Digital Thermometer [For Beginners!]

A digital thermometer which measures temperature in Celsius. Big thanks to Elegoo for their products and their electronic guide!

BeginnerShowcase (no instructions)34,810
Digital Thermometer [For Beginners!]

Things used in this project

Hardware components

ELEGOO UNO R3 Board ATmega328P ATMEGA16U2 with USB Cable
ELEGOO UNO R3 Board ATmega328P ATMEGA16U2 with USB Cable
×1
RGB Backlight LCD - 16x2
Adafruit RGB Backlight LCD - 16x2
×1
Resistor 10k ohm
Resistor 10k ohm
×1
Elegoo Thermistor [Tempature Sensor]
×1
Elegoo Rotary Potentiometer - Linear (10k ohm)
×1
Solderless Breadboard Full Size
Solderless Breadboard Full Size
×1
Jumper wires (generic)
Jumper wires (generic)
×1

Software apps and online services

Arduino IDE
Arduino IDE
Arduino Web Editor
Arduino Web Editor

Story

Read more

Custom parts and enclosures

Here is an image of the project!

Schematics

This is the Wiring Diagram [It show how to connect the wires]

By just looking at it you can build the whole circuit!

Code

Arduino IDE

Arduino
You just can copy & paste it later!
//www.elegoo.com
//2016.12.9

#include <LiquidCrystal.h>
int tempPin = 0;
//                BS  E  D4 D5  D6 D7
LiquidCrystal lcd(7, 8, 9, 10, 11, 12);
void setup()
{
  lcd.begin(16, 2);
}
void loop()
{
  int tempReading = analogRead(tempPin);
  // This is OK
  double tempK = log(10000.0 * ((1024.0 / tempReading - 1)));
  tempK = 1 / (0.001129148 + (0.000234125 + (0.0000000876741 * tempK * tempK )) * tempK );       //  Temp Kelvin
  float tempC = tempK - 273.15;            // Convert Kelvin to Celcius
  float tempF = (tempC * 9.0)/ 5.0 + 32.0; // Convert Celcius to Fahrenheit
  /*  replaced
    float tempVolts = tempReading * 5.0 / 1024.0;
    float tempC = (tempVolts - 0.5) * 10.0;
    float tempF = tempC * 9.0 / 5.0 + 32.0;
  */
  // Display Temperature in C
  lcd.setCursor(0, 0);
  lcd.print("Temp         C  ");
  // Display Temperature in F
  //lcd.print("Temp         F  ");
  lcd.setCursor(6, 0);
  // Display Temperature in C
  lcd.print(tempC);
  // Display Temperature in F
  //lcd.print(tempF);
  delay(500);
}
