Things used in this project

Schematics

Shift Register_LED
Shift Register_LED
18 2 rvaspgaoab

Code

Shift Register_LEDArduino
Control eight LEDs with the Shift Register.
int latchPin = 4;
int clockPin = 3;
int dataPin = 2;

void setup()

{
  pinMode(latchPin, OUTPUT);
  pinMode(dataPin, OUTPUT);
  pinMode(clockPin, OUTPUT);
}

void loop()
{
  for(int i=0; i<8; i++){
    digitalWrite(latchPin, LOW);
    shiftOut(dataPin, clockPin, LSBFIRST, 1<<i);
    digitalWrite(latchPin, HIGH);
    delay(500);
  }
}
