = -374;
ys = (((float)analogRead(potRight) / 511.5)-1.0)*cMax;
int boxSize = ((xs+cMax)/(cMax*2))*31;
int boxColor = (((ys+cMax)/(cMax*2))*127)+32;
drawBox(boxSize, boxColor, true);
// run the neural net forward
int prediction = nnFeedForward(xs, ys);
// prediction 1 = large red -1 = small green
lcd.setCursor(0, 0);
lcd.print(padString(20,"Use the dials to"));
lcd.setCursor(0, 1);
lcd.print(padString(20,"make boxes."));
lcd.setCursor(0, 2);
lcd.print(padString(20,"I think this is a "));
lcd.setCursor(0, 3);
if (prediction == 1)
lcd.print(padString(20,"large red box."));
else
lcd.print(padString(20,"small green box."));
}
lcd.clear();
matrix.clear();
matrix.show();
mode = menu;
return;
}
void aboutMode() {
lcd.clear();
pageClear();
pageAddHeading("--FRYDEN-LEARNING--");
pageAddEntry(0, "Box factory ver:");
pageAddEntry(1, verNum);
pageAddEntry(2, "Please visit:");
pageAddEntry(3, "fryden-learning.com");
pageAddEntry(4, "Supported by:");
pageAddEntry(5, "Arm Inc.");
pageAddEntry(6, "Sunstone Circuits");
while(!buttonPressed(any)) {
int selected = pageUpdate();
}
}
void instructionsMode() {
lcd.clear();
lcd.setCursor(0, 0);
lcd.print("...in "+modeDesc);
delay(2000);
mode = menu;
}
void settingsMode() {
boolean leave = false;
while (!leave) {
lcd.clear();
menuClear();
menuAddHeading("------SETTINGS------");
for (int i=0; i<settingsMenuSize; i++) {
menuAddEntry(i, settingsMenuEntries[i]);
}
int selected = 0;
while(!buttonPressed(any)) {
selected = menuUpdate(false);
}
switch (selected) {
case 0:
setVolume();
break;
case 1:
setDifficulty();
break;
case 2:
enterName();
break;
case 3:
resetBrain();
break;
case 4:
aboutMode();
break;
case 5:
leave = true;
break;
default:
return;
}
}
mode = menu;
}
void resetBrain() {
lcd.clear();
lcd.setCursor(0, 0);
lcd.print("Green = reset brain");
lcd.setCursor(0, 1);
lcd.print("Red = cancel");
boolean answered = false;
while(!answered) {
if (buttonPressed(red)) {
answered = true;
lcd.setCursor(0, 3);
lcd.print("Brain not reset.");
} else if (buttonPressed(green)) {
answered = true;
boxName = "BRAIN BOX";
boxGuild = "NINJA";
nnWeights[0] = -1.0;
nnWeights[1] = 1.0;
nnWeights[2] = 0.0;
nnLearningC = learningRate;
trainCycles = 0;
totalTrainingExamples = 0;
totalCorrect = 0;
workModeAverage = 0;
workModeBest = 0;
goodBoxRadius = 1.1;
lcd.setCursor(0, 3);
lcd.print("Brain reset.");
}
}
removeSettingsLog();
delay(1500);
return;
}
void setVolume() {
lcd.clear();
lcd.setCursor(0,0);
lcd.print("Use the middle dial");
lcd.setCursor(0,1);
lcd.print("to adjust the volume");
unsigned long toneTimeStamp = millis();
boolean hiLow = false;
ampOn();
while(!buttonPressed(any)) {
int pv = potValue(center, 0.01);
if (pv < 0)
pv = 0;
if (pv > 10)
pv = 10;
volume = pv;
lcd.setCursor(0,3);
lcd.print("Volume="+String(volume)+" ");
if (millis() - toneTimeStamp > 300) {
toneTimeStamp = millis();
if (hiLow)
playTone(60,1000);
else
playTone(90,1000);
hiLow = !hiLow;
}
}
ampOff();
return;
}
void removeSettingsLog() {
if (sdInit) {
if (SD.exists("settings.txt"))
SD.remove("settings.txt");
}
}
void logSettings() {
if (sdInit) {
if (SD.exists("settings.txt"))
SD.remove("settings.txt");
paramsToBytes();
File settings = SD.open("settings.txt", FILE_WRITE);
if (settings) {
settings.print("~" + boxName + "~");
settings.print("!" + boxGuild + "!");
for (int i=0; i<paramLen; i++) {
settings.write(params[i]);
}
settings.close();
} else {
}
}
}
boolean readSettings() {
boolean loaded = false;
if (sdInit) {
if (SD.exists("settings.txt")) {
File settings = SD.open("settings.txt");
char c;
int tf=0;
String n = "";
while (tf<2) {
c = (char) settings.read();
if (c=='~')
tf++;
n += c;
}
tf = 0;
String g = "";
while (tf<2) {
c = (char) settings.read();
if (c=='!')
