Victor Altamirano
Published © MIT

Bike Assistant

Weather monitoring system and emergency notifications based on NXP's Rapid IoT Prototyping Kit.

IntermediateFull instructions provided10 hours153

Things used in this project

Hardware components

Rapid IoT Prototyping Kit
NXP Rapid IoT Prototyping Kit
×1

Software apps and online services

Hosting server
NXP Rapid IoT Studio
Pushetta Account
Watson
IBM Watson
CloudMQTT Broker

Hand tools and fabrication machines

A piece of strap or velcro strap.
An acrylic layer 3mm thick.
Screw (diameter 1.9 mm and length 4mm minimum).

Story

Read more

Code

Bicycle.atmo

JSON
ATMO project.
{
  "name": "Rapid IoT Weather Station",
  "createVersion": "2017-08-12",
  "description": "Demonstrates reading of weather related sensors such as temperature, humidity, pressure, ambient light, and air quality. Demonstrates basic BLE Characteristic writing and reading as well as cloud storage.",
  "lastModified": "2018-02-13T00:39:19.386Z",
  "created": "2018-02-13T00:39:19.386Z",
  "meta": {
    "projectTypeName": "NXP Rapid IoT",
    "projectTypeId": "NxpRpk"
  },
  "planes": {
    "NXP Rapid IoT": {
      "type": "mcuxpresso",
      "compilerVersion": "latest",
      "variants": [
        "NxpRpk"
      ],
      "meta": {},
      "elements": [
        {
          "name": "SX9500Touch",
          "type": "EmbeddedSX9500",
          "variants": [
            "embedded",
            "triggers",
            "abilities",
            "properties",
            "variables"
          ],
          "properties": {
            "errorData": {},
            "code": {
              "trigger": "\treturn ATMO_Status_Success;",
              "setup": "\tATMO_SX9500_Config_t config;\n\tconfig.address = ATMO_PROPERTY(SX9500Touch, i2cAddress);\n\tconfig.i2cDriverInstance = ATMO_PROPERTY(SX9500Touch, i2cInstance);\n\tconfig.gpioDriverInstance = ATMO_PROPERTY(SX9500Touch, gpioInstance);\n\tconfig.interruptEnabled = ATMO_PROPERTY(SX9500Touch, interruptEnabled);\n\tconfig.interruptPin = ATMO_PROPERTY(SX9500Touch, interruptGpio);\n\tATMO_SX9500_Init(&config);\n\tATMO_SX9500_RegisterTouchedAbilityHandle(SX9500_Touched_Up, ATMO_ABILITY(SX9500Touch, pressUp));\n\tATMO_SX9500_RegisterTouchedAbilityHandle(SX9500_Touched_Down, ATMO_ABILITY(SX9500Touch, pressDown));\n\tATMO_SX9500_RegisterTouchedAbilityHandle(SX9500_Touched_Left, ATMO_ABILITY(SX9500Touch, pressLeft));\n\tATMO_SX9500_RegisterTouchedAbilityHandle(SX9500_Touched_Right, ATMO_ABILITY(SX9500Touch, pressRight));\n\treturn ATMO_Status_Success;",
              "getTouchData": "",
              "pressUp": "SX9500_TouchState_t touchState;\nATMO_GetBinary(in, &touchState, sizeof(touchState));\nATMO_CreateValueBinary(out, &touchState, sizeof(touchState));\nreturn ATMO_Status_Success;",
              "pressDown": "SX9500_TouchState_t touchState;\nATMO_GetBinary(in, &touchState, sizeof(touchState));\nATMO_CreateValueBinary(out, &touchState, sizeof(touchState));\nreturn ATMO_Status_Success;",
              "pressLeft": "SX9500_TouchState_t touchState;\nATMO_GetBinary(in, &touchState, sizeof(touchState));\nATMO_CreateValueBinary(out, &touchState, sizeof(touchState));\nreturn ATMO_Status_Success;",
              "pressRight": "SX9500_TouchState_t touchState;\nATMO_GetBinary(in, &touchState, sizeof(touchState));\nATMO_CreateValueBinary(out, &touchState, sizeof(touchState));\nreturn ATMO_Status_Success;"
            },
            "variables": {},
            "embeddedPropertyConversions": {},
            "codeUserChanged": {
              "setup": false,
              "getTouchData": false,
              "pressUp": false,
              "pressDown": false,
              "pressLeft": false,
              "pressRight": false
            },
            "i2cInstance": "ATMO_DRIVERINSTANCE_I2C_I2C2",
            "gpioInstance": "ATMO_DRIVERINSTANCE_GPIO_GPIO1",
            "interruptEnabled": true,
            "interruptGpio": "PTA9",
            "i2cAddress": "0x28"
          },
          "meta": {
            "editorX": 1079.33349609375,
            "editorY": 33,
            "lastTrigger": "rightPressed"
          },
          "triggers": {
            "triggered": [],
            "touchDataRead": [],
            "upPressed": [
              {
                "mapping": {},
                "targetOrder": [],
                "targetElement": "EmbeddedPageController",
                "targetAbility": "navigateUp"
              }
            ],
            "downPressed": [
              {
                "mapping": {},
                "targetOrder": [],
                "targetElement": "EmbeddedPageController",
                "targetAbility": "navigateDown"
              }
            ],
            "leftPressed": [
              {
                "mapping": {},
                "targetOrder": [],
                "targetElement": "EmbeddedPageController",
                "targetAbility": "navigateLeft"
              }
            ],
            "rightPressed": [
              {
                "mapping": {},
                "targetOrder": [],
                "targetElement": "EmbeddedPageController",
                "targetAbility": "navigateRight"
              }
            ]
          },
          "interruptAbilities": {
            "trigger": false,
            "setup": false,
            "getTouchData": false,
            "pressUp": false,
            "pressDown": false,
            "pressLeft": false,
            "pressRight": false
          },
          "abilities": [
            {
              "name": "trigger",
              "triggers": [
                "triggered"
              ]
            },
            {
              "name": "setup",
              "triggers": []
            },
            {
              "name": "getTouchData",
              "triggers": [
                "touchDataRead"
              ]
            },
            {
              "name": "pressUp",
              "triggers": [
                "upPressed",
                "touchDataRead"
              ]
            },
            {
              "name": "pressDown",
              "triggers": [
                "downPressed",
                "touchDataRead"
              ]
            },
            {
              "name": "pressLeft",
              "triggers": [
                "leftPressed",
                "touchDataRead"
              ]
            },
            {
              "name": "pressRight",
              "triggers": [
                "rightPressed",
                "touchDataRead"
              ]
            }
          ]
        },
        {
          "name": "Temperature_P",
          "type": "EmbeddedIconLabelDisplay",
          "variants": [
            "embedded",
            "triggers",
            "abilities",
            "properties",
            "variables",
            "rpk"
          ],
          "properties": {
            "errorData": {},
            "code": {
              "trigger": "\treturn ATMO_Status_Success;",
