ESPAgrarian (ESP32-C6 LoRa GNSS, The Ager Environmental Toolkit for Farming and Agriculture)The ESPAgrarian is an Electronics Community based, ESP32-C6 (2.4GHz), SX1262 LoRa and GNSS board, for Worldwide support of The Ager Environmental Toolkit for Farming and Agriculture.
The concept is based on ESPRanger, ESPKnack and AQIL
NEW SDK BOARD - Availability planned for April 2026.
DetailsFurther details can be found on the GitHub
DiscussionsFeature Discussions
Preliminary Information and Spec to follow- Compact Board
- ESP32 C6 Based (but could change)
- LoRa SX1262 Based (Possibly E22-900M22S)
- GNSS GPS Based on ATGM336H-5N (but could change)
- RS485 Based on CS48520AD
- ADS1115 Sensor Input (16 bit)
- Soil Sensor Inputs
- Temperature Sensor Inputs
- BME280 Temperature, Humidity and Barometric Air Pressure Sensor
- SCD40 (400 to 2000 ppm) or SCD41 (400 to 5000ppm), CO2 Sensor.
- SFH2440, Ambient Light Sensor
- 5 to 60V (Max 75VDC). So operation for a wide range of sources
- Solar Input with Battery Charging
- EEPROM 64K
- Relay Output
- Low Power -Type C Interface with UART
LoRa Topology
PDF
ESPAgrarian DesignThe ESPAgrarian project is based on my other boards, such as ESPRanger, ESPKnack and AQIL
