Published June 1, 2025 © GPL3+

Bark Beetle Sentry

Bark Beetle Sentry detects bark beetles early using smart sensors to protect forests from infestation.

IntermediateWork in progressOver 1 day201

Things used in this project

Hardware components

Colibri IoT - NatureGuard

USB-C cable

Software apps and online services

Arduino IDE

Edge Impulse Studio

ThingsBoard

The Things Network

Story

Image 1: Logo

Eruptive outbreaks of bark beetles have caused extensive and often severe tree mortality across tens of thousands to millions of hectares in temperate forests since the late 1990s. Our open-source Bark Beetle Sentry sensor network spots outbreaks before the first needles and leafes turn brown. Low-cost LoRa-enabled nodes listen for the beetles’ signature chewing acoustics, then relay real-time alerts to a dashboard that foresters can check. Because the hardware is solar-powered and self-healing, you can scatter hundreds of sensors across remote terrain in an afternoon and forget about maintenance for years. Actionable data arrives while a single infested tree is still salvageable—saving ecosystems, logging revenue, and firefighting budgets. Join us on Hackster to build, deploy, and protect your local forest with Bark Beetle Sentry.

Machine Learning

To detect bark beetle presence, we trained a machine learning model using Edge Impulse, leveraging audio data sourced from the internet. The model classifies audio into two labels: "bark beetle" or "lubadar" in slovenian (beetle chewing/activity sounds) and "ambient" (all other environmental noises).

image 2: Edge Impulse model testing

image 3: Edge impulse training set results

The default Edge Impulse DSP settings produced feature tensors that overflowed the board’s RAM/flash. We downsized the window and sample rate:

Window size → 2 000 ms
Windowincrease (stride) → 1 000 ms
Audio frequency → 16 kHz

Image 4: Edge impulse model settings

Once trained, the model was exported as an Arduino-compatible library, complete with example code. This library runs directly on our custom Arduino-based hardware, enabling real-time on-device audio classification.

In the future, the model can be retrained and improved using field-collected data for higher accuracy in real forest conditions.

Connectivity

Image 5: LoRaWAN

The custom NatureGuard board integrates Wio-E5 LoRa-WAN module for low-power, long-range data links. The on-device ML model detects bark beetle presence and transmits an alert packet over LoRaWAN to The Things Network. Additional telemetry that is being sent to TTN is also battery percentage. TTN then uses a configured webhook and uplink converter to forward each message - encoded in JSON - to ThingsBoard, where the data is visualized and processed in real time.

Image 6: NatureGuard board

Deployment & Power

Each board must be put inside an IP-rated, UV-stable housing with an acoustic port (mesh-covered) that throughputs sound but keeps out rain, dust and insects.

The boards should be powered by a battery pack and solar panel combination. This allows year-round operation under shady conditions. It also allows for minimal maintenance in the hard-to-reach regions.

ThingsBoard dashboard

Each board is assigned a GPS location (latitude, longitude, and altitude) as well as a unique ID, which are visualized on the dashboard. The sensors are shown on a map.

ThingsBorad recieves sensor telemetry from TTN, which also adds additional radio link data that includes timestamp, SNR and RSSI. If the alert signal is positive, ThingsBoard generates alert notification.

Image 7: ThingsBoard dashboard

#include <Arduino.h>
#include <PDM.h>
#include "secrets.h"
#include <mp3_prvi_model_inferencing.h>

#define MODULE_EN_PIN 5
#define DEVICE_ID "001"

#ifndef EIDSP_QUANTIZE_FILTERBANK
#define EIDSP_QUANTIZE_FILTERBANK 0
#endif
#define EI_CLASSIFIER_SLICES_PER_MODEL_WINDOW 4

const unsigned long MIN_SEND_INTERVAL = 1 * 60 * 1000;  // 1 minute
const unsigned long HEARTBEAT_INTERVAL = 10 * 60 * 1000; // 10 minutes
const float CLASSIFY_THRESHOLD = 0.8;
const unsigned long CLASSIFY_INTERVAL = 10000; // 10 seconds

unsigned long lastSentTime = 0;
unsigned long lastHeartbeatTime = 0;
unsigned long lastClassifyTime = 0;

typedef struct {
    signed short *buffers[2];
    unsigned char buf_select;
    unsigned char buf_ready;
    unsigned int buf_count;
    unsigned int n_samples;
} inference_t;

static inference_t inference;
static bool record_ready = false;
static signed short *sampleBuffer;
static bool debug_nn = false;
static int print_results = -(EI_CLASSIFIER_SLICES_PER_MODEL_WINDOW);

void sendATCommand(String command);
void sendStatusMessage(bool lubadarDetected);
float readBatteryPercent();

void setup() {
    pinMode(MODULE_EN_PIN, OUTPUT);
    digitalWrite(MODULE_EN_PIN, HIGH);
    delay(1000);

    Serial.begin(9600);
    Serial1.begin(9600);
    delay(3000);

    Serial.println("\n\nInitializing module...\n\n");
    sendATCommand("AT");
    sendATCommand("AT+ID=DevEui,\"" + String(DEV_EUI) + "\"");
    sendATCommand("AT+ID=AppEui,\"" + String(APP_EUI) + "\"");
    sendATCommand("AT+KEY=APPKEY,\"" + String(APP_KEY) + "\"");
    sendATCommand("AT+MODE=LWOTAA");
    sendATCommand("AT+JOIN");