              "displayPage": "\n\tATMO_UI_Page_DisplayPageByCoord(ATMO_PROPERTY(Temperature_P, x), ATMO_PROPERTY(Temperature_P, y), false);\n\treturn ATMO_Status_Success;\n\t",
              "onDisplayed": "\n\treturn ATMO_Status_Success;\n    ",
              "topRightButtonPressed": "\n\treturn ATMO_Status_Success;\n\t",
              "bottomRightButtonPressed": "\n\treturn ATMO_Status_Success;\n\t",
              "topLeftButtonPressed": "\n\treturn ATMO_Status_Success;\n\t",
              "bottomLeftButtonPressed": "\n\treturn ATMO_Status_Success;\n\t",
              "setup": "\n    ATMO_UI_PAGE_Config_t config;\n\tconfig.hidden = ATMO_PROPERTY(Temperature_P, pageHidden);\n\tconfig.textColor = ATMO_PROPERTY(Temperature_P, textColor);\n    config.activeButtons = ATMO_UI_Page_GetButtonMask(ATMO_PROPERTY(Temperature_P, topRightButtonEnabled),\n    ATMO_PROPERTY(Temperature_P,bottomRightButtonEnabled), ATMO_PROPERTY(Temperature_P, topLeftButtonEnabled), ATMO_PROPERTY(Temperature_P, bottomLeftButtonEnabled));\n\tconfig.x = ATMO_PROPERTY(Temperature_P, x);\n    config.x = ATMO_PROPERTY(Temperature_P, x);\n    config.y = ATMO_PROPERTY(Temperature_P, y);\n\tstrncpy(config.topLeftButtonLabel, ATMO_PROPERTY(Temperature_P, topLeftButtonLabel), ATMO_BUTTON_LABEL_MAXLEN);\n\tstrncpy(config.topRightButtonLabel, ATMO_PROPERTY(Temperature_P, topRightButtonLabel), ATMO_BUTTON_LABEL_MAXLEN);\n\tstrncpy(config.bottomLeftButtonLabel, ATMO_PROPERTY(Temperature_P, bottomLeftButtonLabel), ATMO_BUTTON_LABEL_MAXLEN);\n\tstrncpy(config.bottomRightButtonLabel, ATMO_PROPERTY(Temperature_P, bottomRightButtonLabel), ATMO_BUTTON_LABEL_MAXLEN);\n    config.spanX = ATMO_PROPERTY(Temperature_P, spanX);\n\tconfig.spanY = ATMO_PROPERTY(Temperature_P, spanY);\n    config.title = ATMO_PROPERTY(Temperature_P, pageTitle);\n    config.titleHidden = ATMO_PROPERTY(Temperature_P, titleHidden);\n\tATMO_UI_SINGLEICONTEXT_Init(&config);\n\tATMO_VARIABLE(Temperature_P, pageHandle) = config.templateInstance;\n    ATMO_UI_SINGLEICONTEXT_SetMainText(config.templateInstance, ATMO_PROPERTY(Temperature_P, label));\n    ATMO_UI_SINGLEICONTEXT_SetIcon(config.templateInstance, ATMO_PROPERTY(Temperature_P, icon));\n    ATMO_UI_SINGLEICONTEXT_RegisterOnDisplayedAbilityHandle(ATMO_VARIABLE(Temperature_P,pageHandle), ATMO_ABILITY(Temperature_P, onDisplayed));\n    ATMO_UI_SINGLEICONTEXT_RegisterButtonAbilityHandle(ATMO_VARIABLE(Temperature_P,pageHandle), 1, ATMO_ABILITY(Temperature_P, topRightButtonPressed));\n\tATMO_UI_SINGLEICONTEXT_RegisterButtonAbilityHandle(ATMO_VARIABLE(Temperature_P,pageHandle), 2, ATMO_ABILITY(Temperature_P, bottomRightButtonPressed));\n\tATMO_UI_SINGLEICONTEXT_RegisterButtonAbilityHandle(ATMO_VARIABLE(Temperature_P,pageHandle), 3, ATMO_ABILITY(Temperature_P, topLeftButtonPressed));\n    ATMO_UI_SINGLEICONTEXT_RegisterButtonAbilityHandle(ATMO_VARIABLE(Temperature_P,pageHandle), 4, ATMO_ABILITY(Temperature_P, bottomLeftButtonPressed));\n    ATMO_UI_SINGLEICONTEXT_RegisterOnLeaveAbilityHandle(config.templateInstance, ATMO_ABILITY(Temperature_P, onLeave));\n\treturn ATMO_Status_Success;\n    ",
              "onLeave": "\n\treturn ATMO_Status_Success;\n\t",
              "setLabel": "\n    char label[32];\n    if(ATMO_GetString(in, label, 32) == ATMO_Status_Success)\n    {\n        ATMO_UI_SINGLEICONTEXT_SetMainText(ATMO_VARIABLE(Temperature_P,pageHandle), label);\n    }\n    else\n    {\n        return ATMO_Status_Fail;\n    }\n\n    return ATMO_Status_Success;\n    "
            },
            "variables": {
              "pageHandle": {
                "type": "ATMO_DriverInstanceHandle_t"
              }
            },
            "embeddedPropertyConversions": {
              "pageTitle": "string",
              "topRightButtonLabel": "string",
              "bottomRightButtonLabel": "string",
              "topLeftButtonLabel": "string",
              "bottomLeftButtonLabel": "string",
              "label": "string"
            },
            "codeUserChanged": {
              "onDisplayed": false,
              "topRightButtonPressed": false,
              "bottomRightButtonPressed": false,
              "topLeftButtonPressed": false,
              "bottomLeftButtonPressed": false,
              "setup": false,
              "onLeave": false,
              "setLabel": false
            },
            "textColor": "GUI_BLACK",
            "pageTitle": "Temperature",
            "titleHidden": false,
            "pageHidden": false,
            "topRightButtonLabel": "",
            "topRightButtonEnabled": false,
            "bottomRightButtonLabel": "",
            "bottomRightButtonEnabled": false,
            "topLeftButtonLabel": "",
            "topLeftButtonEnabled": false,
            "bottomLeftButtonLabel": "",
            "bottomLeftButtonEnabled": false,
            "x": 0,
            "y": 0,
            "spanX": 1,
            "spanY": 1,
            "icon": "icon_applications_thermostat",
            "label": "N/A"
          },
          "meta": {
            "editorX": 639.33349609375,
            "editorY": 5,
            "lastTrigger": "onDisplayed"
          },
          "triggers": {
            "triggered": [],
            "onDisplayed": [],
            "topRightButtonPressed": [],
            "bottomRightButtonPressed": [],
            "topLeftButtonPressed": [],
            "bottomLeftButtonPressed": [],
            "onLeave": []
          },
          "interruptAbilities": {
            "trigger": false,
            "displayPage": false,
            "onDisplayed": false,
            "topRightButtonPressed": false,
            "bottomRightButtonPressed": false,
            "topLeftButtonPressed": false,
            "bottomLeftButtonPressed": false,
            "setup": false,
            "onLeave": false,
            "setLabel": false
          },
          "abilities": [
            {
              "name": "trigger",
              "triggers": [
                "triggered"
              ]
            },
            {
              "name": "displayPage",
              "triggers": []
            },
            {
              "name": "onDisplayed",
              "triggers": [
                "onDisplayed"
              ]
            },
            {
              "name": "topRightButtonPressed",
              "triggers": [
                "topRightButtonPressed"
              ]
            },
            {
              "name": "bottomRightButtonPressed",
              "triggers": [
                "bottomRightButtonPressed"
              ]
            },
            {
              "name": "topLeftButtonPressed",
              "triggers": [
                "topLeftButtonPressed"
              ]
            },
            {
              "name": "bottomLeftButtonPressed",
              "triggers": [
                "bottomLeftButtonPressed"
              ]
            },
            {
              "name": "setup",
              "triggers": []