tf++;
g += c;
}
int i=0;
byte b;
while(settings.available() && i<paramLen) {
b = (byte) settings.read();
params[i++] = b;
}
loaded = true;
bytesToParams();
boxName = n.substring(1,n.length()-1);
boxGuild = g.substring(1,g.length()-1);
}
}
return loaded;
}
void paramsToBytes() {
int i=0;
byte * b;
union {byte b[4];float f;} temp;
temp.f = nnLearningC; params[i++] = temp.b[0]; params[i++] = temp.b[1]; params[i++] = temp.b[2]; params[i++] = temp.b[3];
temp.f = goodBoxRadius; params[i++] = temp.b[0]; params[i++] = temp.b[1]; params[i++] = temp.b[2]; params[i++] = temp.b[3];
temp.f = nnWeights[0]; params[i++] = temp.b[0]; params[i++] = temp.b[1]; params[i++] = temp.b[2]; params[i++] = temp.b[3];
temp.f = nnWeights[1]; params[i++] = temp.b[0]; params[i++] = temp.b[1]; params[i++] = temp.b[2]; params[i++] = temp.b[3];
temp.f = nnWeights[2]; params[i++] = temp.b[0]; params[i++] = temp.b[1]; params[i++] = temp.b[2]; params[i++] = temp.b[3];
temp.f = workModeAverage; params[i++] = temp.b[0]; params[i++] = temp.b[1]; params[i++] = temp.b[2]; params[i++] = temp.b[3];
b = (byte *) &trainCycles; params[i++] = b[0]; params[i++] = b[1]; params[i++] = b[2]; params[i++] = b[3];
b = (byte *) &totalCorrect; params[i++] = b[0]; params[i++] = b[1]; params[i++] = b[2]; params[i++] = b[3];
b = (byte *) &totalTrainingExamples; params[i++] = b[0]; params[i++] = b[1]; params[i++] = b[2]; params[i++] = b[3];
b = (byte *) &workModeBest; params[i++] = b[0]; params[i++] = b[1]; params[i++] = b[2]; params[i++] = b[3];
}
void bytesToParams() {
int i=0;
union {byte b[4];float f;} temp;
temp.b[0] = (params[i++]); temp.b[1] = (params[i++]); temp.b[2] = (params[i++]); temp.b[3] = (params[i++]);
nnLearningC = temp.f;
temp.b[0] = (params[i++]); temp.b[1] = (params[i++]); temp.b[2] = (params[i++]); temp.b[3] = (params[i++]);
goodBoxRadius = temp.f;
temp.b[0] = (params[i++]); temp.b[1] = (params[i++]); temp.b[2] = (params[i++]); temp.b[3] = (params[i++]);
nnWeights[0] = temp.f;
temp.b[0] = (params[i++]); temp.b[1] = (params[i++]); temp.b[2] = (params[i++]); temp.b[3] = (params[i++]);
nnWeights[1] = temp.f;
temp.b[0] = (params[i++]); temp.b[1] = (params[i++]); temp.b[2] = (params[i++]); temp.b[3] = (params[i++]);
nnWeights[2] = temp.f;
temp.b[0] = (params[i++]); temp.b[1] = (params[i++]); temp.b[2] = (params[i++]); temp.b[3] = (params[i++]);
workModeAverage = temp.f;
trainCycles = (int)(((params[i++] & 0xff) << 0) | ((params[i++] & 0xff) << 8) | ((params[i++] & 0xff) << 16) | ((params[i++] & 0xff) << 24));
totalCorrect = (int)(((params[i++] & 0xff) << 0) | ((params[i++] & 0xff) << 8) | ((params[i++] & 0xff) << 16) | ((params[i++] & 0xff) << 24));
totalTrainingExamples = (int)(((params[i++] & 0xff) << 0) | ((params[i++] & 0xff) << 8) | ((params[i++] & 0xff) << 16) | ((params[i++] & 0xff) << 24));
workModeBest = (int)(((params[i++] & 0xff) << 0) | ((params[i++] & 0xff) << 8) | ((params[i++] & 0xff) << 16) | ((params[i++] & 0xff) << 24));
}
void playIntroTune() {
/*
ampOn();
playDualTone(75, 105, 0.1, 100000);
delay(1000);
playDualTone(75, 105, 0.33, 100000);
delay(1000);
playDualTone(75, 105, 0.66, 100000);
delay(1000);
playDualTone(75, 105, 0.9, 100000);
delay(1000);
ampOff();
*/
}
// ***************************************************************************************
// welcomeMode
// ***************************************************************************************
void welcomeMode() {
unsigned long welcomeTimeStamp;
lcd.clear();
if (!loadedSettings) {
enterName();
}
if (!sdInit) {
lcd.setCursor(0, 0);
lcd.print("SD Card init failed!");
delay(5000);
}
lcd.clear();
lcd.setCursor(0, 0);
lcd.print("Box Factory " + verNum + " ");
lcd.setCursor(0, 2);
lcd.print("I am " + boxName);
lcd.setCursor(0, 3);
lcd.print(boxGuild + " guild");
welcomeTimeStamp = millis();
int pv = 0;
if (boxGuild == "PHOENIX")
pv = 1;
if (boxGuild == "LIGHTNING")
pv = 2;
playIntroTune();
while ((millis() - welcomeTimeStamp < 15000) && (!buttonPressed(any))) {
// need to copy this if modded to welcome/set-name
for (int x=0; x<8; x++) {
for (int y=0; y<8; y++) {
uint32_t c = matrix.Color(0,0,0);
switch (guildGlyphs[pv][x][y]) {
case 'R':
c = gRed;
break;
case 'O':
c = gOrange;
break;
case 'Y':
c = gYellow;
break;
