Things used in this project

Hardware components:
A000066 iso both
Arduino UNO & Genuino UNO
×1
  7
Itead Nextion NX8048T070 - Generic 7.0" HMI TFT LCD Touch Display
×1
8 GB SD card (generic)
×1
Push Button (generic)
×1
09590 01
LED (generic)
×1
Toggle Switch (generic)
×3
Male USB Connector
×1
11026 02
Jumper wires (generic)
×1
Power Bank (generic)
×1
Openbuilds cable ties
OpenBuilds Cable Ties (10 Pack)
×1
Housing Unit
One for the switches and one for the screen and Arduino
×2
Adjustable Arm Strap
×1
Hand tools and fabrication machines:
09507 01
Soldering iron (generic)
Hy gluegun
Hot glue gun (generic)
Dremel tool (generic)