            },
            {
              "name": "onLeave",
              "triggers": [
                "onLeave"
              ]
            },
            {
              "name": "setLabel",
              "triggers": []
            }
          ]
        },
        {
          "name": "EmbeddedPageController",
          "type": "EmbeddedPageController",
          "variants": [
            "embedded",
            "triggers",
            "abilities",
            "properties",
            "variables",
            "rpk"
          ],
          "properties": {
            "errorData": {},
            "code": {
              "trigger": "\treturn ATMO_Status_Success;",
              "setup": "\n\tATMO_UI_PAGE_CONTROLLER_Config_t config;\n\tconfig.enableUpDownNavLabels = ATMO_PROPERTY(EmbeddedPageController, upDownNavigationLabelsEnabled);\n\tconfig.enableLeftRightNavLabels = ATMO_PROPERTY(EmbeddedPageController, leftRightNavigationLabelsEnabled);\n\tATMO_UI_Page_SetConfiguration(&config);\n    return ATMO_Status_Success;\n\t",
              "displayRootPage": "\n\t\n\tATMO_UI_Page_DisplayRootPage();\n\treturn ATMO_Status_Success;\n\t",
              "navigateUp": "\n\tATMO_UI_Page_ProcessNavButton(ATMO_UI_PAGE_NAV_UP);\n\treturn ATMO_Status_Success;\n\t",
              "navigateDown": "\n\tATMO_UI_Page_ProcessNavButton(ATMO_UI_PAGE_NAV_DOWN);\n\treturn ATMO_Status_Success;\n\t",
              "navigateLeft": "\n\tATMO_UI_Page_ProcessNavButton(ATMO_UI_PAGE_NAV_LEFT);\n\treturn ATMO_Status_Success;\n\t",
              "navigateRight": "\n\tATMO_UI_Page_ProcessNavButton(ATMO_UI_PAGE_NAV_RIGHT);\n\treturn ATMO_Status_Success;\n\t",
              "processTopRightButton": "\n\tATMO_UI_Page_ProcessUserButton(1);\n\treturn ATMO_Status_Success;\n\t",
              "processBottomRightButton": "\n\tATMO_UI_Page_ProcessUserButton(2);\n\treturn ATMO_Status_Success;\n\t",
              "processTopLeftButton": "\n\tATMO_UI_Page_ProcessUserButton(3);\n\treturn ATMO_Status_Success;\n\t",
              "processBottomLeftButton": "\n\tATMO_UI_Page_ProcessUserButton(4);\n\treturn ATMO_Status_Success;\n\t"
            },
            "variables": {},
            "embeddedPropertyConversions": {},
            "codeUserChanged": {
              "setup": false,
              "displayRootPage": false,
              "navigateUp": false,
              "navigateDown": false,
              "navigateLeft": false,
              "navigateRight": false,
              "processTopRightButton": false,
              "processBottomRightButton": false,
              "processTopLeftButton": false,
              "processBottomLeftButton": false
            },
            "upDownNavigationLabelsEnabled": true,
            "leftRightNavigationLabelsEnabled": true
          },
          "meta": {
            "editorX": 1222.33349609375,
            "editorY": 29,
            "lastTrigger": "triggered"
          },
          "triggers": {
            "triggered": [],
            "navigateUp": [],
            "navigateDown": [],
            "navigateLeft": [],
            "navigateRight": [],
            "processTopRightButton": [],
            "processBottomRightButton": [],
            "processTopLeftButton": [],
            "processBottomLeftButton": []
          },
          "interruptAbilities": {
            "trigger": false,
            "setup": false,
            "displayRootPage": false,
            "navigateUp": false,
            "navigateDown": false,
            "navigateLeft": false,
            "navigateRight": false,
            "processTopRightButton": false,
            "processBottomRightButton": false,
            "processTopLeftButton": false,
            "processBottomLeftButton": false
          },
          "abilities": [
            {
              "name": "trigger",
              "triggers": [
                "triggered"
              ]
            },
            {
              "name": "setup",
              "triggers": []
            },
            {
              "name": "displayRootPage",
              "triggers": []
            },
            {
              "name": "navigateUp",
              "triggers": [
                "navigateUp"
              ]
            },
            {
              "name": "navigateDown",
              "triggers": [
                "navigateDown"
              ]
            },
            {
              "name": "navigateLeft",
              "triggers": [
                "navigateLeft"
              ]
            },
            {
              "name": "navigateRight",
              "triggers": [
                "navigateRight"
              ]
            },
            {
              "name": "processTopRightButton",
              "triggers": [
                "processTopRightButton"
              ]
            },
            {
              "name": "processBottomRightButton",
              "triggers": [
                "processBottomRightButton"
              ]
            },
            {
              "name": "processTopLeftButton",
              "triggers": [
                "processTopLeftButton"
              ]
            },
            {
              "name": "processBottomLeftButton",
              "triggers": [
                "processBottomLeftButton"
              ]
            }
          ]
        },
        {
          "name": "Humidity_Pag",
          "type": "EmbeddedIconLabelDisplay",
          "variants": [
            "embedded",
            "triggers",
            "abilities",
            "properties",
            "variables",
            "rpk"
          ],
          "properties": {
            "errorData": {},
            "code": {
              "trigger": "\treturn ATMO_Status_Success;",
              "displayPage": "\n\tATMO_UI_Page_DisplayPageByCoord(ATMO_PROPERTY(Humidity_Pag, x), ATMO_PROPERTY(Humidity_Pag, y), false);\n\treturn ATMO_Status_Success;\n\t",
              "onDisplayed": "\n\treturn ATMO_Status_Success;\n    ",
              "topRightButtonPressed": "\n\treturn ATMO_Status_Success;\n\t",
              "bottomRightButtonPressed": "\n\treturn ATMO_Status_Success;\n\t",
              "topLeftButtonPressed": "\n\treturn ATMO_Status_Success;\n\t",
              "bottomLeftButtonPressed": "\n\treturn ATMO_Status_Success;\n\t",