case 'B':
c = gBlue;
break;
case 'T':
c = gTeal;
break;
case 'G':
c = gGreen;
break;
case 'P':
c = gPurple;
break;
case 'W':
c = gWhite;
break;
case ' ':
c = gBlack;
break;
default:
c = gBlack;
break;
}
matrix.drawPixel(y,x,c);
}
}
matrix.show();
}
matrix.fillScreen(0);
mode = menu;
}
void mainMenu() {
pongMode = pongWait;
matrix.clear();
matrix.show();
leds.clear();
leds.show();
lcd.clear();
menuClear();
menuAddHeading("-----MAIN--MENU-----");
for (int i=0; i<mainMenuSize; i++) {
menuAddEntry(i, mainMenuEntries[i]);
}
int selected = 0;
int lastSelected = 0;
int sct = millis();
boolean answered = false;
while(!answered) {
selected = menuUpdate(true);
if (lastSelected != selected)
sct = millis();
lastSelected = selected;
if (millis()-sct > screenSaverTime) {
screenSaver();
menuUpdateLCD = true;
sct = millis();
matrix.clear();
matrix.show();
lcd.clear();
}
if (buttonPressed(any) && !menuLocks[selected])
answered = true;
}
switch (selected) {
case 0:
mode = brainstate;
return;
break;
case 1:
mode = train;
return;
break;
case 2:
mode = work;
return;
break;
case 3:
mode = factory;
return;
break;
case 4:
mode = analyze;
return;
break;
case 5:
mode = pong;
return;
break;
case 6:
mode = synth;
return;
break;
case 7:
mode = instructions;
return;
break;
case 8:
mode = settings;
return;
break;
default:
mode = menu;
return;
break;
}
}
void workMode() {
int boxSize = 0;
int boxColor = 0;
unsigned long makeBoxTimeStamp;
unsigned long analyzeBoxTimeStamp;
unsigned long toneTimeStamp;
int toneDuration;
int score = 0;
matrix.clear();
matrix.show();
lcd.clear();
pageClear();
pageAddHeading("-----WORK--MODE-----");
pageAddEntry(0,"My brain will work");
pageAddEntry(1,"on a small set of 10");
pageAddEntry(2,"examples to see how");
pageAddEntry(3,"how well I can tell");
pageAddEntry(4,"the differenence");
pageAddEntry(5,"between small green");
pageAddEntry(6,"boxes and large red");
pageAddEntry(7,"boxes.");
int selected = 0;
selected = pageUpdate();
boolean answered = false;
while(!answered) {
selected = pageUpdate();
if (buttonPressed(red)) {
mode = menu;
return;
}
if (buttonPressed(blue) || buttonPressed(green) || buttonPressed(joy)) {
answered = true;
}
}
delay(500);
for (int j=0; j<10; j++) {
lcd.clear();
lcd.setCursor(0, 0);
lcd.print("Making a sample box");
lcd.setCursor(0, 1);
lcd.print("Please wait.....");
makeBoxTimeStamp = millis();
toneTimeStamp = 0;
int boxType = 0;
float xs = 0;
float ys = 0;
ampOn();
while (millis() - makeBoxTimeStamp < makeBoxDuration) {
matrix.clear();
float x = millis() - makeBoxTimeStamp;
x = ((x-makeBoxDurationBy2)/makeBoxDurationBy2)*6;
float sCurve = 1/(1+exp(-x*1.3));
int sparkleProb = (int) (sCurve * 300);
sCurve = 1/(1+exp(-x*1.0));
int boxRate = (int) (sCurve * 200) + 30;
drawBox(boxSize, boxColor, false);
for (int i=0; i<64; i++) {
int x = random(8);
int y = random(8);
int b = random(128);
uint16_t RGB = matrix.Color(0, 0, b);
if (random(sparkleProb) == 0)
matrix.drawPixel(x, y, RGB);
}
if (millis() - toneTimeStamp > toneDuration) {
toneTimeStamp = millis();
toneDuration = boxRate;
playTone(random(60)+60,toneDuration);
toneDuration = toneDuration * 1.3;
boolean valid = false;
while(!valid) {
xs = random(26, cMax*2);
ys = random(0, cMax*2);
float vDist = sqrt((xs*xs) + (ys*ys));
if (vDist < (goodBoxRadius*cMax)) {
int bc = (int) random(2);
if (bc==1) {
xs -= cMax;
ys -= cMax;
boxType = -1;
} else {
float txs = xs;
xs = (ys*-1)+cMax;
ys = (txs*-1)+cMax;
boxType = 1;
}
valid = true;
}
}
boxSize = ((xs+cMax)/(cMax*2))*31;
boxColor = (((ys+cMax)/(cMax*2))*127)+32;
} // if for making tone.
matrix.show();
} // while
ampOff();
clearTone();
// eval box
drawBox(boxSize, boxColor, true);
lcd.clear();
lcd.setCursor(0, 0);
lcd.print("Analyizing box");
lcd.setCursor(0, 1);
lcd.print("Please wait...");
int prediction = nnFeedForward(xs, ys);
String predictionDesc = "SMALL GREEN box?";
if (prediction == 1)
predictionDesc = "LARGE RED box?";
delay(250);
analyzeBoxTimeStamp = millis();
toneTimeStamp = millis();
toneDuration = 100;
ampOn();
while (millis() - analyzeBoxTimeStamp < analyzeBoxDuration) {
if (millis() - toneTimeStamp > toneDuration * 1.3) {
toneTimeStamp = millis();
playTone(random(40)+30, toneDuration);
} // if for making tone.