    Serial.println("\n\nModule initialization completed!\n\n");
    delay(15000);

    run_classifier_init();
    lastSentTime = millis();
    lastHeartbeatTime = millis();
    lastClassifyTime = millis();
}

void loop() {
    if ((millis() - lastClassifyTime) < CLASSIFY_INTERVAL) return;
    lastClassifyTime = millis();

    microphone_inference_end();
    if (!microphone_inference_start(EI_CLASSIFIER_SLICE_SIZE)) {
        ei_printf("Error: buffer not allocated\n");
        return;
    }

    // Collect all required slices
    for (int i = 0; i < EI_CLASSIFIER_SLICES_PER_MODEL_WINDOW; i++) {
        if (!microphone_inference_record()) {
            ei_printf("Error while capturing slice\n");
            return;
        }
    }

    signal_t signal;
    signal.total_length = EI_CLASSIFIER_SLICE_SIZE;
    signal.get_data = &microphone_audio_signal_get_data;
    ei_impulse_result_t result = { 0 };

    if (run_classifier_continuous(&signal, &result, debug_nn) != EI_IMPULSE_OK) return;

    Serial.println("\nClassification result:");
    float prob = 0.0;
    for (size_t ix = 0; ix < EI_CLASSIFIER_LABEL_COUNT; ix++) {
        Serial.print("  ");
        Serial.print(result.classification[ix].label);
        Serial.print(": ");
        Serial.println(result.classification[ix].value, 5);

        if (String(result.classification[ix].label) == "Lubadar") {
            prob = result.classification[ix].value;
        }
    }

    bool lubadarDetected = prob > CLASSIFY_THRESHOLD;
    bool heartbeatDue = (millis() - lastHeartbeatTime) > HEARTBEAT_INTERVAL;
    bool minIntervalPassed = (millis() - lastSentTime) > MIN_SEND_INTERVAL;

    if ((lubadarDetected && minIntervalPassed) || (heartbeatDue && minIntervalPassed)) {
        sendStatusMessage(lubadarDetected);
        lastSentTime = millis();
        if (heartbeatDue) lastHeartbeatTime = millis();
    }
}


void sendATCommand(String command) {
    Serial1.print(command + "\r\n");
    Serial.print("Sending: ");
    Serial.println(command);

    unsigned long timeout = millis() + 3000;
    while (millis() < timeout) {
        if (Serial1.available()) {
            char c = Serial1.read();
            Serial.write(c);
        }
    }
}

void sendStatusMessage(bool lubadarDetected) {
    int battery = (int)readBatteryPercent();
    String batteryStr = String(battery);
    while (batteryStr.length() < 3) batteryStr = "0" + batteryStr;

    String payload = String(DEVICE_ID) + batteryStr + (lubadarDetected ? "1" : "0");
    sendATCommand("AT+MSG=\"" + payload + "\"");
    Serial.println("[LoRa] Sent: " + payload);
}

float readBatteryPercent() {
    return 77; // Placeholder for testing
}

static void pdm_data_ready_inference_callback(void) {
    int bytesAvailable = PDM.available();
    int bytesRead = PDM.read((char *)&sampleBuffer[0], bytesAvailable);

    if (!record_ready) return;

    for (int i = 0; i < bytesRead >> 1; i++) {
        inference.buffers[inference.buf_select][inference.buf_count++] = sampleBuffer[i];
        if (inference.buf_count >= inference.n_samples) {
            inference.buf_select ^= 1;
            inference.buf_count = 0;
            inference.buf_ready = 1;
        }
    }
}

static bool microphone_inference_start(uint32_t n_samples) {
    inference.buffers[0] = (signed short *)malloc(n_samples * sizeof(signed short));
    inference.buffers[1] = (signed short *)malloc(n_samples * sizeof(signed short));
    sampleBuffer = (signed short *)malloc((n_samples >> 1) * sizeof(signed short));

    if (!inference.buffers[0] || !inference.buffers[1] || !sampleBuffer) return false;

    inference.buf_select = 0;
    inference.buf_count = 0;
    inference.buf_ready = 0;
    inference.n_samples = n_samples;

    PDM.onReceive(pdm_data_ready_inference_callback);
    PDM.setBufferSize((n_samples >> 1) * sizeof(int16_t));
    if (!PDM.begin(1, EI_CLASSIFIER_FREQUENCY)) return false;

    PDM.setGain(127);
    record_ready = true;
    return true;
}

static bool microphone_inference_record(void) {
    if (inference.buf_ready == 1) {
        ei_printf("Buffer overrun!\n");
        return false;
    }
    while (inference.buf_ready == 0) delay(1);
    inference.buf_ready = 0;
    return true;
}

static int microphone_audio_signal_get_data(size_t offset, size_t length, float *out_ptr) {
    numpy::int16_to_float(&inference.buffers[inference.buf_select ^ 1][offset], out_ptr, length);
    return 0;
}

static void microphone_inference_end(void) {
    PDM.end();
    free(inference.buffers[0]);
    free(inference.buffers[1]);
    free(sampleBuffer);
}

function decodeUplink(input) {
  try {
    const decoded = String.fromCharCode.apply(null, input.bytes);

    const id = decoded.substring(0, 3);
    const battery = decoded.substring(3, 6);
    const alert = decoded.substring(6, 7);

    return {
      data: {
        id: parseInt(id, 10),
        battery: parseInt(battery, 10),
        alert: parseInt(alert, 10)
      },
      warnings: [],
      errors: []
    };
  } catch (error) {
    return {
      data: {},
      warnings: [],
      errors: ['Decoding error: ' + error.message]
    };
  }
}