              "setup": "\n    ATMO_UI_PAGE_Config_t config;\n\tconfig.hidden = ATMO_PROPERTY(Humidity_Pag, pageHidden);\n\tconfig.textColor = ATMO_PROPERTY(Humidity_Pag, textColor);\n    config.activeButtons = ATMO_UI_Page_GetButtonMask(ATMO_PROPERTY(Humidity_Pag, topRightButtonEnabled),\n    ATMO_PROPERTY(Humidity_Pag,bottomRightButtonEnabled), ATMO_PROPERTY(Humidity_Pag, topLeftButtonEnabled), ATMO_PROPERTY(Humidity_Pag, bottomLeftButtonEnabled));\n\tconfig.x = ATMO_PROPERTY(Humidity_Pag, x);\n    config.x = ATMO_PROPERTY(Humidity_Pag, x);\n    config.y = ATMO_PROPERTY(Humidity_Pag, y);\n\tstrncpy(config.topLeftButtonLabel, ATMO_PROPERTY(Humidity_Pag, topLeftButtonLabel), ATMO_BUTTON_LABEL_MAXLEN);\n\tstrncpy(config.topRightButtonLabel, ATMO_PROPERTY(Humidity_Pag, topRightButtonLabel), ATMO_BUTTON_LABEL_MAXLEN);\n\tstrncpy(config.bottomLeftButtonLabel, ATMO_PROPERTY(Humidity_Pag, bottomLeftButtonLabel), ATMO_BUTTON_LABEL_MAXLEN);\n\tstrncpy(config.bottomRightButtonLabel, ATMO_PROPERTY(Humidity_Pag, bottomRightButtonLabel), ATMO_BUTTON_LABEL_MAXLEN);\n    config.spanX = ATMO_PROPERTY(Humidity_Pag, spanX);\n\tconfig.spanY = ATMO_PROPERTY(Humidity_Pag, spanY);\n    config.title = ATMO_PROPERTY(Humidity_Pag, pageTitle);\n    config.titleHidden = ATMO_PROPERTY(Humidity_Pag, titleHidden);\n\tATMO_UI_SINGLEICONTEXT_Init(&config);\n\tATMO_VARIABLE(Humidity_Pag, pageHandle) = config.templateInstance;\n    ATMO_UI_SINGLEICONTEXT_SetMainText(config.templateInstance, ATMO_PROPERTY(Humidity_Pag, label));\n    ATMO_UI_SINGLEICONTEXT_SetIcon(config.templateInstance, ATMO_PROPERTY(Humidity_Pag, icon));\n    ATMO_UI_SINGLEICONTEXT_RegisterOnDisplayedAbilityHandle(ATMO_VARIABLE(Humidity_Pag,pageHandle), ATMO_ABILITY(Humidity_Pag, onDisplayed));\n    ATMO_UI_SINGLEICONTEXT_RegisterButtonAbilityHandle(ATMO_VARIABLE(Humidity_Pag,pageHandle), 1, ATMO_ABILITY(Humidity_Pag, topRightButtonPressed));\n\tATMO_UI_SINGLEICONTEXT_RegisterButtonAbilityHandle(ATMO_VARIABLE(Humidity_Pag,pageHandle), 2, ATMO_ABILITY(Humidity_Pag, bottomRightButtonPressed));\n\tATMO_UI_SINGLEICONTEXT_RegisterButtonAbilityHandle(ATMO_VARIABLE(Humidity_Pag,pageHandle), 3, ATMO_ABILITY(Humidity_Pag, topLeftButtonPressed));\n    ATMO_UI_SINGLEICONTEXT_RegisterButtonAbilityHandle(ATMO_VARIABLE(Humidity_Pag,pageHandle), 4, ATMO_ABILITY(Humidity_Pag, bottomLeftButtonPressed));\n    ATMO_UI_SINGLEICONTEXT_RegisterOnLeaveAbilityHandle(config.templateInstance, ATMO_ABILITY(Humidity_Pag, onLeave));\n\treturn ATMO_Status_Success;\n    ",
              "onLeave": "\n\treturn ATMO_Status_Success;\n\t",
              "setLabel": "\n    char label[32];\n    if(ATMO_GetString(in, label, 32) == ATMO_Status_Success)\n    {\n        ATMO_UI_SINGLEICONTEXT_SetMainText(ATMO_VARIABLE(Humidity_Pag,pageHandle), label);\n    }\n    else\n    {\n        return ATMO_Status_Fail;\n    }\n\n    return ATMO_Status_Success;\n    "
            },
            "variables": {
              "pageHandle": {
                "type": "ATMO_DriverInstanceHandle_t"
              }
            },
            "embeddedPropertyConversions": {
              "pageTitle": "string",
              "topRightButtonLabel": "string",
              "bottomRightButtonLabel": "string",
              "topLeftButtonLabel": "string",
              "bottomLeftButtonLabel": "string",
              "label": "string"
            },
            "codeUserChanged": {
              "onDisplayed": false,
              "topRightButtonPressed": false,
              "bottomRightButtonPressed": false,
              "topLeftButtonPressed": false,
              "bottomLeftButtonPressed": false,
              "setup": false,
              "onLeave": false,
              "setLabel": false
            },
            "textColor": "GUI_BLACK",
            "pageTitle": "Humidity",
            "titleHidden": false,
            "pageHidden": false,
            "topRightButtonLabel": "",
            "topRightButtonEnabled": false,
            "bottomRightButtonLabel": "",
            "bottomRightButtonEnabled": false,
            "topLeftButtonLabel": "",
            "topLeftButtonEnabled": false,
            "bottomLeftButtonLabel": "",
            "bottomLeftButtonEnabled": false,
            "x": "1",
            "y": 0,
            "spanX": 1,
            "spanY": 1,
            "icon": "icon_applications_humidity",
            "label": "N/A"
          },
          "meta": {
            "editorX": 707.33349609375,
            "editorY": 5,
            "lastTrigger": "onDisplayed"
          },
          "triggers": {
            "triggered": [],
            "onDisplayed": [],
            "topRightButtonPressed": [],
            "bottomRightButtonPressed": [],
            "topLeftButtonPressed": [],
            "bottomLeftButtonPressed": [],
            "onLeave": []
          },
          "interruptAbilities": {
            "trigger": false,
            "displayPage": false,
            "onDisplayed": false,
            "topRightButtonPressed": false,
            "bottomRightButtonPressed": false,
            "topLeftButtonPressed": false,
            "bottomLeftButtonPressed": false,
            "setup": false,
            "onLeave": false,
            "setLabel": false
          },
          "abilities": [
            {
              "name": "trigger",
              "triggers": [
                "triggered"
              ]
            },
            {
              "name": "displayPage",
              "triggers": []
            },
            {
              "name": "onDisplayed",
              "triggers": [
                "onDisplayed"
              ]
            },
            {
              "name": "topRightButtonPressed",
              "triggers": [
                "topRightButtonPressed"
              ]
            },
            {
              "name": "bottomRightButtonPressed",
              "triggers": [
                "bottomRightButtonPressed"
              ]
            },
            {
              "name": "topLeftButtonPressed",
              "triggers": [
                "topLeftButtonPressed"
              ]
            },
            {
              "name": "bottomLeftButtonPressed",
              "triggers": [
                "bottomLeftButtonPressed"
              ]
            },
            {
              "name": "setup",
              "triggers": []
            },
            {
              "name": "onLeave",
              "triggers": [
                "onLeave"
              ]
            },
            {
              "name": "setLabel",
              "triggers": []
            }
          ]
        },
        {
          "name": "Pressure_Pag",
          "type": "EmbeddedIconLabelDisplay",
          "variants": [
            "embedded",
            "triggers",
            "abilities",
            "properties",
            "variables",
            "rpk"
          ],
          "properties": {
            "errorData": {},
            "code": {
              "trigger": "\treturn ATMO_Status_Success;",
              "displayPage": "\n\tATMO_UI_Page_DisplayPageByCoord(ATMO_PROPERTY(Pressure_Pag, x), ATMO_PROPERTY(Pressure_Pag, y), false);\n\treturn ATMO_Status_Success;\n\t",
              "onDisplayed": "\n\treturn ATMO_Status_Success;\n    ",
              "topRightButtonPressed": "\n\treturn ATMO_Status_Success;\n\t",
              "bottomRightButtonPressed": "\n\treturn ATMO_Status_Success;\n\t",
              "topLeftButtonPressed": "\n\treturn ATMO_Status_Success;\n\t",
              "bottomLeftButtonPressed": "\n\treturn ATMO_Status_Success;\n\t",