} // while
ampOff();
clearTone();
// run NN
// show result
lcd.clear();
lcd.setCursor(0, 0);
lcd.print("I think this box is ");
lcd.setCursor(0, 1);
lcd.print("a ");
lcd.setCursor(2, 1);
lcd.print(predictionDesc);
ampOn();
if(prediction == boxType) {
score++;
lcd.setCursor(0, 3);
lcd.print("------CORRECT-------");
playTone(68,250);
delay(300);
playTone(68,150);
delay(180);
playTone(80,1000);
delay(1300);
} else {
lcd.setCursor(0, 3);
lcd.print("--------WRONG-------");
playTone(62,300);
delay(390);
playTone(56,300);
delay(390);
playTone(45,1000);
delay(1300);
}
ampOff();
clearTone();
delay(1000);
}
// show result
lcd.clear();
lcd.setCursor(0, 1);
lcd.print(padString(20,"Work Results:"));
lcd.setCursor(0, 2);
String finalScore = "";
if (score < 10)
finalScore += "0" + String(score);
else
finalScore += String(score);
finalScore += "/10";
lcd.print(padString(20,finalScore));
delay(3000);
totalCorrect += score;
totalTrainingExamples += 10;
workModeAverage = 100 * ((float)totalCorrect / (float)totalTrainingExamples);
if (score > workModeBest)
workModeBest = score;
if (score == 10)
menuLocks[pongLock] = 0;
ampOff();
logSettings();
mode = brainstate;
}
void trainMode() {
lcd.clear();
matrix.clear();
matrix.show();
pageClear();
pageAddHeading("---TRAINING--MODE---");
pageAddEntry(0,"Use the dials to");
pageAddEntry(1,"make five colored");
pageAddEntry(2,"boxes as examples to");
pageAddEntry(3,"teach my brain.");
pageAddEntry(4,"It will help me");
pageAddEntry(5,"learn if you use");
pageAddEntry(6,"well thought-out");
pageAddEntry(7,"examples. ");
pageAddEntry(8,"I will guess what");
pageAddEntry(9,"the boxes are, and ");
pageAddEntry(10,"learn from my ");
pageAddEntry(11,"mistakes.");
int score = 0;
int selected = 0;
selected = pageUpdate();
boolean answered = false;
while(!answered) {
selected = pageUpdate();
if (buttonPressed(red)) {
mode = menu;
return;
}
if (buttonPressed(blue) || buttonPressed(green) || buttonPressed(joy)) {
answered = true;
}
}
for (int i=0; i<5; i++) {
lcd.clear();
lcd.setCursor(0, 0);
lcd.print(padString(20,"Use the dials to"));
lcd.setCursor(0, 1);
lcd.print(padString(20,"make a box."));
lcd.setCursor(0, 3);
lcd.print(padString(20,"Press blue when done."));
float xs = 0;
float ys = 0;
int error = 0;
// make a box until the blue button is pushed
while(!buttonPressed(blue)) {
xs = (((float)analogRead(potLeft) / 511.5)-1.0)*cMax;
if (xs < -374) xs = -374;
ys = (((float)analogRead(potRight) / 511.5)-1.0)*cMax;
int boxSize = ((xs+cMax)/(cMax*2))*31;
int boxColor = (((ys+cMax)/(cMax*2))*127)+32;
drawBox(boxSize, boxColor, true);
int prediction = nnFeedForward(xs, ys); // run a sneaky prediction
// prediction 1 = large red -1 = small green
uint32_t ledRGB = leds.Color(8,0,0);
if (prediction == -1)
ledRGB = leds.Color(0,8,0);
leds.setPixelColor(0, ledRGB);
leds.show();
}
// run the neural net forward
int prediction = nnFeedForward(xs, ys);
// prediction 1 = large red -1 = small green
boolean answered = false;
while(!answered) {
lcd.setCursor(0, 0);
lcd.print(padString(20,"What type of box"));
lcd.setCursor(0, 1);
lcd.print(padString(20,"is this?"));
lcd.setCursor(0, 2);
lcd.print(padString(20,"Green = small green."));
lcd.setCursor(0, 3);
lcd.print(padString(20,"Red = large red."));
if (buttonPressed(red)) {
answered = true;
error = 1 - prediction;
} else if (buttonPressed(green)) {
answered = true;
error = -1 - prediction;
}
}
lcd.clear();
if (error != 0) {
nnAdjustWeights(xs, ys, error);
lcd.setCursor(0, 0);
lcd.print(padString(20,trainWrong[random(5)]));
lcd.setCursor(0, 1);
if (prediction == -1)
lcd.print(padString(20,"a small green box"));
else
lcd.print(padString(20,"a larger red box"));
lcd.setCursor(0, 3);
lcd.print(padString(20,"Applying learning..."));
unsigned long learningTimeStamp = millis();
unsigned long toneTimeStamp = millis();
int toneDuration = 100;
ampOn();
while (millis() - learningTimeStamp < trainBoxDuration) {
if (millis() - toneTimeStamp > toneDuration * 1.3) {
toneTimeStamp = millis();
playTone(random(40)+30, toneDuration);
} // if for making tone.
