SukoonBand

/*  Getting_BPM_to_Monitor prints the BPM to the Serial Monitor, using the least lines of code and PulseSensor Library.
    Tutorial Webpage: https://pulsesensor.com/pages/getting-advanced

  --------Use This Sketch To------------------------------------------
  1) Displays user's live and changing BPM, Beats Per Minute, in Arduino's native Serial Monitor.
  2) Print: "  A HeartBeat Happened !" when a beat is detected, live.
  2) Learn about using a PulseSensor Library "Object".
  4) Blinks LED on PIN 13 with user's Heartbeat.
  --------------------------------------------------------------------*/

#define USE_ARDUINO_INTERRUPTS true    // Set-up low-level interrupts for most acurate BPM math.
#include <PulseSensorPlayground.h>     // Includes the PulseSensorPlayground Library.

//  Variables
const int PulseWire = A11;       // PulseSensor PURPLE WIRE connected to ANALOG PIN 0
int Threshold = 550;           // Determine which Signal to "count as a beat" and which to ignore.
// Use the "Gettting Started Project" to fine-tune Threshold Value beyond default setting.
// Otherwise leave the default "550" value.

PulseSensorPlayground pulseSensor;  // Creates an instance of the PulseSensorPlayground object called "pulseSensor"


void setup() {
  pinMode (10, OUTPUT);
  Serial.begin(9600);          // For Serial Monitor

  // Configure the PulseSensor object, by assigning our variables to it.
  pulseSensor.analogInput(PulseWire);
  pulseSensor.setThreshold(Threshold);

  // Double-check the "pulseSensor" object was created and "began" seeing a signal.
  if (pulseSensor.begin()) {
    Serial.println("We created a pulseSensor Object !");  //This prints one time at Arduino power-up,  or on Arduino reset.

  }
}



void loop() {

  int myBPM = pulseSensor.getBeatsPerMinute();  // Calls function on our pulseSensor object that returns BPM as an "int".
  // "myBPM" hold this BPM value now.

  if (pulseSensor.sawStartOfBeat()) {            // Constantly test to see if "a beat happened".
    Serial.println("  A HeartBeat Happened ! "); // If test is "true", print a message "a heartbeat happened".
    Serial.print("BPM: ");                        // Print phrase "BPM: "
    Serial.println(myBPM);                        // Print the value inside of myBPM.
    if ( myBPM > 110) {
      digitalWrite(10, HIGH);
    }
else{
  digitalWrite(10,LOW);
}
  }

  delay(20);                    // considered best practice in a simple sketch.

}