              "setup": "\n    ATMO_UI_PAGE_Config_t config;\n\tconfig.hidden = ATMO_PROPERTY(Pressure_Pag, pageHidden);\n\tconfig.textColor = ATMO_PROPERTY(Pressure_Pag, textColor);\n    config.activeButtons = ATMO_UI_Page_GetButtonMask(ATMO_PROPERTY(Pressure_Pag, topRightButtonEnabled),\n    ATMO_PROPERTY(Pressure_Pag,bottomRightButtonEnabled), ATMO_PROPERTY(Pressure_Pag, topLeftButtonEnabled), ATMO_PROPERTY(Pressure_Pag, bottomLeftButtonEnabled));\n\tconfig.x = ATMO_PROPERTY(Pressure_Pag, x);\n    config.x = ATMO_PROPERTY(Pressure_Pag, x);\n    config.y = ATMO_PROPERTY(Pressure_Pag, y);\n\tstrncpy(config.topLeftButtonLabel, ATMO_PROPERTY(Pressure_Pag, topLeftButtonLabel), ATMO_BUTTON_LABEL_MAXLEN);\n\tstrncpy(config.topRightButtonLabel, ATMO_PROPERTY(Pressure_Pag, topRightButtonLabel), ATMO_BUTTON_LABEL_MAXLEN);\n\tstrncpy(config.bottomLeftButtonLabel, ATMO_PROPERTY(Pressure_Pag, bottomLeftButtonLabel), ATMO_BUTTON_LABEL_MAXLEN);\n\tstrncpy(config.bottomRightButtonLabel, ATMO_PROPERTY(Pressure_Pag, bottomRightButtonLabel), ATMO_BUTTON_LABEL_MAXLEN);\n    config.spanX = ATMO_PROPERTY(Pressure_Pag, spanX);\n\tconfig.spanY = ATMO_PROPERTY(Pressure_Pag, spanY);\n    config.title = ATMO_PROPERTY(Pressure_Pag, pageTitle);\n    config.titleHidden = ATMO_PROPERTY(Pressure_Pag, titleHidden);\n\tATMO_UI_SINGLEICONTEXT_Init(&config);\n\tATMO_VARIABLE(Pressure_Pag, pageHandle) = config.templateInstance;\n    ATMO_UI_SINGLEICONTEXT_SetMainText(config.templateInstance, ATMO_PROPERTY(Pressure_Pag, label));\n    ATMO_UI_SINGLEICONTEXT_SetIcon(config.templateInstance, ATMO_PROPERTY(Pressure_Pag, icon));\n    ATMO_UI_SINGLEICONTEXT_RegisterOnDisplayedAbilityHandle(ATMO_VARIABLE(Pressure_Pag,pageHandle), ATMO_ABILITY(Pressure_Pag, onDisplayed));\n    ATMO_UI_SINGLEICONTEXT_RegisterButtonAbilityHandle(ATMO_VARIABLE(Pressure_Pag,pageHandle), 1, ATMO_ABILITY(Pressure_Pag, topRightButtonPressed));\n\tATMO_UI_SINGLEICONTEXT_RegisterButtonAbilityHandle(ATMO_VARIABLE(Pressure_Pag,pageHandle), 2, ATMO_ABILITY(Pressure_Pag, bottomRightButtonPressed));\n\tATMO_UI_SINGLEICONTEXT_RegisterButtonAbilityHandle(ATMO_VARIABLE(Pressure_Pag,pageHandle), 3, ATMO_ABILITY(Pressure_Pag, topLeftButtonPressed));\n    ATMO_UI_SINGLEICONTEXT_RegisterButtonAbilityHandle(ATMO_VARIABLE(Pressure_Pag,pageHandle), 4, ATMO_ABILITY(Pressure_Pag, bottomLeftButtonPressed));\n    ATMO_UI_SINGLEICONTEXT_RegisterOnLeaveAbilityHandle(config.templateInstance, ATMO_ABILITY(Pressure_Pag, onLeave));\n\treturn ATMO_Status_Success;\n    ",
              "onLeave": "\n\treturn ATMO_Status_Success;\n\t",
              "setLabel": "\n    char label[32];\n    if(ATMO_GetString(in, label, 32) == ATMO_Status_Success)\n    {\n        ATMO_UI_SINGLEICONTEXT_SetMainText(ATMO_VARIABLE(Pressure_Pag,pageHandle), label);\n    }\n    else\n    {\n        return ATMO_Status_Fail;\n    }\n\n    return ATMO_Status_Success;\n    "
            },
            "variables": {
              "pageHandle": {
                "type": "ATMO_DriverInstanceHandle_t"
              }
            },
            "embeddedPropertyConversions": {
              "pageTitle": "string",
              "topRightButtonLabel": "string",
              "bottomRightButtonLabel": "string",
              "topLeftButtonLabel": "string",
              "bottomLeftButtonLabel": "string",
              "label": "string"
            },
            "codeUserChanged": {
              "onDisplayed": false,
              "topRightButtonPressed": false,
              "bottomRightButtonPressed": false,
              "topLeftButtonPressed": false,
              "bottomLeftButtonPressed": false,
              "setup": false,
              "onLeave": false,
              "setLabel": false
            },
            "textColor": "GUI_BLACK",
            "pageTitle": "Pressure",
            "titleHidden": false,
            "pageHidden": false,
            "topRightButtonLabel": "",
            "topRightButtonEnabled": false,
            "bottomRightButtonLabel": "",
            "bottomRightButtonEnabled": false,
            "topLeftButtonLabel": "",
            "topLeftButtonEnabled": false,
            "bottomLeftButtonLabel": "",
            "bottomLeftButtonEnabled": false,
            "x": "2",
            "y": 0,
            "spanX": 1,
            "spanY": 1,
            "icon": "icon_applications_pressure",
            "label": "N/A"
          },
          "meta": {
            "editorX": 765.3333740234375,
            "editorY": 11,
            "lastTrigger": "onDisplayed"
          },
          "triggers": {
            "triggered": [],
            "onDisplayed": [],
            "topRightButtonPressed": [],
            "bottomRightButtonPressed": [],
            "topLeftButtonPressed": [],
            "bottomLeftButtonPressed": [],
            "onLeave": []
          },
          "interruptAbilities": {
            "trigger": false,
            "displayPage": false,
            "onDisplayed": false,
            "topRightButtonPressed": false,
            "bottomRightButtonPressed": false,
            "topLeftButtonPressed": false,
            "bottomLeftButtonPressed": false,
            "setup": false,
            "onLeave": false,
            "setLabel": false
          },
          "abilities": [
            {
              "name": "trigger",
              "triggers": [
                "triggered"
              ]
            },
            {
              "name": "displayPage",
              "triggers": []
            },
            {
              "name": "onDisplayed",
              "triggers": [
                "onDisplayed"
              ]
            },
            {
              "name": "topRightButtonPressed",
              "triggers": [
                "topRightButtonPressed"
              ]
            },
            {
              "name": "bottomRightButtonPressed",
              "triggers": [
                "bottomRightButtonPressed"
              ]
            },
            {
              "name": "topLeftButtonPressed",
              "triggers": [
                "topLeftButtonPressed"
              ]
            },
            {
              "name": "bottomLeftButtonPressed",
              "triggers": [
                "bottomLeftButtonPressed"
              ]
            },
            {
              "name": "setup",
              "triggers": []
            },
            {
              "name": "onLeave",
              "triggers": [
                "onLeave"
              ]
            },
            {
              "name": "setLabel",
              "triggers": []
            }
          ]
        },
        {
          "name": "ConvertPressur",
          "type": "EmbeddedFunction",
          "variants": [
            "embedded",
            "triggers",
            "abilities",
            "properties",
            "variables"
          ],
          "properties": {
            "errorData": {},
            "code": {
              "trigger": "\tunsigned int pressurePa = 0;\n\tATMO_GetUnsignedInt(in, &pressurePa);\n\tATMO_CreateValueUnsignedInt(out, pressurePa / 100);\n\treturn ATMO_Status_Success;"