} // while
ampOff();
clearTone();
score++;
} else {
lcd.clear();
lcd.setCursor(0, 0);
lcd.print(padString(20,trainCorrect[random(5)]));
lcd.setCursor(0, 1);
if (prediction == -1)
lcd.print(padString(20,"a green box"));
else
lcd.print(padString(20,"a red box"));
unsigned long learningTimeStamp = millis();
while (millis() - learningTimeStamp < trainBoxDuration) {
} // while
}
}
trainCycles++;
logSettings();
mode = brainstate;
if (score==5)
menuLocks[synthLock] = 0;
return;
}
void drawBox(int boxSize, int boxColor, boolean drawImmediate){
int boxSizeInt = boxSize >> 2;
int boxSizeFrac = boxSize & 3;
int r = boxColor;
int g = 160-boxColor;
int b = 0;
//if (boxSize > 16) {
//r = 96-colVal;
//g = 0;
//b = colVal;
//}
uint16_t boxColorRGB = matrix.Color(r, g, b);
if (drawImmediate)
matrix.clear();
for (int x=0; x<boxSizeInt; x++) {
for (int y=0; y<boxSizeInt; y++) {
matrix.drawPixel(x, 7-y, boxColorRGB);
}
}
if (boxSizeFrac == 0) {
r = 0;
g = 0;
b = 0;
}
if (boxSizeFrac == 1) {
r = r >> 2;
g = g >> 2;
b = b >> 2;
}
if (boxSizeFrac == 2) {
r = r >> 1;
g = g >> 1;
b = b >> 1;
}
if (boxSizeFrac == 3) {
r = (r >> 1) + (r >> 2);
g = (g >> 1) + (g >> 2);
b = (b >> 1) + (b >> 2);
}
boxColorRGB = matrix.Color(r, g, b);
for (int y=0; y<boxSizeInt; y++) {
matrix.drawPixel(boxSizeInt, 7-y, boxColorRGB);
}
for (int x=0; x<=boxSizeInt; x++) {
matrix.drawPixel(x, 7-boxSizeInt, boxColorRGB);
}
if (drawImmediate)
matrix.show();
}
// ***************************************************************************************
// potValue
// ***************************************************************************************
int potValue(potPostion whichPot, float scale) {
int value = -1;
switch (whichPot) {
case left:
value = analogRead(potLeft);
break;
case right:
value = analogRead(potRight);
break;
case center:
value = analogRead(potCenter);
break;
}
value = (int) value * scale;
return value;
}
// ***************************************************************************************
// buttonPressed
// ***************************************************************************************
boolean buttonPressed(buttonColor whichButton) {
int joyPress = digitalRead(joyButton);
int greenPress = digitalRead(greenButton);
int bluePress = digitalRead(blueButton);
int redPress = digitalRead(redButton);
boolean pressed = false;
switch (whichButton) {
case blue:
if (bluePress == 0)
pressed = true;
break;
case red:
if (redPress == 0)
pressed = true;
break;
case joy:
if (joyPress == 0)
pressed = true;
break;
case green:
if (greenPress == 0)
pressed = true;
break;
case any:
if ((bluePress == 0) || (redPress == 0) || (joyPress == 0) || (greenPress == 0))
pressed = true;
break;
default:
pressed = false;
}
unsigned long timeSince = millis() - lastPressed;
if ((pressed) && (timeSince < buttonReleaseDelay)) {
lastPressed = millis();
pressed = false;
} else if (pressed) {
lastPressed = millis();
}
return pressed;
}
// ***************************************************************************************
// setNEOScrollMessage
// ***************************************************************************************
void setNEOScrollMessage(String message, uint16_t color) {
scrollNEOMessage = message;
scrollNEOMilliSec = millis();
scrollNEOMessageReset = -6 * scrollNEOMessage.length();
scrollNEOMessagePos = matrix.width();
scrollNEOColor = color;
}
// ***************************************************************************************
// updateNEOScrollMessage
// ***************************************************************************************
void updateNEOScrollMessage(){
if (millis()-scrollNEOMilliSec > NEOscrollSpeed) {
matrix.fillScreen(0);
matrix.setCursor(scrollNEOMessagePos, 0);
matrix.setTextColor(scrollNEOColor);
matrix.print(scrollNEOMessage);
if(--scrollNEOMessagePos < scrollNEOMessageReset) {
scrollNEOMessagePos = matrix.width();
}
matrix.show();
scrollNEOMilliSec = millis();
}
}
// ***************************************************************************************
// nnFeedForward
// ***************************************************************************************
int nnFeedForward(float xs, float ys) {
float sum = 0;
float inputs[3];
inputs[0] = xs;
inputs[1] = ys;
inputs[2] = 1.0;
for (int i=0; i<3; i++) {
sum += inputs[i] * nnWeights[i];
}
return nnActivate(sum);
}
// ***************************************************************************************
// nnActivate
// ***************************************************************************************
int nnActivate(float sum){
if (sum>0) return 1;
else return -1;
}
