Interfacing 4x4 Keypad, LCD And GSM With Arduino(HOME SECUR

Home security using gsm, keypad 4x4 and gsm

IntermediateFull instructions provided15,642
Interfacing 4x4 Keypad, LCD And GSM With Arduino(HOME SECUR

Things used in this project

Hardware components

Arduino UNO
Arduino UNO
×1
RGB LCD Shield Kit, 16x2 Character Display
RGB LCD Shield Kit, 16x2 Character Display
×1
4x4 Matrix Keypad
×1

Schematics

CIRCUIT

Code

keypad_with_lcd.ino

Arduino
ITS CODE
//BY ARDUICREATE
//INCLUDE THESE LIBRARYS
#include <Keypad.h>
#include <Wire.h>
#include <LiquidCrystal.h>
#include <SoftwareSerial.h>
SoftwareSerial mySerial(2, 3);
LiquidCrystal lcd(14, 15, 16, 17, 18, 19);
#define Password_Lenght 7 // Give enough room for six chars + NULL char
char Data[Password_Lenght]; // 6 is the number of chars it can hold + the null char = 7
char Master[Password_Lenght] = "999999";
byte data_count = 0, master_count = 0;
bool Pass_is_good;
char customKey;
const byte ROWS = 4;
const byte COLS = 4;
char hexaKeys[ROWS][COLS] = {
  {'1', '2', '3', 'A'},
  {'4', '5', '6', 'B'},
  {'7', '8', '9', 'C'},
  {'*', '0', '#', 'D'}
};

byte rowPins[ROWS] = {11, 10, 9, 8}; //connect to the row pinouts of the keypad
byte colPins[COLS] = {7, 6, 5, 4}; //connect to the column pinouts of the keypad
Keypad myKeypad = Keypad( makeKeymap(hexaKeys), rowPins, colPins, ROWS, COLS);

void setup()
{
  mySerial.begin(9600);
  lcd.begin(16, 2);
}

void loop()
{
  lcd.setCursor(0, 0);
  lcd.print("Enter Password");

  customKey = myKeypad.getKey();
  if (customKey) // makes sure a key is actually pressed, equal to (customKey != NO_KEY)
  {
    Data[data_count] = customKey; // store char into data array
    lcd.setCursor(data_count, 1); // move cursor to show each new char
    lcd.print(Data[data_count]); // print char at said cursor
    data_count++; // increment data array by 1 to store new char, also keep track of the number of chars entered
  }

  if (data_count == Password_Lenght - 1) // if the array index is equal to the number of expected chars, compare data to master
  {
    lcd.clear();
    lcd.setCursor(0, 0);
    lcd.print("Passis");

    if (!strcmp(Data, Master)) // equal to (strcmp(Data, Master) == 0)
    {
      lcd.print("CORRECT");
    }

    else {
      lcd.print("INCORRECT");
      SendMessage();
    }
    delay(1000);// added 1 second delay to make sure the password is completely shown on screen before it gets cleared.
    lcd.clear();
    clearData();
  }
}

void clearData()
{
  while (data_count != 0)
  { // This can be used for any array size,
    Data[data_count--] = 0; //clear array for new data
  }
  return;
}
void SendMessage()
{
  mySerial.println("AT\r");
  delay(1000);
  mySerial.println("AT+CMGF=1\r");
  delay(1000);
  mySerial.println("AT+CMGS=\"country code + your number\"\r");
  delay(1000);
  mySerial.println("INTRUDER");
  delay(1000);
  mySerial.println((char)26);
  delay(100);
}
//THANKS FOR DOWNLOADING .......