            },
            "variables": {},
            "embeddedPropertyConversions": {},
            "codeUserChanged": {
              "trigger": true
            }
          },
          "meta": {
            "editorX": 375.3333740234375,
            "editorY": 206,
            "lastTrigger": "triggered"
          },
          "triggers": {
            "triggered": [
              {
                "mapping": {},
                "targetOrder": [],
                "targetElement": "GetPressureStr",
                "targetAbility": "trigger"
              }
            ]
          },
          "interruptAbilities": {
            "trigger": false
          },
          "abilities": [
            {
              "name": "trigger",
              "triggers": [
                "triggered"
              ]
            }
          ]
        },
        {
          "name": "AmientLight_Pag",
          "type": "EmbeddedIconLabelDisplay",
          "variants": [
            "embedded",
            "triggers",
            "abilities",
            "properties",
            "variables",
            "rpk"
          ],
          "properties": {
            "errorData": {},
            "code": {
              "trigger": "\treturn ATMO_Status_Success;",
              "displayPage": "\n\tATMO_UI_Page_DisplayPageByCoord(ATMO_PROPERTY(AmientLight_Pag, x), ATMO_PROPERTY(AmientLight_Pag, y), false);\n\treturn ATMO_Status_Success;\n\t",
              "onDisplayed": "\n\treturn ATMO_Status_Success;\n    ",
              "topRightButtonPressed": "\n\treturn ATMO_Status_Success;\n\t",
              "bottomRightButtonPressed": "\n\treturn ATMO_Status_Success;\n\t",
              "topLeftButtonPressed": "\n\treturn ATMO_Status_Success;\n\t",
              "bottomLeftButtonPressed": "\n\treturn ATMO_Status_Success;\n\t",
              "setup": "\n    ATMO_UI_PAGE_Config_t config;\n\tconfig.hidden = ATMO_PROPERTY(AmientLight_Pag, pageHidden);\n\tconfig.textColor = ATMO_PROPERTY(AmientLight_Pag, textColor);\n    config.activeButtons = ATMO_UI_Page_GetButtonMask(ATMO_PROPERTY(AmientLight_Pag, topRightButtonEnabled),\n    ATMO_PROPERTY(AmientLight_Pag,bottomRightButtonEnabled), ATMO_PROPERTY(AmientLight_Pag, topLeftButtonEnabled), ATMO_PROPERTY(AmientLight_Pag, bottomLeftButtonEnabled));\n\tconfig.x = ATMO_PROPERTY(AmientLight_Pag, x);\n    config.x = ATMO_PROPERTY(AmientLight_Pag, x);\n    config.y = ATMO_PROPERTY(AmientLight_Pag, y);\n\tstrncpy(config.topLeftButtonLabel, ATMO_PROPERTY(AmientLight_Pag, topLeftButtonLabel), ATMO_BUTTON_LABEL_MAXLEN);\n\tstrncpy(config.topRightButtonLabel, ATMO_PROPERTY(AmientLight_Pag, topRightButtonLabel), ATMO_BUTTON_LABEL_MAXLEN);\n\tstrncpy(config.bottomLeftButtonLabel, ATMO_PROPERTY(AmientLight_Pag, bottomLeftButtonLabel), ATMO_BUTTON_LABEL_MAXLEN);\n\tstrncpy(config.bottomRightButtonLabel, ATMO_PROPERTY(AmientLight_Pag, bottomRightButtonLabel), ATMO_BUTTON_LABEL_MAXLEN);\n    config.spanX = ATMO_PROPERTY(AmientLight_Pag, spanX);\n\tconfig.spanY = ATMO_PROPERTY(AmientLight_Pag, spanY);\n    config.title = ATMO_PROPERTY(AmientLight_Pag, pageTitle);\n    config.titleHidden = ATMO_PROPERTY(AmientLight_Pag, titleHidden);\n\tATMO_UI_SINGLEICONTEXT_Init(&config);\n\tATMO_VARIABLE(AmientLight_Pag, pageHandle) = config.templateInstance;\n    ATMO_UI_SINGLEICONTEXT_SetMainText(config.templateInstance, ATMO_PROPERTY(AmientLight_Pag, label));\n    ATMO_UI_SINGLEICONTEXT_SetIcon(config.templateInstance, ATMO_PROPERTY(AmientLight_Pag, icon));\n    ATMO_UI_SINGLEICONTEXT_RegisterOnDisplayedAbilityHandle(ATMO_VARIABLE(AmientLight_Pag,pageHandle), ATMO_ABILITY(AmientLight_Pag, onDisplayed));\n    ATMO_UI_SINGLEICONTEXT_RegisterButtonAbilityHandle(ATMO_VARIABLE(AmientLight_Pag,pageHandle), 1, ATMO_ABILITY(AmientLight_Pag, topRightButtonPressed));\n\tATMO_UI_SINGLEICONTEXT_RegisterButtonAbilityHandle(ATMO_VARIABLE(AmientLight_Pag,pageHandle), 2, ATMO_ABILITY(AmientLight_Pag, bottomRightButtonPressed));\n\tATMO_UI_SINGLEICONTEXT_RegisterButtonAbilityHandle(ATMO_VARIABLE(AmientLight_Pag,pageHandle), 3, ATMO_ABILITY(AmientLight_Pag, topLeftButtonPressed));\n    ATMO_UI_SINGLEICONTEXT_RegisterButtonAbilityHandle(ATMO_VARIABLE(AmientLight_Pag,pageHandle), 4, ATMO_ABILITY(AmientLight_Pag, bottomLeftButtonPressed));\n    ATMO_UI_SINGLEICONTEXT_RegisterOnLeaveAbilityHandle(config.templateInstance, ATMO_ABILITY(AmientLight_Pag, onLeave));\n\treturn ATMO_Status_Success;\n    ",
              "onLeave": "\n\treturn ATMO_Status_Success;\n\t",
              "setLabel": "\n    char label[32];\n    if(ATMO_GetString(in, label, 32) == ATMO_Status_Success)\n    {\n        ATMO_UI_SINGLEICONTEXT_SetMainText(ATMO_VARIABLE(AmientLight_Pag,pageHandle), label);\n    }\n    else\n    {\n        return ATMO_Status_Fail;\n    }\n\n    return ATMO_Status_Success;\n    "
            },
            "variables": {
              "pageHandle": {
                "type": "ATMO_DriverInstanceHandle_t"
              }
            },
            "embeddedPropertyConversions": {
              "pageTitle": "string",
              "topRightButtonLabel": "string",
              "bottomRightButtonLabel": "string",
              "topLeftButtonLabel": "string",
              "bottomLeftButtonLabel": "string",
              "label": "string"
            },
            "codeUserChanged": {
              "onDisplayed": false,
              "topRightButtonPressed": false,
              "bottomRightButtonPressed": false,
              "topLeftButtonPressed": false,
              "bottomLeftButtonPressed": false,
              "setup": false,
              "onLeave": false,
              "setLabel": false
            },
            "textColor": "GUI_BLACK",
            "pageTitle": "Ambient Light",
            "titleHidden": false,
            "pageHidden": false,
            "topRightButtonLabel": "",
            "topRightButtonEnabled": false,
            "bottomRightButtonLabel": "",
            "bottomRightButtonEnabled": false,
            "topLeftButtonLabel": "",
            "topLeftButtonEnabled": false,
            "bottomLeftButtonLabel": "",
            "bottomLeftButtonEnabled": false,
            "x": "3",
            "y": 0,
            "spanX": 1,
            "spanY": 1,
            "icon": "icon_applications_light",
            "label": "N/A"
          },
          "meta": {
            "editorX": 839.3333740234375,
            "editorY": 10,
            "lastTrigger": "onDisplayed"
          },
          "triggers": {
            "triggered": [],
            "onDisplayed": [],
            "topRightButtonPressed": [],
            "bottomRightButtonPressed": [],
            "topLeftButtonPressed": [],
            "bottomLeftButtonPressed": [],
            "onLeave": []
          },
          "interruptAbilities": {
            "trigger": false,
            "displayPage": false,
            "onDisplayed": false,