// ***************************************************************************************
// nnAdjustWeights
// ***************************************************************************************
int nnAdjustWeights(float xs, float ys, int error) {
float inputs[3];
inputs[0] = xs;
inputs[1] = ys;
inputs[2] = 1.0;
for (int i=0; i<3; i++) {
nnWeights[i] += nnLearningC * (float)error * inputs[i];
}
}
int menuUpdate(boolean showIcons) {
if (millis() - lastRead > 150) {
int v = analogRead(joyV);
posLast = posNow;
if (v > 800)
posNow = down;
else if (v < 300)
posNow = up;
else if (v < 600 && v > 400)
posNow = middle;
if (posNow==middle && posLast==down){
entrySel++;
menuUpdateLCD = true;
if (entrySel == menuNumEntries)
entrySel = menuNumEntries-1;
}
else if (posNow==middle && posLast==up) {
entrySel--;
menuUpdateLCD = true;
if (entrySel < 0)
entrySel = 0;
}
lastRead = millis();
}
if (menuUpdateLCD) {
lcd.setCursor(0, 0);
lcd.print(menuHeading);
lcd.setCursor(0, 2);
lcd.print("->");
lcd.setCursor(2, 2);
if (menuLocks[entrySel] && showIcons) {
lcd.write(byte(0));
lcd.setCursor(3, 2);
}
lcd.print(menuEntries[entrySel]);
if (entrySel==0) {
lcd.setCursor(0, 1);
lcd.print(padString(20," "));
} else {
lcd.setCursor(2, 1);
if (menuLocks[entrySel-1] && showIcons) {
lcd.write(byte(0));
lcd.setCursor(3, 1);
}
lcd.print(menuEntries[entrySel-1]);
}
if (entrySel==menuNumEntries-1) {
lcd.setCursor(0, 3);
lcd.print(padString(20," "));
} else {
lcd.setCursor(2, 3);
if (menuLocks[entrySel+1] && showIcons) {
lcd.write(byte(0));
lcd.setCursor(3, 3);
}
lcd.print(menuEntries[entrySel+1]);
}
menuUpdateLCD = false;
}
return entrySel;
}
void menuAddHeading(String h) {
menuHeading = padString(20,h);
}
void menuAddEntry(int i, String e) {
if (i<16) {
menuEntries[i] = padString(17,e);
menuNumEntries++;
menuUpdateLCD = true;
}
}
void menuClear() {
menuNumEntries = 0;
entrySel=0;
menuHeading = " ";
for (int i=0; i<16; i++) {
menuEntries[i] = " ";
}
menuUpdateLCD = true;
}
int pageUpdate() {
if (millis() - lastRead > 150) {
int v = analogRead(joyV);
posLast = posNow;
if (v > 900)
posNow = down;
else if (v < 200)
posNow = up;
else if (v < 576 && v > 448)
posNow = middle;
if (posNow==middle && posLast==down){
entrySel++;
pageUpdateLCD = true;
if (entrySel == pageNumEntries)
entrySel = pageNumEntries-1;
}
else if (posNow==middle && posLast==up) {
entrySel--;
pageUpdateLCD = true;
if (entrySel < 0)
entrySel = 0;
}
lastRead = millis();
}
if (pageUpdateLCD) {
lcd.setCursor(0, 0);
lcd.print(pageHeading);
lcd.setCursor(0, 2);
lcd.print(pageEntries[entrySel]);
if (entrySel==0) {
lcd.setCursor(0, 1);
lcd.print(padString(20," "));
} else {
lcd.setCursor(0, 1);
lcd.print(pageEntries[entrySel-1]);
}
if (entrySel==pageNumEntries-1) {
lcd.setCursor(0, 3);
lcd.print(padString(20," "));
} else {
lcd.setCursor(0, 3);
lcd.print(pageEntries[entrySel+1]);
}
pageUpdateLCD = false;
}
return entrySel;
}
void pageAddHeading(String h) {
pageHeading = padString(20,h);
}
void pageAddEntry(int i, String e) {
if (i<32) {
pageEntries[i] = padString(20,e);
pageNumEntries++;
pageUpdateLCD = true;
}
}
void pageClear() {
pageNumEntries = 0;
entrySel=0;
pageHeading = " ";
for (int i=0; i<32; i++) {
pageEntries[i] = " ";
}
pageUpdateLCD = true;
}
String padString(int len, String in) {
String out;
if (in.length() < len) {
out = in;
int l = len-in.length();
for (int i=0; i<l; i++) {
out+=" ";
}
} else {
out = in.substring(0,len);
}
return out;
}
void playTone(int midiA, int duration) {
tTime = millis();
tDuration = duration;
toneActive = true;
playDual = false;
// 882 to go = 658-665 zero crossing
//samples = ((duration * 1000) / 22.7);// - 882;
//if (samples < 0) samples = 0;
//countSamples = 0;
ulPhaseIncrementA = nMidiPhaseIncrement[midiA];
}
void playDualTone(int midiA, int midiB, float mix, int duration) {
tTime = millis();
tDuration = duration;
toneActive = true;
playDual = true;
ulPhaseIncrementA = nMidiPhaseIncrement[midiA];
ulPhaseIncrementB = nMidiPhaseIncrement[midiB];
if (mix <0.0) mix = 0.0;
if (mix >1.0) mix = 1.0;
toneMixA = mix;
toneMixB = 1-0 - mix;
}
void ampOn() {
digitalWrite(ampEnable,HIGH);
}
void ampOff() {
digitalWrite(ampEnable,LOW);
}
void clearTone() {
toneActive = false;
}
void TC4_Handler()
{
// We need to get the status to clear it and allow the interrupt to fire again
TC_GetStatus(TC1, 1);
if (toneActive) {
ulPhaseAccumulatorA += ulPhaseIncrementA; // 32 bit phase increment, see below
ulPhaseAccumulatorB += ulPhaseIncrementB;
// if the phase accumulator over flows - we have been through one cycle at the current pitch,
// now we need to reset the grains ready for our next cycle
