Innovation Lab #19: Motor Drive Motor

A Bongilcheon High School Innovation Lab project.

BeginnerShowcase (no instructions)10 minutes773
Innovation Lab #19: Motor Drive Motor

Things used in this project

Hardware components

Arduino UNO
Arduino UNO
×1
Arduino DC Motor
×1
Arduino Motor Drive Module
×1

Software apps and online services

Arduino IDE
Arduino IDE

Story

Read more

Code

Motor Drive_Motor forward

Arduino
The car goes forward.
int AIA = 5;
int AIB = 6;
int BIA = 9;
int BIB = 10;
int spe = 200;

void setup() {
  pinMode(AIA, OUTPUT);
  pinMode(AIB, OUTPUT);
  pinMode(BIA, OUTPUT);
  pinMode(BIB, OUTPUT);
  Serial.begin(9600);
}

void loop() {
  forward();
  delay(1000);
}


void forward() {
  analogWrite(AIA, 0);
  analogWrite(AIB, spe);
  analogWrite(BIA, 0);
  analogWrite(BIB, spe);
}

Motor Drive_Motor backward

Arduino
The car goes backward.
int AIA = 5;
int AIB = 6;
int BIA = 9;
int BIB = 10;
int spe = 200;

void setup() {
  pinMode(AIA, OUTPUT);
  pinMode(AIB, OUTPUT);
  pinMode(BIA, OUTPUT);
  pinMode(BIB, OUTPUT);
  Serial.begin(9600);
}

void loop() {
  backward();
  delay(1000);
}

void backward() {
  analogWrite(AIA, spe);
  analogWrite(AIB, 0);
  analogWrite(BIA, spe);
  analogWrite(BIB, 0);
}

Motor Drive_Motor forward / backward / stopped

Arduino
The car went forward and went backward and stopped.
int AIA = 5;
int AIB = 6;
int BIA = 9;
int BIB = 10;
int spe = 200;

void setup() {
  pinMode(AIA, OUTPUT);
  pinMode(AIB, OUTPUT);
  pinMode(BIA, OUTPUT);
  pinMode(BIB, OUTPUT);
  Serial.begin(9600);
}

void loop() {
  forward();
  delay(1000);
  backward();
  delay(1000);
  stopp();
  delay(1000);
}


void forward() {
  analogWrite(AIA, 0);
  analogWrite(AIB, spe);
  analogWrite(BIA, 0);
  analogWrite(BIB, spe);
}

void backward() {
  analogWrite(AIA, spe);
  analogWrite(AIB, 0);
  analogWrite(BIA, spe);
  analogWrite(BIB, 0);
}

void stopp() {
  analogWrite(AIA, 0);
  analogWrite(AIB, 0);
  analogWrite(BIA, 0);
  analogWrite(BIB, 0);
}