            "topRightButtonPressed": false,
            "bottomRightButtonPressed": false,
            "topLeftButtonPressed": false,
            "bottomLeftButtonPressed": false,
            "setup": false,
            "onLeave": false,
            "setLabel": false
          },
          "abilities": [
            {
              "name": "trigger",
              "triggers": [
                "triggered"
              ]
            },
            {
              "name": "displayPage",
              "triggers": []
            },
            {
              "name": "onDisplayed",
              "triggers": [
                "onDisplayed"
              ]
            },
            {
              "name": "topRightButtonPressed",
              "triggers": [
                "topRightButtonPressed"
              ]
            },
            {
              "name": "bottomRightButtonPressed",
              "triggers": [
                "bottomRightButtonPressed"
              ]
            },
            {
              "name": "topLeftButtonPressed",
              "triggers": [
                "topLeftButtonPressed"
              ]
            },
            {
              "name": "bottomLeftButtonPressed",
              "triggers": [
                "bottomLeftButtonPressed"
              ]
            },
            {
              "name": "setup",
              "triggers": []
            },
            {
              "name": "onLeave",
              "triggers": [
                "onLeave"
              ]
            },
            {
              "name": "setLabel",
              "triggers": []
            }
          ]
        },
        {
          "name": "AirQuality_Pag",
          "type": "EmbeddedIconLabelDisplay",
          "variants": [
            "embedded",
            "triggers",
            "abilities",
            "properties",
            "variables",
            "rpk"
          ],
          "properties": {
            "errorData": {},
            "code": {
              "trigger": "\treturn ATMO_Status_Success;",
              "displayPage": "\n\tATMO_UI_Page_DisplayPageByCoord(ATMO_PROPERTY(AirQuality_Pag, x), ATMO_PROPERTY(AirQuality_Pag, y), false);\n\treturn ATMO_Status_Success;\n\t",
              "onDisplayed": "\n\treturn ATMO_Status_Success;\n    ",
              "topRightButtonPressed": "\n\treturn ATMO_Status_Success;\n\t",
              "bottomRightButtonPressed": "\n\treturn ATMO_Status_Success;\n\t",
              "topLeftButtonPressed": "\n\treturn ATMO_Status_Success;\n\t",
              "bottomLeftButtonPressed": "\n\treturn ATMO_Status_Success;\n\t",
              "setup": "\n    ATMO_UI_PAGE_Config_t config;\n\tconfig.hidden = ATMO_PROPERTY(AirQuality_Pag, pageHidden);\n\tconfig.textColor = ATMO_PROPERTY(AirQuality_Pag, textColor);\n    config.activeButtons = ATMO_UI_Page_GetButtonMask(ATMO_PROPERTY(AirQuality_Pag, topRightButtonEnabled),\n    ATMO_PROPERTY(AirQuality_Pag,bottomRightButtonEnabled), ATMO_PROPERTY(AirQuality_Pag, topLeftButtonEnabled), ATMO_PROPERTY(AirQuality_Pag, bottomLeftButtonEnabled));\n\tconfig.x = ATMO_PROPERTY(AirQuality_Pag, x);\n    config.x = ATMO_PROPERTY(AirQuality_Pag, x);\n    config.y = ATMO_PROPERTY(AirQuality_Pag, y);\n\tstrncpy(config.topLeftButtonLabel, ATMO_PROPERTY(AirQuality_Pag, topLeftButtonLabel), ATMO_BUTTON_LABEL_MAXLEN);\n\tstrncpy(config.topRightButtonLabel, ATMO_PROPERTY(AirQuality_Pag, topRightButtonLabel), ATMO_BUTTON_LABEL_MAXLEN);\n\tstrncpy(config.bottomLeftButtonLabel, ATMO_PROPERTY(AirQuality_Pag, bottomLeftButtonLabel), ATMO_BUTTON_LABEL_MAXLEN);\n\tstrncpy(config.bottomRightButtonLabel, ATMO_PROPERTY(AirQuality_Pag, bottomRightButtonLabel), ATMO_BUTTON_LABEL_MAXLEN);\n    config.spanX = ATMO_PROPERTY(AirQuality_Pag, spanX);\n\tconfig.spanY = ATMO_PROPERTY(AirQuality_Pag, spanY);\n    config.title = ATMO_PROPERTY(AirQuality_Pag, pageTitle);\n    config.titleHidden = ATMO_PROPERTY(AirQuality_Pag, titleHidden);\n\tATMO_UI_SINGLEICONTEXT_Init(&config);\n\tATMO_VARIABLE(AirQuality_Pag, pageHandle) = config.templateInstance;\n    ATMO_UI_SINGLEICONTEXT_SetMainText(config.templateInstance, ATMO_PROPERTY(AirQuality_Pag, label));\n    ATMO_UI_SINGLEICONTEXT_SetIcon(config.templateInstance, ATMO_PROPERTY(AirQuality_Pag, icon));\n    ATMO_UI_SINGLEICONTEXT_RegisterOnDisplayedAbilityHandle(ATMO_VARIABLE(AirQuality_Pag,pageHandle), ATMO_ABILITY(AirQuality_Pag, onDisplayed));\n    ATMO_UI_SINGLEICONTEXT_RegisterButtonAbilityHandle(ATMO_VARIABLE(AirQuality_Pag,pageHandle), 1, ATMO_ABILITY(AirQuality_Pag, topRightButtonPressed));\n\tATMO_UI_SINGLEICONTEXT_RegisterButtonAbilityHandle(ATMO_VARIABLE(AirQuality_Pag,pageHandle), 2, ATMO_ABILITY(AirQuality_Pag, bottomRightButtonPressed));\n\tATMO_UI_SINGLEICONTEXT_RegisterButtonAbilityHandle(ATMO_VARIABLE(AirQuality_Pag,pageHandle), 3, ATMO_ABILITY(AirQuality_Pag, topLeftButtonPressed));\n    ATMO_UI_SINGLEICONTEXT_RegisterButtonAbilityHandle(ATMO_VARIABLE(AirQuality_Pag,pageHandle), 4, ATMO_ABILITY(AirQuality_Pag, bottomLeftButtonPressed));\n    ATMO_UI_SINGLEICONTEXT_RegisterOnLeaveAbilityHandle(config.templateInstance, ATMO_ABILITY(AirQuality_Pag, onLeave));\n\treturn ATMO_Status_Success;\n    ",
              "onLeave": "\n\treturn ATMO_Status_Success;\n\t",
              "setLabel": "\n    char label[32];\n    if(ATMO_GetString(in, label, 32) == ATMO_Status_Success)\n    {\n        ATMO_UI_SINGLEICONTEXT_SetMainText(ATMO_VARIABLE(AirQuality_Pag,pageHandle), label);\n    }\n    else\n    {\n        return ATMO_Status_Fail;\n    }\n\n    return ATMO_Status_Success;\n    "
            },
            "variables": {
              "pageHandle": {
                "type": "ATMO_DriverInstanceHandle_t"
              }
            },
            "embeddedPropertyConversions": {
              "pageTitle": "string",
              "topRightButtonLabel": "string",
              "bottomRightButtonLabel": "string",
              "topLeftButtonLabel": "string",
              "bottomLeftButtonLabel": "string",
              "label": "string"
            },
            "codeUserChanged": {
              "onDisplayed": false,
              "topRightButtonPressed": false,
              "bottomRightButtonPressed": false,
              "topLeftButtonPressed": false,
              "bottomLeftButtonPressed": false,
              "setup": false,
              "onLeave": false,
              "setLabel": false
            },
            "textColor": "GUI_BLACK",
            "pageTitle": "Air TVOC",
            "titleHidden": false,
            "pageHidden": false,
            "topRightButtonLabel": "",
            "topRightButtonEnabled": false,
            "bottomRightButtonLabel": "",
            "bottomRightButtonEnabled": false,
            "topLeftButtonLabel": "",
            "topLeftButtonEnabled": false,
            "bottomLeftButtonLabel": "",
            "bottomLeftButtonEnabled": false,
            "x": "5",
            "y": 0,
...