if(ulPhaseAccumulatorA > SAMPLES_PER_CYCLE_FIXEDPOINT)
ulPhaseAccumulatorA -= SAMPLES_PER_CYCLE_FIXEDPOINT;
if(ulPhaseAccumulatorB > SAMPLES_PER_CYCLE_FIXEDPOINT)
ulPhaseAccumulatorB -= SAMPLES_PER_CYCLE_FIXEDPOINT;
uint32_t phaseAdjustPAccA = (ulPhaseAccumulatorA>>20) % SINE_SAMPLES;
uint32_t phaseAdjustPAccB = (ulPhaseAccumulatorB>>20) % SINE_SAMPLES;
// get the current sample
uint32_t ulOutputA = sineWave[phaseAdjustPAccA];
uint32_t ulOutputB = sineWave[phaseAdjustPAccB];
uint32_t ulOutput;
if (!playDual)
ulOutput = ulOutputA;
else {
ulOutput = (uint32_t)(ulOutputA * toneMixA) + (uint32_t)(ulOutputB * toneMixB);
}
ulOutput = ulOutput * (volume/10.0);
dacc_write_conversion_data(DACC_INTERFACE, ulOutput);
if (millis() - tTime > tDuration) {
toneActive = false;
//digitalWrite(41,LOW);
}
}
}
void makeSineWave()
{
for(int i = 0;i < SINE_SAMPLES; i++) {
sineWave[i] = (uint16_t) (((1+sin(((2.0*PI)/SINE_SAMPLES)*i))*4095.0)/2);
}
}
// fill the note table with the phase increment values we require to generate the note
void createNoteTable(float fSampleRate)
{
for(uint32_t unMidiNote = 0;unMidiNote < MIDI_NOTES;unMidiNote++) {
// Correct calculation for frequency
float fFrequency = ((pow(2.0,(unMidiNote-69.0)/12.0)) * 440.0);
nMidiPhaseIncrement[unMidiNote] = fFrequency*TICKS_PER_CYCLE;
}
}
void screenSaver() {
lcd.clear();
matrix.clear();
matrix.show();
for (int x=0; x<8; x++) {
for (int y=0; y<8; y++) {
tile[x][y] = 0;
}
}
for (int i=0; i<32; i++) {
boolean set = false;
while (!set) {
int x = random(8);
int y = random(8);
if (tile[x][y]==0) {
tile[x][y] = random(128)+64;
set = true;
}
}
}
int sts = 0;
int tts = 0;
int tWait = saverTextMinShow;
while (!buttonPressed(any)) {
if (millis()-tts > tWait) {
int r = random(saverTextNum);
for (int i=0; i<4; i++) {
lcd.setCursor(0,i);
String temp = saverText[r][i];
if (temp.substring(0,10).equals("<box name>"))
temp = boxName + temp.substring(10);
lcd.print(padString(20,temp));
}
tts = millis();
tWait = random(10000)+saverTextMinShow;
}
// every 100ms - shuffle the board
if (millis()-sts > 100) {
matrix.clear();
for (int x=0; x<8; x++) {
for (int y=0; y<8; y++) {
if (tile[x][y]!=0) {
matrix.drawPixel(x,y,matrix.Color(tile[x][y],0,192-tile[x][y]));
}
}
}
matrix.show();
for (int x=0; x<8; x++) {
for (int y=0; y<8; y++) {
moved[x][y] = false;
}
}
for (int x=0; x<8; x++) {
for (int y=0; y<8; y++) {
if (tile[x][y]!=0 & !moved[x][y]) {
boolean free = false;
int tries = 0;
while (!free) {
int xd = random(3)-1;
int yd = random(3)-1;
if ((xd!=0 && yd==0) || (xd==0 && yd!=0) ){
int xp = x+xd;
if (xp<0) xp = 0;
if (xp>7) xp = 7;
int yp = y+yd;
if (yp<0) yp = 0;
if (yp>7) yp = 7;
if (tile[xp][yp]==0) {
tile[xp][yp] = tile[x][y];
tile[x][y] = 0;
moved[xp][yp] = true;
free = true;
}
tries ++;
if (tries == 10) {
free = true;
}
}
}
}
}
}
sts = millis();
}// evry 100ms shuffle the tiles
}
}
void setDifficulty() {
lcd.clear();
pageClear();
pageAddHeading("-----DIFFICULTY-----");
pageAddEntry(0, "Use the dials to set");
pageAddEntry(1, "the difficulty of");
pageAddEntry(2, "Work Mode.");
pageAddEntry(3, "This setting adjusts");
pageAddEntry(4, "the radius of the");
pageAddEntry(5, "area that the box");
pageAddEntry(6, "factory will make");
pageAddEntry(7, "boxes.");
while(!buttonPressed(any)) {
int selected = pageUpdate();
}
lcd.clear();
while(!buttonPressed(any)) {
int pv = potValue(center, 0.01);
if (pv < 0)
pv = 0;
if (pv > 10)
pv = 10;
goodBoxRadius = 0.9 + ((float)(pv>>1) / 10.0);
String diffA = "MEDIUM: make some";
String diffB = "medium or orange";
String diffC = "boxes";
if (goodBoxRadius <= 1.05) {
diffA = "EASY: make less";
diffB = "medium or orange";
diffC = "boxes";
}
if (goodBoxRadius >= 1.25) {
diffA = "HARD: make more";
diffB = "medium or orange";
diffC = "boxes";
}
lcd.setCursor(0,0);
lcd.print(padString(20,diffA));
lcd.setCursor(0,1);
lcd.print(padString(20,diffB));
lcd.setCursor(0,2);
lcd.print(padString(20,diffC));
lcd.setCursor(0,3);
lcd.print("Box Radius = " + String(goodBoxRadius,1));
}
logSettings();
return;
}
void synthMode() {
lcd.clear();
lcd.setCursor(0,0);
lcd.print("----ZAPPA--SYNTH----");
lcd.setCursor(0,1);
lcd.print("Use the dials and ");
lcd.setCursor(0,2);
lcd.print("joystick to make");
lcd.setCursor(0,3);
lcd.print("synthesizer sounds");
int tempVolume = volume;
ampOn();
while(!buttonPressed(any)) {
int pv = potValue(left, 0.01);
if (pv < 0)
pv = 0;
if (pv > 10)
pv = 10;
volume = pv;
int horiz = analogRead(joyH);
int vert = analogRead(joyV);
horiz = (horiz>>4)+40;
vert = (vert>>4)+40;
int mix = potValue(center, 1.0);
float mixS = (float)mix/1023.0;
playDualTone(horiz,vert,mixS,100000000);
}
mode = menu;
volume = tempVolume;
clearTone();
ampOff();
}
// ***************************************************************************************
// seedRNG
// ***************************************************************************************
void seedRNG() {
long b0_b9 = (long) analogRead(potLeft);
long b10_b19 = (long) analogRead(potCenter);
long b20_b29 = (long) analogRead(potRight);
long seed = b0_b9 | (b10_b19 << 10) | (b20_b29 << 20);
randomSeed(seed);
}
void pongLoop() {
switch (pongMode) {
case pongWait:
pongWaitMode();
break;
case pongShowScore:
pongShowScoreMode();
break;
case pongPlay:
pongPlayMode();
break;
case pongExit:
mode = menu;
break;
}
}
void pongPlayMode() {
matrix.clear();
readPaddlePosition();
if (stickBallToPaddle) {
if (ballOnPaddle == 0) {
ballPosX = 1;
ballPosY = leftPaddlePos;
} else {
ballPosX = 6;
ballPosY = rightPaddlePos;
}
if (buttonPressed(any)) {
stickBallToPaddle = false;
if (ballOnPaddle == 0)
ballDirX = 1;
else
ballDirX = -1;
ballDirY = random(3) - 1;
lastBallUpdate = millis();
}
} else {
if (millis() - lastBallUpdate > ballSpeed) {
ballPosX += ballDirX;
ballPosY += ballDirY;
lastBallUpdate = millis();
checkBall = true;
}
}
matrix.drawPixel(ballPosX, ballPosY,matrix.Color(0,180,0));
for (int i=-1; i<2; i++) {
matrix.drawPixel(0,leftPaddlePos+i,matrix.Color(180,0,0));
matrix.drawPixel(7,rightPaddlePos+i,matrix.Color(0,0,180));
}
matrix.show();
if (checkBall) {
// bounce off the left paddle
if (ballPosX == 1) {
if (ballPosY <= leftPaddlePos+1 && ballPosY >= leftPaddlePos-1) {
ballDirX *= -1;
ballDirY = ballPosY - leftPaddlePos;
if (random(5) == 0)
ballDirY = random(3) - 1;
if (ballDirY == 1 && ballPosY == 7)
ballDirY = -1;
else if (ballDirY == -1 && ballPosY == 0)
ballDirY = 1;
checkBall = false;
pongScore += map(ballSpeed, 30, 200, 9877, 10);
playTone(102,50);
ballSpeed *= 0.98;
if (ballSpeed < 30) {
ballSpeed = 30;
}
lcd.setCursor(0, 0);
lcd.print(pongScore);
}
}
// bounce off the right paddle
if (ballPosX == 6) {
if (ballPosY <= rightPaddlePos+1 && ballPosY >= rightPaddlePos-1) {
ballDirX *= -1;
ballDirY = ballPosY - rightPaddlePos;
if (random(5) == 0)
ballDirY = random(3) - 1;
if (ballDirY == 1 && ballPosY == 7)
ballDirY = -1;
else if (ballDirY == -1 && ballPosY == 0)
ballDirY = 1;
checkBall = false;
playTone(107,50);
pongScore += map(ballSpeed, 30, 200, 9877, 10);
ballSpeed *= 0.98;
if (ballSpeed < 30) {
ballSpeed = 30;
}
lcd.setCursor(0, 0);
lcd.print(pongScore);
}
}
}
if (checkBall) {
// bounce off the top and bottom walls
if ((ballPosY == 7 || ballPosY == 0) && ballDirY != 0) {
ballDirY *= -1;
checkBall = false;
}
}
if (checkBall) {
// if the balls misses the paddle and has gone off the screen - reset the ball
if (ballPosX < -1 || ballPosX > 8) {
stickBallToPaddle = true;
ballOnPaddle = random(2);
checkBall = false;
ballSpeed = 200;
pongLives--;
lcd.setCursor(0, 1);
lcd.print("Lives left = "+String(pongLives-1));
playTone(65,300);
delay(390);
playTone(59,300);
delay(390);
playTone(46,1000);
delay(1300);
if (pongLives == 0) {
pongMode = pongShowScore;
ampOff();
}
}
}
}
void pongShowScoreMode() {
matrix.clear();
matrix.show();
lcd.clear();
lcd.setCursor(0, 0);
lcd.print("---- GAME OVER ----");
lcd.setCursor(0, 1);
lcd.print(pongScore);
while (!buttonPressed(any)) {
}
pongMode = pongWait;
}
void readPaddlePosition() {
int leftPotVal = analogRead(potLeft);
int rightPotVal = analogRead(potRight);
if (leftPotVal > potMax)
leftPotVal = potMax;
if (leftPotVal < potMin)
leftPotVal = potMin;
if (rightPotVal > potMax)
rightPotVal = potMax;
if (rightPotVal < potMin)
rightPotVal = potMin;
leftPaddlePos = ((leftPotVal-potMin)/44.4)-1;
rightPaddlePos = 8-((rightPotVal-potMin)/44.4);
if (stickBallToPaddle) {
if (leftPaddlePos > 6)
leftPaddlePos = 6;
if (leftPaddlePos < 1)
leftPaddlePos = 1;
if (rightPaddlePos > 6)
rightPaddlePos = 6;
if (rightPaddlePos < 1)
rightPaddlePos = 1;
}
}
void pongWaitMode() {
matrix.clear();
matrix.show();
lcd.clear();
lcd.setCursor(0, 0);
lcd.print("-------BOING!-------");
lcd.setCursor(0, 2);
lcd.print("Push green to play");
lcd.setCursor(0, 3);
lcd.print("Push red to exit");
ampOff();
boolean answered = false;
while (!answered) {
if (buttonPressed(green)) {
ampOn();
pongLives = 4;
pongScore = 0;
pongMode = pongPlay;
lcd.clear();
lcd.setCursor(0, 0);
lcd.print(pongScore);
lcd.setCursor(0, 1);
lcd.print("Lives left = "+String(pongLives-1));
playTone(69,250);
delay(300);
playTone(69,150);
delay(180);
playTone(80,1000);
delay(1300);
answered = true;
}
if (buttonPressed(red)) {
pongMode = pongExit;
answered = true;
}
}
}
/* Midi, Freq, Phase Acc/Inc