This file has been truncated, please download it to see its full contents.

NXPNotification.ipynb

JSON
Python Jupyter Notebook
{
 "cells": [
  {
   "cell_type": "code",
   "execution_count": null,
   "metadata": {},
   "outputs": [],
   "source": [
    "# Run this code first to install the mqtt and pushetta libraries.\n",
    "!pip install paho-mqtt && pip install pushetta"
   ]
  },
  {
   "cell_type": "code",
   "execution_count": null,
   "metadata": {},
   "outputs": [],
   "source": [
    "# Leave this code running to leave pushetta notifications active.\n",
    "\n",
    "import paho.mqtt.client as mqtt \n",
    "import time\n",
    "from pushetta import Pushetta\n",
    "\n",
    "# API Key You get after signup on www.pushetta.com\n",
    "API_KEY=\"YOURPUSHETTAAPIKEY\"\n",
    "p=Pushetta(API_KEY)\n",
    "\n",
    "def on_message(mosq, obj, msg):\n",
    "    p.pushMessage(\"NXP\",\"YOURNAME Needs Help!: \" \"https://maps.google.com/?q=\" + str(msg.payload.decode())[10:-21]+\",\"+str(msg.payload.decode())[-8:])\n",
    "\n",
    "\n",
    "client = mqtt.Client()\n",
    "client.on_message = on_message\n",
    "client.username_pw_set(\"MQTTUSERNAME\", \"MQTTPASSWORD\")\n",
    "client.connect('MQTTURL',  MQTTPORT, 60)\n",
    "client.loop_start()\n",
    "client.subscribe (\"/NXPloc\" ,0 )\n",
    "\n",
    "try:\n",
    "    while True:\n",
    "        time.sleep(1)\n",
    " \n",
    "except KeyboardInterrupt:\n",
    "    print (\"exiting\")\n",
    "    client.disconnect()\n",
    "    client.loop_stop()\n"
   ]
  }
 ],
 "metadata": {
  "kernelspec": {
   "display_name": "Python 3.5",
   "language": "python",
   "name": "python3"
  },
  "language_info": {
   "codemirror_mode": {
    "name": "ipython",
    "version": 3
   },
   "file_extension": ".py",
   "mimetype": "text/x-python",
   "name": "python",
   "nbconvert_exporter": "python",
   "pygments_lexer": "ipython3",
   "version": "3.5.5"
  }
 },
 "nbformat": 4,
 "nbformat_minor": 1
}

location.html

HTML
Location HTML Code
<!DOCTYPE html>
<html>
<head>
<script src="https://ajax.googleapis.com/ajax/libs/jquery/3.3.1/jquery.min.js"></script>
<script src="https://cdnjs.cloudflare.com/ajax/libs/paho-mqtt/1.0.1/mqttws31.js" type="text/javascript"></script>
<script type="text/javascript">

  // Create a client instance
  client = new Paho.MQTT.Client("MQTTURL", MQTTPORT,"MQTTDEVICENAME");
  //Example client = new Paho.MQTT.Client("m11.cloudmqtt.com", 32903, "web_" + parseInt(Math.random() * 100, 10));

  // set callback handlers
  client.onConnectionLost = onConnectionLost;
  client.onMessageArrived = onMessageArrived;
  var options = {
    useSSL: true,
    userName: "MQTTUSERNAME",
    password: "MQTTPASSWORD",
    onSuccess:onConnect,
    onFailure:doFail
  }

  // connect the client
  client.connect(options);

  // called when the client connects
  function onConnect() {
    var data
    // Once a connection has been made, make a subscription and send a message.
    console.log("onConnect");
    $.ajax({
    dataType: "json",
    url: "http://extreme-ip-lookup.com/json/",
    data: data,
    success: function (data)
    {
    var datav = JSON.parse(JSON.stringify(data))
    doStuff(datav.lat, datav.lon)

    message = new Paho.MQTT.Message("Latitude: "+String(datav.lat) + ", Longitude: "+String(datav.lon));
    message.destinationName = "/NXPloc";
    client.send(message);
    }
    });

  }

  function doFail(e){
    console.log(e);
  }

  // called when the client loses its connection
  function onConnectionLost(responseObject) {
    if (responseObject.errorCode !== 0) {
      console.log("onConnectionLost:"+responseObject.errorMessage);
    }
  }

  // called when a message arrives
  function onMessageArrived(message) {
    console.log("onMessageArrived:"+message.payloadString);
  }
</script>

<script>
function doStuff(mylat, mylong)
{
  if (document.getElementById("GeoAPI"))
  {
    document.getElementById("GeoAPI").innerHTML = "<iframe style=\"width: 400px; height: 400px\" frameborder=\"0\" scrolling=\"no\" marginheight=\"0\" marginwidth=\"0\"                src=\"//maps.google.com/?ll=" + mylat + "," + mylong + "&z=16&output=embed\"></iframe>";
  }
}
</script>
</head>
<body>

<div id="GeoAPI"></div>

</body>
</html>

nxp.html

HTML
Main Page HTML
<!DOCTYPE html>
<html>
<head>
<style>
body {
  background-image: url("NXP.png");
  background-repeat: no-repeat;
  background-size: 1500px 800px;
}
</style>
<script src="https://ajax.googleapis.com/ajax/libs/jquery/3.3.1/jquery.min.js"></script>
<script src="https://cdnjs.cloudflare.com/ajax/libs/paho-mqtt/1.0.1/mqttws31.js" type="text/javascript"></script>
<script type="text/javascript">

  // Create a client instance
  client = new Paho.MQTT.Client("MQTTURL", MQTTPORT,"MQTTDEVICENAME");
  //Example client = new Paho.MQTT.Client("m11.cloudmqtt.com", 32903, "web_" + parseInt(Math.random() * 100, 10));

  // set callback handlers
  client.onConnectionLost = onConnectionLost;
  client.onMessageArrived = onMessageArrived;
  var options = {
    useSSL: true,
    userName: "MQTTUSERNAME",
    password: "MQTTPASSWORD",
    onSuccess:onConnect,
    onFailure:doFail
  }

  // connect the client
  client.connect(options);

  // called when the client connects
  function onConnect() {
    // Once a connection has been made, make a subscription and send a message.
    console.log("onConnect");
    client.subscribe("/NXPloc");
  }

  function doFail(e){
    console.log(e);
  }

  // called when the client loses its connection
  function onConnectionLost(responseObject) {
    if (responseObject.errorCode !== 0) {
      console.log("onConnectionLost:"+responseObject.errorMessage);
    }
  }

  // called when a message arrives
  function onMessageArrived(message) {
    console.log("onMessageArrived:"+message.payloadString);
    var text = message.payloadString
    var lati = parseFloat(text.substring(10, 18))
    var long = parseFloat(text.substring(30, 40))
    alert("Victor needs help!");
    doStuff(lati, long)
  }
</script>
<script>
function doStuff(mylat, mylong)
{
    var map = new google.maps.Map(document.getElementById('GeoAPI'),
    {
      center: {lat: mylat, lng: mylong},
      zoom: 20
    });
    var marker = new google.maps.Marker({
    position: {lat: mylat, lng: mylong},
    map: map,
    title: 'YOURNAME'
  });

}
</script>
<meta name="viewport" content="initial-scale=1.0">
<meta charset="utf-8">
<style>
    /* Always set the map height explicitly to define the size of the div
    * element that contains the map. */
    #GeoAPI {
    height: 100%;
    }
    /* Optional: Makes the sample page fill the window. */
    html, body {
    height: 100%;
    margin: 0;
    padding: 0;
    }
</style>
</head>
<body>

<div id="GeoAPI"></div>
<script src="https://maps.googleapis.com/maps/api/js?key=YOUR_API&callback=initMap" async defer></script>
</body>
</html>

Github

https://github.com/altaga/SmartBike-NXP

Github

https://github.com/altaga/The-Ultimate-IBM-Watson-IoT-Platform-Guide

Credits

Victor Altamirano

Victor Altamirano

8 projects • 17 followers
I am a Biomedical engineer who likes to develop hardware and software solutions.

Comments
